Dell EMC Unity Series Manual

Field Upgrade Procedure
Dell EMC Unity™Family
Dell EMC Unity All Flash and Unity Hybrid
Adding an optional 80-drive DAE
302-003-781
REV 01
July 2017
This document describes how to add an optional 80-drive DAE in
Unity All Flash and Unity Hybrid systems.
You will install the 80-drive DAE from the front of the rack, after installing the snap-in
rails into the selected space in the rack.
CAUTION
The enclosure is heavy and should be installed into or removed from a rack by two
people. To avoid personal injury and/or damage to the equipment, do not attempt
to lift and install the enclosure into a rack without a mechanical lift and/or help
from another person.
Note
You do not have to power off any components to add a 80-drive DAE. If an additional
12-Gb SAS back-end I/O module is required to complete the installation, persisting that
I/O module requires a coordinated reboot of the array.
NOTICE
When Data at Rest Encryption is enabled, only drives that meet at least one of these
requirements can be used: factory new drives, securely erased/sanitized drives, or
previously encrypted drives.
lBefore you start......................................................................................................2
lAdding the new 80-drive DAE.................................................................................8
lConnect cables to installed DAE........................................................................... 30
lVerifying the new 80-drive DAE............................................................................39

Before you start
Before you begin this procedure, ensure that you have received the new part and have
correctly identified its intended location in the system. Refer to your Unisphere
Service section for instructions on how to identify failures, order new parts, and
handle hardware components.
Additional resources
As part of an improvement effort, revisions of the software and hardware are
periodically released. Therefore, some functions described in this document might not
be supported by all versions of the software or hardware currently in use. The product
release notes provide the most up-to-date information on product features. Contact
your technical support professional if a product does not function properly or does not
function as described in this document.
Where to get help
Support, product, and licensing information can be obtained as follows:
Product information
For product and feature documentation or release notes, go to Unity Technical
Documentation at: www.emc.com/en-us/documentation/unity-family.htm.
Troubleshooting
For information about products, software updates, licensing, and service, go to Online
Support (registration required) at: https://Support.EMC.com. After logging in, locate
the appropriate Support by Product page.
Technical support
For technical support and service requests, go to Online Support at: https://
Support.EMC.com. After logging in, locate Create a service request. To open a
service request, you must have a valid support agreement. Contact your Sales
Representative for details about obtaining a valid support agreement or to answer any
questions about your account.
Special notice conventions used in this document
DANGER
Indicates a hazardous situation which, if not avoided, will result in death or
serious injury.
WARNING
Indicates a hazardous situation which, if not avoided, could result in death or
serious injury.
CAUTION
Indicates a hazardous situation which, if not avoided, could result in minor or
moderate injury.
NOTICE
Addresses practices not related to personal injury.
Field Upgrade Procedure
2Unity All Flash and Unity Hybrid Field Upgrade Procedure

Note
Presents information that is important, but not hazard-related.
Handling replaceable units
This section describes the precautions that you must take and the general procedures
that you must follow when removing, installing, and storing any replaceable unit.
Avoiding electrostatic discharge (ESD) damage
When replacing or installing hardware units, you can inadvertently damage the
sensitive electronic circuits in the equipment by simply touching them. Electrostatic
charge that has accumulated on your body discharges through the circuits. If the air in
the work area is very dry, running a humidifier in the work area will help decrease the
risk of ESD damage. Follow the procedures below to prevent damage to the
equipment.
Be aware of the following requirements:
lProvide enough room to work on the equipment.
lClear the work site of any unnecessary materials or materials that naturally build
up electrostatic charge, such as foam packaging, foam cups, cellophane wrappers,
and similar items.
lDo not remove replacement or upgrade units from their antistatic packaging until
you are ready to install them.
lBefore you begin service, gather together the ESD kit and all other materials you
will need.
lOnce servicing begins, avoid moving away from the work site; otherwise, you may
build up an electrostatic charge.
lUse ESD anti-static gloves or an ESD wristband (with strap).
If using an ESD wristband with a strap:
nAttach the clip of the ESD wristband to the ESD bracket or bare metal on a
cabinet/rack or enclosure.
nWrap the ESD wristband around your wrist with the metal button against your
skin.
nIf a tester is available, test the wristband.
lIf an emergency arises and the ESD kit is not available, follow the procedures in
Emergency Procedures (without an ESD kit).
Emergency procedures (without an ESD kit)
In an emergency when an ESD kit is not available, use the following precautions to
reduce the possibility of an electrostatic discharge by ensuring that your body and the
subassembly are at the same electrostatic potential.
NOTICE
These precautions are not a substitute for the use of an ESD kit. Follow them only in
the event of an emergency.
lBefore touching any unit, touch a bare (unpainted) metal surface of the cabinet/
rack or enclosure.
Adding an optional 80-drive DAE
Handling replaceable units 3

lBefore removing any unit from its antistatic bag, place one hand firmly on a bare
metal surface of the cabinet/rack or enclosure, and at the same time, pick up the
unit while it is still sealed in the antistatic bag. Once you have done this, do not
move around the room or touch other furnishings, personnel, or surfaces until you
have installed the unit.
lWhen you remove a unit from the antistatic bag, avoid touching any electronic
components and circuits on it.
lIf you must move around the room or touch other surfaces before installing a unit,
first place the unit back in the antistatic bag. When you are ready again to install
the unit, repeat these procedures.
Hardware acclimation times
Systems and components must acclimate to the operating environment before
applying power. This requires the unpackaged system or component to reside in the
operating environment for up to 16 hours in order to thermally stabilize and prevent
condensation.
Refer to the table, Table 1 on page 4, to determine the precise amount of
stabilization time required.
Table 1 Hardware acclimation times (systems and components)
If the last 24 hours of the
TRANSIT/STORAGE
environment was this:
…and the OPERATING
environment is this:
…then let the system
or component
acclimate in the new
environment this many
hours:
Temperature Humidity
Nominal
68-72°F
(20-22°C)
Nominal
40-55% RH
Nominal 68-72°F (20-22°C)
40-55% RH
0-1 hour
Cold
<68°F (20°C)
Dry
<30% RH
<86°F (30°C) 4 hours
Cold
<68°F (20°C)
Damp
≥30% RH
<86°F (30°C) 4 hours
Hot
>72°F (22°C)
Dry
<30% RH
<86°F (30°C) 4 hours
Hot
>72°F (22°C)
Humid
30-45% RH
<86°F (30°C) 4 hours
Humid
45-60% RH
<86°F (30°C) 8 hours
Humid
≥60% RH
<86°F (30°C) 16 hours
Unknown <86°F (30°C) 16 hours
Field Upgrade Procedure
4Unity All Flash and Unity Hybrid Field Upgrade Procedure

NOTICE
lIf there are signs of condensation after the recommended acclimation time has
passed, allow an additional eight (8) hours to stabilize.
lSystems and components must not experience changes in temperature and
humidity that are likely to cause condensation to form on or in that system or
component. Do not exceed the shipping and storage temperature gradient of
45°F/hr (25°C/hr).
lDo NOT apply power to the system for at least the number of hours specified in
the table, Table 1 on page 4. If the last 24 hours of the transit/storage
environment is unknown, then you must allow the system or component 16 hours
to stabilize in the new environment.
Removing, installing, or storing replaceable units
Use the following precautions when removing, handling, or storing replaceable units:
CAUTION
Some replaceable units have the majority of their weight in the rear of the
component. Ensure that the back end of the replaceable unit is supported while
installing or removing it. Dropping a replaceable unit could result in personal
injury or damage to the equipment.
NOTICE
lFor a module that must be installed into a slot in an enclosure, examine the rear
connectors on the module for any damage before attempting its installation.
lA sudden jar, drop, or even a moderate vibration can permanently damage some
sensitive replaceable units.
lDo not remove a faulted replaceable unit until you have the replacement available.
lWhen handling replaceable units, avoid electrostatic discharge (ESD) by wearing
ESD anti-static gloves or an ESD wristband with a strap. For additional
information, refer to Avoiding electrostatic discharge (ESD) damage on page 3.
lAvoid touching any exposed electronic components and circuits on the replaceable
unit.
lNever use excessive force to remove or install a replaceable unit. Take time to
read the instructions carefully.
lStore a replaceable unit in the antistatic bag and the specially designed shipping
container in which you received it. Use the antistatic bag and special shipping
container when you need to return the replaceable unit.
lReplaceable units must acclimate to the operating environment before applying
power. This requires the unpackaged component to reside in the operating
environment for up to 16 hours in order to thermally stabilize and prevent
condensation. Refer to Hardware acclimation times on page 4 to ensure the
replaceable unit has thermally stabilized to the operating environment.
Adding an optional 80-drive DAE
Handling replaceable units 5

NOTICE
Your storage system is designed to be powered on continuously. Most components
are hot swappable; that is, you can replace or install these components while the
storage system is running. However, the system requires that:
lFront bezels should always be attached to ensure EMI compliance. Make sure you
reattach the bezel after replacing a component.
lEach slot should contain a component or filler panel to ensure proper air flow
throughout the system.
Unpacking a part
Procedure
1. Wear ESD gloves or attach an ESD wristband to your wrist and the enclosure in
which you are installing the part.
2. Unpack the part and place it on a static-free surface.
3. If the part is a replacement for a faulted part, save the packing material to
return the faulted part.
Standard touch point colors
Touch points are component locations where you can:
lGrip the hardware to remove or install a component.
lOpen or close a latch.
lTurn a knob to open, close, or adjust a component.
Standard touch point colors are terra-cotta (orange) or blue.
Note
Within this documentation, the color orange is used instead of terra-cotta for
simplicity.
Table 2 Standard touch point colors
Touch point color Description
Terra-cotta
(orange)
This color indicates that you can perform the task, such as remove a
component with a terra-cotta (orange) lever, while the system remains
powered (up/on).
Note
Some tasks may require additional steps.
Blue This color indicates that a shutdown of the system or component is
required before you can perform the task, such as removing a
component with a blue lever.
Field Upgrade Procedure
6Unity All Flash and Unity Hybrid Field Upgrade Procedure

Table 2 Standard touch point colors (continued)
Touch point color Description
Handling disks
Disks are extremely sensitive electronic components. Always handle a disk gently, and
observe the following guidelines:
lFollow the instructions described in Removing, installing, or storing replaceable
units on page 5.
lDo not stack disks upon one another, or place them on hard surfaces.
lMake sure that the replacement disk has the same part number or the part number
of an approved replacement for the faulted disk. The part number (PN005xxxxxx)
appears on the disk. A replacement disk should be the same type (example: SAS,
FLASH) and have the same capacity (size and speed) as the disk it is replacing.
lWhen removing a spinning disk, pull the disk partially out of the slot, then wait 30
seconds for the drive to spin down before removing it.
lWhen installing multiple disks in a powered up system, wait at least 10 seconds
before sliding the next disk into position.
lPlace disks on a soft, antistatic surface, such as an industry-standard antistatic
foam pad or the container used to ship the disk.
Adding an optional 80-drive DAE
Handling disks 7

Adding the new 80-drive DAE
Take the following actions to install the new 80-drive DAE into the system.
Choosing where to install the DAE
Before installing the new DAE, you should determine the placement of the new
enclosure within the rack.
Choose a 3U space in the rack for the new DAE after reviewing the following
guidelines:
lLeave 1U of space at the bottom of the rack for access to cables.
lPopulate all 80-drive DAEs starting from the bottom of the rack before adding
DPEs and other DAEs.
CAUTION
Improper positioning of the 80-drive DAE may cause the cabinet to become
top-heavy and susceptible to falling.
lIf there is already an 80-drive DAE in the rack, place the new DAE directly above
the existing DAE.
lWhen adding a 80-drive DAE to an existing installation, ensure that a 25-slot DAE,
15-slot DAE, or the DPE itself, is not positioned between two 80-drive DAEs. If the
DAE is improperly positioned, it causes a serviceability tunnel and makes servicing
the DPE or DAEs difficult.
Special considerations for adding an 80-drive DAE
The 80-drive DAE supports back-end x8 cabling. However, special steps must be
taken before powering on the system.
If you are connecting the DAE to a 4-port SAS SLIC that requires x8 connectivity,
insert the SAS cable into the 4-port SAS SLIC before persisting the SLIC. The 4-port
SAS SLIC must be persisted with the cable inserted for x8 connectivity.
Note
If the SAS back-end SLIC is powered on without any cables inserted, it is
automatically set at x4 and cannot be used for x8 lane cabling.
80-drive DAE and SLIC port mapping information
BE 0 and 1 can only be x4 and thus will always be back end (BE) 0 and 1.
15-drive, 25-drive and 80-drive DAEs are all valid configurations when connected to
BE 0 and/or 1 as x4.
SLIC BE ports 2 through 5 can be either x4 or x8. They will persist at the time of the
install. To persist x8, at the very least the x8 cable must be in place. The x4 cable does
not have to be in place to be x4.
15-drive, 25-drive and 80-drive DAEs are all valid configurations when connected to
BE 2 through 5 as x4. If they are x4 they will map to BE 2, 3, 4 and 5. If they are x8
they will map to 2 and 4. Only 80-drive DAEs can be connected x8 to BE 2 or 4
therefore an x8 80-drive DAE will always be on either BE 2 or 4.
Field Upgrade Procedure
8Unity All Flash and Unity Hybrid Field Upgrade Procedure

Splitting ports on the SAS SLIC
It is possible to have an x4 on BE 2 and BE 3 with and x8 on BE 4 (ports 2 and 3). It is
also possible to have an x8 on BE 2 (ports 0 and 1) with and x4 on BE 4 and BE 5
(ports 2 and 3).
The mapping of the BE busses is a physical mapping. A DAE’s presence has no effect.
lPhysical ports 0 and 1 of the SLIC will always be bus 2 when configured as x8.
lPhysical ports 0 and 1 of the SLIC will always be bus 2 and bus 3 when configured
as x4.
lPhysical ports 2 and 3 of the SLIC will always be bus 4 when configured as x8.
lPhysical ports 2 and 3 of the SLIC will always be bus 4 and bus 5 when configured
as x4.
Verifying shipping package contents
Confirm that you received all necessary equipment needed to install the new 80-drive
DAE.
Verify that you received the following:
Table 3 80-drive DAE kit
Component Quantity
Disk-array enclosure (DAE) 1
SAS cables (either 1 meter or 2 meter copper) that connect
disk-array enclosures to each other (1 meter cables) or to
DPE (2 meter cables)
2
Table 4 Rail kit
Component Quantity
Rails, each stamped L and R 2
Power cords (AC) 4 (2 gray cables and 2 black
cables)
Bezel for disk-array enclosure 1
Bezel key 1
Cable management arm (A-Side) 1
Cable management arm (B-Side) 1
Screws and nuts for rail installation 1 bag
Label sheets 2
Using the chassis removable handles
Enclosure upgrades and replacements ship with optional chassis handles that you can
use during the installation or replacement of a chassis. The handles provide additional
grip locations for handling the chassis, so you can load it onto the portable lift.
Adding an optional 80-drive DAE
Verifying shipping package contents 9

NOTICE
Remove these handles before fully inserting the enclosure into the cabinet.
Figure 1 Location of removable handles when installed
CL5384
Procedure
1. To install the handles:
a. Position the handle (with the curved edge down) over the chassis pin where
you want to install the handle.
b. Push the handle inward and upward to lock it into place.
c. Repeat these steps for the remaining handles.
Figure 2 Installing the removable handles
CL5385
1 2
2. To remove the handles:
a. Push the handle downward to unlock it and outward to separate it from the
chassis.
b. Repeat these steps for the remaining handles.
Working with the portable lift
If the DAE with all of the FRUs removed is being installed, the chassis can be installed
without using the lift. If the DAE is populated with FRUs prior to installing, then this
task requires the use of a portable lift.
The portable lift commonly used by service personnel is manufactured by Alum-A-Lift.
Instructions for this lift are included in the lift kit. Refer to "http://
www.corkc4.isus.emc.com/wiki/index.php/Lift_Tool". which describes the Lift
Field Upgrade Procedure
10 Unity All Flash and Unity Hybrid Field Upgrade Procedure

equipment, the ordering process, and Links to training material. The Lift Tool Training
Video and Demo on Lift tool using the Voyager assembly (Voyager is the name given
to a Disk enclosure used in several products), are also linked on this page.
Note
If you are using a portable lift other than the Alum-A-Lift, adapt these instructions as
necessary while following all required safety requirements.
CAUTION
The portable lift commonly used by service personnel has two configurations -
one with the lower mast only and one with both the lower and upper masts. The
lower mast configuration is rated for 400 pounds and is for raising or lowering
objects 28U (49 inches) or less above the floor. The dual mast configuration is
rated well under 200 pounds and is for raising objects more than 28U (49 inches)
above the floor.
lFor installations at or below 49 inches, you must use the lower mast
configuration.
lFor installations above 49 inches, use the "Voyager" conversion kit, rated for
225 pounds, and a support table with the lower mast configuration.
Planning your lift
You can use the lift positioned along the side of the DAE or directly in the front of it.
If possible, position the lift adjacent to the LONG side of the enclosure. This reduces
the front clearance required to 50". Aligning the portable lift perpendicular to the
chassis also reduces the possibility of the chassis sliding off the lift and negates the
requirement to adjust the arm width to approximately 17".
Table 5 Planning your lift
Lift
position
Required front
clearance
Arm tray width Notes
Side (long) 50" Greater than 18" Best practice, more stable
Front
(short)
60" Between 16-17" Requires arm adjustment, less stable
Refer to: Adjusting the arms for a frontal lift on page 13
Adding an optional 80-drive DAE
Working with the portable lift 11

Figure 3 Best Practice: Using the portable lift adjacent to the long side of the DAE
CL5431
Assembling and configuring the portable lift
Procedure
1. Using the instructions provided with the lift kit, assemble the portable lift.
2. Configure the lift depending on the height to which the instrument must be
lifted.
Option Description
For installations at or
below 49 inches (28U)
above floor level:
You must use the lower (single) mast
configuration.
Refer to: Using the lift on an enclosure less than
49" above the floor
For installations > 49
inches (28U) above floor
level:
Use the "Voyager" conversion kit and a support
table kit with the lower (single) mast configuration.
See: Using the lift on an enclosure more than 49"
above the floor
Refer ro: Adjusting the portable lift
Field Upgrade Procedure
12 Unity All Flash and Unity Hybrid Field Upgrade Procedure

Option Description
Reconfiguring the lift with Voyager kit
If you are using the Alum-A-Lift for installations or removals above 49 inches (28U),
you must use the single (lower) mast configuration with the "Voyager" conversion kit
and support table.
Refer to Figure 4 on page 13while performing this task.
NOTICE
The "Voyager conversion kit," is used with multiple systems.
Procedure
1. Unpack the Voyager kit.
2. Use the instructions provided within the kit to reconfigure the lift.
Figure 4 Reconfiguring the portable lift with the Voyager conversion kit
CL5422
1 2
Adjusting the arms for a frontal lift
If you plan to use the mechanical lift directly in front of the cabinet, adjust the lift
arm/tray width to just under 17 inches apart to ensure that the arms will stay under
the chassis. Figure 5 on page 14 shows an example of adjusting the lift arm/tray to
just under 17 inches.
Procedure
1. Add the two arms with rollers 17 inches apart measured from the outside edge
of each arm.
2. Tighten the arms to secure them.
Adding an optional 80-drive DAE
Working with the portable lift 13

Figure 5 Adjusting the lift arm bar to just under 17 inches
1
2<17”
CL4900
Using lift on an enclosure 49" or less above the floor
You may need to adjust the lift arm position depending on the height of the enclosure
rails within the rack or cabinet.
Procedure
1. Orient the arm to the low rail position as follows:
a. Remove the bottom ball lock pin first, by pressing the plunger on the pin and
pulling the pin out. It may be necessary to wiggle the pin with the plunger
pressed to free it from its mounting hole.
b. Hold the arm with one hand while pressing the plunger on the top ball lock
pin and pulling the pin out with the other hand. It may be necessary to wiggle
the pin with the plunger pressed to free it from its mounting hole.
The arm will be free of the lift chassis.
c. Remove the arm from the lift and reverse it to achieve the desired
orientation. The adaptor will be attached to the arm. Do not remove the
adaptor plate.
d. Attach the arm to the lift chassis by aligning the mounting holes, pressing
the plunger, and inserting the ball lock pins into the holes. Insert the top pin
first.
Field Upgrade Procedure
14 Unity All Flash and Unity Hybrid Field Upgrade Procedure

Figure 6 Adjusting the arm for a low rail position
CL5441
2. Remove the rotating handle by loosening the set screw and pulling the handle
from the hex fitting.
3. Using the cordless drill that comes with the Voyager conversion kit, place the
cordless drill over the hex fitting and use the drill to raise or lower the arm to
the required height.
4. Adjust the arm of the portable lift to the approximate height of the enclosure
you intend to move.
5. Attach the tray to the lift arm.
6. Lock all four casters by pressing down on the locking tab so the lift will not roll
as the instrument is placed onto it. Refer to Locking the Casters
Figure 7 Locking the Casters
CL5423
7. Pull the enclosure onto the lift (Refer to Removing an enclosure from rails 49"
or less above the floor , and then secure the enclosure to the portable lift using
the securing straps as follows:
Adding an optional 80-drive DAE
Working with the portable lift 15

Figure 8 Removing an enclosure from rails 49" or less above the floor
CL5432
a. Place the strap around the lift and the enclosure.
b. Insert the free end of the securing strap into the slot on the ratchet
mechanism. Pull the ratchet handle down to tighten the securing strap
around the lift and the enclosure. Refer to Tightening the Straps
Figure 9 Tightening the Straps
1 2
CL5429
c. Make sure the enclosure is securely strapped to the lift before moving.
Lower the lift to its lowest point of travel.
This allows the enclosure to be moved with minimal danger of tipping over.
Field Upgrade Procedure
16 Unity All Flash and Unity Hybrid Field Upgrade Procedure

8. Unlock the casters by lifting up on the locking tabs and move the enclosure as
required. Refer to Unlocking the Casters
Figure 10 Unlocking the Casters
CL5424
9. Remove the securing strap by pulling up on the retaining key and pull the
ratchet handle upwards as needed. Refer to Removing the Straps
Figure 11 Removing the Straps
1
CL5430
2
Using the lift on an Enclosure more than 49" above the floor
If you are using an Alum-A-Lift to work on a enclosure that is more than 49 inches
above the floor, you must use the "Voyager" conversion kit and a support table with
the lower mast configuration.
Refer to Adjusting the arm for a high rail position while performing this task.
Procedure
1. If necessary, orient the arm to the high-lift position as follows:
Adding an optional 80-drive DAE
Working with the portable lift 17

Figure 12 Adjusting the arm for a high rail position
CL5422
1 2
a. Remove the bottom ball lock pin first, by pressing the plunger on the pin and
pulling the pin out. It may be necessary to wiggle the pin with the plunger
pressed to free it from its mounting hole.
b. Hold the arm with one hand while pressing the plunger on the top ball lock
pin and pulling the pin out with the other hand. It may be necessary to wiggle
the pin with the plunger pressed to free it from its mounting hole.
The arm with the adaptor attached will be free of the lift chassis.
c. Remove the arm from the lift and reverse it to achieve the desired
orientation.
d. Attach the arm to the lift chassis by aligning the mounting holes, pressing
the plunger, and inserting the ball lock pins into the holes. Insert the top pin
first.
2. Remove the rotating handle (if necessary) by loosening the set screw and
pulling the handle from the hex fitting.
3. Install and configure the arm trays as required for the lift. Refer to Adjusting the
Portable Lift for more information.
4. Lock all four casters by pressing down on the locking tab so the lift will not roll
as the instrument is placed onto it. Refer to Locking the Casters
Field Upgrade Procedure
18 Unity All Flash and Unity Hybrid Field Upgrade Procedure

Figure 13 Locking the Casters
CL5423
5. Using the cordless drill that comes with the Voyager conversion kit, place the
cordless drill over the hex fitting and use the drill to raise or lower the arm to
the required height. With the enclosure extended from the rack on the rails, pull
the enclosure from the rails and onto the lift. Secure the enclosure to the
portable lift using the securing straps as follows:
Figure 14 Removing an enclosure from rails more than 49" above the floor
CL5431
a. Place the securing strap around the lift and the enclosure.
Adding an optional 80-drive DAE
Working with the portable lift 19

b. Insert the free end of the securing strap into the slot on the ratchet
mechanism. Pull the ratchet handle down to tighten the securing strap
around the lift and the enclosure. Refer to Tightening the Straps
Figure 15 Tightening the Straps
1 2
CL5429
c. Make sure the enclosure is securely strapped to the lift before moving. Use
the cordless drill to raise the arm to lift the enclosure from the support table.
Once the enclosure is supported by the arm, lower the arm to the lowest
point that still permits travel.
This allows the enclosure to be moved with minimal danger of tipping over.
6. Unlock the casters by lifting up on the locking tabs and move the enclosure as
required. Refer to Unlocking the casters
Figure 16 Unlocking the Casters
CL5424
7. Move the enclosure to the support table. Use the drill to raise or lower the
enclosure above the support table. Move the enclosure over the support table,
and use the drill to lower the enclosure onto the table. Refer to Support Table
Field Upgrade Procedure
20 Unity All Flash and Unity Hybrid Field Upgrade Procedure
