DellTM UltraSharpTM 3007WFP-HC 30” Widescreen Flat Panel Monitor
Displays
Dell
TM
UltraSharp
TM
3007WFP-HC widescreen flat panel monitor features best-in-
class performance with its 92% colour gamut, 1000:1 contrast ratio, high definition
resolution up to 2560 x 1600
6
and a wide-aspect 30 inch screen. It is ideal for CAD-CAM,
3D modeling, pre-press editing, video editing and both consumer & professional
photographers. This good looking, clean-cut flat panel monitor enables the most
comfortable viewing position with a height adjustable stand, swivel and tilt features.
Uncompromising Front-of-Screen Performance
•UltraSharp 30” Widescreen
- About 52% more screen area than Dell 2407WFP.
2
•92% High colour Gamut delivers rich and life-like colours.
- Reds, greens and blues are deep and vibrant.
- Accurate colour representation for content creation, video & photo editing and desktop
publishing.
- Engaging video and photo experience with captivating colours.
•Fast response time, 8ms (typical) grey-to-grey
- Enables crisp clear images when viewing fast motion video such as gaming or video
editing.
•High contrast ratio, 1000:1
- Images have vivid colour detail, great colour accuracy and uniformity.
•Ultra High Resolution, up to 2560 x 1600
6
(WQXGA Widescreen Format)
Note: For WQXGA resolution, customer’s PC must have a dual-link DVI graphics card
that supports 2560 x 1600 resolution.
- 77% more content area compared to Dell 2407WFP.
3
- Allows viewing of lots of detail without scrolling up/down or left/right.
- Viewing of multiple applications on one screen helps to improve productivity and reduce
the need for dual-monitor displays.
- A 4-megapixel monitor
4
that shows true resolution of megapixel photos.
- Higher definition than HD Television to meet the most stringent video needs.
5
Enhanced Multimedia, Video and Graphics Experience
• Dual Link DVI (Digital) connector helps to ensure high quality image (less jitter).
• HDCP enables viewing of protected high-definition content.
• Easy attachment of optional Dell flat panel attached sound bar.
Designed for Comfort and Convenience
• 4 x USB 2.0 high speed ports for easy access to connect peripheral devices such as cameras,
USB keys or mouse.
• Integrated 9-in-2 card reader/slots allow easy access to download photos or files, no need to
reach under the desk.
• Comprehensive flexibility of height adjustability (90mm up or down), swivel (60
o
left and
right) and tilt (3
o
forward and 19
o
backward).
Quality
Dell-branded monitors are
designed to our exacting quality
standards and manufactured by the
world’s foremost suppliers, who
must pass Dell’s stringent quality
audit. All Dell monitors meet or
exceed relevant industry
standards.
Reliability
Dell-branded monitors undergo
exhaustive testing for performance,
reliability, durability and
compatibility with Dell systems.
Under our H.A.L.T (Highly
Accelerated Life Cycle Testing)
regimen, Dell engineers push our
monitors well past specified
tolerance limits for heat, cold,
vibration, shocks and drops, to
ensure that they can withstand
real-world conditions.
Price-Performance Value
Dell’s enormous buying power and
direct business model allows us to
offer high quality monitors at low
prices. Dealing with Dell, the
world’s largest Flat Panel
provider
1
, means a single point of
contact and accountability, and the
peace of mind of purchasing from
a stable and reliable technology
partner.
See Important Information on Page 3

DETAILED SPECIFICATIONS
92%colour Gamut
Tilt, Swivel, Height AdjustableStand
4 x Universal Serial Bus (USB) 2.0 Ports, 9-in-2 card
reader, Kensington security port
Other Connectors / Features
100 to 240 VAC / 50 Hz / 60 Hz + 3 Hz / 1.6A (Max.)AC input voltage
Operating (Typical Maximum)
Less than 3W- Active Off
49.31 kHz Horizontal, 59.91 Hz VerticalVESA, 1280 x 800
98.71 kHz Horizontal, 59.97 VerticalVESA, 2560 x 1600
641.28mm (25.25 inches)Horizontal
400.8mm (15.78 inches)Vertical
YES (100mm)VESA Mounting Support
Dual Link DVI-D with HDCP ReadyConnector Type
Less than 1W- Switched Off
Preset Display Area:
0.250mmPixel Pitch
178
o
(vertical), 178
o
(horizontal)Viewing Angle (Typical)
16 Kg (35.24 Ib)Weight (with packaging)
11.38 Kg (25.07 Ib)Weight (monitor only)
559.7 (extended) x 469.7 (compressed) x 690 x 200Dimensions (H x H x W x D) mm
22 (extended) x 18.49 (compressed) x 27.26 x 7.87Dimensions (H x H x W x D) Inch
Preset Display Modes:
2560 x 1600
6
at 60 HzOptimal Resolution
60 HzVertical Scan Frequency Hz
49.31 kHz and 98.71 kHz (automatic)Horizontal Scan Frequency kHz
1000:1Contrast Ratio (Typical)
300cd/m
2
TypicalLuminance (Brightness)
8ms grey to grey, 12ms black to blackResponse Type (Typical)
30 inches (30-inch)Monitor Size (Viewable Image
Screen)
3007WFP-HCModel Name and Number
Flat Panel DisplayProduct Category
• Ultra-Resolution Widescreen Helps
Improve Productivity!
• A 4 megapixel monitor
4
that shows
true resolution of megapixel photos!
Recycling: Dell recommends that customers dispose of their used computer hardware,
including monitors, in an environmentally sound manner. Potential methods include
reuse of parts or whole products and recycling of product, components and/or
materials. For more information, please visit http://dell.com/recycling_programs and
www.dell.com/environment.
See Important Information on Page 3

Important Information
Dell cannot be responsible for typography and photography.
1. DisplaySearch Q2 2006 Quarterly Desktop Monitor Report, “No.1 Worldwide LCD Monitor
Shipment Brand Ranking for Q1 2006”, May 2006.
2. 52% more viewing area claim: Viewing area comparison based on Dell 3007WFP-HC area of
~257,025mm/398” (~641.28mm/25.25” Length, 400.8mm/15.78” Height) and Dell 2407WFP
area of 167,962mm/259” (~518.4mm/20.4” Length, 324mm/12.7” Height).
3. 77% more content claim: Content comparison based on Dell 3007WFP-HC pixel count of
4,096,000 (2560 Horizontal x 1600 Vertical) and Dell 2407WFP pixel count of 2,304,000
(1920 Horizontal x 1200 Vertical).
4. 3007WFP-HC’s highest resolution, 2560 x 1600 = 4,096,000 pixels
5. HD Television highest resolution is 1080p while 3007WFP-HC is 1600p (2560 x 1600
resolution).
6. 3007WFP-HC requires a dual-link DVI graphics card that supports 2560 x 1600 resolution.
