dB Technologies LVX P10 Manual

LVX P10
420120302Q REV.1.1
A.E.B. Industriale Srl Via Brodolini, 8 Località Crespellano 40053 VALSAMOGGIA BOLOGNA (ITALIA)
Tel [phone] Fax [phone] www.dbtechnologies.com [email protected]
The warnings in this manual must be observed together with the “USER MANUAL - Section 2”.
Le avvertenze nel presente manuale devono essere osservate congiuntamente al “MANUALE D’USO - Sezione 2”.
Die Warnungen in diesem Handbuch müssen in Verbindung mit der “BEDIENUNGSANLEITUNG - Abschnitt 2” beobachtet
werden”.
Les avertissements speciés dans ce manuel doivent être respectés ainsi que les “CARACTERISTIQUES TECHNIQUES -Section 2”
Las advertencias del presente manual se deben tener en cuenta conjuntamente con las del “MANUAL DEL USUARIO” - Sección 2”.
QUICK START USER MANUAL
Section 1
VERTICAL DIRECTIVITY HORIZONTAL DIRECTIVITY
ROTATABLE
HORN
ROTATABLE
HORN

LVX P10
420120302Q REV.1.1
Caratteristiche, speciche e aspetto dei prodotti sono soggetti a possibili cambiamenti senza previa comunicazione.
dBTechnologies si riserva il diritto di apportare cambiamenti o miglioramenti nel design o nelle lavorazioni senza assumersi
l’obbligo di cambiare o migliorare anche i prodotti precedentemente realizzati.
Features, specication and appearance of products are subject to change without notice.dBTechnologies reserves the right
to make changes or improvements in design or manifacturing without assuming any obligation change or improve products
previously manufactured.
ATTENZIONE: Per l’installazione e l’uso degli ac-
cessori è obbligatorio fare riferimento al ma-
nuale completo disponibile all’indirizzo: www.
dbtechnologies.com. Ogni altro uso è proibito.
CAUTION: For installation and the usage of the
accessories is mandatory to refer to the com-
plete user manual, available on: www.dbtech-
nologies.com, Any other usage is prohibited.
IN / LINK
IN / LINK
REAR PANEL
IN
IN
LINK
LINK
IN
IN
SOURCE [S]
[S]
[S]
[S]
[X]
[X] = XLR connectors
[S] = speakON connectors
[X]
-6dB
0 dB
-3dB
-9dB
-18dB
-12dB
-24dB
-30dB
PROTECT
LIMIT
d
TECHNOLOGIES
B
HIGH POWER PROFESSIONAL AMPLIFIER
POWER
ON
OFF
CH1 CH2
0dB
0 0
-
0 0
0dB
-
8Ὠ
8Ὠ
8Ὠ
8Ὠ
4Ὠ
4Ὠ
AMPLIFIER
Type: 2-way wooden passive loudspeaker (weather resistant)
Connector type: 4-pole speakON
Main installation uses: Wall mounting, pole mounting (36 mm hole), wedge (40°)
Main accessories: Wall brackets (WBH-LVXP - WBV-LVXP series)
HF transducer: neodymium, 1” exit
HF voice coil: 1”
LF transducer: 10”
LF voice coil: 1,5”
Frequency response (-10 dB) 73 Hz -19 kHz
Frequency response (-6 dB) 81 Hz - 15 kHz
Max SPL 125 dB
Rotatable Horn Ye s
Nominal Impedance: 8 Ω
Power Handling (RMS) 300 W
Power Handling (Peak) 600 W
MAIN FEATURES
ACOUSTIC SECTION
POWER SECTION
IN/LINK SECTION USAGE EXAMPLE (FOR INFORMATION ONLY)
SPEAKON AND XLR CONNECTORS
Scan with your QR Reader
App to download the
complete User Manual!
