Dell Latitude 5300 Operation and maintenance manual

Vostro 5300
Setup and Specifications
Regulatory Model: P121G
Regulatory Type: P121G001

Notes, cautions, and warnings
NOTE: A NOTE indicates important information that helps you make better use of your product.
CAUTION: A CAUTION indicates either potential damage to hardware or loss of data and tells you how to avoid the
problem.
WARNING: A WARNING indicates a potential for property damage, personal injury, or death.
© 2020 Dell Inc. or its subsidiaries. All rights reserved. Dell, EMC, and other trademarks are trademarks of Dell Inc. or its
subsidiaries. Other trademarks may be trademarks of their respective owners.
Rev. A00

Set up your Vostro 5300
NOTE: The images in this document may differ from your computer depending on the configuration you ordered.
1. Connect the power adapter and press the power button.
NOTE: All pictures shown are for illustration purposes only. Actual product may differ in color.
NOTE: To conserve battery power, the battery might enter power saving mode. Connect the power adapter and
press the power button to turn on the computer.
2. Finish operating system setup.
For Ubuntu:
Follow the on-screen instructions to complete the setup. For more information about installing and configuring Ubuntu, see the
knowledge base articles SLN151664 and SLN151748 at www.dell.com/support.
For Windows:
Follow the on-screen instructions to complete the setup. When setting up, Dell recommends that you:
• Connect to a network for Windows updates.
NOTE: If connecting to a secured wireless network, enter the password for the wireless network access when
prompted.
• If connected to the internet, sign-in with or create a Microsoft account. If not connected to the internet, create an offline account.
• On the Support and Protection screen, enter your contact details.
3. Locate and use Dell apps from the Windows Start menu—Recommended.
Table 1. Locate Dell apps
Resources Description
My Dell
Centralized location for key Dell applications, help articles, and other important information about your
computer. It also notifies you about the warranty status, recommended accessories, and software updates
if available.
1
Set up your Vostro 5300 3

Resources Description
SupportAssist
Pro-actively checks the health of your computer’s hardware and software. The SupportAssist OS Recovery
tool troubleshoots issues with the operating system. For more information, see the SupportAssist
documentation at www.dell.com/support.
NOTE: In SupportAssist, click the warranty expiry date to renew or upgrade your warranty.
Dell Update
Updates your computer with critical fixes and latest device drivers as they become available. For more
information about using Dell Update, see the knowledge base article SLN305843 at www.dell.com/support.
Dell Digital Delivery
Download software applications, which are purchased but not pre-installed on your computer. For more
information about using Dell Digital Delivery, see the knowledge base article 153764 at www.dell.com/
support.
4 Set up your Vostro 5300

Views of Vostro 5300
Right
NOTE: All pictures shown are for illustration purposes only. Actual product may differ in color.
1. microSD-card slot
Reads from and writes to the microSD card. The computer supports the following card types:
• microSecure Digital (microSD)
• microSecure Digital High Capacity (microSDHC)
• microSecure Digital Extended Capacity (microSDXC)
2. Headset port
Connect headphones or a headset (headphone and microphone combo).
3. USB 3.2 Gen 1 port
Connect peripherals such as external storage devices and printers. Provides data transfer speeds up to 5 Gbps.
Left
NOTE: All pictures shown are for illustration purposes only. Actual product may differ in color.
1. Power-adapter port
Connect a power adapter to provide power to your computer.
2. HDMI port
Connect to a TV or another HDMI-in enabled device. Provides video and audio output.
3. USB 3.2 Gen 1 port
Connect peripherals such as external storage devices and printers. Provides data transfer speeds up to 5 Gbps.
4. USB 3.2 Gen 1 (Type-C) port with Power Delivery/DisplayPort
Connect peripherals such as external storage devices, printers, and external displays.
Supports Power Delivery that enables two-way power supply between devices. Provides up to 15 W power output that enables faster
charging.
NOTE:
The Dell Adapter USB-C to USB-A 3.0 is shipped with this computer. Use this adapter to connect legacy USB 3.0
accessories to USB (Type-C) ports on your computer.
NOTE: A USB Type-C to DisplayPort adapter (sold separately) is required to connect a DisplayPort device.
2
Views of Vostro 5300 5

Base
NOTE: All pictures shown are for illustration purposes only. Actual product may differ in color.
1. Left-click area
Press to left-click.
2. Touchpad
Move your finger on the touchpad to move the mouse pointer. Tap to left-click and two finger tap to right-click.
3. Right-click area
Press to right-click.
4. Power button with optional fingerprint reader
Press to turn on the computer if it is turned off, in sleep state, or in hibernate state.
When the computer is turned on, press the power button to put the computer into sleep state; press and hold the power button for 4
seconds to force shut-down the computer.
If the power button has a fingerprint reader, place your finger on the power button to log in.
NOTE: You can customize power-button behavior in Windows. For more information, see
Me and My Dell at
www.dell.com/support/manuals.
6 Views of Vostro 5300

Display
NOTE: All pictures shown are for illustration purposes only. Actual product may differ in color.
1. Left microphone
Provides digital sound input for audio recording and voice calls.
2. Camera
Enables you to video chat, capture photos, and record videos.
3. Camera-status light
Turns on when the camera is in use.
4. Right microphone
Provides digital sound input for audio recording and voice calls.
Views of Vostro 5300 7

Bottom
1. Speaker grills
Provides audio output.
2. Fan vents
Provides for entry of air intake.
3. Service Tag label
The Service Tag is a unique alphanumeric identifier that enables Dell service technicians to identify the hardware components in your
computer and access warranty information.
8Views of Vostro 5300

Specifications of Vostro 5300
Dimensions and weight
The following table lists the height, width, depth, and weight of your Vostro 5300.
Table 2. Dimensions and weight
Description Values
Height:
Front height 13.97 mm (0.55 in.)
Rear height 15.85 mm (0.62 in.)
Width 305.96 mm (12.04 in.)
Depth 203.40 mm (8.01 in.)
Weight (maximum) • UMA: 1.16 kg (2.56 lb)
• DSC: 1.23 kg (2.71 lb)
NOTE: The weight of your computer depends on the
configuration ordered and manufacturing variability.
Processors
NOTE: Global Standard Products (GSP) are a subset of Dell’s relationship products that are managed for availability and
synchronized transitions on a worldwide basis. They ensure the same platform is available for purchase globally. This
allows customers to reduce the number of configurations managed on a worldwide basis, thereby reducing their costs.
They also enable companies to implement global IT standards by locking in specific product configurations worldwide.
Device Guard (DG) and Credential Guard (CG) are the new security features that are only available on Windows 10 Enterprise today.
Device Guard is a combination of enterprise-related hardware and software security features. When you configure together, it locks a
device down so that it can only run trusted applications. Credential Guard uses virtualization-based security to isolate secrets (credentials)
so that only privileged system software can access them. Unauthorized access to these secrets can lead to credential theft attacks.
Credential Guard prevents these attacks by protecting NT LAN Manager (NTLM) password hashes and Kerberos Ticket Granting Tickets.
NOTE: Processor numbers are not a measure of performance. Processor availability is subject to change and may vary
by region/country.
Table 3. Processors
Description Option one Option two Option three
Processors 10th Generation Intel Core
i5-10210U
10th Generation Intel Core
i7-10510U
10th Generation Intel Core i7
Wattage 15 W 15 W 15 W
Core count 4 6 4
Thread count 888
Speed 1.6 GHz to 4.2 GHz 1.1 GHz to 4.9 GHz Up to 4.9 GHz
3
Specifications of Vostro 5300 9

Description Option one Option two Option three
Cache 6 MB 6 MB 8 MB
Integrated graphics Intel UHD Graphics Intel UHD Graphics Intel UHD Graphics
Chipset
The following table lists the details of the chipset supported by your Vostro 5300.
Table 4. Chipset
Description Values
Chipset Intel Q490
Processor 10th Generation Intel Comet Lake Core i3/i5/i7
DRAM bus width 64-bit
Flash EPROM 16 MB + 8 MB
PCIe bus Up to Gen3
Operating system
Your Vostro 5300 supports the following operating systems:
• Windows 10 Home (64-bit)
• Windows 10 Professional (64-bit)
• Ubuntu 18.04 LTS (64-bit)
Memory
The following table lists the memory specifications of your Vostro 5300.
Table 5. Memory specifications
Description Values
Memory slots Onboard system memory
Memory type Single-channel DDR4
Memory speed 2666 MHz
Maximum memory configuration 8 GB
Minimum memory configuration 4 GB
Memory configurations supported • 4 GB, 1 x 4 GB, Single-Channel DDR4, 2666 MHz
• 8 GB, 1 x 8 GB, Single-Channel DDR4, 2666 MHz
Ports and connectors
Table 6. External ports and connectors
Description Values
External:
