DeDietrich DOE7560X User manual

OVEN
EN USER GUIDE

DEAR CUSTOMER,
EN
Discovering a De Dietrich product means experiencing the range of unique
emotions.
The attraction is immediate, from the moment you set eyes on the product.
The sheer quality of the design
shines through, thanks to the timeless style and outstanding finishes which
make each component an elegant and refined masterpiece in its own right,
each one
in perfect harmony with the others. Next, comes the irresistible urge to
touch it.
De Dietrich design makes extensive use of robust and prestigious
materials, where the accent is placed firmly upon authenticity. By combining
state-of-the-art technology
with top quality materials, De Dietrich produces
beautifully crafted products to help you get the most from the culinary arts,
a passion
shared by all lovers of cooking and fine food. We hope that you enjoy
using this new appliance.
Thank you for choosing a De Dietrich product.

3
CONTENTS
EN
1 / Description of the oven ................................................................4
The controls and display ......................................................................5
The accessories....................................................................................6
Initial settings - using the oven for the first time....................................8
2 / The cooking modes ......................................................................9
«Expert» mode ....................................................................................9
ºCooking functions..........................................................................10
ºDrying ............................................................................................13
ºFavourites (saved cooking) ..........................................................14
«Recipes» mode ................................................................................14
«Low temperature» mode ..................................................................16
3 / Settings ........................................................................................18
º Time ..............................................................................................18
º Language ......................................................................................18
º Sound ............................................................................................18
º Demo mode ..................................................................................18
º Lamp management ......................................................................18
Locking the controls............................................................................19
4 / Minute Minder ..............................................................................19
5 / Cleaning and Maintenance ........................................................20
External surface..................................................................................20
Removing the shelf runners................................................................20
Changing the catalytic liners ..............................................................20
Cleaning the inner glass ....................................................................20
Removing and putting back the door..................................................20
Replacing the light bulb ......................................................................22
6 / Anomalies and solutions ............................................................22
7 / After-Sales Service ......................................................................23

4
C
A
B
•1DESCRIPTION OF THE OVEN
DESCRIPTION OF THE OVEN
AControl panel
Lamp
Shelf runners (6 heights available)
C
B

5
•1DESCRIPTION OF THE OVEN
THE CONTROLS AND DISPLAY
Start a cooking programme
Stop a cooking programme
Temperature degrees
Cooking time
Cooking end time
(delayed start function)
Saved cooking
programmes
Keypad locked indicator
Recommended shelf height indicator for placing
dishes
DISPLAY SYMBOLS
Oven off touch control
(press and hold)
Go back touch control
(active in programming
search, not cooking)
MENU access touch control
(cooking, settings, minute
minder)
Displays
Rotating knob with central button
(cannot be removed):
- Choose programmes, increase or
reduce values by turning it.
- Validate each action by pressing
the centre.
B
C
A
A
B
C
D
D
E
E

•1DESCRIPTION OF THE OVEN
6
ACCESSORIES
(depending on model)
- Anti-tip safety rack
The rack can be used to support all
dishes and moulds containing food for
cooking or browning. It can be used for
grilling (placed directly on top).
Position the anti-tip stop towards the back
of the oven.
Multi-purpose tray, drip tray45 mm
When inserted in the shelf runners under
the grill with the handle towards the oven
door, it collects juice and fat from grilling,
and can be used half-filled with water as a
double-boiler.
- 20 mm pastry dish
Insert in the shelf runners with the handle
towards the oven door. Ideal for baking
cookies, shortbread and cupcakes. The
tilted surface makes it easier for you to put
your preparations in a dish. Can also be
inserted into the shelf runners under the
grill to collect juice and fat from grilling.
- «Flavour» grills
These half «flavour» grills are used
separately, but only when placed in one of
the dishes or drip tray with the anti-tip
handle towards the back of the oven.
By using just one grill, it is easy to moisten
your food with the cooking juices collected
in the dish.

7
•1DESCRIPTION OF THE OVEN
- Sliding rail system
The new sliding rail system makes food
more practical and easier to handle as the
trays can be effortlessly pulled for simpler
handling. The trays can be completely
removed, providing full access.
Their stability ensures that food can be
handled safely, reducing the risk of burns.
This means that you can take food out of
the oven far more easily.
INSTALLING AND REMOVING THE
SLIDING RAILS
After removing the 2 shelf runners,
choose the height (2 to 5) at which you
want to fit your rails. Snap the left rail
against the left shelf runner by applying
enough pressure to the front and back
of the rail so that the 2 tabs on the side
of the rail slot into the shelf runner. Do
the same for the right-hand rail.
NOTE: the telescopic sliding part of the
rail must unfold towards the front of the
oven, with the buffer opposite you.
Insert your 2 shelf runners and then put
your tray on the 2 rails. The system is
now ready to use.
To remove the rails, remove the shelf
runners again.
Slightly prise apart the bottom of the tabs
fixed on each rail to release the shelf
runner. Pull the rail towards you.
A
Tip
To avoid fumes when cooking fatty
meats, we recommend you add a small
amount of water or oil to the bottom of
the drip pan.
The accessories may warp with
the effect of heat, but this will not
alter their function. They will return to
their original shape once cooled.
A
A

8
- Starting - General menu
Press the MENU key key to access
the general menu when the oven only
displays the time.
You will access the first cooking mode:
Expert mode.
Turn the knob to scroll through the
different programmes :
Before using your oven for the
first time, heat it at maximum
temperature while empty for
approximately 30 minutes. Make sure
that the room is sufficiently
ventilated.
•1DESCRIPTION OF THE OVEN
- Select the language
The first time you use your oven or after
a power cut, turn the knob to select
your language and press to confirm
your choice.
- Set the time
The displays flashes 12:00.
Adjust the hours and minutes by turning
the knob, then press to confirm.
Your oven displays the time.
Note: To modify the time again, refer to
the «Settings» chapter. NB: To modify
the time again, refer to the «Settings»
chapter. Expert
Recipes
Low
temperature
Settings
Minute
Minder
To enter the selected mode, validate by
pressing the knob.
To go back (except during cooking),
press the back key and to stop the
oven, press the stop key for a few
seconds.
INITIAL SETTINGS - USING THE
OVEN FOR THE FIRST TIME

9
•2COOKING
THE COOKING MODES
This mode lets you set the cooking
parameters yourself: temperature,
cooking type, cooking time.
When the oven is only displaying the ti-
me, press the MENU key to access
the general menu then confirm «Expert»
mode.
- Turn the control knob until you get to
the cooking function of your choose,
then confirm:
Fan cooking
Combined heat
Traditional
Eco cooking
Grill ventilated
Bottom heat ventilated
Variable grill
Keep warm
Defrost
Bread
Drying
Shabbat (special function)
****************************
Favourites (enables 3 cooking
programmes to be saved)
«EXPERT» MODE
Select one of the following modes
according to your experience in cooking
your recipe:
Select “EXPERT” mode for a
recipe for which you will select
the type of cooking, the
temperature and the cooking time
yourself.
Select «RECIPES» mode for a
recipe for which you need
assistance from the oven.
Simply select the type of food proposed
and its weight and the oven will select
the most suitable parameters.
Select “LOW TEMPERATU-
RE” mode for a recipe mana-
ged completely by the oven
using a specific electronic programme
(slow cooking).
1
1
2
3

10
•2COOKING
COOKING FUNCTIONS (depending on model)
Grill
ventilated
Roasts and poultry are juicy and crisp all
over.
Slide the drip tray on to the bottom shelf
support.
Recommended for all spit-roasted poultry
or meat, for sealing and thoroughly
cooking a leg or a rib of beef. To retain the
moist texture of fish steaks.
200°C
100°C - 250°C
ECO* This setting saves energy while
maintaining the quality of the cooking. In
this setting, pre-heating is not required.
200°C
35°C - 275°C
Traditional Recommended for meat, fish,
vegetables, preferably in an earthenware
dish.
200°C
35°C - 275°C
Fan
cooking*
Recommended for keeping white meat,
fish and vegetables moist. For cooking
multiple items on up to three levels.
Position Use
180°C
35°C - 250°C
Combined
heat
Recommended for meat, fish,
vegetables, preferably in an earthenware
dish.
205°C
35°C - 230°C
T°C recommended
mini - maxi
Pre-heat your oven empty before cooking.
Bottom heat
ventilated
Recommended for meat, fish,
vegetables, preferably in an earthenware
dish.
180°C
75°C - 250°C
*Cooking mode as per standard EN 60350-1: 2016 to demonstrate compliance with requirements
of the energy label of European regulation UE/65/2014.
Never place tin foil directly in contact with the oven floor as the build up
of heat may damage the enamel.

11
•2COOKING
Variable grill Recommended for grilling cutlets,
sausages, toasting bread and prawns
placed on the grill. Cooking is done by the
upper element. The grill covers the entire
shelf surface.
4
1 - 4
Keep
warm
Recommended for letting dough rise for
bread, brioche, kügelhopf.
Put the mould on the bottom, not
exceeding 40°C (plate-warming,
defrosting).
60°C
35°C - 100°C
Defrost Ideal for delicate dishes (fruit tarts,
custard pies, etc.). Meat, rolls, etc. are
defrosted at 50°C (meat should be placed
under the grill with a dish underneath to
catch the drips).
35°C
30°C - 50°C
Bread Recommended cooking sequence for
bread making. Pre-heat, then place the
ball of dough on a baking sheet - 2nd
shelf. Do not forget to place a dish of
water in the bottom to obtain a crisp,
golden crust.
205°C
35°C - 220°C
Drying Sequence to dehydrate certain food such
as fruits, vegetables, seeds, roots,
seasoning plants and herbs. Refer to the
specific drying table below.
80°C
35°C - 80°C
Position Use
T°C recommended
mini - maxi
Shabbat Special sequence: the oven operates
uninterrupted for 25 or 75 hours at 90°C
only.
90°C
Advice on how to save energy
Avoid opening the door during cooking to avoid heat escaping from the
oven.

•2COOKING
12
Based on the type of cooking you
already selected, the oven will
recommend the ideal cooking
temperature.
This can be adjusted as follows:
- Select the temperature symbol
then confirm.
- Turn the control knob to change the
temperature then confirm your choice.
CHANGING THE TEMPERATURE
IMMEDIATE COOKING
(Expert mode)
COOKING TIME
You can enter the cooking time for your
dish by selecting the cooking time
symbol and confirming.
Enter the cooking time by turning the
control knob then confirm.
Your oven has the “SMART ASSIST”
function which, when programming a
When you have selected and validated
your cooking function, example: Bottom
heat ventilated, the oven recommends
one or two shelf heights.
- Place your dish in the oven at the
recommended level.
- Press the control knob again to start
cooking. The temperature starts to
increase at once.
Note: Certain parameters may be
modified before cooking starts
(temperature, cooking time and delayed
start); see the following chapters.
cooking time, will suggest a cooking time
which can be modified depending on the
selected cooking mode.
The time starts to count down as soon
as the cooking temperature is
reached.
DELAYED START COOKING
When you set the cooking time, the end
of cooking time automatically adjusts. You
can change the end of cooking time if you
want to delay the programme start.
-Select the end of cooking symbol
and confirm.
Once you have set the cooking end time,
confirm.
Note: You may start cooking without
selecting a duration or end time. In this
case, when you feel that you have
cooked your dish for long enough, stop
cooking (see the «Stopping cooking in
progress» chapter).
STOPPING COOKING IN PROGRESS
To stop a cooking programme in
progress, press the control knob.
The oven displays a message:
«Do you want to stop the cooking in
progress?».
Confirm by selecting «I agree» then
validate or select «I refuse» and validate
to continue cooking.

13
Drying is one of the oldest methods of
preserving food. The aim is to remove all
or some of the water in the food to
preserve foodstuffs and prevent the
development of microbes. Drying
preserves the nutritional qualities of food
(minerals, proteins and other vitamins). It
allows food to be stored in optimal
conditions thanks to their reduced size
and makes food easy to use once re-
hydrated.
Only use fresh food.
Wash the food carefully, drain and wipe.
Cover the grill in parchment paper and
distribute the cut food evenly on top.
Use shelf level 1 (if you have several grill
pans, put them on levels 1 and 3).
Turn the food over several times during
drying. The values provided in the table
may vary depending on the type of food
to dehydrate, its maturity, its thickness
and its humidity rate.
•2COOKING
DRYING FUNCTION
Guide table to dehydrate your food
Fruits with seeds (in 3 mm slices, 200
g per grill pan)
Fruits with stones (plums)
Sliced mushrooms
Tomato, mango, orange, banana
Edible roots (carrots, parsnips),
grated and blanched
80°C
80°C
80°C
60°C
60°C
5-9
8-10
5-8
8
8
Sliced red beetroot 60°C 6
1 or 2 grill pans
1 or 2 grill pans
1 or 2 grill pans
1 or 2 grill pans
1 or 2 grill pans
Herbs 60°C 61 or 2 grill pans
1 or 2 grill pans
Time in
hours Accessories
Fruits, vegetables and herbs Temperature

14
•2COOKING
«RECIPES» MODE
This mode selects for you the
appropriate cooking parameters based
on the food to be prepared.
IMMEDIATE COOKING
- Select «RECIPES» mode when you are
in the general menu then confirm.
The oven suggests several categories
which contain a range of dishes (see
detailed list below):
- Select the category, example «The
fishmonger», then confirm.
- Choose the specific dish to be prepared,
for example «trout», and confirm.
The weight (or size) must be entered for
certain food.
- A weight is then suggested. Enter the
weight and confirm; the oven will
automatically calculate and display the
cooking time and the shelf height.
- Place your dish in the oven and confirm.
For certain recipes the oven must
be warmed up before you place
your disk in it.
You may open your oven to baste your
dish at any time during cooking.
- The oven beeps and turns off when the
cooking time is finished; your screen then
indicates that the dish is ready.
- Memorise a cooking
The «Favourites» function lets you save
3 recipes in «Expert» mode that you
make frequently.
In Expert mode, first of all select a
cooking, its temperature and its time.
Then select the symbol by turning
the control knob to memorise this
cooking, then validate.
The screen then suggests saving these
parameters in a memory or
. Choose one then confirm. Your
cooking is then memorised.
Confirm again to start cooking.
NB: If the 3 memories are already used,
any new memorisation will replace the
previous one.
A delayed start cannot be programmed
for memorisations.
- Use a memory that is already saved in
the “Favourites” function
Go to the “Expert” menu and confirm.
Scroll through the functions to the
«Favourites « function by turning the
control knob.
- Select one of the memories already
saved or and press to
confirm.
The oven starts.
FAVOURITES
(in Expert mode)
2

15
•2COOKING
* For these dishes, the oven must be
warmed up before you place your
disk in it.
The screen tells you not to insert
your dish until the oven has reached its
temperature.
A beep sounds to let you know that
warm-up is complete; the time starts
counting down from this point.
Place your dish in the oven at the shelf
level indicated.
LIST OF DISHES
THE PASTRY COOK
Fruit pie
Crumble
Sponge cake
Cupcakes
Crème caramel
Chocolate cake
Short bread / Cookies *
Cake
Yoghurt cake
THE POULTERER
Chicken
Duck
Duck breast *
vTurkey
THE BUTCHER
Rare shoulder of lamb
Rare beef
Beef medium done
Well-cooked beef
Roast pork
Roast veal
Veal rib *
THE FISHMONGER
Salmon
Trout
Fish terrine
THE CATERER
Lasagne
Pizza
Quiche
THE GREENGROCER
Potato gratin
Stuffed tomatoes
Jacket potatoes
THE BAKER
Puff pastry
Shortcrust pastry
Leavened dough
Brioche
Bread
Baguettes
DELAYED START COOKING
If you wish, you can change the cooking
end time by selecting the end of cooking
symbol and confirming.
Once you have set the cooking end time,
confirm.
For recipes which require pre-
heating, it is not possible to use the
delayed start function.

16
•2COOKING
This cooking mode makes meat fibres
tender thanks to slow cooking at low
temperature.
Cooking quality is optimal.
No preheating is required when
using LOW TEMPERATURE mode.
Cooking ABSOLUTELY must begin in
a cool oven.
Cooking at low temperature
requires food to be extremely
fresh. For poultry, it is important to
rinse the outside and inside with cold
water and to dray with absorbent
paper before cooking.
IMMEDIATE COOKING
- In the general menu, select «Low
Temperature” cooking mode with the
control knob and confirm your choice.
The oven proposes a choice of dishes
(see the list of dishes below).
- Select your dish.
- Once you have selected your dish for
example: roast veal, put your meat on
the grill pan in the upper level (No. 2) and
slide the drip pan onto the shelf below
(No. 1).
- Confirm the selection by pressing the
control knob. Cooking starts.
«LOW
TEMPERATURE” mode
3
When cooking is complete, the oven
switches off automatically and a signal
sounds.
Press the stop key .
DELAYED START COOKING
You can choose a delayed «low
temperature» start.
Once you have selected your
programme, select the cooking end
symbol . The display flashes; set the
cooking end time by turning the knob
then confirm.
The cooking end time display stops
flashing.

17
•2COOKING
LIST OF DISHES
Roast veal (4h00)
Roast beef:
rare (3h00)
well done (4h00)
Roast pork (5h00)
Lamb:
rare (3h00)
well done (4h00)
Chicken (6h00)
Small fish (1h20)
Large fish (2h10)
Yoghurts (3h00)
NOTE: Do not use the grill for the
following programmes: small fish
- large fish and yoghurts.
Put them directly on the drip tray on the
shelf level shown on the screen.

18
•3SETTINGS
SETTINGS FUNCTIONS
In the general menu, select the
«SETTINGS» function by turning the
control knob and confirm.
Different settings are proposed:
- The time, the language, the sound,
demo mode, lamp management
.
Select the function you want by turning
the control knob and then confirm.
Then set your parameters and confirm
them.
Time
Modify the time; validate then modify the
minutes and validate again.
Language
Choose your language and confirm.
Sound
Your oven emits sounds when you use
the keys. To keep these sounds, select
ON, otherwise select OFF to deactivate
them and confirm.
DEMO mode
By default, the oven is configured in
normal heating mode.
If it is activated in DEMO mode (ON
position), the mode for presenting
products in stores, your oven will not
warm up.
To return it to normal mode, set it to OFF
and confirm.
Lamp management
Two setting options are proposed:
Position ON, the light stays on
throughout cooking (except in ECO
mode).
Position AUTO, the oven light turns off
after 90 seconds when cooking.
Choose your position and confirm.
After 90 seconds without any action
by the user, the display
brightness decreases to limit
energy consumption and the oven
light goes off (when it is in «AUTO»
mode).
Press the back or menu keys
once to restore the display’s
brightness and activate the light
during cooking if necessary.

19
•4MINUTE MINDER
•3SETTINGS
MINUTE MINDER FUNCTION
This function can only be used when the
oven is off.
In the general menu, select the
«MINUTE MINDER» function by turning
the control knob and confirm.
00:00 is displayed on the screen.
Set the minute minder by turning the
knob and then press to confirm. The
timer starts.
Once the time has lapsed, there is a
sound signal. To stop it, press any key.
Note: You can modify or cancel the
minute minder at any time.
To cancel, return to the minute minder
menu and set to 00:00.
If you press the control knob during the
countdown you will stop the minute
minder.
LOCKING THE CONTROLS
Child safety lock
Press the back and menu keys at
the same time until the padlock symbol
is displayed on the screen.
Control locking is accessible during
cooking or when the oven has stopped.
NOTE: only the key remains active.
To unlock the keypad, press the back
and menu keys at the same time until
the padlock symbol disappears from
the screen.

20
commercial scouring products.
Replace the liners when they get too dirty
with new liners and fix them to the shelf
runners before putting the shelf runners
back.
CLEANING THE INNER GLASS
To clean the inner glass, remove the
door. Before doing this, remove any
excess grease with a soft cloth and
washing up liquid.
Warning
Do not use scouring products,
abrasive sponges or metal scrapers to
clean the glass oven door as this
could scratch the surface and cause
the glass to shatter.
REMOVING AND PUTTING BACK THE
DOOR
Open the door fully and block it with one
of the plastic wedges provided in your
appliance’s plastic pouch.
Remove the clipped glass panel:
Using the other wedge (or a screwdriver),
press the slots to unclip the glass.
A
EXTERNAL SURFACE
Use a window washing product applied
to a soft cloth. Do not use abrasive
creams or scouring sponges.
REMOVING THE SHELF RUNNERS
Side liners with shelf runners:
Lift the front part of the shelf runner
upwards. Press the entire shelf runner
and release the front hook from its
housing. Then, gently pull the whole of
the shelf runner towards you to release
the rear hooks from their housing. Pull
out the two shelf supports.
REPLACEMENT OF THE OVEN
CATALYTIC LINERS (depending on
model)
This oven has a cavity with removable
liners which are slotted into the shelf
supports. These liners are covered with a
special micro-porous enamel (catalytic
enamel) with self-cleaning properties.
Dirt spreads out and is dispersed into the
micro-porous holes. It is oxidised on both
sides and gradually disappears.
We strongly recommend:
- That you do not scrub these catalytic
liners with metallic brushes, pointed or
sharp instruments.
- That you do not try to clean them with
•5CARE
