decon Adventus Quick start guide

Adventus Folding wheelchair
adaptor
Assembly Instructions

Adventus Folding wheelchair adaptor, Assembly Instructions Rev0
__________________________________________________________________________________
2
1. Overview
A Holder adapter bar
B QR-pin
C Adapter bar
D Fork adapter bar
E Adjustment tool
E
C
A
B
D

Adventus Folding wheelchair adaptor, Assembly Instructions Rev0
__________________________________________________________________________________
3
2. Mounting of adapter bar
First mount the holder (A). The shape of the holder can vary depending on wheelchair model.
Mount the holders so that they still can be moved along the wheelchair chassis. Now mount
the adapter bar (C) into the holders (A) by using the QR-Pins (B).
Make sure the ends of the adapter bar (C) are parallell otherwise it can be hard to assemble it
into the holders (A).
Now tighten the screws in the holders (A) so that it grips the wheelchair chassis.
Picture2&3, Universal holder for wheelchairs with round tubing
Picture4&5, Holder for Etac Cross/Cross5

Adventus Folding wheelchair adaptor, Assembly Instructions Rev0
__________________________________________________________________________________
4
Picture6, Holder mounted on both sides
Picture7, Mount the adapter bar into the holders using the QR-pins
Picture8, Mounted adapter bar

Adventus Folding wheelchair adaptor, Assembly Instructions Rev0
__________________________________________________________________________________
5
3. Adjustment of adapter bar
Step 3.1
Mount the adjustment toll onto the fork (D). Remove the screws in the fork that locks the
rotation (see picture bellow). Also make sure that the fork sits in the center of the wheelchair.
Picture9, Universal holder for wheelchair with round tubing chassis

Adventus Folding wheelchair adaptor, Assembly Instructions Rev0
__________________________________________________________________________________
6
Step 3.2
Now rotate both the adapter bar and the fork to a position where the adjustment tool shows
the correct angle and the fork doesn’t collide with the footrests. If possible, make sure that
the fork doesn’t sit lower than the footrest and that the height, if possible, corresponds to the
picture bellow.
=
Approx. 30mm

Adventus Folding wheelchair adaptor, Assembly Instructions Rev0
__________________________________________________________________________________
7
Step 3.3
Reassemble the screw in the hole that is fits the best, se picture bellow for example.

Adventus Folding wheelchair adaptor, Assembly Instructions Rev0
__________________________________________________________________________________
8
Step 3.4
Now tighten the screws that sits in the clamp of the adaptor bar. Slightly tighten all four
screws on the clamp. It is important to not completely tighten each screw, but to slowly
tighten all four, a little at a time. Keep tightening until all four screws are secured (30-35Nm
of torque). Also make sure one last time that the fork is centered and the angle of the
adjustment tool is still correct.
Step 3.5
Check one last time that all screws are properly secured. Now see the user manual of
Adventus to continue the installation. This can be downloaded from www.decon.se/en/.
