dB Technologies VIO X10 Manual

www.dbtechnologies.cominfo@dbtechnologies‐aeb.com 
VIOX10Rev1.1cod.420120280Q
Quick start user manual
Section 1
The warnings in this manual must be observed together with the "USER MANUAL - Section 2".
Le avvertenze nel presente manuale devono essere osservate congiuntamente al “MANUALE D’USO – Sezione 2”.
Die Warnungen in diesem Handbuch müssen in Verbindung mit der "BEDIENUNGSANLEITUNG - Abschnitt 2" beobachtet
werden”.
Les avertissements specifiés dans ce manuel doivent être respectés ainsi que les "CARACTERISTIQUES TECHNIQUES -
Section 2"
Las advertencias del presente manual se deben tener en cuenta conjuntamente con las del “MANUAL DEL USUARIO” -
Sección 2”.

A.E.B. Industriale Srl Via Brodolini, 8 Località Crespellano 40053 VALSAMOGGIA BOLOGNA (ITALIA)
Tel [phone] Fax [phone] www.dbtechnologies.com [e-mail]

www.dbtechnologies.cominfo@dbtechnologies‐aeb.com 
VIOX10Rev1.1cod.420120280Q
Thank you for choosing a dBTechnologies Product!
VIO X10 is an active two-way loudspeaker, designed for professional use, equipped with one 1” compression driver
(voice coil: 1.75”) and one 10” neodymium woofer (voice coil: 2.5”). The powerful DIGIPRO®G3 amplifier section,
capable of handling up to 900 W (RMS power), is controlled by a DSP, which can perform a detailed customization
of the output sound of the loudspeaker. Thanks to the mechanical design and the complete control interface, it is
possible to use VIO X10 in live scenarios and as a monitor on the stage, or for installations in medium/large venues.
The RDnet connections allow in-depth remote control, thanks also to free available software (AURORA NET).
Professional accessories (like a rain cover, or vertical WB-VIOX10V and horizontal WB-VIOX10H wall brackets) ensure
versatility and an easy set-up.
Check the site www.dbtechnologies.com for the complete user manual!
1) Unpacking
The box contains:
No. 1 VIO X10
No. 1 Mains cable with Neutrik® powerCON TRUE1
connector
No. 1 Fuse for the use in the 100-120V~ range.
This quick start and warranty documentation
2) Easy installation
The easy use in different configurations is guaranteed
by:
handle [A], on the top
fast pin locks [B], 2 for each side, for the usage
in installation with WB-X10V wall-brackets
pole mount adapter [C], 36 mm diameter
12 pick points[D], with M10 threaded holes,
for the usage in installation with WB-X10H
wall brackets, or for the use of eyebolts (not
supplied)
tilted side [E], (angle: 50°) for the use as live
stage monitor
All those mechanical particulars were thought for an
easy use and for different configuration needs. VIO X10
is perfect for live shows as well as medium/large venue
installations. The acoustical design allows to face
different environments.
As shown in the following picture, the related
dispersion pattern data are:
a) horizontal coverage: 90°
b) vertical coverage: 40°
The product and accessories must be handled by
trained personnel only! The user is required to
follow regulations and mandatory laws on safety
of the country in which the product is used. Don’t use the
handle to suspend VIO X10!

www.dbtechnologies.cominfo@dbtechnologies‐aeb.com 
VIOX10Rev1.1cod.420120280Q
3) First switch-on
The DIGIPRO G3 amplifier of VIO X10 is controlled by a
powerful DSP. All the connections and controls are in
the rear amplifier control panel:
The loudspeaker is supplied with a mounted fuse for
operation within the 220-240V~ range. If you need to
operate in the 100-120V~ voltage range:
Disconnect all connections, including the power
supply
Wait 5 minutes
Replace the fuse with the one provided in the
package for the 100-120V~ range
1 – Input (balanced) connector
2 – Input sensitivity potentiometer
3 – Audio Input Sensitivity switch (MIC/LINE)
4 – Output Link (balanced) connector
5 – Status LEDs (Limiter, Signal, Status, On)
6 – DSP Preset rotary control
7 – RDNet Data In
8 – RDNet Data Out
9 – RDNet status LEDs
10 – USB Data Service (USB-standard Type B)
11 – Mains Input connector
12 – Mains Link connector
13 – Mains Fuse
a) Once you have properly set up the desired
configuration (see also the VIO X10 complete user
manual and accessories instructions for further
information), connect the audio input (1).
In case of dynamic microphone, select “MIC” in Input
Sensitivity switch [3], otherwise select “LINE”. Please
note that this parameter can be selected only on the
control panel, it cannot be remotely controlled.
Adjust the Input Sensitivity level [2] to 0 dB.
b) If you need to send the audio signal to a second
speaker, connect the “Output Link” [4] to the
Input [1] of another VIO X10 (for example)
using a cable with XLR (balanced) connector.
c) Set properly the DSP Preset rotary [6], choosing
between “Fullrange” or “Wedge” configurations, or
apply a specific HPF filter frequency
(cut-off: 80/85/90/100/110 Hz).
d) In case of remote control, connect the proper Data
Input [7] to the hardware remote controller (RDNet
Control 2 or RDNet Control 8) with cables equipped
with etherCON connectors. Then connect the Data
Output [8] to the Data Input [7] of a second VIO X10,
and so on. When the RDNet network is on and
it has recognized the connected device, the LED
“Link” [9] is on. The other LED [9] “Active” starts
blinking when there is the presence of data
transmission, the “Remote Preset Active” advises that
the local controls set on the amplifier panel (level,
DSP presets, etc.) are by-passed and controlled
remotely by AURORA NET software. See also RDNet
Control 2, RDNet Control 8 and AURORA NET user
manuals for further information.
e) Plug the Mains Input [11] and Mains Link [12]
(powerCON) cables.
Check the complete user manual on www.dbtechnologies.com
for further information about the system and available
accessories.
Scarica il manuale completo da www.dbtechnologies.com per
ogni ulteriore informazione sul sistema e sugli accessori
disponibili.
Für weitere Informationen und verfügbares Zubehör lesen sie
bitte die vollständige Bedienungsanleitung unter
www.dbtechnologies.com. 
Vérifiez le manuel de l'utilisateur complet sur
www.dbtechnologies.com pour des informations
complémentaires du système et des accessoires disponibles.
Compruebe el manual de usuario completo sobre
www.dbtechnologies.com para la información adicional sobre el
sistema y accesorios disponibles.

www.dbtechnologies.cominfo@dbtechnologies‐aeb.com 
VIOX10Rev1.1cod.420120280Q
Technical Data
Speaker Type: active 2-way loudspeaker
Acoustical data
Frequency Response [-6 dB]:82 Hz – 20 kHz
Frequency Response [-10 dB]:73 – 21.4 kHz
Max SPL (1 m): 130 dB
HF: 1 x 1”
HF Voice Coil: 1.75”
LF: 1 x 10”, Neodymium
LF Voice Coil: 2.5”
Crossover freq.: 1600 Hz (24 dB/oct)
Directivity (HxV): 90° x 40° (rotatable)
Amplifier
Amp Technology: Digipro® G3
Power supply: Auto-range
Amp Class: Class-D
RMS Power: 900 W
Peak Power: 1800 W
Cooling: Passive (convection)
Operating voltage:
220-240V~ / 100-120V~ 50-60 Hz (Auto Range)
Processor
Controller: DSP, 28/56 bit
AD/DA converter: 24 bit, 48 kHz
Advanced DSP functions: FIR filters
Limiter: Peak, RMS, Thermal
Controls: Rotary Encoder (presets), input sensitivity
potentiometer, Mic/Line switch, LEDs
Input / Output
Mains connections: PowerCON ® TRUE1 In/link
Maximum number of VIO X10 for each daisy chain
power connection [mains input + mains link]:
1+5* (220-240V~), 1+3** (100-120V~)
Signal Input: (Balanced) 1x IN (female) XLR connector
Signal Out: (Balanced) Link OUT (male) XLR connector
RDNET connectors: Data In / Data Out
USB connector: standard USB B-type (for SERVICE DATA)
Mechanics
Housing: Wooden box/black polyurea finish
Grille: Full metal (CNC machining)
Handles: 1 on top
Rigging points: 12 M10 Threaded holes + 4 fast pin locks
Width: 280 mm (11.02 in)
Height: 550 mm (21.65 in)
Depth: 375 mm (14.76 in)
Weight: 16.6 kg (36.59 lbs.)
Download the complete user manual on: www.dbtechnologies.com/EN/Downloads.aspx
EMI CLASSIFICATION
According to the standards EN 55103 this equipment is designed and suitable to operate in E3 (or lower E2, E1) Electromagnetic environments.
FCC CLASS B STATEMENT ACCORDING TO TITLE 47, PART 15, SUBPART B, §15.105
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules.
These limits are designed to provide reasonable protection against harmful interference in a residential installation.
This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may
cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference
to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
1. Reorient or relocate the receiving antenna.
2. Increase the separation between the equipment and receiver.
3. Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
4. Consult the dealer or an experienced radio/TV technician for help.
Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the
equipment.
WARNING: Make sure that the loudspeaker is securely installed in a stable position to avoid any injuries or damages to persons or properties.
For safety reasons do not place one loudspeaker on top of another without proper fastening systems. Before hanging the loudspeaker check
all the components for damages, deformations, missing or damaged parts that may compromise safety during installation. If you use the
loudspeakers outdoor avoid spots exposed to bad weather conditions.
Contact dB Technologies for accessories to be used with speakers. dBTechnologies will not accept any responsibility for damages caused by
inappropriate accessories or additional devices.
Features, specification and appearance of products are subject to change without notice.
dBTechnologies reserves the right to make changes or improvements in design or manufacturing without assuming any obligation to change
or improve products previously manufactured.
POWER SUPPLY SPECIFICATIONS (POWER ABSORPTION)
Draw at 1/8 of full power in average use conditions (*): 1.3 A (220-240V~) – 2.1 A (100-120V~)
Draw at 1/3 of full power in maximum use conditions (**): 2.6 A (220-240V~) – 4.4 A (100-120V~)
Power absorption with speaker turned on without signal (idle): 19 W
* INSTALLER NOTES: The values refer to 1/8 of full power, in average operating conditions (music program with
infrequent or no clipping). It is recommended to consider them the minimum sizing values for any type of
configuration.
** INSTALLER NOTES: The values refer to 1/3 of full power, in heavy operating conditions (music program with
frequent clipping or activation of the limiter). We recommend sizing according to these values in case of
professional installations and tours.
