DeDietrich G30 User manual

4 feux gaz
4 gas ring
3 feux gaz
+ 1 foyer électrique
3 gas ring
+ 1 electric hotplate hob
Le guide d’utilisation de
votre table de cuisson
Hob operating guide
FR
GB
99627402_ML_A.qxd 01/04/03 13:44 Page 1

23
In this Manual,
displays safety instructions
displays tips and hints
List of contents
Using your hob in complete safety 25
What your hob looks like? 26
Installing your hob in all simplicity 27
Fitting recommendations 27-29
Electrical connections 30
Gas connections 31-32
Changing the type of gas supply 33-37
Using your hob in all simplicity 38
How to use your gas burners? 38
Which pans are best adapted for use 39
on the gas burner?
How to use the electric hotplate? 40
Which pans are best adapted for use on the electric hotplate? 40
How to look after your hob? 41
Minor troubleshooting 42
Gas-cooking guide 43
Cooking guide for electrical hobs 43
GB
99627402_ML_A.qxd 01/04/03 13:45 Page 23

24
Dear Customer,
Thank you for buying a DE DIETRICH hob.
Our research teams have designed a new generation of kitchen
appliances. As a result of our unique expertise, we have produced
a range of goods whose quality, design and technical advance are
unsurpassed.
You will find that the clean lines and modern look of your
DE DIETRICH hob blends in perfectly with your kitchen décor. It
is easy to use and performs to a high standard.
DE DIETRICH also makes a range of products that will enhance
your kitchen such as hobs, extractor hoods, built-in dishwashers
and refrigerators. There are models to complement your new DE
DIETRICH hob.
Of course, we make every effort to ensure that our products meet
all your requirements, and our Customer Relations department is
at your disposal, to answer all your questions and to listen to all
your suggestions (see back cover of manual).
DE DIETRICH is certain that by setting new standards of
excellence by which comparisons can be made, customers will
find that DE DIETRICH appliances offer a better and more
exciting way of living.
DE DIETRICH.
Editorial
99627402_ML_A.qxd 01/04/03 13:45 Page 24

25
- We have designed your hob for private
domestic use.
- With a view to the constant
improvement of our products, we reserve
the right to make any changes in their
technical, functional or aesthetic
characteristics as a result of technical
evolution.
- These hobs are designed exclusively for
the cooking of drinks and foodstuffs.
These products do not contain any
asbestos-based component parts.
- Using a gas-powered hob produces both
heat and humidity in the room where it is
used.
Make sure your kitchen is well
ventilated :
keep all natural air-vents open or have a
mechanical ventilation system installed (a
mechanically ventilated hood) with a
minimum airflow of 2m3/h.
- You must always keep an eye on your
cooking.
- Please read the instructions before
installing and using this appliance.
- Never leave any CLEANING OU
INFLAMMABLE products in the cupboard or
drawer beneath your hob (aerosols or
other pressurised cans, papers, recipe
books, etc.).
- If you use a drawer under your hob, we
advise you not to keep any objects in it
that are liable to suffer from heat (plastic,
paper, aerosols, etc.).
- Prolonged, intensive use of the hob may
require extra ventilation; by opening a
window for example or producing more
Your hob in complete safety
efficient ventilation by increasing the
power of the existing mechanical
ventilation.
- Disconnect your hob from both electrical
and gas supplies before carrying out any
maintenance operations.
- If you plug in any electrical appliance
near the hob, make sure that its power
cable is not in contact with any source of
heat.
- For safety reasons, do not forget to
close the main gas valve for built in gas
lines or the valve on the top of your
butane/propane gas cylinder.
- If a knob is difficult to turn, DO NOT
FORCE IT. Call up your installer.
- The EC mark of conformity can be found
on all these hobs.
Using your hob in complete safety
YOUR HOB IS DELIVERED PRE-SET FOR USE WITH NATURAL TOWN GAS.
99627402_ML_A.qxd 01/04/03 13:45 Page 25

26
①①Right back burner switch
What your hob looks like?
4 gas ring hob
3 gas ring + 1 electric hotplate hob
Semi-fast
burner ②②
Double-crown
burner ③③
Fast burner ①①
Auxiliary
burner ④④
②②Left back burner switch
③③Front left burner switch
④④Front right burner switch
①①Right back burner switch
②②Left back burner switch
③③Front left burner switch
④④Front right burner switch
②②Right back burner switch
electric hotplate
hob ⑤⑤
Double-crown
burner ④④
Fast burner
②②
Auxiliary
burner ③③
①①Electric ring indicator
③③Front right burner switch
④④Front left burner switch
⑤⑤Electric ring switch
Semi-fast
burner ②②
Extra fast burner ③③
Fast burner ①①
Auxiliary
burner ④④
99627402_ML_A.qxd 01/04/03 13:45 Page 26

27
This appliance should be installed by a
qualified technician / installer.
Prior to installation, ensure that the
local distribution conditions (nature of
the gas and gas pressure) and the
adjustment conditions of the
appliance are compatible.
The adjustment conditions are stated on a
label in the wallet and also on the
packaging.
This appliance must be installed and
connected in accordance with your
country's regulations. It must be used in a
place that is well-ventilated. Please read the
instructions before installing or using.
Installing your hob in all simplicity
This appliance is not connected to a smoke
extractor. Please ensure that its installation
complies with ventilation requirements.
On this subject, combustion can take place
only if oxygen from the air is present, so
this air must be constantly renewed and
the combustion products must be
evacuated (a minimum air input of 2 m3/h
per kW of gas energy is required).
• These hobs comply with the require-
ments of heating in accordance with stan-
dard EN 60.335.2.6 and Class 3 for installa-
tion itself (in accordance with standard EN
30.1.1).
Fitting recommendations
Keep this guide near your appliance and stick the identity label to the last
page.
Cut-out
Model
Width Depth Height
Depending on cupboard
Outside
dimensions above
the work surface
60 cm 52 cm 5,6 cm
Outside
dimensions under
work surface
55 cm 47,5 cm 3,4 cm
49 cm
56 cm
99627402_ML_A.qxd 01/04/03 13:45 Page 27

28
Installing your hob in all simplicity
The hob must be built into the work-
top of a support cupboard. This work-
top must be at least 3 cm thick and
heat-resistant or else coated with a
heat resistant material.
A side-clearance of at least 30 cm
should be left to the right and left of
the hob. A tall cupboard or partition
too close to the hob would hinder free
movement of kitchen utensils.
If a horizontal partition is put under
the hob, it must be placed between 10
and 15 cm from the bottom of the
worktop. In any case, do not keep any
sprays or pressurized containers in
the compartment which could be just
under the hob.
To prevent any foreign bodies or li-
quid from getting between the hob
and the worktop, stick the foam seal
provided in the wallet in position before
installing the hob. This will also protect
your work surface from the heat given
out by the hob.
1- remove the pan support grates,
the burner caps and heads after chec-
king their position.
2- Turn the hob over and place it
gently over the opening in the work-
top paying attention not to damage
the control knobs, thermocouples and
lighters.
3- Stick the foam seal around the
outside of the hob. This foam seal
ensures that no water can seep bet-
ween the top of the hob and the sur-
rounding work surface. It also helps
to insulate the work surface from the
heat of the hob.
4- Put the hob back the right way
up and place the burners, caps and
pan grates back in position.
Fitting recommendations (cont'd)
49 cm
3 cm mini
30 cm mini 30 cm mini
56 cm
5,3 cm mini
70 cm mini
Casing
Foam seal
99627402_ML_A.qxd 01/04/03 13:45 Page 28

29
Installing your hob in all simplicity
- Place the hob in position in the worktop
cut-out taking care to centre it as well as
possible.
- replace the burner heads, the burner
caps and the pan stands.
- Connect the hob power cable to your
kitchen electricity supply (See "Elec-
trical Connections").
-Connect to your gas supply (see "How
to connect the hob to the mains gas
supply" or "How to connect the hob
to butane or propane gas").
If you want, you can fix the hob in posi-
tion on its four corners, using the four
lugs and screws provided (See diagram).
Only use the holes provided,
Shown by arrows on the hob unit
(see diagram opposite)
Stop screwing when the lug
starts to bend.
Do not use a power screwdriver.
Fitting recommendations (cont'd)
Worktop Mounting pad
Underside of the hob unit
Mounting pad FRONT
Mounting pad BACK
Connector terminal
Fixing holes, shown by
arrows
99627402_ML_A.qxd 01/04/03 13:45 Page 29

30
Cable
H05V2V2F - T90
Cross section of
conductors in
mm2
Fuse
220-240 V~- 50 Hz
All-gas and
mixed
3 conductors of
which 1 is to be
earthed
1
10 A
CROSS SECTION OF THE CABLE TO USE
Installing your hob in all simplicity
Hobs are delivered with a three-conduc-
tor (phase + ground + neutral)
H05V2V2F - T90, 1mm section cable,
ref. SAV : 77X3767 and must be
connected to a 220-240 V~single pha-
se mains supply by the intermediary of
a phase + earth + CEI 60083 standardi-
sed neutral plug, or a single pole cut-off
device with a contact opening by at
least 3mm.
The mains plug must be accessible after
installation.
Electrical connections
The protective conductor is connected to the earth connection on the hob
and therefore must also be connected to an external earth connection .
Use a 10 A fuse.
If the supply cable is damaged it must be replaced by a cable or a special unit avai-
lable from the manufacturer or its After-Sales Service.
●Mixed and all-gas hobs
99627402_ML_A.qxd 01/04/03 13:45 Page 30

31
Installing your hob in all simplicity
Gas connections
●Possible connections
One of the 3 following connections must
be used:
-
connection with a rigid pipe (gas
standard G1/2).
The connection should be made at the end of
the elbow seal on the appliance,
or -
connection with a reinforced,
braided, flexible gas hose with threa-
ded connectors
(fig. A).
You may also use a "Gazinox" type, stain-
less steel flexible tube available from your
local distributor,
or - connection with a flexible gas ho-
se with threaded connectors
(fig. B).
These hoses must not exceed 2 metres
in length and their entire length must be
accessible.
NATURAL GAS
Meter
;
;
@
@




;
;
Q
Q


fig.A fig.B
Reinforced, braided,
flexible gas hose with
threaded connectors
Flexible gas hose with
threaded connectors
●Preliminary remarks
Access to the whole length of the connection hose must be possible and the gas hose
must be replaced before its use before date (indicated on the hose).
Whatever means of connections is chosen, make sure that it is gas sound after installa-
tion by using soapy-water.
If the hob is to be installed above an oven
or if other nearby heating appliances risk
heating and damaging the gas hose then it
is essential that a rigid pipe be installed
instead.
If a flexible hose is used (in the case of
butane gas) then it must not be installed
in a place where it may be in contact with
a moving part of the kitchen unit or a pla-
ce likely to get cluttered.
TOWN GAS (NATURAL GAS)
99627402_ML_A.qxd 01/04/03 13:45 Page 31
