dB Technologies B-Hype M Manual

www.dbtechnologies.com [e-mail]
B-HYPE MOBILE cod. 42 12 272Q PRELIMINARY
Quick start user manual
Section 1
The warnings in this manual must be observed together with the "USER MANUAL Section 2".
Le avvertenze nel presente manuale devono essere osservate congiuntamente al “MANUALE D’USO Sezione2”.
Die Warnungen in diesem Handbuch müssen in Verbindung mit der "BEDIENUNGSANLEITUNG Abschnitt 2" beobachtet
werden”.
Les avertissements specifiés dans ce manuel doivent être respectés ainsi que les "CARACTERISTIQUES TECHNIQUES
Section 2"
Las advertencias del presente manual se deben tener en cuenta conjuntamente con las del “MANUAL DEL USUARIO”
Sección 2”.
A.E.B. Industriale Srl Via Brodolini, 8 Località Crespellano 40053 VALSAM GGIA B L GNA (ITALIA)
Tel [phone] Fax [phone] www.dbtechnologies.com [e-mail]

www.dbtechnologies.com [e-mail]
VIO L2 8 2 cod. 42 12 268Q PRELIMINARY
Thank you for choosing a dBTechnologies Product!
B-HYPE M BILE is the new bi-amped dBTechnologies battery speaker, available in two versions: handheld
transmitter or bodypack transmitter. It is equipped with: one 1” compression driver exit (1.4” voice coil) and one 10”
woofer (2” voice coil). The input section allows the user to connect: up to three cabled inputs, one wireless
microphone, and different media inputs (included Bluetooth
®
one).
Check the site www.dbtechnologies.com for the complete user manual!
1) Unpacking
The box contains:
2) Before you start
a) Mount the antennas
b) Place the batteries (not included)

www.dbtechnologies.com [e-mail]
VIO L2 8 3 cod. 42 12 268Q PRELIMINARY
Please note that for the proper use of the integrated
charger of B-HYPE M BILE, only Ni-MH batteries must
be used with the HT-BHM.
3) A controls overview
The top and rear panel can be divided in main sections:
•MAIN DISPLAY AND MEDIA SECTION
•CONNECTIONS AND CONTROL SECTION
•RECEIVER MODULE R BHM
•BATTERY HOLDER
•HT BHM CHARGER
•MAINS SECTION
In the following chapters these sections are presented
and they are recalled with reference to this scheme.

www.dbtechnologies.com [e-mail]
VIO L2 8 4 cod. 42 12 268Q PRELIMINARY
4) Turn on and synchronize your transmitter
to the receiver module R BHM
A – STATUS LED
B – P WER/MUTE SWITCH
C – IR LENS
D – GAIN (INPUT SENSITIVITY)
E – PLASTIC SCREWDRIVER F R [D] GAIN
F – BATTERY C VER
G – ANTENNA
H – STATUS LED
I – P WER/MUTE SWITCH
L – 4-P LE C NNECT R F R HEADSET
M – PLASTIC SCREWDRIVER F R [N] GAIN
N – GAIN (INPUT SENSITIVITY)
O – IR LENS
P – BATTERY C VER
1. Turn on the B-HYPE M BILE (see chapter 8 for
further information), and check that the MASTER
Volume is on a medium/low level (see chapter
6).
2. Unscrew the battery cover [F] of HT-BHM or
open the [P] one of BT-BHM
3. n the transmitter, hold down for some seconds
the “P WER” button [B], or [I] (for HT-BHM or
BT-BHM).
4. n the receiver, select one of the eight available
channels by pressing shortly [X] or [Z] buttons.
5. Hold down for some seconds the [X] button,
then release it. The CHANNEL number in the
display starts blinking.
6. The IR LENS of the transmitter must be faced
with the display of the RECEIVER M DULE R-
BHM as shown in the pictures.
7. The transmitter is then synchronized to the
receiver in some seconds, and the CHANNEL
number in the display become fixed.
8. RF indicator in the display shows the wireless
reception intensity with a synchronized
transmitter, the AF the audio volume one. You
can enter the related submenus by pressing SET
button. In the transmitter you can set the gain
([D] or [N]) with the related screwdriver [E] or
[M].
9. Screw the battery cover [F] of HT-BHM or close
the [P] one of BT-BHM.

www.dbtechnologies.com [e-mail]
VIO L2 8 5 cod. 42 12 268Q PRELIMINARY
5) Main display and media section
In this section you can find:
•SD Audio Input:
•USB Audio Input:
•Controls buttons
6) Connections and controls section
In this section you can find:
•CH1: Balanced\Unbalanced input (XLR/TLR
combo connector type) with input sensitivity
switch and channel volume control.
•CH2: Aux input connector for 3,5 mm jack and
RCA input connectors with channel volume
control.
•Master section with EQUALIZER rotaries
(Treble and Bass separated regulations) and
MAIN volume control.
•Bluetooth
®
/USB/SD volume control.
•Unbalanced Line utput.
•CH1/RF Priority. If in “ n” position the source
audio level of CH2 and of Bluetooth
®
/USB/SD is
instantly reduced by the presence of the
CH1/RF signal).

www.dbtechnologies.com [e-mail]
VIO L2 8 6 cod. 42 12 268Q PRELIMINARY
7) The HT BHM charger
B-hype M BILE can be used while charging the
handheld transmitter HT-BHM. In order to correctly
charge the transmitter:
1. Use the proper HT-BHM batteries (Ni-MH AA
type only)
2. Insert the handheld in the charger on the rear
panel
3. Turn on the B-HYPE M BILE (LED “Power”
green)
4. The Led in the charger can be:
•RED – the batteries are charging
•GREEN – the batteries are fully charged
•FLASHING RED – the batteries are not
of the proper type
8) Mains section
The mains section contains:
•Mains VDE connector
•Mains switch
The B-HYPE usage mode are:
•N (B-HYPE M BILE is fully operative and it
can operate with the battery without the
mains cable, if charged, or with the mains
cable inserted)
•FF
•RECHARGE (the battery charges with the
power cord inserted)

www.dbtechnologies.com [e-mail]
VIO L2 8 8 cod. 42 12 268Q PRELIMINARY
Check periodically the site
www.dbtechnologies.com
for any firmware, documentation, and new
accessories update.
Check the complete user manual on www.dbtechnologies.com
for further information about the system and available
accessories.
Scarica il manuale completo da www.dbtechnologies.com per
ogni ulteriore informazione sul sistema e sugli accessori
disponibili.
Für weitere Informationen und verfügbares Zubehör lesen sie
bitte die vollständige Bedienungsanleitung unter
www.dbtechnologies.com.
Vérifiez le manuel de l'utilisateur complet sur
www.dbtechnologies.com pour des informations
complémentaires du système et des accessoires disponibles.
Compruebe el manual de usuario completo sobre
www.dbtechnologies.com para la información adicional sobre el
sistema y accesorios disponibles.

www.dbtechnologies.com [e-mail]
B-HYPE MOBILE cod. 42 12 272Q PRELIMINARY
Technical Data
Speaker Type: 2 way battery speaker with wireless
microphone (handheld or bodypack versions)
Acoustical data
Usable Bandwidth [ 10 dB]: 62 – 20000 Hz
Frequency Response [ 6 dB]: 66 – 18100 Hz
Max SPL (1 m): 123 dB
HF compression driver: 1" Exit
HF voice coil: 1.4”
LF: 10”
LF Voice Coil: 2”
Crossover frequency: 2400 Hz
Horizontal dispersion: 90°
Vertical dispersion: 45°
Amplifier
Amp Technology: Amp SMPS Power Supply
Amp Class: Class D
RMS Power: 95 W
Peak Power: 190 W
Cooling: Passive (convection)
Integrated transmitter Charger
Rechargeable Device: HT BHM handheld only
Compatible batteries: Ni MH rechargeable only
B-HYPE M BILE battery
Battery type: Lithium
Charging time: Less than 4 hours
Mean usage time: 2 hours
Controls
Controls: Audio attenuation, DSP presets
RF section
Available bands:
Input / utput
Mains connections: VDE
Signal Input: (Balanced) 1x XLR IN
Signal Out: (Balanced) 1 x XLR link OUT
USB connector: mini USB B type (for SERVICE DATA)
Mechanics
Housing: Plastic cabinet
Grille: Full grille
Handles: 1 for each side, 1 on top (retractable)
Width: 300 mm (11.81 in)
Height: 568 mm (22.36 in)
Depth: 301 mm (11.86 in)
Weight (without transmitter): 12.5 kg (27 lbs.)
Download the complete user manual on:
www.dbtechnologies.com/EN/Downloads.aspx
EMI CLASSIFICATION
According to the standards EN 55103 this equipment is designed and suitable to operate in CLASS B Electromagnetic environments.
FCC CLASS B STATEMENT ACCORDING TO TITLE 47, PART 15, SUBPART B, §15.105
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules.
These limits are designed to provide reasonable protection against harmful interference in a residential installation.
This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may
cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference
to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
1. Reorient or relocate the receiving antenna.
2. Increase the separation between the equipment and receiver.
3. Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
4. Consult the dealer or an experienced radio/TV technician for help.
Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the
equipment.
B-HYPE MOBILE:
CC ID:2ADDV-BHYPEM(USA) IC:12207A-BHYPEM(CANADA)
WARNING: Make sure that the loudspeaker is securely installed in a stable position to avoid any injuries or damages to persons or properties.
For safety reasons do not place one loudspeaker on top of another without proper fastening systems. Before hanging the loudspeaker check
all the components for damages, deformations, missing or damaged parts that may compromise safety during installation. If you use the
loudspeakers outdoor avoid spots exposed to bad weather conditions.
Contact dB Technologies for accessories to be used with speakers. dBTechnologies will not accept any responsibility for damages caused by
inappropriate accessories or additional devices.
Features, specification and appearance of products are subject to change without notice. dBTechnologies reserves the right to make changes or
improvements in design or manufacturing without assuming any obligation to change or improve products previously manufactured.
The Bluetooth
®
word mark and logos are registered trademarks owned by Bluetooth
®
SIG, Inc. and any use of such marks by AEB
Industriale S L is under license. Other Trademarks and trade names are those of their respective owners.
