Defy DCH609 User manual

DCH609
COOKERHOOD
Cooking
Instruction manual

Please read this user manual first!
Dear Valued Customer,
Thank you for preferring this Defy appliance. We hope that you get the best results from your
appliance which has been manufactured with high quality and state-of-the-art technology.
For this reason, please read this entire user manual and all other accompanying documents
carefully before using the appliance and keep it as a reference for future use. If you handover
the appliance to someone else, give the user manual as well. Follow the instructions by pay-
ing attention to all the information and warnings in the user manual.
Remember that this user manual may also apply to other models. Differences between mod-
els are explicitly described in the manual.
Meanings of the Symbols
Following symbols are used in various sections of this user manual:
CImportant information and useful hints
about usage.
AWARNING: Warnings against danger-
ous situations concerning the security
of life and property.
Warning for danger of fire.
BWarning for electric shock.
Complies with the WEEE regulation. It does not contain PCB.
This appliance has been manufactured in environmentally friendly modern plants without giving any
harm to the nature.

Cooker Hood / User Manual 3 / EN
CONTENTS
1 Important Safety and Environmental
Instructions 4-6
1.1 General Safety . . . . . . . . . . . . . . . . . . . . 4
1.2 Compliance with the WEEE Directive
and Disposing of the Waste Product. . . . . . . . 6
1.3 Compliance with RoHS Directive . . . . . . . 6
1.4 Package Information . . . . . . . . . . . . . . . . 6
2 General Appearance 7
2.1 Overview . . . . . . . . . . . . . . . . . . . . . . . . 7
2.2 Technical Data . . . . . . . . . . . . . . . . . . . . 7
3 Using the Appliance 8-9
3.1 Use of the Rocker Switch. . . . . . . . . . . . . 8
3.2 Things to Do for Energy Saving . . . . . . . . 8
3.3 Operating the Hood. . . . . . . . . . . . . . . . . 8
3.4 Lamp Replacement. . . . . . . . . . . . . . . . . 9
3.5 Operation with Flue Connection . . . . . . . . 9
3.6 Operation without Flue Connection . . . . . 9
4Cleaning and Maintenance 10
4.1 Cleaning of Grease Filter . . . . . . . . . . . . 10
4.2 Changing of Carbon Filter . . . . . . . . . . . 10
5 Installation Of Appliance 11-12
5.1 Position of the Appliance . . . . . . . . . . . . 11
5.2 Installation Accessories . . . . . . . . . . . . . 11
5.3 Installation of the Hood . . . . . . . . . . . . . 11
5.4 Connecting to Flue . . . . . . . . . . . . . . . . 12
6 Troubleshooting 13
01M-9201523600-0621-01

4 / EN Cooker Hood / User Manual
1.1 General Safety
Important Safety Instructions Read Care-
fully And Keep For Future Reference This
section contains safety instructions that
will help protect from risk of fire, electric
shock, exposure to leak microwave en-
ergy, personal injury or property damage.
Failure to follow these instructions shall
void any warranty.
•Defy products comply with the appli-
cable safety standards; therefore, in
case of any damage on the appliance
or power cable, it should be repaired or
replaced by the dealer, service center or
a specialist and authorized service alike
to avoid any danger. Faulty or unquali-
fied repair work may be dangerous and
cause risk to the user.
•This appliance is intended to be used in
household and similar applications such
as:
– Staff kitchen areas in shops, offices
and other working environments;
– Farm houses
– By clients in hotels, and other residen-
tial type environments;
– Bed and Breakfast type environments.
•Operate the appliance for its intended
purpose only as described in this man-
ual.
•The manufacturer cannot be held liable
for damages resulting from improper in-
stallation or misuse of the product.
•This product is not intended for use
by persons (including children) with
reduced physical, sensory or mental
capabilities or lack of experience and
knowledge, unless they have been given
supervision or instruction concerning
the use of the product by a person re-
sponsible for their safety.
•Children must be supervised to prevent
them from tampering with the product.
•The minimum distance between the
supporting surface for the cooking ves-
sels on the hob and the lowest part of
your product must be at least 65 cm.
•If the instructions for installation for the
gas hob specify a greater distance, this
has to be taken into account.
•Make sure that your mains power supply
complies with the information supplied
on the rating plate of the appliance.
•Never use the appliance if the power
cable or the appliance itself is damaged.
•Prevent damage to the power cable by
not squeezing, bending, or rubbing it
on sharp edges. Keep the power cable
away from hot surfaces and naked
flame.
•Use the appliance with a grounded out-
let only.
WARNING: Do not connect the appli-
ance to the mains until the installation
is fully complete.
•Place the appliance in a way so that the
1 Important safety and environmental instructions

Cooker Hood / User Manual 5 / EN
plug is always accessible.
•Do not touch the lamps if they have op-
erated for a long time. They can burn
your hands since they will be hot.
•Follow the regulations set out by com-
petent authorities on discharge of the
exhaust air (this warning is not applica-
ble for use without flue).
•Operate your appliance after putting a
pot, pan etc. on the hob. Otherwise, high
heat may cause deformation in some
parts of your product.
•Turn off the hob before taking the pot,
pan etc. from it.
•Do not leave hot oil on the hob. Pans
with hot oil may cause self combustion.
•Pay attention to your curtains and cov-
ers since oil may catch fire while cook-
ing food such as fries.
•Grease filter must be replaced at least
monthly. Carbon filter must be replaced
at least every 3 months.
•Product shall be cleaned accordance
with user manual. If cleaning was not
carried out in accordance with user
manual, there may be fire risk.
•Do not use non-fire-resistant filtering
materials instead of the current filter.
•Only use the original parts or parts rec-
ommended by the manufacturer.
•Do not operate the product without the
filter and do not remove the filters while
the product is running.
•In the event of be started any flame,
de-energize your product and cooking
appliances.
•In the event of be started any flame,
cover the flame and never use water to
extinguish.
•Unplug the appliance before each clean-
ing and when the appliance is not in use.
•The negative pressure in the environ-
ment should not exceed 4 Pa (4 x 10
bar) while the hood for electric hob and
appliances running on another type of
energy but electricity operate simulta-
neously.
•In the environment where the appliance
is being used, the exhaust of devices
running on fuel oil or gas, such as room
heater must be absolutely isolated or
device must be hermetical type.
•When connecting the flue, use pipes
with a diameter of 120 or 150 mm. Pipe
connection must be as short as possi-
ble and have as few elbows as possible.
Danger of choking! Keep all the pack-
aging materials away from children.
CAUTION: Accessible parts may be-
come hot when used with cooking ap-
pliances.
•The product outlet must not be con-
nected to air channels that include other
smoke.
•The ventilation in the room may be in-
sufficient when the hood for electric hob
1 Important safety and environmental instructions

6 / EN Cooker Hood / User Manual
is used simultaneously with the devices
operating on gas or other fuels (this
may not apply to appliances that only
discharge the air back into the room).
•Objects placed on the product may fall.
Do not place any objects on the product.
•Do not flambe under the your product.
WARNING: Before installing the Hood,
remove the protective films.
•Never leave high naked flames under
the hood when it is in operation
•Deep fat fryers must be continuously
monitored during use: overheated oil
can burst into flames.
1.2 Compliance with the WEEE Di-
rective and Disposing of the Waste
Product:
This product complies with EU WEEE Di-
rective (2012/19/EU). This product bears
a classification symbol for waste electrical
and electronic equipment (WEEE).
This symbol indicates that this
product shall not be disposed
with other household wastes at
the end of its service life. Used
device must be returned to offical collec-
tion point for recycling of electrical and
electronic devices. To find these collection
systems please contact to your local au-
thorities or retailer where the product was
puchased. Each household performs im-
portant role
in recovering and recycling of old appli-
ance. Appropriate disposal of used ap-
pliance helps prevent potential negative
consequences for the environment and
human health.
1.3 Compliance with RoHS Directive
The product you have purchased complies
with EU RoHS Directive (2011/65/EU). It
does not contain harmful and prohibited
materials specified in the Directive.
1.4 Package Information
Packaging materials of the prod-
uct are manufactured from recy-
clable materials in accordance
withour NationalEnvironment Regulations.
Do not dispose of the packaging materials
together with the domestic or other
wastes. Take them to the packaging ma-
terial collection points designated by the
local authorities.
1 Important safety and environmental instructions

Cooker Hood / User Manual 7 / EN
2 General Apperance
2.1 Overview
2.2 Technical Data
1. Front Panel
2. Switch
3. Aluminum Grease Filter
4. LED Lighting
(Figure 1).
Model DCH609
Supply voltage 220-240V ~ 50 Hz
Lamp Power (W) 2 x 3
Motor Power (W) 125
Flow rate (m³/h) – 3. Level 253
Insulation Class of Motor Class F
Insulation Class Class I
(Figure 2)

8 / EN Cooker Hood / User Manual
3 Operation of the Appliance
3.1 Controlling the Appliance
KEY FUNCTION
(A) : Light On / Off Pull the sliding plate to the front. Press the button down-
wards to turn on the lamp or upwards to turn off the lamp.
(B) : 1 and 2 Speed
Button
Pull the sliding plate to the front. Press the button upwards to
operate the hood at speed level 1, and downwards to operate
the hood at speed level 2.
(C) : 3rd Speed Button Pull the sliding plate to the front. Press the button downwards
to operate the hood at speed level 3.
3.2 Energy Efficient Operation in
Terms of Saving
Use
•When using your appliance, adjust the speed set-
tings according to vapour and odour intensity, in
order to save energy.
•Use low speeds (1-2) under normal conditions,
and high speeds (3) in intense odour and vapour.
•The lamps on the hood are placed for illuminating
the cooking area.
Using them for environmental lighting shall cause
unnecessary energy expenditure and insufficient
lighting.
3.3 Operating Instructions
•Your appliance contains a motor that has various
speeds.
•For better performance, we recommend using low
speeds under normal conditions and high speeds
in cases of strong odours and intense vapour.
•You can start your appliance by pressing on the
desired speed setting button. (B,C)
•You can illuminate the cooking area by pressing
the lamp.
(Figure 3)

Cooker Hood / User Manual 9 / EN
3 Operation of the Appliance
3.5 Operation with Flue Connection
•Vapour is extracted through the
flue duct, which is fastened to the con-
nection head on the hood.
•The diameter of the flue duct must
be the same as the connection ring. In
horizontal settings, the pipe has to have a slight up-
ward slope (around 10º) so that the air can exit the
room easily.
3.6 Operation without Flue
Connection
•Air is filtered through the carbon
filter and recirculated in the room. Car-
bon filter is used when it is impossible
to use a flue in the house.
•In flueless use, remove the flaps
inside the flue adapter.
•Remove the Grease Filter . To install the carbon filter,
fit the filter to the tabs by centring it on the plastic
piece on both sides of the fan body. tighten it by turning
right or left.
•Replace aluminium Grease Filter .
Bulb
Bulb Power (W) 3
Holder / Socket E 14
Bulb Voltage (V) 220 - 240
Size (mm) 35 x 100
ILCOS Code DRBB/F-3-220-
240-E14-35/100
A
CAUTION
Disconnect the electrical supply of the
hood. Leave the lamps to cool down first
because they could burn your hands
when they are hot.
•Remove the aluminium cartridge filter. Remove the de-
fective bulb and replace with a new one with the same
rating (Figure 4).
3.4 Replacement of Lamp
(Figure 4)
MAX 3 W

10 / EN Cooker Hood / User Manual
4 Cleaning and Maintenance
C
Before cleaning and maintenance, unplug
the product or turn off the switch.
4.1 Cleaning of Aluminium
Grease Filter
Aluminium grease filter is used to retain the oil particles
in the air. Aluminium grease filter may change colour as
it is washed; this is normal and does not require replacing
your filter.
1
2
(Figure 5)
1- External Aluminium Grease Filter
2- Internal Aluminium Grease Filter
•Pull the sliding plate out by holding the front panel.
Remove the external aluminium Grease Filter first,
and then the internal aluminium Grease Filter .
•Push the Aluminium grease filter lock forward.
•Then lower it slightly down and pull it out (Figure 5).
Otherwise, you can bend the filter. Wash and rinse
Aluminium grease filter s with liquid detergent and
replace Aluminium grease filter s to their sockets by by
carrying out the steps specified above in reverse order.
This filter retain the oil particles in the air.
C
You may wash your Aluminium Grease
Filter s in the dishwasher.
A
CAUTION
In case of normal use, clean your alumini-
um Grease Filter once in a month.
4.2 Replacement of Carbon Filters
Odour removing filters contain charcoal (Active carbon).
Aluminium grease filter s must be installed in the prod-
uct, regardless of whether or not carbon filters are used.
(Figure 6)
•Remove Aluminium grease filter (Figure 5).
•To remove the charcoal filter, remove the charcoal filter
from its housing by rotating it counter-clockwise from
the tab (Figure 6).
•Install the new charcoal filter.
•Install the Aluminium Grease Filter s.
A
CAUTION
Carbon filter shall never be washed.
A
CAUTION
Replace carbon filters once every 3
months.
A
CAUTION
You can obtain the carbon filter from the au-
thorized services.

Cooker Hood / User Manual 11 / EN
5.1 Position of the Appliance
•Distance between the cooker and the cooker hood
must be considered prior to assembly. This distance
should be 65 cm (Figure 7).
•Distance must be measured from the surface of grate
for gas cookers,
•from surface of glass for electric cookers.
5.2 Installation Accessories
1. Hood
2. 4x 4 x 40 Screws
3. Operating Manual and Other Documents
4. Mounting Template
5. Ø120mm Plastic Flue Flap
The information required to make the location suitable for
the installation of the hood is given below.
5.3 Installation of the Hood
A
CAUTION
Use protective gloves and goggles for
drilling and cutting operations.
•Paste the installing template provided with the hood on
the surface where the hood is to be mounted.
•Make holes with Ø4 mm diameter on the points
marked as A, B, C, D on the installation template.
•Drill the flue outlet hole specified in the installing tem-
plate in the sizes given.
5 Installation Of Appliance
A
WARNING!
Before starting the installation, read the
safety information on User Manual.
A
WARNING!
Failure to install with screws and stabilizers in
accordance with these instructions may result
in electric shock.
For the installation of the hood, please contact the near-
est Beko Authorized Service.
It is the customer's responsibility to prepare the location
and electrical installation of the hood.
DCH609
COOKERHOOD
Cooking
Instruction manual
(Figure 7)

12 / EN Cooker Hood / User Manual
•Install flexible aluminium pipe to plastic flue outlet. In-
stall the other end of the pipe to the flue hole on the
wall (Figure 10).
5 Installation Of Appliance
Remove the appliance from its packaging. Install the
plastic flue flaps provided in the accessories to the air
outlet flue of the appliance as shown below.
•Insert the plastic pin (Figure 8 / area no. 2) on the pin
socket on the motor exhaust (Figure 8 / area no.1).
Then bend the flap lightly to insert the other pin on the
flap and insert the other pin to its socket (Figure 8).
•By using the 4 x 40 screws provided with the hood,
install the appliance to the cabinet from the points A,
B, C and D. When the slider set moves, the front panel
shall not rub on the cabinet door (Figure 9)
B
C
D
A
A
B
C
D
(Figure 8)
(Figure 10)
(Figure 9)
1. Flap Pin Socket
2. Flap Pin
5.4 Connecting to Flue
If you are going to use the Ø 120/150 mm plastic flue
adapter, connect one end of the pipe to this adapter, if
you are not going to use it, to the direct output on the
product. Connect the other end of the pipe to your flue.
Check that these two connections are tight enough so
they will not come out when the appliance runs on full
power. Ensure that the flaps inside the flue work when
tightened with clamp. Connect the flue connection duct
outside the adapter. If the connection duct is fitted inside
the adapter, the covers that prevent air return shall re-
main closed and air won't be sucked in. The length of the
pipe connection as well as the number of elbows must be
as minimum as possible.
Suitable Not suitable
A : Flue exit pipe
B : Non return flaps
C: Plastic Flue
The valves are closed then the appliance is not operating
and prevent possible outside odour and dust from enter-
ing inside.

Cooker Hood / User Manual 13 / EN
6 Troubleshooting
Troubleshooting Root Cause Help
Appliance is not working. Check your fuse. Your fuse may be off, bring it to the
operating condition.
Appliance is not working. Check the electrical connection. Mains voltage shall be between 220
and 240 V.
Appliance is not working. Check the electrical connection. Check if other appliances available
in the kitchen are operating.
Illumination lamp does
not operate.
Check the electrical connection. Mains voltage shall be between 220
and 240 V.
Illumination lamp does
not operate.
Inspect the lamp switch. Lamp switch shall be at "on"
position.
Illumination lamp does
not operate.
Inspect the lamps. The lamps of the appliance shall not
be faulty.
Air intake of the appli-
ance is weak.
Inspect the aluminium filter. Under normal operating conditions,
aluminium Grease Filter shall be
cleaned at least once in a month.
Air intake of the appli-
ance is weak.
Check the air discharge flue. Air discharge flue shall be “open”.
Air intake of the appli-
ance is weak.
Inspect the carbon filter. For the appliances with carbon
filters, this filter shall be replaced
once in every 3 months under
normal conditions.

Branches
If you have followed the instructions and still have a problem, contact the customer care line on
086 100 3339. They will be able to advise you on any aspect of the appliance.
South African Branches:
BLOEMFONTEIN
Unit Number 5
Monument Business Park
50 Monument Road
Oranjesig
Bloemfontein
[e-mail]
CAPE TOWN
5A Marconi Rd. Montague Gardens, 7441
[e-mail]
DURBAN
135 Teakwood Road, Jacobs,
Durban, 4052
[e-mail]
EAST LONDON
Robbie de Lange Road, Wilsonia,
East London, 5201
[e-mail]
GAUTENG, MIDRAND
127 15th Road, Cnr Pharmaceutical &15th Rd,
Midrand, Gauteng
[e-mail]
POLOKWANE
87 Nelson Mandela Drive, Superbia 0699
[e-mail]
PORT ELIZABETH
112 Patterson Road, North End, Port Elizabeth
6001
[e-mail]
Sub-Saharan Africa Branches:
ZAMBIA: SOUTHGATE INVESTMENTS LTD
Plot 1606, Sheki Sheki Road
P.O. Box 33681
Lusaka, 10101, Zambia
Tel: [phone]
Fax: [phone]
[e-mail]
NAMIBIA: ATLANTIC DISTRIBUTORS (PTY)
LTD
10 Tienie Louw Street, Northern Industrial Area
P.O. Box 21158, Windhoek, Namibia
Tel: [phone]
Fax: [phone]
[e-mail]
ZIMBABWE: TRADECOMAFRICA
Trade Com Africa, 183 Loreley Crescent
Msasa, Harare, Zimbabwe
Tel: [phone]
Cell: [phone]
Cell: [phone]
BOTSWANA: RAY MORGAN AGENCIES
RMA Service Centre, Plot 48, East Gate
Gaborone International Commerce Park
Kgale View, Gaborone
Botswana
Tel: [phone]
Fax: [phone]
Cell: [phone]
[email protected]; [e-mail]
SWAZILAND: LYNDS DISTRIBUTORS
P.O Box 716, Mbabane, Swaziland, H100
Tel: [phone]
Fax: [phone]
MOZAMBIQUE: COOL WORLD. LDA
Rua da Resistencia No. 97B R/C
Cell: [phone]
[e-mail]
Nosso Show Room
Av: da Industrias, Parcela No.735 * 735A
Machava, Maputo

Warranty
This certificate is issued by DEFY APPLIANCES (PTY) LTD manufacturers of Defy and Ocean
products, hereinafter the Company, to the original purchaser only, of the appliance described on the
certificate and shall constitute the only warranty given in respect of this appliance.
The Company warrants to the original purchaser that for a period of TWO YEARS from date of
purchase the appliance is free from defect under normal domestic use, both in workmanship and
material, subject to the following conditions.
1. Repair or replacement of any part of this appliance, found by the Company to be defective, shall
be at the election of the Company. The Company reserves the right to effect such service through
any of its Service Divisions or Authorised Service Dealers. The cost of such service shall be borne
by the Company in full, provided that the appliance is located no further than 50 km from a
Company Service Centre or an Authorised Service Dealer. Where the appliance is located beyond
the 50 km radius, the purchaser shall be liable for the standard travelling charges, as determined by
the Company.
CARRY IN SERVICE Microwave ovens, Compact cookers and small appliances are repaired in our
service centres and are not collected from the customers home. Faulty units must be delivered to
the purchasing dealer or to the nearest Company Service Centre for warranty repairs.
2. Rusted or corroded plates, vitreous enamelware, fuses and lamps are specifically excluded from
these warranties. It is an express condition of these warranties that the purchaser takes due care
and attention in the use and maintenance of the appliance. Abuse, misuse in conflict with operating
instructions, connection to incorrect voltages and subjection to commercial use shall release the
Company from its obligations.
3. This warranty shall become void and cease to operate if the appliance is dismantled by, or any
repairs to the appliance are effected by any persons not duly authorised by the Company, or if
substitute parts not approved by the Company are used in the appliance, or if the serial number of
the appliance is removed.
4. The Company shall not be responsible for damages resulting from fire, flood, civil disturbances or
any Act of God. The Company shall not, in terms of these warranties be responsible nor held liable
for any consequential loss or damage of any kind caused by or due to the failure or malfunction of
the appliance. The Company shall not be responsible for damages caused by insect and/or animal
infestation.
5. The Company shall not be responsible for transportation or other costs other than those incurred
within the provisions of Point 1 of this Certificate.
6. For warranties in the Republic of South Africa and Sub-Saharan Africa, please contact the
customer care line. Please refer to the previous page for respective South African branches
and Sub-Saharan Africa branches.
7. Where service is requested under warranty and no fault or defect can be found by the Company,
all costs incurred will be for the purchaser's account.
8. This Certificate as well as your invoice will serve as proof of purchase. For the purpose of
warranty, it will be essential to produce this Certificate and invoice. Failure to do so, will render the
purchaser liable for service costs.
KEEP THIS CERTIFICATE AND SALES INVOICE AS PROOF OF PURCHASE FOR
WARRANTY PURPOSES.

Arçelik A.Ş. Karaağaç Caddesi No:2-6,
34445, Sütlüce / İSTANBUL
www.defy.co.za
