Motion Concepts M270 User manual

TRD0323 REV E
USER MANUAL
M270 Remote
Attendant Control
DEALER: This manual contains important safety and operational instructions specific to the
Motion Concepts M270 Remote Attendant Control box. This Manual MUST be given to the
End User of the product.
USER: Before using this product, please read through the instructions carefully and save
for future reference.
for use with
M610LX,M610Q AND M610EM
SEAT CONTROLS

- 3 -
If you have any questions or concerns regarding the programming instructions contained in this manual,
please contact our Technical Service Department for assistance.
USA 888-433-6818
CAN 800-680-4191
Safety Symbols:
Programming your Power Positioning System correctly and safely depends upon your diligence in
following the warnings, cautions and information provided in this User Manual.
The symbols below are used throughout all Motion Concepts’ manuals to identify warnings, cautions
and important notes. It is very important for you to read and understand them completely.
CAUTION! Failure to heed the cautions in this Manual may result in damage to your
Electronics and/or your Power Positioning System.
WARNING! Failure to heed the warnings in this manual may result in personal injury.
IMPORTANT! Important information to remember when operating your Seating System
This manual may not be reproduced or reprinted either partly or completely without previous written consent from
Motion Concepts or its statutory representatives.
This manual is compiled from the latest specifications and product information available at the time of publication.
We reserve the right to make any necessary as they become necessary. Any changes made to our products may
cause slight variations between the illustrations and explanations in this manual and the product you have purchased.
If you have any questions or concerns regarding the information provided in this manual, please contact our Technical
Service Department for assistance.
Motion Concepts LP Copyright © 2017

- 4 -
Select/Save
Button
Exit/Back
Button
Left/Right Arrows
wStandard Mode: SelectMotor Function
wProgram Mode: Scroll Program Options
LED
Indicator
Screen Display
SCREEN DISPLAY:
When not in use, the screen display is designed to enter into sleep mode after 10 sec. in Standard mode
and after 120 sec. in Program mode ; Pressing any button on the remote will re-awaken the display.
EXIT/BACK BUTTON:
The exit/back button is utilized during Program Mode to return to the previous screen display, or to exit
at any stage during programming without saving your changes.
SELECT/SAVE BUTTON:
The select/save button is used in Program Mode to select (enter) the specific option/function you wish
to re-program, and is utilized to save your changes once programming is completed.
STANDARD MODE:
In Standard Mode the remote operates as an attendant control box using the Left/Right arrows to
cycle through the available motor functions on the power positioning system (PPS), and the Up/Down
arrows to operate the selected motor function.
TOP
LED INDICATOR:
The LED light is a visual signal as to the position/status of the power positioning system. The LED light
on remote box is designed to mirror the indicator lights on the 4-way and 8-way switch boxes:
Green Light = indicates that seating system is in the Home position;
Flashing Green = indicates that seating system is Out of Home;
Flashing Red = indicates that a TIlt/Recline and/or Elevating system is in Reduced Speed Drive;
Red Light = indicates the seating system is in Drive Lockout (DLO).
Up/Down Arrows
wStandard Mode: Operate Motor Function
wProgram Mode: Alter Program Setting
M270 REMOTE ATTENDANT CONTROL - OVERVIEW
PROGRAM MODE:
In Program Mode, the remote functions as a hand-held programmer to allow qualified technicians
the flexibility to reconfigure the PPS to better meet the specific needs of the end user when necessary.
IMPORTANT! Program Mode on the M270 remote is password protected. Program access is restricted
to Qualified Technical Service personnel only. If you require any changes to your existing programming
configurations, please contact your local Dealer or Service Provider for assistance. (A summary of program
options is provided for reference in Section 2.1)

- 5 -
1
2
3
TILT TILT
FORWARD
In Standard Mode the M270 remote operates as an attendant control box using the Left/Right arrows
to cycle through the available motor functions on the power positioning system (PPS), and the Up/Down
arrows to operate the selected motor function.
TILT
BACKWARD
1.1 ATTENDANT CONTROL - OPERATING MOTOR FUNCTIONS
1. Use Left/Right arrows (1) to scroll through the available power positioning (motor) functions (i.e.
Tilt, Recline, Elevate, etc..).
Note: the remote will only display the power positioning functions that are available.
2. Select the desired motor function (in the screen display), then press and hold the Up/Down arrows (2)
and (3) to operate the actuator. The power positioning function and direction of travel will be indicated
on the display screen (See example below showing Tilt function).
1.2 ATTENDANT CONTROL - ADJUSTING MOTOR SPEED
1. Select the motor function (i.e.; Tilt, Recline, Legs, Elevate...) and direction
you wish to adjust.
2. To decrease the motor speed, press the Speed Down button (left) while
simultaneously pressing the motor function/direction button (1).
3. To increase the motor speed, press the Speed Up button (right) while
simultaneously pressing the motor function/direction button (2). Speed
Up
Speed
Down
‘Motor’
‘Direction’
TILT
93
TILT
88
TILT
BACKWARD
Decrease Motor Speed Increase Motor Speed
Motor speeds may be adjusted independently while in attendant control (standard) mode. In
standard mode, the ‘Exit/Back’ and ‘Select/Save’ buttons function as ‘Speed Down’ and ‘Speed Up’
while operating a motor function.
e.g. Adjusting ‘Tilt Backward’ speed
12
WARNING! Risk of system damage, serious injury or death
DO NOT operate your power positioning system without first reading and understanding all the Safety
Information from Section 2.0 of your Motion Concepts Owners Manual, TRD0000 (provided separately)
1.0 USING THE M270 REMOTE as an ATTENDANT CONTROL

- 6 -
2.1 PROGRAMMING OPTIONS (for Reference-Only)
IMPORTANT!
The programming of your Motion Concepts power positioning system using the M270 remote is
restricted to qualified Technical Service personnel only. Section 2.1 identifies the various programming
options available through the M270 remote. If you require programming changes beyond your
existing seating system set-up, please contact your local Dealer or Service Provider provider for further
assistance.
1Note: Access to the Program Options via the M270 is restricted (password protected) for qualified Technical
Service personnel only.
WARNING! Risk of system damage or serious personal injury
Incorrect programming could result in an unsafe wheelchair set-up.
Your qualified Dealer or Healthcare Professional is responsible to ensure that the seating system is set-up
properly and safely to meet your individual requirements; Always ensure that you are comfortable with all
safety and functional aspects of your power positioning system prior to use.
If you have questions or concerns regarding your existing program settings, or any of the available program
options, please contact your local Dealer or Service Provider for assistance.
2.0 PROGRAM MODE for the M270 REMOTE
2Note: the M270 software version is also indicated briefly on the display screen when the remote attendant
control is intially powered on.
PROGRAM OPTIONS1DESCRIPTION
Set Tipsy1Sets the wheelchair/seating system safety limits & lockout angles. Refer to Section 2.2-
Recommended Safety Limits
Set ATT SW1Configures the operation of the power positioning system (actuator motors) thru the
operator attendant switch.
Set Motor Type1
Sets the motor current for each actuator. Motor current settings are factory preset. Motion
Concept’s Technical Service Dept. must be contacted for authorization prior to reconfiguring
the motor current settings.
Set Config1‘On/Off’ settings for miscellaneous system features (e.g. R/L Display, Beep, Att Set, Ang
Disp, Tilt Lim, etc...)
Set ASM1
Configures the controls for operating the power positioning system through the Joystick, or
through a Specialty Control Device (e.g. Head Array, Sip N Puff, etc...)
(Note: ASM programming is not available with the M610Q Seat Control)
Set Actuator1Actuator functions may be individually programmed (i.e.; turned on and off). Actuator
functions are factory preset.
Get Version1,2
Indicates current software version of the M270. In order to properly diagnose any potential
issues, it may be necessary to identify the software version of the remote attendant
control.

- 7 -
2.0 PROGRAM MODE for the M270 REMOTE
If you have any questions or concerns regarding the instructions contained in this manual, please contact
our Technical Service Department for assistance.
USA 888-433-6818
CAN 800-680-4191
PROGRAM OPTIONS DESCRIPTION
Set Tipsy1sets safety limits & lockout angles
Set ATT SW1,2 configures operation of seating system (actuators) thru the operator/at-
tendant switch
Set Motor Type1sets motor type (motor current) for each actuator
Set Config1‘On/Off’ settings for miscellaneous system features (e.g. R/L Display, Beep, Att
Set, Ang Disp, Tilt Lim, etc...)
Get Version1indicates current software version of the M270
Set Actuator2turns motor functions ‘On/Off’
Joystick Controls2configures operation of seating system (actuators) thru the joystick (or
specialty control)
IMPORTANT! RECOMMENDED TIPSY ANGLES (SAFETY LIMITS)
Please refer to the following factory recommended limits/lockout angles:
HOME POSITION Home Setting = 0° - 20° Max
REDUCED DRIVE SPEED Limit RDS Limit = 10° - 20° Max
DRIVE LOCKOUT (DLO) Limit1Max. DLO Limit = 30° (with Reduced Drive Speed)
Max. DLO Limit = 25° (without Reduced Drive Speed)
MAXIMUM BACK ANGLE: Max. Tilt Limit = 50° for 50T module or 45° for 45T12 module
Max. Tilt Limit = 55° for MCT system or (30°or 45°)for MCT-B system2
Max. Tilt/Recline Limit = 168° for all Tilt/Recline, Recline-Only
1Note: DO NOT exceed the maximum recommended DLO Limit.
2Note: The Max. Tilt Limit for a UL Bariatric (MCT-B) system is restricted to 30° or 45° based on the user weight.
FACTORY DEFAULT SETTINGS = 15°Home, 20°Reduced Drive, 30°DLO, 168°Max Angle
2.2 RECOMMENDED SAFETY LIMITS
WARNING! Risk of system damage, serious injury or death
Your power positioning system should never exceed the recommended safety limits (see below). The angle
at which limits are set is critical to the safe operation of the power positioning system. Motion Concepts will
not be liable for any injuries or damage sustained when adjustments are made beyond the maximum recom-
mended safety limits.
If at any time your power positioning system/wheelchair is operating beyond the recommended safety limits,
or if you feel unstable at any time while operating your power positioning system, return the system to its stable
(home) position and contact your Dealer or Service Provider immediately for assistance and/or inspection.
