decon INFM7002 User manual

Assembly Instructions
INFM7002, INFM7102, INFM7202
Infinity Mounting set
Panthera S3/U3/U3 Light/U3 Light L
2023-01
Revision 2

Mounting set
INFM7002, INFM7102, INFM7202
__________________________________________________________________________________
__________________________________________________________________________________
Page 2/8
1. Safety
Symbols
Warning!
Risk of serious injury or death.
An operation that, if not correctly performed, may lead to injury to the operator or others.
CAUTION!
Risk of material damage.
An operation that, if not correctly performed, may lead to material damage.
INFO
Particularly important or explanatory information
General instructions
These instructions shall always be followed when placing the mounting set INFM7002,
INFM7102, INFM7202 Mounting set Panthera S3/U3 on a wheelchair.
To be able to connect Infinity to the wheelchair Infinity also needs to be adjusted according
to the assembly instructions that is included in the delivery of Infinity.
Warnings
WARNING!
Assembly work or changes made to the mounting set must be carried out by trained service
technician, reseller or another person assigned by Decon.

Mounting set
INFM7002, INFM7102, INFM7202
__________________________________________________________________________________
__________________________________________________________________________________
Page 3/8
2. Overview
A Center pipe adapter bar
B Outer pipe adapter bar
C Clamp adapter bar
D Preassembled adapter plate
E QR-Pin
F Universal clamp
G Panthera clamp
A
B
C
E
F
F
G

Mounting set
INFM7002, INFM7102, INFM7202
__________________________________________________________________________________
__________________________________________________________________________________
Page 4/8
3. Assembly and adjustment of adaptor
First mount preassembled adapter plate (D),
universal clamp (F), wedge (I), sleeve (J), screw
(K) and washer (L) onto the wheelchair. Tighten
loosely so that the parts can move along the
frame.
Mount the Panthera clamp (G) around the frame
using screw (K), washer (L) and locking nut (M)
and tighten loosely.
Check that the preassembled adapter plate sits
correctly and then tighten the screws
Assemble both sides.
WARNING!
The screws (K) in universal clamp (F) and
Panthera clamp (G) must be tightened to 10-
15Nm.
Loctite 243 or eq. shall be applied to the screws
in the universal clamp (F)
M
L
K
L
F
K
L
I
J

Mounting set
INFM7002, INFM7102, INFM7202
__________________________________________________________________________________
__________________________________________________________________________________
Page 5/8
Now mount the complete
adapter bar that consists of
center pipe (A), outer pipe (B)
and clamp (C). The complete
adapter bar is mounted into
the holders (D) by using the
QR-pins (E).
Make sure the ends of the
outer pipe (B) are parallell
otherwise it can be hard to
assemble it into the holders
(D). It shall be possible to move
the center pipe (A) sideways
and also rotate it if correctly assembled.
First tighten the screws in the
panthera clamp (H), it shall be
possible to move the center pipe
sideways and also rotate it even
after tightening of the screws. Now
tighten the screws in the universal
clamp (G).
INFO
Check that the arrow on the labeling mounted on the center pipe (A) is pointing towards the
front of the wheelchair. If the center pipe (A) is mounted the wrong way around it will not be
possible to attach Infinity to the bar.
WARNING!
The screws holding the panthera clamp (H) shall be tightened to 15-20Nm of torque.
The screws holding the universal clamp (G) shall be tightened to 10-15Nm of torque.

Mounting set
INFM7002, INFM7102, INFM7202
__________________________________________________________________________________
__________________________________________________________________________________
Page 6/8
Now use the leveling tool that is included in the
delivery of Infinity. Since the adapter bar have splines
inside it will not be possible to get the bubble of the
spirit level exactly right. Just choose the most correct
position.
The leveling tool has two marks “H” and “L”. When the
bubble of the spirit level is towards the “H” the castors
of the wheelchair will lift higher from the ground
compared to if the bubble of the spirit level is towards
the “L”.
Adjustment of the angle can be done in two different manners. Both is descriped bellow.
Alt.1
Using the adjustment tool that is
included in the delivery of Infinity (not
this mounting set), set the angle of
the adaptorbar so that the spirit level
is in level. Inside the pipes there are
splines so when rotating you will feel
and hear a clicking. When desired
angle have been accomplished, check
that the center pipe is centered in the
wheelchair. Now tighten the screws in
the clamps (C).
WARNING!
The screws holding the clamps (C)
shall be tightened to 7-9Nm of torque.

Mounting set
INFM7002, INFM7102, INFM7202
__________________________________________________________________________________
__________________________________________________________________________________
Page 7/8
Alt.2
Using the adjustment tool that is included in the
delivery of Infinity (not this mounting set), set
the angle of the adaptorbar. Only mount the
inner pipe on one side and then rotate the
center pipe to the correct angle. Now mount the
other inne pipe in the same position/angle as
the first one. Check that the center pipe is
centered in the wheelchair. Now tighten the
screws in the clamps (C).
WARNING!
The screws holding the clamps (C)
shall be tightened to 7-9Nm of torque.
Now read the assembly instructions that was included in the delivery of the Infinity unit.
Assemble and adjust the Infinity according to the instruction.
INFO
Don’t forget to reassemble the brakes of the wheelchair in case these were removed when
mounting the adaptor. Also, if the seat cloth was loosened during mounting of the adaptor
don’t forget to reassemble this.
