Dell™ 1355cn/1355cnw Multifunction Color Printer
Quick Reference Guide
About Your Printer
1
11 1014 13 12
1 Operator Panel
3 Document Feeder Tray
5 Toner Access Cover
7 Power Switch
9 Paper Width Guides
11 MPF Extension
13 Front USB Port
Locating the Service Tag
23 4 5 6
1
2
3
9
9 8 7
2 Automatic Document Feeder (ADF)
4 Document Output Tray
6 Cleaning Rod
8 Front Cover
10 Length Guide
12 Multipurpose Feeder (MPF)
14 Priority Sheet Inserter (PSI)
One Touch Dial button Calls up the stored Fax number.
(Copy) button Moves to the top menu for the Copy menu.
(Fax) button Moves to the top menu for the Fax menu.
4 Data LED Lights up for incoming, outgoing, or pending Fax jobs.
5 Ready / Error LED • Lights up when the printer is ready. (Ready LED)
• Lights up when the prinetr has an error. (Error LED)
6
7
button
button
Moves a cursor or highlight to the selected position.
Moves a cursor or highlight to the selected position.
8 (Set) button Confirms the entry of values.
9 (Contacts) button Moves to the Address Book menu for the Fax and Scan services.
10 (Redial / Pause) button Redials a telephone number.
11 (Cancel) button Cancels the current processing or pending job.
12 B&W / Color LED Lights up to display which color mode is being selected.
Switches the color mode.
(Color Mode) button
(Start) button Starts a job.
(Speed Dial) button Calls up the stored telephone number.
(Backspace) buton Deletes characters and numbers.
Numeric keypad Enters characters and numbers.
AC (All Clear) button Resets the current setting, and returns to the top menu.
(Back) button Returns to a previous screen.
LCD Panel Displays various settings, instructions, and error messages.
(Scan) button Moves to the top menu for the Scan menu.
(Menu) button Moves to the top menu for the Print from USB Memory, Job Status,
and System menus.
www.dell.com | support.dell.comNovember 2010
Service Tag
13
14
15
16
17
18
19
20
21
22
604E46631/0Y6GYNA00
KB3148X03-2
Service Tag Express Service Code
xxxxxxx 000 000 000 00

4
765
Loading Letterhead
Load the letterhead in the printer with the print-side facing up. Ensure that the title on the letter head
enters the printer first.
Multipurpose Feeder (MPF) Priority Sheet Inserter (PSI)
Loading Envelopes
Load envelopes in the printer as shown below:
Envelope#10, DL, or Monarch
Multipurpose Feeder (MPF) Priority Sheet Inserter (PSI)
To prevent DL and Monarch from being wrinkled, they are recommended to be loaded with the
print-side facing up, flap opened, and facing you.
Multipurpose Feeder (MPF) Priority Sheet Inserter (PSI)
C5
Multipurpose Feeder (MPF) Priority Sheet Inserter (PSI)
Finding Information Troubleshooting
Clearing jams
available on the
Drivers and Utilities disc.
For more information, see the following documents
ÆSee "Clearing Jams"
in the
User's Guide
•
Setup Guide
Setup instructions for printer hardware. Access to Print quality and other printing problems
software and drivers. ÆSee "Troubleshooting"
•
User’s Guide
in the U
ser's Guide
Additional information about printer components,
paper jam clearance, and consumable replacement. Common error messages
ÆSee "Understanding Printer
Messages" in the
User's Guide
Identifying the Location of Paper Jams
The paper jams may occur at any of the locations shown below:
CAUTION: To avoid permanent damage to your printer, do not attempt to clear paper
jams using any tools or instruments.
3
12
1 Scanner Unit
2 Fuser
3 Fuser Release Lever
4 Rear Cover
5 ADF Cover
6 Front Cover
7 Multipurpose Feeder (MPF)
CAUTION: Do not attempt to clear jams using tools or instruments. This may permanently
damage the printer.
Printing the System Settings Page
1 In the operator panel, press the (Menu) button.
2 Press the button until System is highlighted, and then press the button.
3 Press the button until Report/List is highlighted, and then press the button.
4 Ensure that System Settings is highlighted, and then press the button.
The system settings page is printed.
Cleaning the Printer Replacing Toners
Vertical blanks in prints To replace toners
ÆSee "Maintaining Your Printer" ÆSee "Maintaining Your Printer"
in the
User's Guide
in the
User's Guide
An alert for the CTD sensor appears
ÆSee "Maintaining Your Printer"
in the
User's Guide
support.dell.com
