DeDietrich DME 1135B User manual

EN USER GUIDE
Oven

2
Dear Customer,
When you discover DDeeDDiieettrriicchhproducts you experience the same feelings
that only objects of value can arouse.
You are immediately attracted as soon as you see them. The quality of the
design is illustrated by its timelessness, degree of refinement and elegance,
and high standard of finish, resulting in perfect harmony between different
appliances.
Then comes the irresistible urge to touch. DDeeDDiieettrriicchhdesign makes the most
of sturdy and noble materials; priority is given to authenticity.
By combining the most advanced technologies with the best materials,
DDeeDDiieettrriicchhmakes products of the highest quality for the benefit of all those
who love cooking.
We hope you are extremely satisfied with this new appliance and will be happy
to receive your suggestions and to answer your questions. Please contact our
customer service department or use our Internet site.
We invite you to register your product at wwwwww..ddee--ddiieettrriicchh..ccoommto take
advantage of all the benefits the brand has to offer.
Thanking you for your confidence.
DDeeDDiieettrriicchh
Find further details on the brand at wwwwww..ddee--ddiieettrriicchh..ccoomm
Visit La Galerie De Dietrich, 6 rue de la Pépinière in Paris
Open Tuesday to Saturday 10 a.m. to 7 p.m.
Customer Service: 0892 02 88 04
Warning:
Before installing and using your appliance, please read this Installation and Use Guide
carefully, which will allow you to quickly familiarise yourself with the appliance’s operation.

3
EN
CONTENTS
1 / DESCRIPTION OF YOUR APPLIANCE
••Introduction to your oven____________________________________ 4
••Introduction to the programmer ______________________________ 5
2 / USING YOUR APPLIANCE
••Using the programmer
ºResetting the time______________________________________ 6
ºImmediate cooking _____________________________________ 7
••Programmed cooking
ºImmediate start ________________________________________ 8
ºDelayed start __________________________________________ 9
••Using the “minute minder” function ___________________________ 10
••Locking the controls________________________________________ 11
••Standby mode _____________________________________________ 11
••Adjusting screen contrast ___________________________________ 12
••Demo mode_______________________________________________ 12
••Starting and stopping the turntable ___________________________ 13
••Microwave ________________________________________________ 14
ºUsing the power levels __________________________________ 14
ºHeating on two levels ___________________________________ 14
ºDefrosting ____________________________________________ 15
ºDefrost Guide _________________________________________ 16
3 / FUNCTION SUITABILITY TESTS _________________________________ 17
4 / AFTER-SALES SERVICE
••Service calls ______________________________________________ 18

4
EN 1 / DESCRIPTION OF YOUR APPLIANCE
INTRODUCTION TO YOUR OVEN
••
A
B
Programmer
Control knob
Wire shelf supports
C
C
B
A
1
2
3

5
EN
1 / DESCRIPTION OF YOUR APPLIANCE
••
INTRODUCTION TO THE PROGRAMMER
A
B
Cooking mode display
Cooking time symbol
Cooking time/”minute minder” display
“Minute minder” symbol
End of cooking time symbol
C
D
E
Clock display
Shelf /Stop turntable symbol
Keypad locking symbol (child safety device)
Oven power display
F
G
H
I
A
B
Power setting touch button
Time, cooking time, end of cooking time and “minute minder” touch button
Stop touch button
C
C
AB
A
CH
F
B
ED G I

6
EN 2 / USING YOUR APPLIANCE
-
+
•Resetting the time
--When power is switched on
The display flashes 12:00.
- Set the time using the knob.
Example: 12:30.
- Press the knob to confirm.
The display stops flashing.
3
2
1
- TTooaalltteerrtthheettiimmeeoonntthheecclloocckk
- Press the button for a few
seconds until the display flashes and then
release it.
A beep indicates that the time may now be
set.
- Adjust the time, using the knob.
Press the knob to confirm.
5
4
Warning
If the setting is not confirmed, the
adjustment will automatically be saved in
the appliance’s memory after a few
seconds.
••
USING THE PROGRAMMER
-
+
5
4
1
2
3

••
USING THE PROGRAMMER
7
EN
2 / USING YOUR APPLIANCE
•Immediate cooking
— The programmer should only display the
time. It should not be flashing.
- Use the knob to select the required
cooking setting.
- Example: —> Power setting 1000W.
- Confirm by pressing the knob once.
- The cooking time flashes in the display.
- Set the cooking time, using the knob.
- Example: 1mn30s
- Confirm by pressing the knob.
Cooking starts.
TThheeppoowweerroorrtteemmppeerraattuurreesseettttiinnggmmaayybbee
cchhaannggeedd..
Press the touch button until the
display flashes and then release it.
- When the (1000W) power setting
flashes you may adjust it.
- Set the power, using the knob.
- Example: 800 Watts
- Confirm by pressing the knob.
To stop cooking, press the button for a
few seconds.
4
3
2
W
1
4
3
2
1
3
2
1
2
1
4
1
2
3
3
2
1
43

8
EN 2 / USING YOUR APPLIANCE
--
Cooking with immediate start and a set
cooking time
- Select the desired cooking mode and adjust
the power (see paragraph: “Immediate
cooking”).
- Press the button.
- The display flashes to indicate
that a setting may be entered.
- Using the knob, set the cooking time.
- Example: 2 minutes.
Press the knob to confirm.
- At the end of the (programmed)
cooking time:
- the oven stops,
- flashes,
- a series of beeps are emitted for a few
minutes. The beeps can be stopped by
pressing any button.
5
4
3
2
1
PROGRAMMED COOKING
••
1
34
2
5
Warning
All cooking is done with the door closed.
After a cooking cycle, the cooling fan continues to run for a time, in order to guarantee
optimum oven reliability.

9
EN
2 / USING YOUR APPLIANCE
--
Cooking with delayed start and
selected end of cooking time
PPrroocceeeeddaassffoorrpprrooggrraammmmeeddccooookkiinngg..
- Press the button until the cooking
end time indicator flashes.
- The end of cooking time indicator
flashes to indicate that it may now be set.
- Turn the knob to set the end of
cooking time.
- Example: end of cooking time 1:30 p.m.
- Press the knob to confirm.
The end of cooking time will automatically be
saved in the appliance’s memory after a few
seconds.
The end of cooking time display stops
flashing.
- The display returns to the time of day.
- An animated display indicates that the
oven is in delayed cooking mode.
The light inside the oven comes on when
cooking starts and goes out at the end of
cooking.
OOnncceetthheessee33sstteeppsshhaavveebbeeeennccoommpplleetteedd,,tthhee
oovveennhheeaat
tiinnggssttaarrttttiimmeeiissddeellaayyeeddssootthhaatt
ccooookkiinnggeennddssaatt1133::3300..
At the end of the (programmed) cooking time:
- The oven stops and the cooking time
symbol and 0:00 flash.
- A series of beeps are emitted for a few
minutes. The beeps can be stopped by
pressing any button.
6
5
4
3
2
1
PROGRAMMED COOKING
••
1
34
5
2
6

10
EN 2 / USING YOUR APPLIANCE
--YYoouurroovveenn’’sspprrooggrraammmmeerrccaannbbeeuusseeddaassaann
iinnddeeppeennddeennttttiimmeerrtthhaattaalllloowwssyyoouuttooccoouunntt
ddoowwnnttiimmeewwiitthho
ouuttuussiinnggtthheeoovveenn..
In this case, the “minute minder” display
takes priority over the clock display.
- Press the touch button three times.
- The “minute minder” symbol and
0m00s flash.
- Set the time using the knob.
- Press the knob to confirm.
The display stops flashing after a few
seconds and the “minute minder” starts to
run, counting down the time in seconds.
Once the time is up, the minute minder emits
a series of beeps to let you know.
The beeps can be stopped by pressing any
touch button.
2
1
Warning
You can modify or cancel at any time the “minute minder” by pressing the button
and by reducing the time to 0:00.
USING THE “MINUTE MINDER” FUNCTION
••
1
2

11
EN
2 / USING YOUR APPLIANCE
LOCKING THE CONTROLS (CHILD SAFETY)
OVEN OFF
You have the option of preventing access to
the oven controls by taking the following
steps:
when the oven is off, press the
SSTTOOPP
and buttons simultaneously for a few
seconds.
A “padlock” will then be displayed in the
screen
- Access to the oven controls is blocked.
To unlock them, simultaneously press the
SSTTOOPP
and buttons for a few seconds.
The oven controls are once again accessible.
2
1
••
1
2
THE “STANDBY MODE” FUNCTION
••
--
Your oven is equipped with a standby function
- The display shows the time of day.
- After 4 minutes with no action by the user, the oven display switches over to standby mode.
NNookkeeyyccaannbbeeaaccttiivvaatteedd....
To reactivate the display, use the function selector.
- The oven display is once again operational and you can start cooking again.

12
2 / USING YOUR APPLIANCE
EN
--Set the time to 00:10 (see “Resetting the
time” on p.6)
- Press the WWbutton until -CO- is
displayed.
- Adjust the contrast, using the knob.
- Press the knob to confirm.
3
2
1
ADJUSTING THE DISPLAY CONTRAST
••
-
+
1
23
--Set the time to 00:00 (see “Resetting the
time” on p.6)
- Press the WW
SSTTOOPP
buttons
simultaneously for 10 seconds until DEMO
appears in the display.
- To return to normal mode,set the time to
00:00 and press the WW
SSTTOOPP
buttons
again until DEMO disappears from the display.
1
DEMO MODE
••
1
Warning
When the oven is in DEMO mode the
heating elements are inactive.

13
2 / USING YOUR APPLIANCE EN
Stopping the turntable
--To stop the turntable rotating, press and
hold the knob. The (stop) symbol
appears in the display.
••Restarting the turntable
- Once again, press and hold the knob until
the symbol disappears from the display.
1
STOPPING AND STARTING THE TURNTABLE
••
If you think that there is insufficient space for
the turntable to rotate freely in the oven, you
can stop it before or during the programme.
1

14
MICROWAVE
When using the 500W microwave power function, you can heat two dishes at the same time. In
this case, put one plate on the turntable and the other on the shelf on the third level.
Tips:
Cover the plates with special microwave film, a plate cover or another plate placed upside-down
on the first:
- To obtain the most even reheating.
- To avoid the food drying out.
- To reduce the reheating time.
- To prevent food spatter in the oven.
The foods keep all their flavour due to the steaming effect.
Type of food Quantity Time
Homogeneous foods like mashed
potatoes, petits pois, celery, etc. 2 x 200 g plates 4 to 6 min
Heterogeneous foods like
cassoulet, bourguignon, ravioli, etc... 2 x 300 g plates 6 to 8 min
HEATING ON TWO LEVELS
Power Use
1000W / 900W
Quickly reheating drinks, water, dishes containing a lot of water.
Cooking foods containing a lot of water (soups, sauces, tomatoes,
etc.)
800W / 700W Cooking fresh or frozen vegetables.
600W Melting chocolate.
500W Cooking fish and seafood. Heating on 2 levels. Gently simmering dry
vegetables. Reheating or cooking delicate egg-based foods.
400W / 300W Gently simmering dairy products, jams.
200W Manual defrost. Softening butter and ice cream.
100W Defrosting cream-based pastries.
MICROWAVE POWER OUTPUT: 1000W
USING THE POWER LEVELS
••
••
2 / USING YOUR APPLIANCE
EN

Using your microwave oven to defrost frozen food will save you a lot of time.
To defrost food, use the AAUUTTOOMMAATTIICCDDEEFFRROOSSTTfunction or the MMIICCRROOWWAAVVEEfunction with the
power set at 220000WW.
WWhhaattyyoouunneeeeddttookknnooww::
Small pieces of meat or fish can be cooked straight after defrosting. Larger pieces such as meat
joints or whole fish will still be slightly frozen at the end of the defrost programme.
We recommend that you let the food stand for a period of time at least equal to the defrosting
time to ensure an even temperature.
Food covered with ice crystals will take longer to defrost. In this case, you should increase the
defrosting time.
AAffeewwttiippss::
The defrosting time depends on the type of appliance. It also depends on the shape, size,
starting temperature and quality of the food.
In most cases, the food must be removed from its packaging. Remember to remove any metal
staples from the packaging.
Halfway through defrosting, the pieces of food should be turned over, stirred and separated if
they were frozen together.
If you are defrosting large pieces of meat or fish that prevent rotation of the turntable, use the
turntable stop function. In this case, turn the food regularly.
Defrost meat or fish by putting it on an upside-down saucer on top of a plate to let the juices
run. If they stay in contact with the food, it will overheat.
Never refreeze food before cooking it.
DDeeffrroossttp
prrooggrraammmmeettiimmee::
The defrost programme time is calculated for food frozen at -18°C. This gives you an indication
of the time needed for defrosting but the actual time may vary depending on the thickness,
shape, size and packaging of the food.
DEFROST
DEFROSTING
••
This oven allows you to access two different types of programmes in the defrost mode
- Automatic defrost programme P1 or P2. You simply select the type of programme and enter the
weight.
PP11::TThheeaauuttoommaattiiccddeeffrroossttmmooddeeffoorrmmeeaatt,,ppoouullttrryyaannddrreeaaddyy--mmaaddeemmeeaallss..
PP22::TThheeaauuttoommaattiiccddeeffrroosstt
mmooddeeffoorrbbrreeaaddaannddppaassttrriieess..
••
15
2 / USING YOUR APPLIANCE EN

16
Food Quantity Time Recommendations
Flaky or short crust pastry 400 g 1 - 3 min Place on absorbent paper and turn
over halfway through.
Food Quantity Time Recommendations
Scallops 500 g 5 - 7 min
Place on a plate and mix
midway through programme.
Shelled prawns 100 g 1 - 2 min
Whole pink shrimp 200 g 2 - 4 min
Prawns (10) 500 g 6 - 8 min
Food Quantity Time
Whole fish/darns/fillets/ steaks
100 g
200 g
400 g
500 g
750 g
1000 g
1 - 2 min
3 - 5 min
5 - 7 min
7 - 9 min
12 - 14 min
17 - 19 min
Turkey/Pork/Veal/Beef/Poultry
Roasts/slices/cubes/etc.
100 g
200 g
400 g
500 g
750 g
1000 g
1250 g
1500 g
1750 g
2000 g
1 - 2 min
3 - 5 min
5 - 7 min
7 - 9 min
12 - 14 min
17 - 19 min
23 - 25 min
28 - 30 min
34 - 36 min
39 - 41 min
Cauliflower / broccoli / carrots / mushrooms /
diced mixed vegetables / etc...
500 g
750 g
1000 g
7 - 9 min
12 - 14 min
17 - 19 min
Food Quantity Time
Strawberries
Raspberries/cherries
Gooseberries / blueberries /blackcurrants
250 g
250 g
250 g
7 - 9 min
6 - 8 min
5 - 7 min
DEFROSTING GUIDE
••
2 / USING YOUR APPLIANCE
EN

EN3 / FUNCTION SUITABILITY TESTS
Test Load Approx.
time
Power level
selector
Cookware/Tips
Custard
(12.3.1)
1000 g
750 g
16 - 18
min
13 - 15
min
500W Pyrex 227
On the turntable
Pyrex 220
On the turntable
Sponge cake
(12.3.2)
475 g 6 - 7 min 700W Pyrex 827
On the turntable
Meatloaf
(12.3.3)
900 g 14 min 700W Pyrex 838
Cover with plastic film
On the turntable
Defrosting
meat
(13.3)
500 g 11 - 12
min
200W On the turntable
Defrosting
raspberries
(B.2.1)
250 g 6 - 7 min 200W On a flat plate
On the turntable
FFuunnccttiioonnaallssuuiittaabbiilliittyytteessttssiinnaaccccoorrddaanncceewwiitthhIIEECC//EENN//NNFFEENN6600770055ssttaannddaarrddss;;
TThheeIInntteerrnnaattiioonnaallEElleec
cttrrootteecchhnniiccaallCCoommmmiissssiioonn,,SSCC..5599KK,,hhaasseessttaabblliisshheeddaassttaannddaarrddffoorr
ccoommppaarraattiivveeppeerrffoorrmmaanncceetteessttssccoonndduuc
ctteeddoonnvvaarriioouussmmiiccrroowwaavveeoovveennss..WWeerreeccoommmmeennddtthhee
ffoolllloowwiinnggffoorrtthhiissaapppplliiaannccee::
17

18
EN 4 / AFTER-SALES SERVICE
Any repair made to your appliance must be
carried out by a qualified professional,
authorised to work on the brand. When you
call, state your appliance’s complete reference
information (model, type, serial number). This
information appears on the manufacturer’s
nameplate
(Fig.1).
ORIGINAL PARTS
During maintenance work, request the
exclusive use of
certified genuine
replacement parts.
• SERVICE CALLS
BRANDT APPLIANCES SAS
7 rue Henri Becquerel
92500 RUEIL MALMAISON
230V ~ 50 Hz
MADE IN FRANCE
fig.1

19
EN
FFaaggoorrBBrraannddttSSAASS,,tenant-manager – SAS with share capital of 20 000 000 euros RCS Nanterre 440 303 196.
CZ5700726-00 - 08/11
