Setup and Features Information
Vostro 3300 — Front View
5
6
1microphones (2)
2camera light
3camera
4display
5volume control buttons
6power button
7security slot
8cooling vent
9video connector (VGA)
10 e-SATA connector (shared)
11 USB 2.0 connector
12 power and battery status lights
13 5-in-1 Secure Digital (SD)
memory card reader
14 wireless switch
15 audio connectors
16 touchpad buttons (2)
17 speaker
18 touchpad
19 keyboard
20 keyboard and device status lights
1
4
3
2
8
9
7
10
13
12
20
19
11
15
14
17
16
18
Regulatory Model: P09S, P10G, P09F, P06E
Regulatory Type: P09S001, P10G001, P09F001, P06E001
Dell™Vostro™3300/3400/3500/3700 About Warnings
WARNING: A WARNING indicates a potential
for property damage, personal injury, or death.
January 2010
CG5YYcc1.fm Page 1 Thursday, January 21, 2010 12:14 PM

FILE LOCATION: C:\Documents and Settings\kandasamy_m\Desktop\Winery_A01\Info Dev
Vostro 3300 — Back View
WARNING: Do not block, push objects into, or allow dust to accumulate in the cooling vents. Do not store your Dell computer in a low-airflow
environment, such as a closed briefcase, while it is running. Restricting the airflow can damage the computer or cause a fire. The computer
turns on the fan when the computer gets hot. Fan noise is normal and does not indicate a problem with the fan or the computer.
6
5
2
4
1cooling vent
2AC adapter connector
3USB 2.0 connector
4network connector
5optical drive/bay
6ExpressCard connector
3
1
Use the following template for Business Portables only.
Graphics and callout tables in this section are placeholders only. Work with your illustrator to replace with correct art and callouts for your platform.
CG5YYcc1.fm Page 2 Thursday, January 21, 2010 12:14 PM

FILE LOCATION: C:\Documents and Settings\kandasamy_m\Desktop\Winery_A01\Info Dev
Vostro 3400/3500 — Front View
1
4
5
6
9
10
8
11
16
19
21
1microphones (2)
2camera light
3camera
4display
5volume control buttons
6power button
7right speaker
8network connector
9USB 2.0 connector
10 optical drive/bay
11 fingerprint reader
12 ExpressCard connector
13 8-in-1 Secure Digital (SD)
memory card reader
14 power and battery status lights
15 audio connectors
16 wireless switch
17 touchpad buttons (2)
18 touchpad
19 keyboard
20 left speaker
21 keyboard and device status lights
3
2
12
13
14
15
18
17
7
20
CG5YYcc1.fm Page 3 Thursday, January 21, 2010 12:14 PM

FILE LOCATION: C:\Documents and Settings\kandasamy_m\Desktop\Winery_A01\Info Dev
Vostro 3400/3500 — Back View
7
6
4
2
3
1security cable slot
2AC adapter connector
3cooling vent
4video connector (VGA)
5e-SATA connector (shared)
6HDMI connector
7USB 2.0 connectors (2)
5
1
CG5YYcc1.fm Page 4 Thursday, January 21, 2010 12:14 PM

FILE LOCATION: C:\Documents and Settings\kandasamy_m\Desktop\Winery_A01\Info Dev
Vostro 3700 — Front View
1microphones (2)
2camera light
3camera
4display
5volume control lights
6power button
7right speaker
8network connector
9USB 2.0 connectors (2)
10 optical drive/bay
11 fingerprint reader
12 IEEE 1394 connector
13 ExpressCard slot
14 8-in-1 Secure Digital (SD) memory
card reader
15 power and battery status lights
16 audio connectors
17 wireless switch
18 touchpad buttons (2)
19 touchpad
20 keyboard
21 left speaker
22 keyboard and device status lights
1
4
5
6
9
10
8
12
17
20
22
3
2
14
16
19
18
13
11
15
21
7
CG5YYcc1.fm Page 5 Thursday, January 21, 2010 12:14 PM

FILE LOCATION: C:\Documents and Settings\kandasamy_m\Desktop\Winery_A01\Info Dev
Vostro 3700 — Back View
1security cable slot
2AC adapter connector
3cooling vent
4video connector (VGA)
5e-SATA connector (shared)
6HDMI connector
7USB 2.0 connectors (2)
7
6
4
2
3
5
1
CG5YYcc1.fm Page 6 Thursday, January 21, 2010 12:14 PM

FILE LOCATION: C:\Documents and Settings\kandasamy_m\Desktop\Winery_A01\Info Dev
1Connect the AC adapter to the
AC adapter connector on the portable
computer and to the electrical outlet.
2Connect the network cable
(optional).
3Connect USB devices, such as a
mouse or a keyboard (optional).
4Connect IEEE 1394 devices, such as a
DVD player (optional).
5Open the computer display and
press the power button to turn on
the computer.
NOTE: It is recommended that you
turn on and shut down your computer
at least once before you install any
cards or connect the computer to a
docking device or other external
device, such as a printer.
Quick Setup
WARNING: Before you begin any of
the procedures in this section, read the
safety information that shipped with
your computer. For additional best
practices information, see
www.dell.com/regulatory_compliance.
WARNING: The AC adapter works with
electrical outlets worldwide. However,
power connectors and power strips vary
among countries. Using an incompatible
cable or improperly connecting the cable
to the power strip or electrical outlet may
cause fire or equipment damage.
CAUTION: When you disconnect the
AC adapter cable from the computer,
grasp the connector, not the cable
itself, and pull firmly but gently to avoid
damaging the cable. When you wrap the
AC adapter cable, ensure that you
follow the angle of the connector on the
AC adapter to avoid damaging the cable.
NOTE: Some devices may not be
included if you did not order them.
CG5YYcc1.fm Page 7 Thursday, January 21, 2010 12:14 PM

FILE LOCATION: C:\Documents and Settings\kandasamy_m\Desktop\Winery_A01\Info Dev
Specifications
NOTE: Offerings may vary by region. For more information
regarding the configuration of your computer, click Start→
Help and Support and select the option to view information
about your computer.
System Information
Processor type Intel®Core™ i3
Intel Core i5
Intel Core i7
(Quad-core for Vostro 3700 only)
Chipset Intel HM57
Video
Video type integrated on system board and
discrete video card
Video controller
UMA
Discrete
Intel Graphics Media Accelerator HD
NVIDIA™ GeForce™ 310M
NVIDIA GeForce GT 330M (Vostro 3700 only)
Memory
Type DDR3 SDRAM with 1066 MHz
Module connectors two SODIMM slots
Module capacity 1 GB, 2 GB, or 4 GB
Minimum memory 1 GB
Maximum memory 8 GB
NOTE: Only 64-bit operating systems can detect memory capacities
greater than 4 GB.
Battery
Vostro 3300
Ty p e 4-cell "smart" lithium ion (2.8 AHr)
8-cell "smart" lithium ion (2.8 AHr)
Depth
4-cell
43.00 mm (1.69 inches)
8-cell 42.63 mm (1.67 inches)
Height
4-cell
19.60 mm (0.77 inches)
8-cell 42.10 mm (1.65 inches)
Width
4-cell
205.00 mm (8.07 inches)
8-cell 276.00 mm (10.86 inches)
Weight
4-cell
231.00 g (0.51 lb)
8-cell 446.00 g (0.98 lb)
Voltage
4-cell/8-cell
14.8 V
Vostro 3400/3500
Ty p e 4-cell "smart" lithium ion (2.6 AHr)
6-cell "smart" lithium ion (2.6 AHr)
9-cell "smart" lithium ion (2.8 AHr)
Depth
4-cell/6-cell/9-cell
57.80 mm (2.27 inches)
CG5YYcc1.fm Page 8 Thursday, January 21, 2010 12:14 PM

FILE LOCATION: C:\Documents and Settings\kandasamy_m\Desktop\Winery_A01\Info Dev
Height
4-cell/6-cell
20.80 mm (0.81 inch)
9-cell 40.15 mm (1.58 inches)
Width
4-cell/6-cell/9-cell
255.60 mm (10.06 inches)
Weight
4-cell
250.00 g (0.55 lb)
6-cell 340.00 g (0.75 lb)
9-cell 504.50 g (1.11 lb)
Voltage
4-cell
14.8 V
6-cell/9-cell 11.1 V
Vostro 3700
Ty p e 6-cell "smart" lithium ion (2.6 AHr)
9-cell "smart" lithium ion (2.8 AHr)
Depth
6-cell
57.80 mm (2.27 inches)
9-cell 57.80 mm (2.27 inches)
Height
6-cell
20.80 mm (0.82 inch)
9-cell 40.15 mm (1.58 inches)
Battery (continued)
Width
6-cell/9-cell
255.60 mm (10.06 inches)
Weight
6-cell
340.00 g (0.75 lb)
9-cell 504.50 g (1.11 lb)
Voltage
6-cell/9-cell
11.1 V
Temperature range:
Operating 0 °C to 35 °C (32 °F to 95 °F)
Storage –40 °C to ~65 °C (–40 °F to ~149 °F)
Coin-cell battery 3 V CR2032 lithium coin cell
AC Adapter
Input voltage 100–240 VAC
Input current (maximum) 2.5 A
Input frequency 50–60 Hz
Output power 65 W, 90 W, or 130 W
NOTE: 130 W AC power adapter is available for Vostro 3700 only.
Output current
65 W 4.34 A (maximum at 4-second pulse)
3.34 A (continuous)
90 W 5.62 A (maximum at 4-second pulse)
4.62 A (continuous)
130 W 6.70 A (continuous)
Battery (continued)
CG5YYcc1.fm Page 9 Thursday, January 21, 2010 12:14 PM

FILE LOCATION: C:\Documents and Settings\kandasamy_m\Desktop\Winery_A01\Info Dev
Depth
65 W 57.80 mm (2.27 inches)
90 W 70.00 mm (2.75 inches)
130 W 76.20 mm (3.00 inches)
Height
65 W 28.30 mm (1.11 inches)
90 W 22.60 mm (0.88 inches)
130 W 25.40 mm (1.00 inch)
Width
65 W 137.20 mm (5.40 inches)
90 W 147.00 mm (5.78 inches)
130 W 154.70 mm (6.09 inches)
Rated output voltage 19.5 +/– 1.0 VDC
Temperature range
Operating 0 °C to 35 °C (32 °F to 95 °F)
Storage –40 °C to 65 °C (–40 °F to 149 °F)
Physical
Vostro 3300
Depth 229.00 mm (9.01 inches)
Height 20.10 mm–28.60 mm (0.79 inches–1.12 inches)
with 4-cell
AC Adapter (continued)
Width 325.00 mm (12.79 inches)
Weight 1.80 kg (3.96 lb)
with 4-cell and air-bay.
Vostro 3400
Depth 242.2 mm (9.53 inches)
Height 21.90 mm–29.50 mm (0.86 inch–1.16 inches)
with 4-cell/6-cell battery and out-of-battery area
Width 339.00 mm (13.34 inches)
Weight 2.05 kg (4.51 lb)
with 4-cell and media drives.
Vostro 3500
Depth 250.0 mm (9.84 inches)
Height 22.90 mm–31.90 mm (0.90 inches–1.25 inches)
with 6-cell battery and out-of-battery area
Width 375.00 mm (14.76 inches)
Weight 2.30 kg (5.07 lb)
with 4-cell and media drives.
Vostro 3700
Depth
271.0 mm (10.66 inches)
Height 26.80 mm–34.40 mm (1.05 inches–1.35 inches)
Width 410.8 mm (16.17 inches)
Weight
2.90 kg (6.39 lb)
with 6-cell and media drives.
NOTE: Optical drive includes the optical drive, bracket, and bezel.
Physical (continued)
CG5YYcc1.fm Page 10 Thursday, January 21, 2010 12:14 PM

FILE LOCATION: C:\Documents and Settings\kandasamy_m\Desktop\Winery_A01\Info Dev
Finding More Information and Resources
See the safety and regulatory documents that shipped with your computer
and the regulatory compliance website at
www.dell.com/regulatory_compliance for more information on:
• Safety best practices
• Warranty
• Terms and Conditions
• Regulatory certification
• Ergonomics
• End User License Agreement
________________
Information in this document is subject to change without notice.
© 2009–2010 Dell Inc. All rights reserved. Printed in China.
Printed on recycled paper.
Reproduction of these materials in any manner whatsoever without the written
permission of Dell Inc. is strictly forbidden.
Trademarks used in this text: Dell, the DELL logo, and Vo s t r o are trademarks
of Dell Inc.; Bluetooth is a registered trademark owned by Bluetooth SIG, Inc.
and is used by Dell under license; Intel is a registered trademark and Core is a
trademark of Intel Corporation in the U.S. and other countries. NVIDIA and
GeForce are trademarks of NVIDIA Corporation in the U.S. and other
countries.
Other trademarks and trade names may be used in this document to refer to
either the entities claiming the marks and names or their products. Dell Inc.
disclaims any proprietary interest in trademarks and trade names other
than its own.
Environmental
Temperature range
Operating 0 °C to 35 °C (32 °F to 95 °F)
Storage –40 °C to ~65 °C (–40 °F to ~149 °F)
Relative humidity
Operating 10% to 90% (noncondensing)
Storage 5% to 95% (noncondensing)
CG5YYcc1.fm Page 11 Thursday, January 21, 2010 12:14 PM

FILE LOCATION: C:\Documents and Settings\kandasamy_m\Desktop\Winery_A01\Info Dev
CG5YYcc1.fm Page 12 Thursday, January 21, 2010 12:14 PM
