Audio Board
Dell™Vostro™3400ServiceManual
Removing the Audio Board
1. Follow the procedures in Before Working Inside Your Computer.
2. Remove the battery.
3. Remove the base cover.
4. Remove the hard drive assembly.
5. Remove the optical drive.
6. Remove the keyboard.
7. Remove the palm rest.
8. Remove the screw that secures the audio board to the palm rest.
9. Disconnect the speaker cable from its connector on the audio board.
WARNING: Before working inside your computer, read the safety information that shipped with your computer. For additional safety best
practices information, see the Regulatory Compliance Homepage at www.dell.com/regulatory_compliance.

Great user manuals database on UserManuals.info
10. Gently pry the latch that secures the audio board to the computer.
11. Lift the audio board up and away from the computer.

Great user manuals database on UserManuals.info
12. Open the clip that secures the audio board data cable to the audio board.
13. Disconnect the audio board data cable from its connector on the audio board.

Great user manuals database on UserManuals.info
Replacing the Audio Board
To replace the audio board, perform the above steps in reverse order.
