SPECIFICATION LINE: SELF-CONTAINED SLIDING DOOR REACH-IN REFRIGERATOR
Project __________________________
Item ____________________________
Quantity _________________________
CSI Section 11400
Specifi cation Line
Self-Contained Sliding Door Reach-In Refrigerator
980 S. Isabella Road
Mt. Pleasant, MI 48858
www.delfi eld.com
Phone: 800-733-8948
Fax: 800-669-0619
Email: info@delfi eld.com
Approval _________________
Date ____________________
SPECIFICATIONS
Exterior: Cabinet exterior sides, front and shroud
shall be 22-gauge, corrosion resistant stainless steel.
Upper shroud shall be hinged, with stay-open feature
to provide easy access to refrigeration system.
Interior: Cabinet interior shall be 22-gauge, corrosion
resistant stainless steel (SS models) or heavy gauge
aluminum (SA models). Bottom and top surfaces are
die stamped to provide radius corners and recessed
fl oor. Three chrome plated wire shelves are provided
per section. Shelves rest on clips which are adjustable
in 1” increments on stainless steel pilasters affi xed to
the cabinet interior. Pilasters are removable without
tools for cleaning. An air duct is mounted to the
ceiling assuring low velocity, even air movement
throughout the cabinet interior.
Doors:
Solid Sliding. Exterior and interior shall be 22-gauge
corrosion resistant stainless steel.
Glass Sliding. Double thermopane glass set in high impact
black plastic frame.
Doors are set in tracks for easy movement. Spring action
assures self closing. Gasket seals both ends of doors. Doors
are removable for cleaning.
Refrigeration system: All components are mounted to
the exterior cabinet ceiling, outside the food zone and are
assembled as one piece and can be removed as one piece.
Environmentally friendly R404A refrigerant is used. System
has the capability of maintaining between 27˚F and 40˚F in
heavy use food service operations. Refrigerant is metered
using a highly responsive thermostatic expansion valve.
System is controlled using Delfi eld’s ACT-Advanced
Control Technology electronic temperature control, which
provides improved pull down times, reducing compressor
cycling and longer compressor life with lower energy
consumption.
Control system uses adaptive defrost to assure
evaporator coil is free of ice and operating at optimum
effi ciency. Evaporator condensate is eliminated using an
energy effi cient hot gas system.
Electrical: Standard electrical connections shall be 115V,
60Hz, single phase. A 10’ cord and plug is supplied
attached to a junction box mounted on the exterior top
of the cabinet.
MODELS
❑ SSR2-SLS 2 section stainless interior
sliding solid full height doors
❑ SSR2-SLSH 2 section stainless interior
sliding solid half height doors
❑ SSR2-SLG 2 section stainless interior
sliding glass full height doors
❑ SSR2-SLGH 2 section stainless interior
sliding glass half height doors
❑ SAR2-SLS 2 section aluminum interior
sliding solid full height doors
❑ SAR2-SLSH 2 section aluminum interior
sliding solid half height doors
❑ SAR2-SLG 2 section aluminum interior
sliding glass full height doors
❑ SAR2-SLGH 2 section aluminum interior
sliding glass half height doors
STANDARD FEATURES
• Stainless steel interior and exterior (SS)
• Stainless steel exterior, aluminum interior (SA)
• Exterior digital thermometer
• Easy to use electronic control
• Three chrome plated wire shelves per section
• 10’ attached cord and plug standard on 115V units
• 6” adjustable stainless steel legs
• Energy savings door heater switch
• Flourescent lights with on/off switch
(Glass door units only)
• Two year parts & labor warranty
OPTIONS AND ACCESSORIES
❑ Additional shelves
❑ Tray slides
❑ Stainless steel back
❑ Laminate on front, sides and back
❑ Bottom mount electrical
❑ Stainless steel banking strip
❑ Heat shield end
❑ Stainless steel kick plate
❑ Laminate kick plate
❑ 4” stainless steel utility base
❑ Alarm control display
❑ 220-50-1 electrical
❑ 220-60-1 electrical
❑ Security package
SSR2-SLG
Specification Line: Self contained sliding door reach in refrigerator
Model #__________
CSI Section 11400
Printed in the USA.
09/05
DSSSR2SL
980 S. Isabella Road
Mt. Pleasant, MI 48858
www.delfield.com
Phone: 800-733-8948
Fax: 800-669-0619
Email: info@delfield.com
Delfield reserves the right to make changes in design or specifications without prior notice.
Mechanical Data
MODEL
NUMBER VOLTAGE AMPS STORAGE SHELVES SQ.FT. NO. OF
SHELVES
UNIT
H.P.
BTU/HR CAB
LOAD
BTU/HR
SYSTEM CAP SHIP WEIGHT NEMA PLUG
SSR2-SLS, SAR2-SLS,
SSR2-SLSH, SAR2-SLSH 115 11.2 51.92 27.54 6 1/3 1853 2801 670 5/15P
SSR2-SLG, SAR2-SLG,
SSR2-SLGH, SAR2-SLGH 115 11.2 51.92 27.54 6 1/3 1853 2801 670 5/15P
ELEVATION VIEW
SSR2-SLS, SAR2-SLS ELEVATION VIEW
SSR2-SLSH, SAR2-SLSH
PLAN VIEW
SSR2-SLS, SAR2-SLS
PLAN VIEW
SSR2-SLSH, SAR2-SLSH
END SECTION VIEW
ALL MODELS
PLAN VIEW
SSR2-SLG, SAR2-SLG
PLAN VIEW
SSR2-SLGH, SAR2-SLGH
ELEVATION VIEW
SSR2-SLG, SAR2-SLG
ELEVATION VIEW
SSR2-SLGH, SAR2-SLGH
