DEKALA Sunrise ACA-002-B User manual

Dekala Sunrise Alarm Clock
ACA-002-B
Instructions
Please read the instructions carefully before use and keep it in proper storage
(V2.0)

What’s Included
Get Started
Product Overview
Operation Guide
Specifications
Cautions
Storage
02
02
03
05
15
15
16
CONTENT
[email protected]
If you need any assistance please feel free to contact us
Instruction Videos

WHAT'S INCLUDED
GET STARTED
Sunrise Alarm Clock USB Cable Adapter User Manual
Instructions
Please read the instructions carefully before use and keep it with proper storage
(V2.0)
1. Remove the Insulation Film from the
Button Cell Compartment at the bottom.
2. Connect the Sunrise Alarm Clock to power
with the USB Cable and Adapter provided.
Important:
This product has no power on/off button, and it will be on once you plug the power adapter into the socket.
To disconnect power, unplug the power adapter.
02

03
PRODUCT OVERVIEW
3. Loosen the tie that wraps the FM Radio
Antenna, then unroll the wire for receiving
strong signals when turning on the FM Radio.
Alarm 2
Alarm 1
Down
LED Light
Up
Time Setup
LED Display Mode
Sleep Aid
Volume -
FM Radio
Volume +
Snooze
LED Display

04
USB Output
Speaker
FM Antenna
Button
Cell Compartment
Micro USB Input

Step 2:
Press to change the Hour, then
press Setting/ to confirm and switch to
adjust "Minute".
OPERATION GUIDE
Note:
The Sunrise Alarm Clock will automatically save the current setting and
exit from setting mode if the operation is not resumed within 15s.
Step 1:
Press and hold the Setting/ button for 2
seconds until the hour starts flashing
Step 3:
Press to change the Minute, then
press Setting/ to confirm and start to set the
Time Format.
05
Setting
Setting
Setting
Watch Instruction Video
Time Setting

Press Setting/ to toggle the brightness of the LED Display among Day Mode, Night Mode
and OFF.
Step 4:
Press to select Time Format 24-hour
clock or 12-hour clock, then press
Setting/ to confirm and complete the setting.
06
lf the 12-hour time format is selected, PM or AM will be displayed accordingly.
Tip:
Day Mode indicates that the brightness level of the LED display will remain
consistently bright, even during nighttime.
Night Mode indicates the brightness level of the LED Display will always be
the lowest.
Setting
Setting
Setting
Adjust the Brightness of Time Display

Step 1:
Press and hold Alarm 1/ for 2 seconds until the
icon and the Hour start flashing on the LED display.
Step 2:
Press to change the Hour, then press Alarm
1/ to confirm and switch to adjust "Minute".
07
Alarm 1
Alarm 1
Setting
OFF means turning off the LED display.
You could set Alarm 1 and Alarm 2 with the wake-up light.
We will take setting Alarm 1 as an example to guide you how to set an alarm.
Watch Instruction Video
Alarms Setting

Step 3:
Press to change the Minute, then
press Alarm 1/ to confirm and start the
Ringtone Setting.
08
S-00: Ringtone off
S-01 to S-07: Nature sounds
F-08: The last FM station you were tuned to before turning off the radio.
lf you prefer another station, please turnon the FM radio to search and select the one you like,
then set the alarm again.
Tip:
U-01 to U-16: Volume levels
Tip:
Step 4:
Press to select your favorite ringtone for
Alarm 1, then press Alarm 1/ to confirm and start
the Volume Setting.
Alarm 1
Alarm 1
Alarm 1
Step 5:
Press to adjust the ringtone volume, then
press Alarm 1/ to confirm and start the Sunrise
Light Setting.

Note:
-When the alarm is ringing, press the button to close the alarm
-If you don't need to use the alarm function on the weekend, you can identify it by icon , whether the
alarm clock is turned on. The screen shows the icon which means that the alarm function is turned on.
On the contrary, it means that the alarm function is turned off.
09
L-00: Light off
L-01 to L-20: Brightness levels
lf you select L-00, there will be no sunrise light (but only ringtone) when Alarm 1 rings.
Tip:
If you set the duration to 10 minutes and the alarm time to 7:00 AM, the light will turn on at 6:50
AM and slowly increase in brightness. By the time the alarm goes off at 7:00 AM, the light will be
at the brightness level you selected in Step 6.
Tip:
Step 6:
Press to adjust the brightness level for the
light, Once done, press Alarm 1/ to confirm
your selection and start setting the sunrise time that
is the lighting time before the alarm ringing.
Step 7:
Press to select the sunrise time from 10,
20, 30, 40, 50 and 60 MIN, then press Alarm 1/
to confirm and complete all the settings for Alarm 1.
Alarm 1 is on after setup.
Alarm 1
Alarm 1

10
Step 1:
Press FM Radio/ to turn on/off FM radio.
Snooze
FM Radio
FM Radio
Note:
1. You can snooze up to 5 times.
2. Press the corresponding Alarm Button / to manually stop the alarm.
3. If you don't respond to it within 15 minutes after the alarm rings, the alarm will automatically stop for this
time.
When the alarm rings, press Snooze/ to activate
Snooze Mode to delay the alarm for 9 minutes.
①. Press and hold the FM Radio/ button down for 2 seconds, the
clock will scan all the available staions automatically and save them as
P-01/P-02 and so on(up to 20 channels). You can simply wait until the
process is complete without needing to take any further action.
②. After finishing, the clock radio will select P01channel by default.
Watch Instruction Video
Snooze
FM Radio

Note: To improve your reception, please completely extend the antenna and
adjust its position until you achieve the strongest signal.
Sleep-aid
Step 1:
Press the Fall-asleep/ button for 2 seconds to
enter the fall-asleep mode. Press the
button to adjust the Timer(up to 120minutes). And
then press the fall-asleep button to confirm it.
11
Step 2:
Press and hold to select other the channel you are interested in.
Step 3:
Press to adjust the volume.
Long Press
Short Press
U-01 to U-16: Volume levels
Tip:
Falling-asleep mode simulates the natural process of a sunset to help
you easily drift off to sleep. Once enabled, the light will gradually dim to
simulate the setting sun, while the volume of your chosen nature
sounds will decrease over time.
Watch Instruction Video
Falling-asleep Mode

Sleep-aid
Sleep-aid
Sleep-aid
12
Step 2:
Press button to adjust the brightness. And then
press the Fall-asleep/ button to confirm it.
Step 3:
Press button to adjust the sound. You can
choose pre-set natural sounds or FM radio as fall-asleep
sound. And then press the Fall-asleep/ button to
confirm it.
Step 4:
Press button to adjust the volume.
L-00: Light off
L-01 to L-20: Brightness levels
Tip:
S-00: Sound off
S-01 to S-03: Nature sounds
F-04: The last FM station you were tuned to before turning off the radio.
lf you prefer another station, please turn on the FM radio to search and select the one you like,
then set it again.
Tip:

Sleep-aid
Light
Press to turn on/off Sleep Aid mode.
Tip:
13
Step 2:
Press to adjust
the brightness level.
Step 5:
Press Fall-asleep/ to confirm your selection and
complete all the setting for Sleep Aid. Sleep Aid is enabled
after setup.
Step 1:
Press Light/ to enter
the manual color light
mode.
Manual Color Light Mode
Watch Instruction Video
Colorful Light Setting

Short press to choose one solid color (7 colors
are available), which means it will stay the same color
until you press the button again.
Light
Light
14
Short press Light/ again to turn off the Colorful Light .
Auto Color Light Mode
Double press Light/ to enter the auto
color light mode,which means the color of
the light will change automatically.

Model
Size
Weight
Material
FM radio frequency
Control mode
Adaptor
Certification
ACA-002-B
168×165×84.6mm
320g
ABS、PC、Electronic components
5V-2A/100-240V
87.5-108MHz
Button control
Please use the product correctly according to the instructions. Disassembling and collision
are strictly prohibited.
Please place the product on a stable, horizontal, and non-smooth surface.
15
SPECIFICATIONS
CAUTIONS

Please wipe the product with a soft cloth.
Do not scrub the product with abrasive cleaner, rough chemical, alcohol or acetone
detergent to avoid damage to the surface of the product.
Store the product in a safe, dry place where it will not be crushed, bruised or damaged.
Do not wrap the power cord around the appliance during storage.
16
Do not use it in high temperature, humidity and corrosive environment to avoid electric
leakage due to circuit damage.
Please keep it in a proper place and out of reach of children to avoid accidents.
This product is not fireproof, do not throw it into the fire, and do not place it close to any fire
source.
This product is not waterproof, do not put it into the water to avoid damage.
STORAGE
Feel free to contact us if you need further assistance, our troubleshooting team will
get back to you ASAP.
Official Website : www.dekalastore.com
Email : [e-mail]
