Quick start user manual
Section 1
The warnings in this manual must be observed together with the "USER MANUAL - Section 2".
Le avvertenze nel presente manuale devono essere osservate congiuntamente al “MANUALE D’USO - Sezione2”.
Die Warnungen in diesem Handbuch müssen in Verbindung mit der "BEDIENUNGSANLEITUNG - Abschnitt 2" beobachtet
werden”.
Les avertissements specifiés dans ce manuel doivent être respectés ainsi que les "CARACTERISTIQUES TECHNIQUES -
Section 2"
Las advertencias del presente manual se deben tener en cuenta conjuntamente con las del “MANUAL DEL USUARIO” -
Sección 2”.

A.E.B. Industriale Srl Via Brodolini, 8 Località Crespellano 40053 VALSAMOGGIA BOLOGNA (ITALIA)
Tel [phone] Fax [phone] www.dbtechnologies.com [e-mail]

www.dbtechnologies.cominfo@dbtechnologies‐aeb.com 
SYA10Rev1.1cod.420120308Q
Thank you for choosing a dBTechnologies Product!
The SYA 10 is a versatile active speaker. It is equipped with one 1” compression driver (1” voice coil), and one 10”
woofer (2” voice coil). The multiple input pattern allows an easy and versatile use. For example the user can connect
a dynamic microphone (CH1), an independent source from a mixer (CH2), a Bluetooth MP3 reader (CH3), controlling
each volume level. The user can enhance lower and upper frequencies with the convenient DSP preset function. A
balanced link output allows the audio connection to a second loudspeaker, choosing among “Mix” or “Line” output
type.
Check the site www.dbtechnologies.com for the complete user manual!
1) Unpacking
The box contains:
N°1 SYA 10
N°1 Rain cover
N°1 Mains cable (VDE)
This quick start and warranty documentation
2) Easy installation
SYA 10 is equipped with:
A – Lateral integrated handles
B – Pole mount hole, with two tilt angles
selection (0°/ 7.5°)
Those mechanical particulars were thought for an easy
use and for different configuration needs. SYA 10 is
perfect for gigging bands as well as small venues
installations. The 36 mm pole-mount predisposition is
designed for the use on standard pole stand (like a
tripod).
The acoustical design allows to face different
environments. The dispersion pattern is shown in the
upper picture.
As described, the related pattern data are:
a) vertical coverage: 60°
b) horizontal coverage: 90°
The rear side inclination, symmetrical, as shown in the
upper picture, is 40°. SYA10 can be used as a stage
monitor in small contexts, in this case please consider
the characteristic dispersion pattern presented above.
IT IS MANDATORY TO READ AND
FULLY UNDERSTAND THE COMPLETE
USER MANUAL FOR THE ADMITTED
CONFIGURATIONS OF THE PRODUCT, SAFETY
INFORMATION, AND THE PROPER USE OF
ACCESSORIES (IF ANY).
NEVER USE THE HANDLES TO SUSPEND
THE SPEAKER!

www.dbtechnologies.cominfo@dbtechnologies‐aeb.com 
SYA10Rev1.1cod.420120308Q
3) Connections, controls, first turn on
All the connections and controls are in the amplifier
panel side:
CH1:
1–Audio Combo Input (for XLR or TRS connectors)
2–Line/Mic selector
3–Mic/Line Volume Control
CH2:
4–Audio Input (Balanced / TRS)
5–Line Volume control
CH3 (Bluetooth ):
6–BT status sync LED
7–BT Volume Control
MASTER SECTION
8–DSP Preset switch
9–Balanced audio output
10–Link/Mix switch
11–Master Volume with control LEDs
MAINS SECTION
12–VDE MAINS INPUT (with fuse)
13–ON-OFF SWITCH
a) Connect the audio input (1). The combo connector
allows a TRS or XLR connection. In case of a dynamic
microphone, plug it and select “Mic” in the Audio input
sensitivity switch (2). In the other cases check that the
switch is set on “Line”. Adjust the level of Volume (3).
b) Connect a second input, depending on the kind of
connection (XLR/TRS), then adjust the related volume
level.
c) If needed, enable with the switch (7) the Bluetooth
receiver. Pair it with a visible device (ex. a MP3 reader).
d) If you need to link SYA 10 to another one, please use
a cable with XLR connectors (not supplied). Connect
the Link output (9) of the first, to the balanced Input
(1) of the second one. In the second loudspeaker,
please check that Selector (2) is set on “Line” position
and that Volume (3) is set to the correct value.
e) Set properly the DSP preset switch (8), choosing
between “Playback”, ”Flat”, Bass Boost” or “Wedge”
configuration.
e) Plug properly the mains VDE input cable (supplied)
in the related input (12). Check that the audio source is
set on the minimum level. Then switch the POWER
switch (13) to “ON” position. Increase gradually the
volume of the audio source to the desired level.
Check the site www.dbtechnologies.com for further
information, for added accessories and for the
complete user manual!

www.dbtechnologies.cominfo@dbtechnologies‐aeb.com 
SYA10Rev1.1cod.420120308Q
Technical Data
Speaker Type: 2-way active speaker
Acoustical data
Max SPL (1 m): 125 dB
Frequency response (-10 dB): 55 -18000 Hz
Frequency response (-6 dB): 58 -17000 Hz
HF compression driver: 1 " Exit
HF voice coil: 1”
LF: 10”
LF Voice Coil: 2”
Horizontal dispersion: 90°
Vertical dispersion: 60°
Amplifier
Amp: Custom made, Class-D + A/B– Active Fan cooling
Peak Power: 400 W
Operating voltage ( factory set ):
220-240V~ (50-60Hz) or
110-120V~ (50-60 Hz)
Processor
Controller: 28/56 bit
AD/DA Conversion: 24 bit, 48 kHz
Advanced DSP functions: FIR
Limiter: Peak, RMS, Thermal
Controls: Line/mic, Channel Volume, Link/Mix, Presets
Input / Output
Mains connections: VDE
Signal Inputs: 3 channels (Combo, XLR+trs, Bluetooth )
Signal Out: (Balanced) 1x XLR OUT (LINK)
Mechanics
Housing: Polypropylene
Handles: 2 (on sides)
Width: 310 mm (12.2 in)
Height: 530 mm (20.9 in)
Depth: 299 mm (11.8 in)
Weight: 11.3 kg (24.9 lbs)
EMI CLASSIFICATION
According to the standards EN 55032 and EN 55035 this equipment is designed and suitable to operate in class B electromagnetic environments.
FCC ID: 2ADDV-TLSYA10
FCC CLASS B STATEMENT ACCORDING TO TITLE 47, PART 15, SUBPART B, §15.105
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules.
These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment
generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause
harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the
equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:
1. Reorient or relocate the receiving antenna.
2. Increase the separation between the equipment and receiver.
3. Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
4. Consult the dealer or an experienced radio/TV technician for help.
Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the
equipment.
The Bluetooth® word mark and logos are registered trademarks owned by Bluetooth® SIG, Inc. and any use of such marks by AEB
Industriale SRL is under license. Other Trademarks and trade names are those of their respective owner.
RED CERTIFICATION
Hereby, AEB Industriale declares that SYA loudspeaker is in compliance with Directive 2015/53/EU, in reference to the following
harmonized standards:
Health & Safety EN 62479 / EN 62368-1+A11
EMC EN 301 489-1 V2.2.0, EN 301 489-9 V2.1.1, EN 55032, EN 55035
Spectrum EN 300 328 V2.1.1
SIMPLIFIED EU DECLARATION OF CONFORMITY
The full text of the EU declaration of conformity is available at the following internet address:
http://www.dbtechnologies.com/en/downloads
Features, specification and appearance of products are subject to change without notice.dBTechnologies reserves the right to make changes or
improvements in design or manufacturing without assuming any obligation to change or improve products previously manufactured.
Scan with your QR Reader App to download the
complete User Manual Download the complete user manual from the site:
www.dbtechnologies.com/en/downloads.aspx
