DEEP SEA ELECTRONICS DSEM840 User manual

057-248 ISSUE: 1
DEEP SEA ELECTRONICS PLC
DSEM840 Operator Manual
Document Number: 057-248
Author: Anthony Manton

DSEM840 Operator Manual
057-248 ISSUE: 1 Page 2 of 50
Deep Sea Electronics Plc
Highfield House
Hunmanby
North Yorkshire
YO14 0PH
ENGLAND
Sales Tel: [phone]
Sales Fax: [phone]
E-mail: [e-mail]
Website: www.deepseaplc.com
DSEM840 Operator Manual
© Deep Sea Electronics Plc
All rights reserved. No part of this publication may be reproduced in any material form (including
photocopying or storing in any medium by electronic means or other) without the written permission of
the copyright holder except in accordance with the provisions of the Copyright, Designs and Patents
Act 1988.
Applications for the copyright holder’s written permission to reproduce any part of this publication
must be addressed to Deep Sea Electronics Plc at the address above.
The DSE logo and the name DSEControl
®
are UK registered trademarks of Deep Sea Electronics
PLC.
Any reference to trademarked product names used within this publication is owned by their respective
companies.
Deep Sea Electronics Plc reserves the right to change the contents of this document without prior
notice.
Revision History
Issue No.
Comments
1
Initial release of document

DSEM840 Operator Manual
Page 3 of 50 057-246 ISSUE: 1
TABLE OF CONTENTS
Section Page
1 INTRODUCTION..................................................................................................5
1.1 CLARIFICATION OF NOTATION............................................................................................6
1.2 GLOSSARY OF TERMS..........................................................................................................6
1.3 RELATED INFORMATION ......................................................................................................7
1.3.1 TECHNICAL INFORMATION............................................................................................7
1.4 SAFETY INSTRUCTIONS .......................................................................................................8
1.4.1 GENERAL .........................................................................................................................8
1.4.2 INSTALLATION NOTES ...................................................................................................8
2 SPECIFICATIONS...............................................................................................9
2.1 PROCESSOR...........................................................................................................................9
2.2 MEMORY..................................................................................................................................9
2.3 DC SUPPLY .............................................................................................................................9
2.3.1 FUSING.............................................................................................................................9
2.3.2 IGNITION (Pin A13) ..........................................................................................................9
2.4 ENVIRONMENTAL ................................................................................................................10
2.5 USER INTERFACE................................................................................................................10
2.5.1 CONTROLS.....................................................................................................................10
2.5.2 DISPLAY .........................................................................................................................10
2.5.3 LED..................................................................................................................................10
2.6 REAL TIME CLOCK...............................................................................................................10
2.7 INPUTS...................................................................................................................................11
2.7.1 DIGITAL INPUTS ............................................................................................................11
2.7.1.1 DIGITAL ...................................................................................................................11
2.7.1.2 FREQUENCY...........................................................................................................11
2.7.2 ANALOGUE INPUTS ......................................................................................................11
2.7.2.1 VOLTAGE ................................................................................................................11
2.7.2.2 CURRENT................................................................................................................12
2.7.2.3 RESISTIVE...............................................................................................................12
2.7.2.4 RATIOMETRIC ........................................................................................................12
2.8 OUTPUTS...............................................................................................................................13
2.8.1 NEGATIVE SWITCHING.................................................................................................13
2.8.2 POSITIVE SWITCHING ..................................................................................................13
2.9 COMMUNICATIONS..............................................................................................................14
2.9.1 CAN.................................................................................................................................14
2.9.2 ETHERNET.....................................................................................................................14
2.9.3 USB .................................................................................................................................14
2.10 CAMERA INPUTS..............................................................................................................15
3 INSTALLATION.................................................................................................16
3.1 DIMENSIONS AND MOUNTING ...........................................................................................16
3.1.1 DIMENSIONS..................................................................................................................16
3.1.2 FASCIA MOUNTING.......................................................................................................17
3.1.3 RAM MOUNTING............................................................................................................18
3.2 FUSING ..................................................................................................................................19
3.3 TYPICAL CONNECTION DIAGRAM.....................................................................................19
3.4 USER CONNECTIONS..........................................................................................................20
3.4.1 CONNECTOR A..............................................................................................................21
4 OPERATION......................................................................................................22
4.1 SYSTEM PAGES ...................................................................................................................22
4.1.1 NAVIGATION ..................................................................................................................22
4.1.1.1 PAGE SELECTION..................................................................................................22
4.1.1.2 OPTION SELECTION AND EDITING......................................................................22
4.1.2 DEVICE SETTINGS........................................................................................................23
4.1.2.1 NETWORK...............................................................................................................23
4.1.2.2 CAN..........................................................................................................................24

DSEM840 Operator Manual
057-248 ISSUE: 1 Page 4 of 50
4.1.2.3
BACKLIGHT.............................................................................................................24
4.1.2.4 REAL TIME CLOCK.................................................................................................24
4.1.3 DEVICE ACTIONS..........................................................................................................25
4.1.3.1 INSTALL SPLASH SCREEN ...................................................................................25
4.1.3.2 CLONE / RECOVER SELECTION ..........................................................................26
4.1.3.3 FORMAT MEMORY / DATA....................................................................................27
4.1.3.4 KEYTEST.................................................................................................................27
4.1.3.5 HISTORY .................................................................................................................28
4.1.4 DEVICE INFORMATION.................................................................................................28
4.2 FIRMWARE UPDATE AND FILE SYSTEM OPERATIONS..................................................29
5 CONNECTING TO CODESYS...........................................................................30
5.1 START NEW PROJECT ........................................................................................................30
5.2 ETHERNET TCP....................................................................................................................31
5.3 ETHERNET UDP....................................................................................................................32
5.4 CONFIGURE SETTINGS AND MONITOR THE DEVICE .....................................................34
5.4.1 DEVICE SETTINGS PARAMETERS..............................................................................35
5.4.2 DEVICE SETTINGS I/O MAPPING.................................................................................36
5.5 ADD INPUTS, OUTPUTS AND BUTTONS TO THE PROJECT...........................................37
5.5.1 BUTTONS .......................................................................................................................38
5.5.1.1 BUTTON LOCATION...............................................................................................38
5.5.1.2 BUTTON SETTINGS ...............................................................................................39
5.5.2 INPUTS AND OUTPUTS ................................................................................................40
5.5.3 DIGITAL INPUT PARAMETER CONFIGURATION........................................................41
5.6 USING THE DISPLAY IN THE PROJECT ............................................................................42
5.6.1 USING CUSTOM IMAGES ON THE DISPLAY ..............................................................43
5.6.1.1 ADDING AN IMAGE POOL......................................................................................43
5.6.1.2 ADDING IMAGES TO THE IMAGE POOL ..............................................................43
5.6.1.3 USING THE IMAGE POOL ON THE DISPLAY.......................................................44
6 DSEM840 CODESYS ERROR CODES.............................................................45
6.1 DEVICE ..................................................................................................................................45
6.2 ANALOGUE INPUTS.............................................................................................................45
6.3 DIGITAL INPUTS...................................................................................................................46
6.4 DIGITAL OUTPUTS...............................................................................................................46
7 CABLES, CONNECTORS, HARNESSES AND SPARE PARTS......................47
7.1 DSEM840 CONNECTOR HARNESS KIT (016-168).............................................................47
8 MAINTENANCE AND WARRANTY..................................................................48
9 DISPOSAL.........................................................................................................48
9.1 WEEE (WASTE ELECTRICAL AND ELECTRONIC EQUIPMENT).....................................48

Introduction
Page 5 of 50 057-246 ISSUE: 1
1 INTRODUCTION
This document details the operation and setup requirements of the DSEM840 Mobile Controller and
Display, part of the DSEControl
®
range of products.
The manual forms part of the product and should be kept for the entire life of the product. If the
product is passed or supplied to another party, ensure that this document is passed to them for
reference purposes.
This is not a controlled document. DSE do not automatically inform on updates. Any future updates of
this document are included on the DSE website at www.deepseaplc.com
Observe the operating instructions. Non-observance of the instructions, operation not in accordance
with use as prescribed below, wrong installation or incorrect handling seriously affects the safety of
operators and machinery.
A robust metal case designed for chassis mounting houses the module. Connections are via locking
plug and sockets.
The controller is supplied with no application program. The equipment manufacturer is responsible for
creating and managing the application program and installing it in the controller. This is achieved
using CODESYS V3.5 or C programming. Contact DSE Technical Support for further details.

Introduction
057-248 ISSUE: 1 Page 6 of 50
1.1 CLARIFICATION OF NOTATION
Clarification of notation used within this publication.
NOTE:
Highlights an essential element of a procedure to ensure correctness.
CAUTION!
Indicates a procedure or practice, which, if not strictly observed, could
result in damage or destruction of equipment.
WARNING!
Indicates a procedure or practice, which could result in injury to
personnel or loss of life if not followed correctly.
1.2 GLOSSARY OF TERMS
Term
Description
Application The application is the program that allows the DSEM840 to control the
machine it is connected to.
The Application within the DSEM840 is designed and provided by the
manufacturer of the complete machine.
Bootloader The Bootloader is the program within the DSEM840 responsible for loading
the Operating System.
CAN Control Area Network. A high-speed data transmission system used
extensively within the Automotive and Off-Highway industries.
CODESYS
(Previously stylised
as CoDeSys)
Integrated Development Environment for programming controller
applications according to the international industrial standard IEC 61131-3.
DSEM840 supports CODESYS V3.5
ECU Electronic Control Unit. For example the DSEM840 device.
Firmware The Firmware of the DSEM840 is the Operating System of the DSEM840
that reads and executes the Application program.
FSD Full Scale Deflection. For example 0 mA to 20 mA is the Full Scale
Deflection of a current sink input.
I/O Input / Output. For example “The I/O is taken out to an external terminal
strip in the user panel”.
IDE Integrated Development Environment. For example the CODESYS V3.5
application that runs on the host PC is an IDE.
Ixyyy An Input, where x is the connector and yyy is the input number. For
example IA003 means Input 3 on Connector A.
PLC Programmable Logic Controller. Industrial computer used primarily for the
automation of electromechanical machinery.
PWM
PWMi A digital signal is used to represent an analogue value by using Pulse Width Modulation. The mark-space ratio of a square wave changes to
represent the value.
Used for many control applications including proportional valves.
PWM= Voltage control.
PWMi = Current control.
Off-Highway An industrial vehicle used primarily “off road”. For example construction
and farm machinery. A wider interpretation includes on road access
platforms, emergency vehicles and other industrial machinery, used either
on the road, or off road.
Pin A male or female pin connection in a housing (plug or socket).
Qxyyy An Output, where x is the connector and yyy is the output number. For
example QA002 means Output 2 on Connector C.

Introduction
Page 7 of 50 057-246 ISSUE: 1
1.3 RELATED INFORMATION
This document refers to, and is referred by the following DSE publications which are obtained from
the DSE website: www.deepseaplc.com or by contacting DSE technical support:
[e-mail].
1.3.1 TECHNICAL INFORMATION
DSE Part
Description
055-198 DSEM640 Datasheet
055-222 DSEM840 Datasheet
053-188 DSEM840 Installation Instructions
057-244 DSEM640 Operator Manual

Introduction
057-248 ISSUE: 1 Page 8 of 50
1.4 SAFETY INSTRUCTIONS
1.4.1 GENERAL
•These instructions are for authorised persons according to the EMC and low-voltage directives.
The device must be installed, connected and put into operation by a qualified electrician.
•It is not permissible to open the controller or to modify or repair the controller. Modification or
repairs to the wiring could result in dangerous malfunctions. Repairs to the controller must be
performed by DSE. Contact your original equipment supplier in the case of malfunction.
•When the device is unpowered, ensure that no connection pins are connected to a voltage
source. Thus, when the supply is switched off, the supply for the electronics, the power outputs
and the external sensor supply must be switched off together.
•The customer is responsible for performing risk analysis of the mobile working machine and
determining the possible safety related functions. The user is responsible for the safe function of
the application programs created. If necessary, they must additionally carry out an approval test
by corresponding supervisory and test organisations according to the national regulations.
•All connectors must be unplugged from the electronics during electrical welding and painting
operations.
1.4.2 INSTALLATION NOTES
•Follow the instructions of the connector manufacturer, specifically with respect to preventing
water from entering the device. See Section entitled Cables, Connectors, Harnesses and Spare
Parts for details of DSE Part Numbers.
•M12 protection plugs (supplied) must be installed in both the USB and Ethernet interfaces to
ensure IP67 rating when the connectors are not in use. Where IP protection is required when the
interfaces are in use, suitable O-rings must be fitted.

Specifications
Page 9 of 50 057-246 ISSUE: 1
2 SPECIFICATIONS
2.1 PROCESSOR
Description
Spec
ification
NXP LPC4357 dual core M4 & M0
Speed 200 MHz
2.2 MEMORY
Description
Specification
Flash 32 Mb
RAM 16 Mb
2.3 DC SUPPLY
Description
Specification
Operating Voltage (Pin A7) 6 V to 36 V
Maximum Current (Full Backlight, no External Loads) <1000 mA at 24 V
Maximum Current (Full Backlight & Heater, no External Loads) <1500 mA at 24 V
Maximum Current (After Controlled Shutdown With Ignition off) <0.1 mA at 24 V
2.3.1 FUSING
Description
Specification
DC Supply (Pin A7)
Supplies DSEM840 and High Current Outputs
Fuse as Required by Output Loads (Pins A2, A3, A4, A5)
3 A Min (to supply DSEM840)
10 A Max.
Ignition (15) (Pin A13) 1 A Max
2.3.2 IGNITION (Pin A13)
NOTE: Ignition (Pin A13) must be utilised correctly to enable / disable the application
program. This ensures that logs and other changed parameters are stored when the Ignition is
switched off.
Pin A7 is used to give a constant DC supply to the DSEM840, with the Ignition pin being used to
energise and de-energise the ECU. Typically, this pin is controlled by an external ignition switch.
To stop the application, de-energise the Ignition pin. This allows the DSEM840 to store any changed
parameters and logs before closing down.

Specifications
057-248 ISSUE: 1 Page 10 of 50
2.4 ENVIRONMENTAL
Description
Specification
Operating Temperature -30 ºC to +65 ºC
(-22 ºF to 149 ºF)
Storage Temperature -40 ºC to +80 ºC
(-40 ºF to 176 ºF)
Degrees of Protection Provided by Enclosure
(With All Mating Connectors Fitted) IP67 (NEMA 6)
2.5 USER INTERFACE
2.5.1 CONTROLS
Description
Specification
Push Buttons 14
2.5.2 DISPLAY
Description
Specification
Size (Across Diagonal) 109 mm
(4.3”)
Size (W x H) WQVGA (480 x 272)
Aspect Ratio 16:9
Type Optically Bonded TFT
Lifetime > 30,000 hours
Colour 24 bit
Splash Screen Image Type Uncompressed Bitmap Image (BMP)
24 bit Colour
480 x 272
2.5.3 LED
Description
Specification
LED Type Tricolour (Red, Blue, Green)
2.6 REAL TIME CLOCK
Description
Specification
Retention Type Standard RTC.
Retention Time (Approx.) 5 years

Specifications
Page 11 of 50 057-246 ISSUE: 1
2.7 INPUTS
2.7.1 DIGITAL INPUTS
2.7.1.1 DIGITAL
Descripti
on
Specification
Applicable Pins Pins A10, A11, A16, A17
Minimum Voltage For High Level Configurable
Maximum Voltage For Low Level Configurable
2.7.1.2 FREQUENCY
Description
Specification
Applicable Pins Pins A10, A11, A16, A17
Frequency Range 5 Hz to 30 kHz
Resolution 100 Hz at Maximum Frequency
Accuracy 400 Hz at Maximum Frequency
Minimum Voltage For High Level (Mark) >4 V
Maximum Voltage For Low Level (Space) <0.5 V
2.7.2 ANALOGUE INPUTS
Description
Specification
Applicable Pins Pins A10, A11, A16, A17
Reference Voltage Pins A6
Reference Voltage Programmable 0 V / 5 V / 10 V
±500 mV
2.7.2.1 VOLTAGE
Description
Specification
Applicable Pins Pins A10, A11, A16, A17
Configurable Ranges 0 V to 5 V
0 V to 10 V
0 V to 32 V
Input Resistance >=7.5 kΩ
Sampling Rate 500 Hz
Voltage Measurement resolution and accuracy
Configured Range
Resolution (1
0
bits)
Accuracy (
±
1%) FSD
0 V to 5 V
0 V to 10 V
0 V to 32 V
0.007 V
0.017 V
0.035 V
±0.05 V
±0.1 V
±0.32 V

Specifications
057-248 ISSUE: 1 Page 12 of 50
2.7.2.2 CURRENT
Description
Specification
Applicable Pins Pins A10, A11, A16, A17
Configurable Ranges 0 mA to 20 mA
4 mA to 20 mA
Input Type Current sink only
Input Sink Resistance 100 Ω± 1%
Sampling Rate 500 Hz
Resolution 10 bits
Accuracy (± 1 % Full Scale Deflection) 0.2 mA
2.7.2.3 RESISTIVE
Description
Specification
Applicable Pins Pins A10, A11, A16, A17
Measurement Range 0 Ωto 3400 Ω
Measurement Source Voltage 12 V maximum
Measurement Source Current 1 mA
Sampling Rate 500 Hz
Resolution 10 bits
Accuracy (± 1 % Full Scale Deflection) 34 Ω
2.7.2.4 RATIOMETRIC
Description
Specification
Applicable Pins Pins A10, A11, A16, A17
Measurement Voltage Reference Supply / Vref
Measurement Type Ratio of input Pin to Reference
Accuracy (± 1 % Full Scale Deflection) 0.36 V (based upon maximum
supply voltage of 36 V)

Specifications
Page 13 of 50 057-246 ISSUE: 1
2.8 OUTPUTS
2.8.1 NEGATIVE SWITCHING
Description
Specification
Applicable Pins Pins A2, A3, A4, A5
Maximum Current 1 A selectable
Digital Output Active Low ‘ON’ State Maximum Voltage at
Rated Current < 100 mV
Digital Output Active Low ‘OFF’ State Leakage Current <5 μA at 24 V output supply
2.8.2 POSITIVE SWITCHING
Description
Specification
Applicable Pins Pins A2, A3, A4, A5
Maximum Current 1 A selectable
Digital Output Active Low ‘ON’ State Maximum Voltage at
Rated Current <100 mV
Digital Output Active Low ‘OFF’ State Leakage Current <120 μA at 24 V output supply

Specifications
057-248 ISSUE: 1 Page 14 of 50
2.9 COMMUNICATIONS
2.9.1 CAN
NOTE: CAN connections are NOT internally terminated. A complete CAN network must
have 120 Ωterminators at each end of the network.
NOTE: Screened 120 Ω
ΩΩ
Ωimpedance cable specified for use with CAN must be used for the
CAN links.
DSE stock and supply Belden cable 9841 which is a high quality 120 Ω
ΩΩ
Ωimpedance cable
suitable for CAN use (DSE part number 016-030).
Description
Specification
Number of CAN Interfaces 2
Supported Protocols J1939
CAN open
Raw CAN
Supported Baud Rates 50 kbit/s, 100 kbit/s, 125 kbit/s, 250 kbit/s, 500 kbit/s, 800
kbit/s, 1 Mbit/s
2.9.2 ETHERNET
Description
Specification
Number Of Ethernet Ports 1
Supported Data Rates 10 Mbit/s / 100 Mbit/s, Duplex
Supported Protocols MODBUS TCP
CODESYS 3.5
M12 ‘D’ Coded
–
4 Pin
F
emale
Pin
Description
1 Tx+
2 Rc+
3 Tx-
4 Rc-
2.9.3 USB
Description
Specification
Number of USB Ports 1
USB Version 2
Supported Speeds Full Speed (12 Mbit/s)
Device Class 08 (Mass Storage)
Max Size 64 GB
Filing System VFAT or FAT32
M12 ‘B’ Coded
–
5 Pin
F
emale
Pin
Description
1 5 V
2 Data-
3 Data+
4 0 V
5 Shield

Specifications
Page 15 of 50 057-246 ISSUE: 1
2.10 CAMERA INPUTS
Description
Specification
Number of Camera Inputs 1
Connection Pins A12 (signal), A18 (gnd).
Interface Type Analogue (Composite) Video for PAL / NTSC

Installation
057-248 ISSUE: 1 Page 16 of 50
3 INSTALLATION
3.1 DIMENSIONS AND MOUNTING
3.1.1 DIMENSIONS
Description
Specification
Overall Dimensions (Height x Width x Depth) 208 mm x 131 mm x 56 mm
(8.18 ” x 5.14 ” x 2.19 ”)
Mounting Type 4 x mounting bolts or RAM mount.
Overall Weight <1 kg
(2.2 lb)

Installation
Page 17 of 50 057-246 ISSUE: 1
3.1.2 FASCIA MOUNTING
Description
Specification
Fascia Mounting Holes Suitable for M5 bolts
(0.3 “ holes)
Fascia Mounting Hole Centres 180 mm x 70 mm
(7.09 “ x 2.76 “)
See Diagram Below
Panel Cut-Out 163 mm x 98 mm
(6.42 “ x 3.86 “)
Fascia Mounting Bolt Material Recommendation Steel or Stainless Steel
Fascia Mounting Bolt Tightening Torque to prevent
distortion of the sealing gasket and subsequent seal
failure / mechanical damage to the controller.
1.2 Nm Maximum
(0.89 ft. lb Maximum)

Installation
057-248 ISSUE: 1 Page 18 of 50
3.1.3 RAM MOUNTING
DSE840 has four holes on the rear face, suitable for fitting of a RAM type mount.The spacing for the
mounting holes is detailed in the image below.
Description
Specification
RAM Mounting Holes Suitable for M5 bolts
(0.3 “ holes)
RAM Mounting Hole Centres 30 mm x 38 mm
(1.19 “ x 1.50 “)
RAM Mounting Bolt Material Recommendation Steel or Stainless Steel
RAM Mounting Bolt Tightening Torque 4 Nm Maximum
(2.95 ft. lb Maximum)

Installation
Page 19 of 50 057-246 ISSUE: 1
3.2 FUSING
The individual electric circuits must be protected in order to protect the whole system. Select
appropriate fuses to protect the outputs being supplied.
Pin
Description
Comments
Recommended
Fuse Size
A7 ECU Supply Supplies DSEM840 CPU and Outputs 3 A to 10 A Max
A13 Ignition (15) 1 A Max
3.3 TYPICAL CONNECTION DIAGRAM

Installation
057-248 ISSUE: 1 Page 20 of 50
3.4 USER CONNECTIONS
NOTE: If a prewired connection cable is used, remove the cores with unused signal inputs
and outputs. Unused cores, in particular core loops, lead to interference coupling that can
influence the connected controller.
NOTE: USB and Ethernet connectors are coded differently. Do not try to force a connector
into the wrong socket.
Connector A
USB
Ethernet
