LVX PSW15
420120305Q REV.1.1
QUICK START USER MANUAL
Section 1
A.E.B. Industriale Srl Via Brodolini, 8 Località Crespellano 40053 VALSAMOGGIA BOLOGNA (ITALIA)
Tel [phone] Fax [phone] www.dbtechnologies.com [email protected]
The warnings in this manual must be observed together with the “USER MANUAL - Section 2”.
Le avvertenze nel presente manuale devono essere osservate congiuntamente al “MANUALE D’USO - Sezione 2”.
Die Warnungen in diesem Handbuch müssen in Verbindung mit der “BEDIENUNGSANLEITUNG - Abschnitt 2” beobachtet
werden”.
Les avertissements speciés dans ce manuel doivent être respectés ainsi que les “CARACTERISTIQUES TECHNIQUES -Section 2”
Las advertencias del presente manual se deben tener en cuenta conjuntamente con las del “MANUAL DEL USUARIO” - Sección 2”.

LVX PSW15
420120305Q REV.1.1
Caratteristiche, speciche e aspetto dei prodotti sono soggetti a possibili cambiamenti senza previa comunicazione.
dBTechnologies si riserva il diritto di apportare cambiamenti o miglioramenti nel design o nelle lavorazioni senza assumersi
l’obbligo di cambiare o migliorare anche i prodotti precedentemente realizzati.
Features, specication and appearance of products are subject to change without notice.dBTechnologies reserves the right
to make changes or improvements in design or manifacturing without assuming any obligation change or improve products
previously manufactured.
ATTENZIONE: Per l’installazione e l’uso degli ac-
cessori è obbligatorio fare riferimento al ma-
nuale completo disponibile all’indirizzo: www.
dbtechnologies.com. Ogni altro uso è proibito.
CAUTION: For installation and the usage of the
accessories is mandatory to refer to the com-
plete user manual, available on: www.dbtech-
nologies.com, Any other usage is prohibited.
AMPLIFIER
IN
LINK
IN
SOURCE [S]
[X] = XLR connectors
[S] = speakON connectors
AC 26N
REMOTE CONTROLLED AUDIO PROCESSOR
Push
Enter
Functions
Selector
ESCMENU
TECHNOLOGIES
B
d
Local
M
0
!
IN
LINK
IN
[S]
AC26N
[S]
[X]
[X]
IN
LINK
IN
[S]
[S]
IN
IN
LINK
8Ὠ
8Ὠ
8Ὠ
8Ὠ
8Ὠ
8Ὠ
8Ὠ
8Ὠ
4Ὠ
4Ὠ
4Ὠ
4Ὠ
Type: Passive wooden subwoofer (weather resistant)
Connector type: 4-pole speakON
Main installation uses: Live or xed installation with LVX P series loudspeakers
Mechanics: 2 x pole-mount housings, 2 handles
LF transducer: 15”
LF voice coil: 3”
Frequency response (-10 dB) 36 Hz -250 Hz
Frequency response (-6 dB) 41 Hz - 250 Hz
Max SPL 130 dB
Nominal Impedance: 8 Ω
Power Handling (RMS) 500 W
Power Handling (Peak) 1000 W
MAIN FEATURES
ACOUSTIC SECTION
POWER SECTION
USAGE EXAMPLE WITH AC26N (FOR INFORMATION ONLY)
SPEAKON AND XLR CONNECTORS
Scan with your QR Reader
App to download the
complete User Manual!
