Defy DCH309 User manual

Page 1
YOU CAN RELY ON DEFY
900 C PREMIUM ISLAND
EXTRACTOR HOOD
Users Manual
Part Number 068206
Record in the space below the listed information for future reference.
SER AL NUMBER$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$..
DATE OF PURCHASE$$$$$$$$$$$$$$$$$$$$$$$$$$$$$...
PURCHASED FROM$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$..
$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$.
DCH309
900 C PREMIUM
ISLAND EXTRACTOR HOOD
WITH CURVED GLASS

Page 2
Introdu tion
Dear customer,
Your new Defy Extractor Hood was manufactured in a state of the art facility and has passed
the strictest quality control procedures.
Please read this manual carefully before using your Extractor Hood for the first time and then
store it within easy reach for future reference.
This manual will provide you with information on how to operate and care for your Extractor
Hood to gain the maximum benefit from it.
We trust you will enjoy years of trouble free use.
EXPLANATION OF SYMBOLS
mportant information
Warning—Hazardous situations
Warning—Electric shock
SAVE THESE INSTRUCTIONS
Index
3 Important safety instru tions.
4 Des ription.
4 Before use.
4 Safety advi e.
4 Ele tri al onne tion.
5 Preparing for installation.
5 Re ir ulating filtered air.
5 Venting air to the outside.
6 Mounting diagram.
7 Installation.
8 Before and after use.
8 Grease filters.
8 Optional arbon pad filters.
9 Operation.
9 Repla ing the light bulbs.
10 Maintenan e and leaning.
11 Owner’s responsibility.
11 Problem he k.
11 Servi e Centres.
12 Warranty.
The manufacturer strives for continuous improvement. For this reason, the text and
illustrations in this manual are subject to change without notice.

Page 3
This section contains safety instructions
that will help you avoid risk of injury and
damage. All warranties will be void if you
do not follow these instructions.
General safety
• This e tractor hood is not intended for
use by persons (including children) with
reduced physical, sensory or mental
capabilities or lack of e perience and
knowledge, unless they have been given
supervision or instruction concerning
the use of the e tractor hood by a person
responsible for their safety.
• Children must be supervised to prevent
them from tampering with the e tractor
hood.
• Connect the e tractor hood to an
earthed outlet/line protected by a fuse of
suitable capacity. Have the earth
installation made by a qualified
electrician. This e tractor hood must be
earthed and the manufacturer and the
seller do not accept responsibility for
any damage due to incorrect installation
or electrical connection.
• If the supply cord is damaged, it must
be replaced by the manufacturer, its
service agent or similarly qualified
persons in order to avoid a hazard.
• Do not operate the e tractor hood if it is
defective or has any visible damage.
• Do not carry out any repairs or
modifications on the e tractor hood.
• Never wash down the e tractor hood
with water! There is a risk of electric
shock!
• Never use the e tractor hood when your
judgment or coordination is impaired by
the use of alcohol and/or drugs.
• The e tractor hood must be
disconnected from the mains during
installation, maintenance, cleaning and
repair procedures.
Important safety instru tions
• Do not place any flammable materials
close to the e tractor hood.
• Make sure that the e tractor hood
function knobs are switched off after
every use.
Safety for children
Electrical products are dangerous to
children. Keep children away from the
e tractor hood when it is operating and
do not allow them to play with the
e tractor hood. The packaging materials
will be dangerous for children. Keep the
packaging materials away from children.
Please dispose of all parts of the
packaging in a responsible manner.
Plastic bags should be cut up to prevent
children playing with them and
accidentally suffocating.
Safety when working with electricity
Defective electric equipment is one of the
major causes of house fires.
Any work on electrical equipment and
systems should only be carried out by
authorized and qualified persons.
In case of any damage, switch off the
e tractor hood and disconnect it from the
mains. Report the damage to your dealer,
who will take the necessary corrective
action.
Intended se
This e tractor hood is designed for
domestic use. Commercial use will void
the warrantee.
CAUTION:
The manufacturer shall not be liable for
any damage caused by improper use or
handling errors.

Page 4
• Do not touch any part of the light
fittings or adjacent areas during or
straight after prolonged use as they get
very hot and could cause severe burns.
• In certain circumstances electrical
appliances may be a hazard.
• Do not check the status of the filters
while the e tractor hood is operating.
• Avoid leaving e posed flames
unattended and always ensure that the
burners are covered as open flames are
damaging for the filters and a fire
hazard.
• Constantly check food frying to avoid
overheated oil becoming a fire hazard.
• There must be adequate ventilation of
the room when the e tractor hood is
used at the same time as appliances
burning gas or other fuels.
• There is a risk of fire if cleaning is not
carried out in accordance with the
instructions.
• The e tractor hood uses a 220-
230V~ /50Hz power supply.
• If the mains power cord is damaged, it
must be replaced by a qualified
electrician.
• The power cord is located in the
chimney area. Should you require an
installation with no visible wiring, a 15
amp earthed plug socket should be
accessible either in the ceiling above
the e tractor hood or on the wall behind
the chimney area. (A qualified
electrician should provide this facility).
• The extractor hood m st be earthed.
The man fact rer and the seller do
not accept responsibility for any
damage d e to incorrect electrical
connection.
• This extractor hood may not be sed
with a battery inverter power s pply.
Safety advi e
Before use
• This e tractor hood complies with all
relevant safety regulations.
• Never operate the e tractor hood
without a grease filter.
• Never leave cooking fat or oil
unattended. Overheated fat or oil can
easily catch fire.
• Do not flambé food directly under the
e tractor hood. The flames pose the risk
of the grease filter catching fire. (see
page 10 Maintenance and cleaning).
• Restrictions apply to the use of the
e tractor hood over a solid fuel or gas
stove. (See Preparing for installation on
page 5).
• Switch off the power at the mains in the
event of a fault or when cleaning the
e tractor hood.
Before using your new e tractor hood for
the first time, please read this manual
carefully. It contains important
information concerning your personal
safety as well as on the use and care of the
e tractor hood.
• Remove all packaging (e cept the
protective film on the two chimney
sections) and dispose of it in an
environmentally friendly manner.
• If the e tractor hood is damaged in any
way, do not use it. Report the damage to
your dealer, who will take the necessary
corrective action. (Refer to Owner’s
responsibility on page 11 of this
manual).
Des ription
• The e tractor hood fan e tracts the
kitchen vapours and passes them
through the grease filter.
• The grease filter absorbs the solid
particles in the cooking vapours,
keeping the kitchen almost free of
grease.
Ele tri al onne tion

Page 5
ceiling
Re- ir ulating
filtered air
ceiling
ceiling
Exhaust air through a dedi ted pipe
not shared with a fuel burning applian e.
Preparing for installation
Venting air to the outside
When discharging the air into a ventilation
duct or directly through the ceiling into the
open, please take note of the following:
• Exha st air from the extractor hood
m st not be directed into a fl e or
chimney which is sed for exha sting
the f mes or smoke from other
appliances b rning gas or f els.
• Please ens re that reg lations
concerning the discharge of exha st
air have been f lfilled. (SABS IEC
60335-2-31).
For optimum e tractor hood efficiency
use a short, smooth, round air e haust
pipe with as few bends as possible. A 150
mm diameter e haust pipe is
recommended. A long bo section,
narrowed or bent pipes will hinder
performance and increase noise levels.
• Connecting a 150 mm diameter pipe:
Mount the pipe directly onto the air
outlet on the e tractor hood.
• The e tractor hood filters out solid
particles before the air is re-circulated,
via the vents on the side of the upper
chimney, back into the kitchen.
Re- ir ulating filtered air
The extractor hood has the ability to
either recirc late the filtered air back
into the kitchen, or the filtered air can
be circ lated thro gh a d ct to the
o tside of the b ilding or into the
ceiling.
Decide on which option best suits you
before commencing with the installation.
Tools req ired for installation:
• An electric drill.
• A saw for the chimney duct.
• A star screw driver (Posi 2).
• A ratchet with a 10 mm socket and a
100 mm e tension.
• A tape measure, masking tape and a
pencil.
ITEM DESCRIPTION QTY
Wall plug & screw 8 mm plug, 6 mm screw 4
Washer Slotted 4
Fi ing bolt &
washer
M6 16 he bolt and
washer
32
Nut M6 he nut 20
Screw Self tapping 6
• Care must be taken during installation
not to obstruct these vents.
• No ducting is required for this type of
installation.

Page 6
Mounting Diagram

Page 7
Installation
Note: The extractor hood is intended to hang
from a horizontal ceiling capable of s pporting
the weight of the hood. (Approximately 40Kg.)
Step 1
• Carefully unpack the e tractor hood, the
component parts and remove the grease filter.
See page 8.
• With the assistance of a qualified installer,
mount the top e tension adaptor to the ceiling
directly above the cooking surface using the 4
M6 bolts as supplied.
• Where applicable, cut a hole in the ceiling to
accept the power cord, the fitted plug and an
outlet pipe.
Step 2
• Fit and secure the angular mounting structures
into the four recesses on the e tractor hood
using the 12 M6 bolts and washers supplied.
Step 3
• Slide the lower chimney duct onto the
e tractor hood.
• Slide the top chimney (the one with the slotted
vents) into the lower chimney duct.
Step 4
• Lift the e tractor hood assembly into the top
e tension adaptor. Adjust to a suitable height
(A minim m clearance height of 650 mm is
req ired when installed above a b ilt in
electric hob or 700 mm when installed above
a b ilt in gas hob).
• Ensure that the e tractor hood is level before
tightening the 4 M8 clamping bolts which
hold the hood in place.
• Connect the outlet pipe, if required, and insert
the fitted plug into a 15A earthed socket.
Step 5
• Slide the upper chimney duct into place
against the ceiling.
• Fasten from the sides with 2 4.8 mm self
tapping screws.
Step 6
• Fasten the lower chimney duct to the e tractor
hood from underneath.
• Refit the grease filter.

Page 8
Optional Carbon pad filters
We recommend that the e tractor hood
is switched on before any food is
cooked. We also recommend that the
e tractor hood is left running for 15
minutes after the food is cooked, in
order to thoroughly eliminate all
contaminated air. The effective
performance of the e tractor hood
depends on constant maintenance; the
anti-grease filter and the active carbon
filter both require special attention.
• Remove the plastic outer protective
lining on the grease filters before fitting
them to the e tractor hood.
• To fit the filters, engage the two lugs at
the rear of each filter into the
rectangular slots of the e tractor hood
frame, lift the filter and press the handle
catch inwards.
• Engage the filter and release the catch.
• To remove the filter, for cleaning
purposes, reverse the procedure
described above.
• The anti-grease filter is used to trap
any grease particles suspended in the
air, therefore is subject to saturation
(the time it takes for the filter to
become saturated depends on the way
in which the appliance is used).
To prevent potential fire hazards, the
anti-grease filters should be washed a
minimum of every 2 months (it is
possible to use the dishwasher for this
task).
After a few washes, the colour of the
filters may change. This does not mean
they have to be replaced.
If the replacement and washing
instructions are not followed, the anti-
grease filters may present a fire hazard.
Grease filters
• Carbon pad filters assist in removing
any unwanted cooking odours from the
atmosphere.
• If your installation ducts filtered air to
the outside, the carbon pad filters are
not required.
• Should you require them, factory
approved, carbon pad filters and
installation kits may be purchased from
your nearest Defy Service Centre or
their authorised agents.
The Carbon pad filters are used to purify
the air which is released back into the
room.
The filters are not washable or re-usable
and must be replaced at least once every
four months. The active carbon filter
saturation level depends on the frequency
with which the appliance is used, the type
of cooking performed and the regularity
with which the anti-grease filters are
cleaned.
Before and after use

Page 9
Repla ing the light bulbs
• Switch off the electricity supply.
• If the b lb has recently failed, it
might still be very hot. Allow the
glass cover to cool before attempting
to replace the b lb.
• Hold the glass cover and unclip the
retaining ring. Be careful not to let the
glass cover fall.
• Replace the light bulb with a
commercially available G9 220V 25W
halogen or equivalent bulb.
• Take care not to handle the
replacement b lb with bare fingers
as transferred skin oil may shorten
the life expectancy of the halogen
b lb.
• Fit the glass cover in the retaining ring,
align the 3 clips to the slots and clip
back into place.
• Switch on the electricity supply.
• Select the fan speed you require.
• Push button ‘3’ for high e traction
level.
• Push button ‘2’ for medium.
• Push button ‘1’ for low.
• The fan indicator light will glow when
the fan is operating.
• To switch the fan off, push the fan
speed OFF button ‘0’.
• If required, you may illuminate the
cooking area by switching the hood
lights on.
• Leave the hood running for a short
period after the cooking has been
completed to clear any smoke and
odours.
Operation
Figures in this manual are schematic and may not exactly match your product.

Page 10
Maintenan e and leaning
Important:
Before cleaning any part of the hood,
switch the power off at the mains.
Cleaning the metal grease filters.
• In normal operation (1 to 2 hours daily),
the metal grease filters must be cleaned
every 8 to 10 weeks.
• The filters may washed in a
dishwasher, however they may
discolour slightly.
• When hand cleaning the filters, soak
them in hot, soapy water to loosen the
grease.
• Brush with a stiff nylon brush.
• Rinse clean and allow to air dry before
re-fitting.
• If cleaning is not carried o t in
accordance with the instr ctions, the
acc m lated grease co ld, over time,
become a fire risk.
General cleaning.
Stainless steel is not adversely affected by
normal household use but because of its
reputation for durability, it is sometimes
assumed to be indestructible, and
therefore subjected to misuse or even
abuse. Care should be taken to avoid such
‘abnormal use’.
Cleaning materials.
Do se:
• A moist lint free soft cloth or synthetic
sponge.
• Soap, or mild liquid detergent.
• A mild window cleaner.
• Diluted ammonia in warm water.
• A nylon bristle brush.
• Cleaners labelled “Suitable for stainless
steel”.
Do not se:
• A steam cleaner.
• Acid, alcohol, soda, chloride or spirit
based cleaners.
• Coarse abrasive cleaning powders.
• Metallic scourers, steel wool, metal
scrapers, or plastic scouring pads.
• Wire brushes or emery paper.
• So called “silver cleaners”.
Cleaning proced re
• Frequent cleaning is recommended
rather than an occasional aggressive
clean.
• Routine cleaning will preserve the
corrosion resistance and the appearance
of the stainless steel for many years.
• Clean the stainless steel as often as
necessary (i.e. when it is noticeably dull
or dirty) and use the simplest cleaning
method that will effectively do the job.
• Use clean water, or a mild detergent
solution applied with a soft cloth or
sponge. Rinse well and wipe dry.
• Always wipe in the direction of the
brushed te ture on the stainless steel.
• Periodically apply a fine film of
dedicated stainless steel cleaner or
baby oil to the canopy of the e tractor
hood to add lustre and sparkle to the
steel.

Page 11
Problem he k
Before calling a service technician to
assist with a problem please check:
• The main distribution board. See if a
circuit breaker has tripped or a fuse has
blown.
• The wall socket.
• Have the filters been cleaned?
• Is the chimney blocked?
Remember that you may be charged for a
service call even during the warranty
period if the fault is due to or caused by
any of the above.
NOTE: Since the following are not
factory fa lts, they are the owner’s
responsibility.
• Damage to e terior finish.
• Breakage of glass and other
components.
• Replacement of the light bulbs.
• Damage through improper use or
installation.
Owner’s responsibility
Servi e entres
• If yo have followed the instr ctions
and still have a problem, contact the
nearest Defy Service Centre.
• (See list at right of page).
Other areas are serviced by over 200
a thorised service agents.
Cons lt the nearest regional service
centre for details.
BLOEMFONTEIN
160 Long Street, Hilton,
Bloemfontein 9301.
Tel. [phone]
[email protected]
CAPE TOWN
5A Marconi Rd.
Montague Gardens, 7441.
Tel. [phone]
[email protected]
DURBAN
35 ntersite Avenue,
Umgeni Business Park, Durban 4051.
Tel. [phone]
[email protected]
EAST LONDON
16 Bowls Rd. Arcadia,
East London 5201.
Tel. [phone]
[email protected]
JOHANNESBURG
Commercial Head Office,
Administration, Distribution, National Groups,
Tel. Sales, Contracts and Credit.
Cnr. Mimetes & Kruger Sts. Denver ext.12
Johannesburg. 2094.
Tel. [phone] or 011 621 0300
[email protected]
POLOKWANE
87 Nelson Mandela Drive.
Superbia 0699.
Tel. [phone] / 7 / 8 / 9.
[email protected]
PORT ELIZABETH
112 Patterson Road,
North End, Port Elizabeth 6001.
Tel. [phone]
[email protected]
PRETORIA
Block A1 Old Mutual ndustrial Park.
Cnr. D.F.Malan Drive & Moot Str.
Hermanstad. 0082.
Tel. [phone]
[email protected]
PLEASE REGISTER YOUR PRODUCT AT
www.defy. o.za
DEFY APPL ANCES (PTY) LTD
P.O.BOX 12004
JACOBS
DURBAN
4026
SOUTH AFR CA

Page 12
This certificate is issued by DEFY APPLIANCES LIMITED manufacturers of Defy and Ocean
products, hereinafter the Company, to the original purchaser only, of the appliance described on the
certificate and shall constitute the only warranty given in respect of this appliance.
The Company warrants to the original purchaser that for a period of TWO YEARS from date of
purchase the appliance is free from defect under normal domestic use, both in workmanship and
material, subject to the following conditions.
1. Repair or replacement of any part of this appliance, found by the Company to be defective, shall
be at the election of the Company. The Company reserves the right to effect such service through
any of its Service Divisions or Authorised Service Dealers. The cost of such service shall be borne
by the Company in full, provided that the appliance is located no further than 50 km from a
Company Service Centre or an Authorised Service Dealer. Where the appliance is located beyond
the 50 km radius, the purchaser shall be liable for the standard travelling charges, as determined by
the Company.
CARRY IN SERVICE Microwave ovens, Compact cookers and small appliances are repaired in
our service centres and are not collected from the customers home. Faulty units should be
delivered to the purchasing dealer or to the nearest Company Service Centre for warranty repairs.
2. Rusted or corroded plates, vitreous enamelware, fuses and lamps are specifically e cluded from
these warranties. It is an e press condition of these warranties that the purchaser takes due care and
attention in the use and maintenance of the appliance. Abuse, misuse in conflict with operating
instructions, connection to incorrect voltages and subjection to commercial use shall release the
Company from its obligations.
3. This warranty shall become void and cease to operate if the appliance is dismantled by, or any
repairs to the appliance are effected by any persons not duly authorised by the Company, or if
substitute parts not approved by the Company are used in the appliance, or if the serial number of
the appliance is removed.
4. The Company shall not be responsible for damages resulting from fire, flood, civil disturbances or
any Act of God. The Company shall not, in terms of these warranties be responsible nor held liable
for any consequential loss or damage of any kind caused by or due to the failure or malfunction of
the appliance.
5. The Company shall not be responsible for transportation or other costs other than those incurred
within the provisions of Point 1 of this Certificate.
6. These warranties shall not apply to the appliance if it is purchased or used beyond the borders of
the Republic of South Africa, Namibia, Botswana, Swaziland and Lesotho.
7. Where service is requested under warranty and no fault or defect can be found by the Company,
all costs incurred will be for the purchaser's account.
8. This Certificate as well as your invoice will serve as proof of purchase. For the purpose of
warranty, it will be essential to produce this Certificate and invoice. Failure to do so, will render
the purchaser liable for service costs.
KEEP THIS CERTIFICATE AND SALES INVOICE AS PROOF OF PURCHASE FOR
WARRANTY PURPOSES.
Warranty
