DeDietrich Cooker hood Instruction Manual

FR GUIDE D’UTILISATION
EN GUIDE TO INSTALLATION
CS N¡VOD NA INSTALACI A POUéITÕ
DA INSTALLATIONS- OG BRUGSVEJLEDNING
DE BETRIEBSANLEITUNG
Hotte de cuisine
Cooker hood
KuchyÚsk· digesto¯
Emhætte til køkken
Dunstabzugshaube

DearCustomer,
YouhavejustacquiredaDEDIETRICHhood,andwewouldliketothank
you.
Ourresearchteamshavecreatedthisnewgenerationofappliancesfor
you. Their quality, design, features and technological advances make
themexceptionalproducts,andrevealouruniqueknow-how.
YournewDEDIETRICHhoodwillblendharmoniouslyintoyourkitchen
andwillperfectlycombineextractionperformanceandeaseofuse.We
wanted to offer you a product of excellence.
In the DE DIETRICH product range, you will also find a wide choice of
hobs,ovens,microwaves,dishwashers,cookers,fridges,freezers,that
youcancoordinatewithyournewDE DIETRICH hood.
Visitourwebsitewww.dedietrich-electromenager.com,whereyouwill
findourlatestinnovationsaswellasusefulandcomplementaryinformation.
DEDIETRICH
SettingNewValues
As part of our commitment to constantly improving our products, we reserve the right to make
changes to them based on technical advances to their technical and functional features and
appearance.
Warning : Before installing and using your appliance, please
carefullyreadthisGuide to Installation andUse,whichwillallowyouto
quickly familiarise yourself with its operation.
17
FR 01
EN 17
CS 32
DA 47
DE 62

18
1 / NOTICES TO THE USER
• Safetyrecommendations___________________________________ 19
• Environmentalprotection ___________________________________ 20
• ForAustralia only(Legalinstruction) __________________________ 21
• Descriptionofyourappliance________________________________ 21
2 / INSTALLING YOUR APPLIANCE
• Usingtheevacuationmode_________________________________ 22
• Usingtherecyclingmode___________________________________ 22
• Electricalconnections______________________________________ 23
• Assemblingthehood_______________________________________ 24
• Fixing the telescopic flues
• Ductingmode _____________________________________ 25
• Filteringmode ____________________________________ 26
3 / USING YOUR APPLIANCE
• Descriptionof thecontrolpanel______________________________ 27
4/CARINGFORANDCLEANINGYOURAPPLIANCE
• Cleaningthegreasefilter___________________________________ 28
• Changingthecharcoalfilter_________________________________ 28
• Cleaningand caringofthe casing____________________________ 29
• Changingthelightbulb_____________________________________ 29
• Maintainingyourappliance__________________________________ 30
5/TROUBLESHOOTING_________________________________________ 31
6/AFTERSALESSERVICE _____________________________________ 31
TABLE OF CONTENTS EN

19
Attention
Keep this user guide with your appliance. If
the appliance is ever sold or transferred to
another person, ensure that the new owner
receives the user guide. Please become
familiar with these recommendations before
installing and using your oven. They were
written for your safety and the safety of
others.
•SAFETY RECOMMENDATIONS
- This oven was designed for use by private
persons in their homes.
- This appliance is to be used by adults.
Make sure that children do not touch and that
they do not treat it as a toy. Make sure that they
do not touch the appliance's control panel.
- When you receive the appliance, unpack or
have it unpacked immediately. Give it an over-all
general inspection. Make note of any concerns
or reservations on the delivery slip and make
sure to keep a copy of this form.
- Your appliance is intended for standard
household use. Do not use it for commercial or
industrial purposes or for any other purpose than
that for which it was designed.
- Do not modify or attempt to modify any of the
characteristics of this appliance. This would be
dangerous to your safety.
- Repairs must only be carried out by an approved
specialist.
- Always unplug the hood before cleaning it or
performing other maintenance acts.
- Provide adequate ventilation for the room in the
case of simultaneous use of the hood and other
appliances powered by an energy source other
than electricity. This will prevent the hood from
aspirating the combustion gases.
- You should never "flambé" dishes under the
hood or operate gas rings under the hood without
placing cookware on them (the flames sucked
up into the hood can damage the appliance).
- When frying food under the appliance, you must
carefully monitor the preparation at all times.
Oils and grease brought to very high
temperatures can catch fire.
- Respect the recommended frequency of
cleanings and filter replacements. The
accumulation of grease deposits may cause a
fire.
- The hood should never be used over a
1 / NOTICES TO THE USER
EN
combustible fuel burning stove (wood, coal, etc.).
- Never use steam or high-pressure devices to
clean your appliance (requirement imposed by
electrical safety).
-Withaviewtoconstantlyimprovingourproducts,
we reserve the right to modify their technical,
functionaloraestheticcharacteristics, making any
changes to their features considered necessary
or desirable in view of technical progress.
-Inordertoeasilylocatethereferenceinformation
for your appliance, we recommend that you note
thesedataonthe "After-Sales Service Department
and Customer Relations" page.
(This page also explains to you where to find this
information on your appliance.)
Warning
In the case of a kitchen heated by a
device connected to a chimney (a stove, for
example) the "filtering" version of the hood
should be installed. Do not use the hood
without grease filters.
Suitable ventilation should be provided in
the room when the hood is used at the same
time as appliances operated by gas or another
combustible fuel.

20
•ENVIRONMENTAL PROTECTION
- This appliance’s packaging material is recyclable. Help recycle it and protect the environment by
dropping it off in the municipal receptacles provided for this purpose.
- Your appliance also contains a great amount of recyclable material. It is marked with this label to
indicate the used appliances that should not be mixed with other waste. This way, the
appliance recycling organised by your manufacturer will be done under the best possible
conditions, in compliance with European Directive 2002/96/EC on Waste Electrical and
Electronic Equipment. Contact your town hall or your retailer for the used appliance
collection points closest to your home.
- We thank you doing your part to protect the environment.
Warning
Installation should only be performed by installers and qualified technicians
Warning
Remove the protective film from the grease filter before use.
1 / NOTICES TO THE USER EN
• FOR AUSTRALIA ONLY (Legal instruction)
Young children should be supervised to ensure that they do not play with the appliance.
The appliance is not intended for use by young children or infirm person without supervision.
If the supply cord is damaged, it must be replaced by the manufacturer or its service agent or a similarly
qualified person in order to avoid hazard.
WARNING : Ensure the appliance is switched off before replacing the lamp to avoid the possibility of
electric shock.
For service issues, telephone number: 1300
Do not install the product if you see any damage on it.

21
•DESCRIPTIONOF YOUR APPLIANCE
1 / NOTICES TO THE USER
EN
Fixing tabsATelescopic fluesB
Control panelC

22
- The appliance must be unplugged during installation or when any repairs or maintenance work is
being performed.
- Ensure that the network voltage corresponds to the voltage noted on the identification plate located
inside the hood.
- If the electrical installation at your residence requires any changes in order to hook up your
Appliance, call upon a professional electrician.
- If the hood is being used in evacuation mode, do not connect the appliance to a combustion gas
exhaust duct (boiler, chimney, etc.) or to a CMV (controlled mechanical ventilation) system.
- Under no circumstances should the exhaust duct empty into the attic.
- Install the hood at safe distance of at least 35 cm from an cooking hob.
This appliance can be installed in either duction version or filtering version.
The appliance is supplied in the filtering version, the charcoal filter is installed (Ref.AH4063U1).
• USING THE DUCTING MODE
If you posses an outlet to the exterior
(fig. 1)
Your hood can be connected to this outlet using a
flue (minimum Ø 125mm that is enamelled, in
aluminium, flexible or made of inflammable
material).
Your cooker hood is a filtering version. All you
need to do is to remove the charcoal filter first.
• USING THE FILTERING MODE
If you do not posses an oulet to the exterior
(fig. 2)
All of our appliances can be used in recycling
mode.
The air and steam taken up by the unit are
purified with charcoal filter and returned to the
environment.
2 / INSTALLING YOUR APPLIANCE EN
fig. 1
fig. 2

23
•ELECTRICALCONNECTIONS
During installation and maintenance operations,
the appliance must be unplugged from the
electrical grid; fuses must be cut off or removed.
The electrical connections are made before the
appliance is installed in its housing.
Ensure that
- the electrical installation has sufficient voltage,
- the electrical wires are in good condition,
- the diameter of the wires complies with the
installation requirements.
Warning
This appliance must be grounded.
We cannot be held responsible for any
accident resulting from an inexistent,
defective or incorrect ground lead.
In case your appliance is not furnished with a non
separating flexible cable and has no plug, or has
not got any other device ensuring omnipolar
disconnection from the electricity main, with a
contact opening distance of at least 3mm, such
separating device ensuring disconnection from
the main must be included in the fixed installation.
This appliance is delivered with a H05VVF power
cord that has three-0.75mm2 conductors (neutral,
phase and ground). It must be connected to the
main power supply (which should be a 230-240V
single phase current) via a CEI60083
standardised socket that should remain
accessible after installation, in keeping with
installation guidelines.
If the power cable is damaged, call the after-sales
service department in order to avoid danger.
Warning
If the electrical installation at your
residence requires any changes in order to
hook up your appliance, call upon a
professional electrician.
Warning
If the hood displays any malfunctions,
unplug the appliance or remove the fuse
corresponding to the electrical socket where
your appliance is plugged in.
2 / INSTALLING YOUR APPLIANCE
EN

24
• ASSEMBLING THE HOOD
Warning
The hood must be installed in
compliance with all applicable regulations
concerning the ventilation of premises. In
France these regulations are described in
DTU 61.1 from the CSTB. In particular, the
evacuated air should never be conveyed to
a duct used to evacuate smoke from
appliances that use gas or other
combustible fuels. Unused ducts may only
be used after approval from a competent
specialist.
The distance between the supporting surface for
the cooking vessels on the hob and the lower part
of the hood must be at least 350 mm. If the
instructions for installation for the hob specify a
greaterdistance,thishastobetakenintoaccount.
Fixing to the wall
Drawalineonthewallinverticallinewithyourhob.
Mark the first 2 holes to be drilled in the wall,
respecting the distances indicated in Fig.3. Drill
the 2 holes and fit the screw anchors provided.
Bear in mind that the distance between the lower
edge of the hood and the hob must be 350 mm.
Fix the metal bracket (A) to the wall using the 2
holes just drilled (Fig. 4); the screws for fixing the
bracket are provided. Use the 2 cut-out triangles
on the bracket to position it exactly along the
vertical axis of the hood.
Hang the hood on the bracket (Fig.5). Adjust the
horizontal position moving the hood to the right or
leftsothatitisalignedwiththewallunits.Ifyoualso
need to adjust the hood in height, operate on the
adjusting screws (B) provided.
When adjustment has been completed, without
removing the hood, mark the other 6 holes to be
drilled(C)inthewall.Removethehoodanddrillthe
holes marked (8 mm diameter). Then use the 6
screw anchors and the 6 screws provided for final
fixing.
2 / INSTALLING YOUR APPLIANCE EN
fig. 3
fig. 4
fig. 5

25
2 / INSTALLING YOUR APPLIANCE
EN
Warning
This is the filtering version of your
cooker hood; you must first remove the
charcoal filter.
Tip
For optimal use of your appliance, we
recommend that you connect the hood to a
150 mm-diameter flue (not delivered with the
appliance). Minimise the number of angles
and bends and the lengths of the flue. In
the event that the hood will be operated
using out-door evacuation, you should
ensure a sufficient inflow of fresh air to
avoid a pressure deficiency in the room.
fig. 6
• FIXING THE TELESCOPIC FLUES
• Ducting mode
- Assemble the tube support using a 4 screws kit
(Fig.7); then, by means of the screw anchors and
screws (F) provided, fix the bracket to the ceiling
insuchawaythatitispositionedalongtheaxiswith
your hood (Fig.8).
- Connect the air outlet pipe to the air vent of the
hood.
-Usea flexiblepipeandlockit totheairventof the
hood with a metal hose clamp - Fig.9 (pipe and
clamp are not provided).
-Forductinghoods,turntheupperflueoversothat
theairexhaust grid isinthelowersection (Fig.10).
- Plug in the hood.
- Insert the extension flues setting them on the
hood; extend the upper flue to the ceiling and
secure with the 2 screws (H) - Fig.11.
Install the flange in the device air outlet and
press slightly (Fig.6).
fig. 7
fig. 8
fig. 9

• Filtering mode
- Assemble the tube support using a 4 screws kit
(Fig.7).
- Then, by means of the screw anchors and
screws (F) provided, fix the bracket to the ceiling
insuchawaythatitispositionedalongtheaxiswith
your hood (Fig.8).
- Mount the flange on the hood in correspondence
to the air outlet point (Fig.12).
- Take the air baffle and fit a flexible pipe to it (125
mm diameter) locking it with a metal hose clamp
(pipe and clamps are not provided). Fit the air
baffle to the upper flue (Fig.13) with 4 screws.
- Connect the flexible pipe to the flange on the air
vent (Fig.14).
- Plug in the hood.
- Insert the extension flues setting them on the
hood; extend the upper flue to the ceiling and
secure with the 2 screws H (Fig.11).
fig.10 fig.11
fig.12
fig.13
fig.14
2 / INSTALLING YOUR APPLIANCE EN
26

27
Tip
This guide to installation and use is valid for several models. Minor differences in
details and fittings may emerge between your appliance and the descriptions provided.
3 / USING YOUR APPLIANCE
EN
•DESCRIPTION OF CONTROLPANEL
Model DHD697 (fig. 15)
A) Turns the LIGHTS off.
B) Turns the LIGHTS on.
C) reduces the motor speed until reaching
minimum. If pressed for about 2", it stops the
motor and storse the speed.
D) drives the motor (calling the last speed used)
and increases the speed until reaching maximum.
L Display:
- signals the running speed.
- signals the filter alarm (with motor off) by displaying the central segment for 30".
- signals Timer activation with a flashing number.
E) activates the TIMER (when the motor is running), so that the hood stops automatically after 5'. Also
Zero-sets hour metering when the Filter Alarm is active (motor OFF).
FILTER ALARM
Displayed for 30" when the motor is off:
After 30h of operation, the central segment lights up on the display; It indicates that the grease filters
need to be cleaned.
After 120h of operation, the central segment flashes on the display; It indicates that the grease filters
need to be cleaned and the charcoal filters replaced.
Aftercleaningthegreasefilters(and/orreplacingthecharcoalfilters),restartthehourcounter(RESET)
by pressing the key E during display of the filter
alarm.
Models DHD497 / DHD790 (fig. 16)
A) Turns the LIGHTS off.
B) Turns the LIGHTS on.
C) Decreases speed down to minimum speed. If
pressed for 2" the motor is turned off.
D) Activates the motor (calling the last speed
used) and increases the speed until reaching
maximum..
E) FILTER ALARM/TIMER RESET: when pressing the key during display of the filter alarm (motor off)
it resets the hour counter. When pressing the key when the motor is running, the TIMER is activated
and the hood will automatically be switched off after 5 minutes.
L1) The 4 green LEDs indicate the running speed.
L2) When the LED is red (motor off) it indicates the FILTER ALARM. When the LED is green (flashing)
it indicates that the TIMER has been activated with the key E.
FILTER ALARM
After 30h of operation, the LED L2 turns RED. It indicates that the grease filters need to be cleaned.
After 120h of operation, the LED L2 turns RED and flashes; It indicates that the grease filters need to
be cleaned and the charcoal filters replaced.
After cleaning the grease filters (and/or replacing the charcoal filters), restart the hour counter (RESET)
by pressing the key E during display of the filter alarm.
fig.15
fig.16

28
Warning
Always unplug the hood before cleaning it or performing other maintenance acts.
Regular maintenance of your appliance is a guarantee of proper functioning, good perfor-
mance and durability.
Warning
Failure to respect the guidelines for cleaning the appliance and filters may cause fires.
Please carefully adhere to the maintenance recommendations.
4 / CARING FOR AND CLEANING YOUR APPLIANCE EN
• CLEANING THE GREASE FILTER
Pay special attention to the grease filter, that
must be cleaned at regular intervals.
Filter cleaning frequency:
Model DHD697
The grease filter must be cleaned about every
30 hours of operation (when, with the motor off,
the central segment on the display lights up).
Once the clean filter has been refitted, press the
button E (while the central segment is lit up) and
restart the hour counter.
Models DHD497 / DHD790
The grease filter must be cleaned about every
30 hours of operation (when, with the motor off,
the LED L2 turns red). Once the clean filter has
been refitted, press the button E (while the LED
L2 is red) and restart the hour counter.
Wash the filters with a commercial household
cleanser, then rinse fully and dry. They may be
cleaned in a dishwasher making sure that the
filter does not come into contact with dirty
dishes or silver tableware.
• Removing the grease filter (fig. 17 / 18)
Pull the catch and move the metal grille upwards
(Fig.17); Remove the grease filter by pushing it
downwards and turning it outwards (Fig.18).
•CHANGINGTHECHARCOAL FILTER
If the hood is used in the filtering version, the
charcoalfilterwillperiodicallyhave to be replaced.
Frequency of filter replacement:
Model DHD697
The charcoal filter must be replaced about every
120 hours of operation (when, with the motor
off, the central segment on the display lights up
fig.17
fig.18

29
4 / CARING FOR AND CLEANING YOUR APPLIANCE
EN
or flashes). Once the clean filter has been
refitted, press the button E (while the central
segment is lit up or flashing) and restart the hour
counter.
Models DHD497 / DHD790
The charcoal filter must be replaced about every
120 hours of operation (when, with the motor
off, the LED L2 turns red or flashes red). Once
the clean filter has been refitted, press the button
E (while the LED L2 is red or flashing) and restart
the hour counter.
• Replacing the charcoal filter (Fig. 19)
Remove the metal grille (Fig.17) and the grease
filter (Fig.18).
Remove the charcoal filter by pressing the catch
inwards and turn the charcoal filter until the two
tabs come out of their seats (Fig.19).
Charcoal filter ref. no.
AH4063U1
• CLEANING AND CARING OF THE
CASING
Avoid products containing abrasives when
cleaning the casing.
•CHANGING THE LIGHT BULB
Warning
Before carrying out any work, the
power supply to the hood must be turned
off, either by unplugging it or by using the
circuit breaker switch.
To reach the lamps you remove the metallic
support tightening the two screws (Fig. 20) and
moving it oo the right;
toreplacethehalogenlampstighten thelocknutin
the anti-clockwise direction and pull out the bulb
(Fig.21). Replace the lamps of the same type.
fig.19
fig.20
fig.21

30
Warning
Before carrying out any work, the power supply to the hood must be turned off, either
by unplugging it or by using the circuit breaker switch.
•MAINTAINING YOUR APPLIANCE
Top surface and
accessoires
Grease filter
Charcoal filter
MAINTENANCE... WHAT TO DO ? PRODUCTS/ACCESSORIES
TO USE
Never use metal scouring
pads, abrasive products or
excessively stiff brushes.
To clean the body and the lighting
port, you should use only
commercial household cleaning
products diluted in water and
then rinse using clean water,
drying with a soft cloth.
This filter traps fatty vapours and
dust. This component plays an
important role in ensuring the
effectiveness of your hood. In the
event of tough stains, use a non-
abrasive cream, then rinse with
clean water.
Use a commercial household
cleaning product then rinse
abundantly and dry. These filters
can be cleaned in a vertical
position in your dishwasher. (Do
not alow them touch dirty
dishes or silverware).
This filter traps odours and must
be changed at least once every
6 months depending on your level
of use. You should order these
filters from your dealer (quoting
the reference shown on the
identification plate located inside
the hood) and note the date the
filter was changed.
To keep your appliance in good working order, we recommend that you use Clearit household products.
Professional expertise for
the general public
Clearit offers you professional products and adapted solutions for the daily upkeep of your household
and kitchen appliances.
You may find them in conventional retail outlets, along with a complete line of by-products and
consumables.
4 / CARING FOR AND CLEANING YOUR APPLIANCE EN

31
The hood is not
working...
The hood is not
operating effectively...
The hood stopped
working
SYMPTOMS SOLUTIONS
Ensure that:
• The power is not cut off.
• A speed has been selected.
Ensure that:
• The selected motor speed is sufficient for the
quantity of smoke and vapours to be cleared.
• The kitchen is sufficiently ventilated to allow une
for fresh air intake.
• The charcoal filter is not worn (hood operating in
filtering mode).
Ensure that:
• The power is not cut off.
• The single-pole cut-off device was not activated.
5 / TROUBLESHOOTING
EN
6 / AFTER SALES SERVICE
EN
Any maintenance on your equipment should be undertaken by:
- either your dealer,
- or another qualified mechanic who is an authorized agent for the brand appliances.
When making an appointment, state the full reference of your equipment (model, type and
serial number). This information appears on the manufacturer’s nameplate attached to your
equipment.

04307818
