Dell EMC Unisphere 360
Version 9.0.1
Installation Guide
REV 02

Copyright ©2014-2018 Dell Inc. or its subsidiaries. All rights reserved.
Published October 2018
Dell believes the information in this publication is accurate as of its publication date. The information is subject to change without notice.
THE INFORMATION IN THIS PUBLICATION IS PROVIDED “AS-IS.“ DELL MAKES NO REPRESENTATIONS OR WARRANTIES OF ANY KIND
WITH RESPECT TO THE INFORMATION IN THIS PUBLICATION, AND SPECIFICALLY DISCLAIMS IMPLIED WARRANTIES OF
MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE. USE, COPYING, AND DISTRIBUTION OF ANY DELL SOFTWARE DESCRIBED
IN THIS PUBLICATION REQUIRES AN APPLICABLE SOFTWARE LICENSE.
Dell, EMC, and other trademarks are trademarks of Dell Inc. or its subsidiaries. Other trademarks may be the property of their respective owners.
Published in the USA.
Dell EMC
Hopkinton, Massachusetts 01748-9103
1-508-435-1000 In North America 1-866-464-7381
www.DellEMC.com
2Dell EMC Unisphere 360 9.0.1 Installation Guide

5
About this content 7
Pre-installation considerations 9
Product description.................................................................................... 10
Before you begin.........................................................................................10
Server operating system requirements....................................................... 10
Server hardware requirements.....................................................................11
Client operating system requirements......................................................... 11
Client browser requirements........................................................................11
Setting up the PostgreSQL user on Linux.................................................... 11
Installing Unisphere 360 13
Installing Unisphere 360 on a Windows system........................................... 14
Installing Unisphere 360 on a Linux system................................................. 15
Launching Unisphere 360............................................................................16
Starting and stopping the Unisphere 360 server......................................... 17
Starting and stopping the Unisphere 360 server on Windows........ 17
Starting and stopping the Unisphere 360 server on Linux.............. 17
Upgrading Unisphere 360............................................................................17
Configuring security settings 19
Configuring X.509 certification.................................................................. 20
Using Lightweight Directory Access Protocol or Active Directory.............. 20
Configuring Certificate Revocation List for X.509 certificate-based
authentication............................................................................................. 21
Tables
Chapter 1
Chapter 2
Chapter 3
CONTENTS
Dell EMC Unisphere 360 9.0.1 Installation Guide 3

CONTENTS
4Dell EMC Unisphere 360 9.0.1 Installation Guide

Unisphere 360 server hardware requirements............................................................. 111
TABLES
Dell EMC Unisphere 360 9.0.1 Installation Guide 5

TABLES
6Dell EMC Unisphere 360 9.0.1 Installation Guide

About this content
As part of an effort to improve its product lines, Dell EMC periodically releases
revisions of its software and hardware. Therefore, some functions described in this
document might not be supported by all versions of the software or hardware
currently in use. The product release notes provide the most up-to-date information
on product features.
Contact your Dell EMC technical support professional if a product does not function
properly or does not function as described in this document.
This document was accurate at publication time. New versions of this document might
be released on the Dell EMC Online Support website. Check the Dell EMC Online
Support site https://support.EMC.com to ensure that you are using the latest version
of this document.
Purpose
This document describes how to configure and use Unisphere 360.
Related documentation
The following publications provide additional information:
l
Dell EMC Unisphere for PowerMax Release Notes
l
Dell EMC Unisphere for PowerMax Online Help
l
Dell EMC Unisphere 360 Online Help
l
Dell EMC Solutions Enabler Installation Guide
l
Dell EMC Solutions Enabler Release Notes
l
Dell EMC Solutions Enabler SRM CLI Product Guide
l
Dell EMC Solutions Enabler CLI Command Reference
l
Dell EMC PowerMax Family Security Configuration Guide
Dell EMC technical support, documentation, release notes, software updates, or
information about Dell EMC products can be obtained at https://support.emc.com
(registration required) or https://www.dellemc.com/en-us/documentation/vmax-all-
flash-family.htm.
About this content 7

Where to get help
Dell EMC support, product, and licensing information can be obtained as follows:
Product information
Dell EMC support, product, and licensing information can be obtained on the Dell EMC
Online Support site as described next. To open a service request through the Dell
EMC Online Support site, you must have a valid support agreement. Contact your Dell
EMC sales representative for details about obtaining a valid support agreement or to
answer any questions about your account.
Technical support
Dell EMC offers a variety of support options:
lSupport by Product — Dell EMC offers consolidated, product-specific information
on the Web at: https://support.EMC.com/products
The Support by Product web pages offer quick links to Documentation, White
Papers, Advisories (such as frequently used Knowledgebase articles), and
Downloads, as well as more dynamic content, such as presentations, discussion,
relevant Customer Support Forum entries, and a link to Dell EMC Live Chat.
lChat with Support — Open a Chat or instant message session with a Dell EMC
Support Engineer.
eLicensing support
To activate your entitlements and obtain your PowerMax license files, visit the Service
Center on https://support.EMC.com, as directed on your License Authorization Code
(LAC) letter emailed to you.
For help with missing or incorrect entitlements after activation (that is, expected
functionality remains unavailable because it is not licensed), contact your Dell EMC
Account Representative or Authorized Reseller.
For help with any errors applying license files through Solutions Enabler, contact the
Dell EMC Customer Support Center.
If you are missing a LAC letter, or require further instructions on activating your
licenses through the Online Support site, contact Dell EMC's worldwide Licensing
team at [email protected] or call:
lNorth America, Latin America, APJK, Australia, New Zealand: SVC4EMC
(800-782-4362) and follow the voice prompts.
lEMEA: [phone] and follow the voice prompts.
Your comments
Your suggestions help us improve the accuracy, organization, and overall quality of the
documentation. Send your comments and feedback to:
[email protected]
About this content
8Dell EMC Unisphere 360 9.0.1 Installation Guide

CHAPTER 1
Pre-installation considerations
This chapter lists some points to consider before installing Unisphere 360:
lProduct description............................................................................................ 10
lBefore you begin................................................................................................ 10
lServer operating system requirements............................................................... 10
lServer hardware requirements............................................................................ 11
lClient operating system requirements................................................................. 11
lClient browser requirements............................................................................... 11
lSetting up the PostgreSQL user on Linux............................................................11
Pre-installation considerations 9

Product description
Unisphere 360 is an on-premises management solution that provides an aggregated
view of the storage environment, as provided by the enrolled Unisphere instances.
The term Unisphere incorporates "Unisphere for PowerMax" for the management of
PowerMax and All Flash storage systems using PowerMaxOS 5978, and "Unisphere
for VMAX" for the management of VMAX All Flash and VMAX storage systems using
HYPERMAX OS 5977 and Enginuity 5876.
Unisphere 360 consolidates and simplifies management of PowerMax and All Flash
storage systems using PowerMaxOS 5978, and management of VMAX All Flash and
VMAX storage systems using HYPERMAX OS 5977 and Enginuity OS 5876.
Note
DMX arrays (arrays running Enginuity OS 5773) are not supported in Unisphere 360.
Before you begin
The following section contains information to consider before beginning the
installation.
lThe user performing the installation must have operating system administrator
permissions on the system.
lOn Linux systems, before starting the installation procedure, create the
postgres user and group. For more information about how to do this, see Setting
up the PostgreSQL user on Linux on page 11.
Server operating system requirements
Windows
The following Windows versions are supported:
lWindows Server 2016
lWindows Server 2012 R2
lWindows Server 2008 R2 (64-bit only)
Linux
Note
Before you attempt to install Unisphere 360 on Red Hat Linux 6.0 or a later release,
verify that the packages listed below are installed. Not all installer packages include
these libraries by default so it is important to verify their presence before running the
installation program. Do not attempt to run the installation process without them.
Without these items, an error may occur at the end of the product install and in some
cases the product might not function as intended. The package is:
unzip_XYZ_x86_64.rpm / corresponding package.
The following Linux versions are supported:
lRed Hat Enterprise Linux 6.7 (64-bit)
Pre-installation considerations
10 Dell EMC Unisphere 360 9.0.1 Installation Guide

lRed Hat Enterprise Linux 7.2 (64-bit)
lSUSE Linux Enterprise Server 11 (64-bit)
lSUSE Linux Enterprise Server 12 (64-bit)
Server hardware requirements
The following hardware requirements apply for Unisphere 360:
Table 1 Unisphere 360 server hardware requirements
Operating system Windows Linux
Minimum processor 2-core 1.8 GHz processor 2-core 1.8 GHz processor
Minimum available memory 16 GB 16 GB
Minimum available disk
space
120 GB 120 GB
Client operating system requirements
The following client operating systems are supported:
lWindows 7
lWindows 8
lWindows 10
Client browser requirements
The minimum browser versions supported are:
lFirefox version 59.0
lChrome version 65.0.3325
lInternet Explorer 11.0 (Desktop only)
lMicrosoft Edge 38
Setting up the PostgreSQL user on Linux
Before starting a new installation of Unisphere for PowerMax or Unisphere 360 on
Linux, the PostgreSQL user (postgres) and group (postgres), must be present. In
addition, the user must be a member of the postgres group.
Use the following commands to create the postgres group and add the postgres
user to the postgres group:
groupadd postgres
useradd -g postgres postgres
Pre-installation considerations
Server hardware requirements 11

Pre-installation considerations
12 Dell EMC Unisphere 360 9.0.1 Installation Guide

CHAPTER 2
Installing Unisphere 360
This chapter explains how to install Unisphere 360:
lInstalling Unisphere 360 on a Windows system...................................................14
lInstalling Unisphere 360 on a Linux system.........................................................15
lLaunching Unisphere 360................................................................................... 16
lStarting and stopping the Unisphere 360 server.................................................17
lUpgrading Unisphere 360................................................................................... 17
Installing Unisphere 360 13

Installing Unisphere 360 on a Windows system
The default installation method for Windows is the wizard, but you can launch the
console mode using the following command:
UNISPHERE360_version_WINDOWS_X86_64.exe -i console
To install Unisphere 360:
Procedure
1. To run the installer, double click the executable file.
2. In the Introduction page, click Next.
3. In the Choose Install Folder page, do one of the following:
lIn the Where Would You Like to Install field, type the installation path.
lClick Choose and navigate to the installation path.
4. Click Next.
5. In the Ports Configuration page, do the following:
a. In the HTTPS Port No field, type the HTTPS port number, or accept the
default value of 8470.
b. In the DB Port No field, type the database port number, or accept the
default value of 3424.
c. Click Next.
6. In the X.509 Certificate-based Client Authentication page, do one of the
following:
Note
Enable X.509 certificate-based authentication only if it is enabled on the
Unisphere for PowerMax instance. Otherwise, enrollment of the Unisphere for
PowerMax instance will fail.
lTo continue installing without configuring X.509 certificate-based
authentication, click Next.
lTo configure X.509 certificate-based authentication, complete the following
steps:
a. Select Enable certificate based client authentication.
b. Specify whether to use the CN or UPN of the client's identify.
Note that instances of the following special characters are stripped from
the alias: @:?;|<>[]+=,*/\
c. In the Admin User Name field, specify the admin user name.
The admin user name must match CN/UPN of the X.509 certificate
(minus any special characters that are stripped out) as configured in step
6.b on page 14.
This user is created in Unisphere 360 and assigned administration
privileges to bootstrap administration of the system.
d. Click Next.
Installing Unisphere 360
14 Dell EMC Unisphere 360 9.0.1 Installation Guide

After you complete the installation of Unisphere 360, further configuration is
required to use X.509 certificate-based authentication. For more information,
refer to Configuring X.509 certification on page 20.
7. In the Pre-Installation Summary page, review the summary information and
click Install. A first-time fresh installation on Windows Server 2016 may ask for
the Microsoft Visual C++ Redistributable Package. Click OK.
The installation operation completes.
8. In the Install Complete page, click Done.
After you finish
The installation operation creates a shortcut on the Windows desktop. Double-click
this shortcut to launch Unisphere 360.
Installing Unisphere 360 on a Linux system
The default installation method for Linux is the console mode, but you can launch the
wizard mode using the following command:
./UNISPHERE360_version_LINUX_X86_64.bin -i swing
To install Unisphere 360:
Procedure
1. To run the installer, run the following command:
./UNISPHERE360_version_LINUX_X86_64.bin -i console
2. In the Introduction panel, press Enter.
3. In the Choose Install Folder panel, do one of the following:
lType the installation path and press Enter.
lPress Enter to accept the default installation path.
4. In the Ports Configuration panel, do the following:
a. Type the database port number and press Enter, or press Enter to accept
the default value of 3424.
b. Type the HTTPS port number and press Enter, or press Enter to accept the
default value of 8470.
5. In the X.509 Certificate-based Client Authentication panel, do one of the
following:
Note
Enable X.509 certificate-based authentication only if it is enabled on the
Unisphere for PowerMax instance. Otherwise, enrollment of the Unisphere for
PowerMax instance will fail.
lTo continue installing without configuring X.509 certificate-based
authentication, type 1.
lTo configure X.509 certificate-based authentication, type 2 and complete
the following steps:
Installing Unisphere 360
Installing Unisphere 360 on a Linux system 15

a. Do one of the following:
nTo use the CN of the client's identity, type 1.
nTo use the UPN of the client's identity, type 2.
Note that instances of the following special characters are stripped from
the alias: @:?;|<>[]+=,*/\
b. Type the admin user name and press Enter.
The admin user name must match CN/UPN of the X.509 certificate
(minus any special characters that are stripped out) as configured in step
5.a on page 16.
This user is created in Unisphere 360 and assigned administration
privileges to bootstrap administration of the system.
After you complete the installation of Unisphere 360, further configuration is
required to use X.509 certificate-based authentication. For more information,
refer to Configuring X.509 certification on page 20.
6. In the Pre-Installation Summary panel, review the summary information and
press Enter.
The installation operation completes.
7. In the Install Complete panel, press Enter to exit the installer.
Launching Unisphere 360
Consider the following points when launching Unisphere 360:
lWhen using X.509 certificate-based authentication, ensure that the certificate for
Unisphere 360 is imported into the trust store for each Unisphere for PowerMax
to be enrolled.
lWhen using Lightweight Directory Access Protocol (LDAP) or Active Directory
(AD), ensure that you use the same user names as when signing in to Unisphere
for PowerMax using LDAP/AD. For more information about this, refer to Using
Lightweight Directory Access Protocol or Active Directory on page 20.
To launch Unisphere 360:
Procedure
1. Type the following URL in a browser:
https://host_IP|host_name:port_number/unisphere360
The port number is configured during installation. The default HTTPS port
number is 8470.
If the host IP address is an IPv6 address, surround the IP address with square
brackets, for example:
https://[2001:db8:ffff:ffff:ffff:ffff:ffff:ffff]:8470/
unisphere360
If the host IP address is an IPv4 address, type the IP address as normal, for
example:
https://198.51.100.255:8470/unisphere360
Installing Unisphere 360
16 Dell EMC Unisphere 360 9.0.1 Installation Guide

2. Do one of the following:
lAt the login window, type the Unisphere Initial Setup User username and
password.
The default username for the Unisphere Initial Setup User in Unisphere 360
is admin and the default password is admin.
lIf X.509 certificate-based user authentication is configured on the server,
the Use X.509 Client Certificate checkbox is automatically selected.
3. Click Login.
Starting and stopping the Unisphere 360 server
If required to do so, you can start and stop the Unisphere 360 server manually.
Starting and stopping the Unisphere 360 server on Windows
To start or stop the Unisphere 360 server in Windows, use the Services panel. Click
Control Panel > Administrative Tools > Services to open the Services panel.
Right-click on the EMCUnisphere360Server service. Select Start, Stop, or
Restart, as appropriate.
Alternatively, you can use the following commands to start or stop the Windows
services using the CLI:
net start " EMCUnisphere360Server"
net stop " EMCUnisphere360Server"
Starting and stopping the Unisphere 360 server on Linux
To start or stop the Unisphere 360 server in Linux, change to this directory: /etc/
init.d and use the following commands:
Action Command
Start server ./unisphere360 start
Stop server ./unisphere360 stop
Restart server ./unisphere360 restart
Upgrading Unisphere 360
Note
As part of the upgrade process, you must re-enroll all Unisphere for PowerMax
instances to enhance security and system-to-system trust.
The following upgrade paths are supported:
lV8.4.x -> V9.0.x
lV8.3.x -> V9.0.x
lV8.3.x -> V8.4.x
lV8.2.x -> V8.4.x
Installing Unisphere 360
Starting and stopping the Unisphere 360 server 17

lV8.2.x -> V8.3.x
To upgrade Unisphere 360:
Procedure
1. Take note of the currently enrolled Unisphere for PowerMax instances.
2. Navigate to the location of the kit and run the appropriate executable for your
operating system.
3. When prompted to do so, confirm that you want to upgrade the installed
features.
4. Complete the upgrade by following the instructions on screen.
After you finish
Launch Unisphere 360 and re-enroll the required Unisphere for PowerMax instances.
Installing Unisphere 360
18 Dell EMC Unisphere 360 9.0.1 Installation Guide

CHAPTER 3
Configuring security settings
This chapter explains how to configure security settings for Unisphere 360:
lConfiguring X.509 certification..........................................................................20
lUsing Lightweight Directory Access Protocol or Active Directory......................20
lConfiguring Certificate Revocation List for X.509 certificate-based
authentication.....................................................................................................21
Configuring security settings 19

Configuring X.509 certification
To use X.509 certification, complete the following
Procedure
1. When installing Unisphere 360, select the option to use certificate based client
authentication.
For more information, refer to the following topics:
lInstalling Unisphere 360 on a Windows system on page 14
lInstalling Unisphere 360 on a Linux system on page 15
2. When installing Unisphere 360, specify an administration name.
For more information, refer to the following topics:
lInstalling Unisphere 360 on a Windows system on page 14
lInstalling Unisphere 360 on a Linux system on page 15
3. Stop the Unisphere 360 server.
For more information, refer to Starting and stopping the Unisphere 360 server
on page 17.
4. Import the required certificates for Unisphere 350.
5. (Optional) Import Unisphere server certificates for any Unisphere for
PowerMax instances that you plan to enroll.
6. Start the Unisphere 360 server.
For more information, refer to Starting and stopping the Unisphere 360 server
on page 17.
Using Lightweight Directory Access Protocol or Active
Directory
Before you begin
LDAP and AD users need to be configured as external users under "domain.com
\username".
When using Lightweight Directory Access Protocol (LDAP) or Active Directory (AD)
complete the following steps:
Procedure
1. Configure LDAP or AD for a Unisphere for PowerMax instance.
2. Enroll that Unisphere for PowerMax in Unisphere 360.
3. Add users as external users to ensure that they can login to Unisphere 360.
When signing in to Unisphere for PowerMax, specify the user name in the
following format:
lAD users sign in specifying "domain\name".
Configuring security settings
20 Dell EMC Unisphere 360 9.0.1 Installation Guide
