Deditec RO-INTERFACE-ETH Guide

Hardware-Description
Oktober
RO-INTERFACE-ETH
2010

INDEX
Index | 2Seite
1. Introduction 5
1.1. General remarks 5
1.2. Customer satisfaction 5
1.3. Customer response 5
2. Hardware description 7
2.1. Overview screen 7
2.2. Technical data 8
2.3. Plug-in connector of the module 9
9
2.3.1. Power supply
9
2.3.2. Ethernet interface
2.4. Buttons of the module 10
2.5. Controll LEDs 11
11
2.5.1. Definition of LEDs
3. Configuring the module 13
3.1. Configuration via DELIB Configuration utility 13
3.2. Configuration via internal web server 17
3.3. Factory settings 18
4. Firmware Update 20
4.1. DEDITEC Flasher 20
4.2. Web interface 21
5. Restore basic configuration 24
5.1. Restore IP address 24

INDEX
Index | 3Seite
5.2. Restore firmware 24
6. Software 26
6.1. Using our products 26
26
6.1.1. Access via graphical applications
26
6.1.2. Access via the DELIB driver library
26
6.1.3. Access via protocol
27
6.1.4. Access via provided test programs
6.2. DELIB driver library 28
28
6.2.1. Overview
30
6.2.2. Supported operating systems
30
6.2.3. Supported programming languages
31
6.2.4. Installation DELIB driver library
33
6.2.5. DELIB Configuration Utility
6.3. Test programs 34
34
6.3.1. Digital Input-Output Demo
35
6.3.2. Analog Input-Output Demo
36
6.3.3. Stepper Demo
7. Appendix 38
7.1. Revisions 38
7.2. Copyrights and trademarks 39

I
Introduction | Seite 4
Introduction

Introduction | Seite 5
1. Introduction
1.1. General remarks
First of all, we would like to congratulate you to the purchase of a high quality
DEDITEC product.
Our products are being developed by our engineers according to quality
requirements of high standard. Already during design and development we take
care that our products have -besides quality- a long availability and an optimal
flexibility.
Modular design
The modular design of our products reduces the time and the cost of
development. Therefor we can offer you high quality products at a competitive
price.
Availability
Because of the modular design of our products, we have to redesign only a
module instead of the whole product, in case a specific component is no longer
available.
1.2. Customer satisfaction
Our philosophy: a content customer will come again. Therefor customer
satisfaction is in first place for us.
If by any chance, you are not content with the performance of our product,
please contact us by phone or mail immediately.
We take care of the problem.
1.3. Customer response
Our best products are co-developments together with our customers. Therefor
we are thankful for comments and suggestions.

II
Hardware description | Seite 6
Hardware description

Hardware description | Seite 7
2. Hardware description
2.1. Overview screen
The figure shows the control module with ethernet interface (left side) combined
with an input/output module (right side).
The figure shows the control module with ethernet interface (left side) combined
with a flexible connector input/output module (right side).

Hardware description | Seite 8
2.2. Technical data
Single power supply +7V..+24V DC
10/100 Mbit/sec Ethernet interface
Input/output access over TCP/IP
WEB interface
Configuration over web interface
9 Control LEDs
RJ45 Socket
Timeout feature providing ability to disconnect outputs for safety reasons
Expandable in 16 gradations
Can be combined without any problem to other modules of the RO series
Windows driver library DELIB

Hardware description | Seite 9
2.3. Plug-in connector of the module
2.3.1. Power supply
The input-power-supply-range lies between +7V and +24V DC.The power
supply can be realized with a standard AC/DC adaptor with 1A output current. A
suitable plug-in connector is delivered.
2.3.2. Ethernet interface
The network connection is provided by a RJ45 socket.
LED
Description
1
Activity
2
10/100 Mbit

Hardware description | Seite 10
2.4. Buttons of the module
Left Button:
Reset IP address to default
(see chapter 5.1)
Right Button:
Reset firmware to factory settings.
(see chapter 5.2)

Hardware description | Seite 11
2.5. Controll LEDs
The Ethernet module has a series of control LEDs. They are used for easy visual
indication of various state functions.
While switching the module on, in normal operating mode, the module should
signalize the following sequence:
approx. 20 sec after switching the module on, LED 1 and 2 are flashing briefly.
-> Operating system has been loaded successfully.
Then LED 3 is on permanently and LED 1 is flashing. -> Module is ready.
2.5.1. Definition of LEDs
LED
Label
Description
above
3,3V
Internal 3,3V power supply
above
5V
Internal 5V power supply
1
CPU Activity
2x flashing + long break. Operating system reports:
Status OK
2
Interface
Activity
Active communication over Ethernet
3
Status
LED is on -> Module is ready
4
ERROR
Error during ethernet-transfer (for details see document
”Serial protocol”)
5
Inputs:
Change
"State change" between 2 read-out cycles detected
6
Outputs: Auto-
Off
Due to timeout, all outputs are switched-off for safety
reasons
7
I/O Access
CPU-access to the connected I/O modules.

III
Configuring the module | Seite 12
Configuring the module

Configuring the module | Seite 13
3. Configuring the module
3.1. Configuration via DELIB Configuration utility
This method allows a simple configuration of the product. Following basic
values can be changed.
Module name
IP address
Net mask
Default gateway
DNS server
Additionally with this tool all DEDITEC ethernet devices in the LAN network are
displayed.
The following pages describe how it works...

Configuring the module | Seite 14
Start DELIB Configuration utility as follows:
Start -> Programs -> DEDITEC -> DELIB -> DELIB Configuration Utility
1. Module Selection: select RO-ETH
2. Find and configure RO-ETH Module

Configuring the module | Seite 15
1. Scan RO-ETH modules: So you can find all DEDITEC ETH modules on local
ethernet stream. Therefore we use an ethernet protocol which will not be
routed. Because of that you can configure only modules which are connected
to the bus. The advantage of this method is, that you can find modules which
are not in the same sub net, of which you are configuring.
2. Click on the module, which you want to configure.

Configuring the module | Seite 16
Here you can change the module name according to your wishes
1. You can change module name, IP address, net mask, default gateway and
DNS server.
2. Write new Values to Module.
Notice:
At the configuration of the RO-ETH module should be paid attention to the IP
address. It has to be in the same IP segment in which the control PC is. Of
course you must not select an already used IP address.
If the standard IP address of the module is not from the address range of the
network, the module will not be reachable by TCP/IP at the moment. Problems
of accessibility will also occur, if the IP address is already used. However the IP
address and the net mask of the ethernet module are configurable by this utility.
Alternatively you can connect the module to the PC and set the IP address and
the net mask directly. After the accessibility is given, the further configuration is
ensued by a browser via the integrated web server of the ethernet module.
To these belongs ask your system administrator.

Configuring the module | Seite 17
3.2. Configuration via internal web server
The RO-ETH module has an own web server by which it can be configured, too.

Configuring the module | Seite 18
3.3. Factory settings
The factory settings of the ethernet module include following settings:
IP address: 192.168.1.1
The factory settings can be restored by pushing the left button -> see chapter
5.2
IP address 192.168.1.1
Subnet mask 255.255.255.0
Standard gateway 192.168.1.254

IV
Firmware Update | Seite 19
Firmware Update

Firmware Update | Seite 20
4. Firmware Update
4.1. DEDITEC Flasher
Approach:
Download the latest firmware inclusive software update. http://www.deditec.
de/en/module/software/delib/download.html
Extract all data to one folder
Start the application deditec-flasher.exe
1. Select the interface. For ethernet press the key "E"
2. Select the module which you want to update. Press the key "M" for CPU
interface
3. After successfully flashing , in the prompt appears: Flash OK!
