decon Panthera S3 Large User manual

Assembly Instructions
INFM7112, INFM7212
Liberty Mounting set
Panthera S3 Large
2021-12
Revision 0

Mounting set
INFM7 Infinity Mounting set Universal
__________________________________________________________________________________
__________________________________________________________________________________
Sida 2/8
1. Safety
Symbols
Risk of serious injury or death.
An operation that, if not correctly performed, may lead to injury to the operator or others.
Risk of material damage.
An operation that, if not correctly performed, may lead to material damage.
Particularly important or explanatory information
General instructions
These instructions shall always be followed when placing the mounting set INFM7112 and
INFM7212 on a wheelchair. Maximum user weight for the mounting set is 150kg
To be able to connect Liberty to the wheelchair Liberty also needs to be adjusted according
to the assembly instructions that is included in the delivery of Liberty.
Warnings
Assembly work or changes made to the mounting set must be carried out by trained service
technician, reseller or another person assigned by Decon.
Maximum user weight for the mounting set is 150kg.

Mounting set
INFM7 Infinity Mounting set Universal
__________________________________________________________________________________
__________________________________________________________________________________
Sida 3/8
2. Overview
A Center pipe adapter bar
B Outer pipe adapter bar
CClamp adapter bar
D Holder adapter bar
E QR-Pin
F Bar
G Chassis clamp
H Holder screw
H
A
B
C
D
E
F
G
H

Mounting set
INFM7 Infinity Mounting set Universal
__________________________________________________________________________________
__________________________________________________________________________________
Sida 4/8
3. Assembly and adjustment of adaptor
First mount the holder (D) onto the bar (F)
and secure it by using the screws (H). Now
mount the preassembled parts onto the
wheelchair by using the chassis clamps (G),
see picture as example. The distance Xfrom
the edge of the seating cushion to the
holder (D) should be, if possible, 20-30mm
so that the upper pin of the center pipe
adapter bar (A) is visible outside the edge of
the seating cushion.
The distance Yshould not be greater than
20mm to ensure that the bar (F) gets
sufficient support. The front clamp (G)
should be mounted as close as possible to
the holder (D).
Tighten the screws in the clamps (G) just
enough to grip the wheelchair chassis so
that the bar (F) can still be adjusted inside
the clamps.
Assemble both sides.

Mounting set
INFM7 Infinity Mounting set Universal
__________________________________________________________________________________
__________________________________________________________________________________
Sida 5/8
WARNING!
One clamp (G) is to be mounted on each
side of the holder (D) to avoid that the bar
breaks due to fatigue stress.
Now mount the complete adapter bar that
consists of center pipe (A), outer pipe (B)
and clamp (C). The complete adapter bar is
mounted into the holders (D) by using the
QR-pins (E).
Make sure the ends of the outer pipe (B)
are parallell otherwise it can be hard to
assemble it into the holders (D). It shall be
possible to move the center pipe sideways
and also rotate it if correctly assembled.
Now tighten the screws in all of the clamps (G).
INFO
Check that the arrow on the labeling mounted on the center pipe (A) is pointing towards the
front of the wheelchair. If the center pipe (A) is mounted the wrong way around it will not be
possible to attach Liberty to the bar.
7-9Nm of torque (M6)
10-15Nm of torque (M8)

Mounting set
INFM7 Infinity Mounting set Universal
__________________________________________________________________________________
__________________________________________________________________________________
Sida 6/8
Now use the leveling tool that is included in the
delivery of Infinity. Since the adapter bar have splines
inside it will not be possible to get the bubble of the
spirit level exactly right. Just choose the most correct
position.
The leveling tool has two marks “H” and “L”. When the
bubble of the spirit level is towards the “H” the castors
of the wheelchair will lift higher from the ground
compared to if the bubble of the spirit level is towards
the “L”.
Adjustment of the angle can be done in two different manners. Both is descriped bellow.
Alt1.
Using the adjustment tool that
is included in the delivery of
Infinity (not this mounting set),
set the angle of the adaptorbar
so that the spirit level is in level.
Inside the pipes there are
splines so when rotating you
will feel and hear a clicking.
When desired angle have been
accomplished, check that the
center pipe is centered in the
wheelchair. Now tighten the
screws in the clamps (C).
WARNING!
The screws holding the clamps
(C) shall be tightened to 7-9Nm
of torque.

Mounting set
INFM7 Infinity Mounting set Universal
__________________________________________________________________________________
__________________________________________________________________________________
Sida 7/8
Alt.2
Using the adjustment tool that is included in the delivery
of Infinity (not this mounting set), set the angle of the
adaptorbar. Only mount the inner pipe on one side and
then rotate the center pipe to the correct angle. Now
mount the other inne pipe in the same position/angle as
the first one. Check that the center pipe is centered in
the wheelchair. Now tighten the screws in the clamps
(C).
WARNING!
The screws holding the clamps (C)
shall be tightened to 7-9Nm of
torque.
Now read the assembly instructions that was included in the delivery of the Infinity unit.
Assemble and adjust the Infinity according to the instruction.

Decon Wheel AB
Södra Ekeryd 119, SE-314 93 Hyltebruk, Sweden
Tel: [phone]
Fax: [phone]
E-mail: [email protected]
