Dell S5000 Series User manual

Dell S5000 Series Servers for SAP HANA
Customer Service Guide
Regulatory Model: M3S2G8, M3UX16
September 2022
Rev. A01

Copyright
©2022 Dell Inc. or its subsidiaries. All rights reserved. Dell Technologies, Dell, and other trademarks are trademarks of Dell Inc.
or its subsidiaries. Other trademarks may be trademarks of their respective owners.

WARNING: Please read carefully the safety instructions in the
Multilingual Safety Notices Guide before you
perform the procedures described in this document.
Intended audience
This document is intended for use by administrators and operators.
Related documents
For the most recent product information, documentation, firmware updates, software fixes, and service offers, see the Dell
Technologies Support Site.
Preface
Preface 3

Contents i
Table of Contents
Chapter 1. Servicing Compute Unit Components 1-1...............................
1.1. Servicing a FDB Disk 1-1...................................................
1.1.1. Removing a Disk 1-2..............................................
1.1.2. Installing a Disk 1-5...............................................
1.2. Servicing a Front Disk Blade (FDB) 1-7.....................................
1.2.1. Removing a FDB 1-8..............................................
1.2.2. Installing a FDB 1-11...............................................
1.3. Servicing a Memory Module 1-14............................................
1.3.1. Removing a Memory Module 1-15...................................
1.3.2. Installing a Memory Module 1-24...................................
1.4. Servicing a USB Raid SD Card (URS) 1-33...................................
1.4.1. Removing a USB Raid SD Card (URS) 1-34..........................
1.4.2. Installing a USB Raid SD Card (URS) 1-44...........................
Chapter 2. Servicing Optional Unit Components 2-1...............................
2.1. Removing a SAS fan assembly 2-2.........................................
2.2. Installing a SAS fan assembly 2-5..........................................
Chapter 3. Servicing Rear Components 3-1.........................................
3.1. Servicing a Power Supply Unit (PSU) 3-1...................................
3.1.1. Removing a PSU 3-2..............................................
3.1.2. Installing a PSU 3-3...............................................
3.2. Servicing a Phy Ethernet Board (PEB) 3-5..................................
3.2.1. Removing a PEB 3-5...............................................
3.2.2. Installing a PEB 3-7...............................................
3.3. Servicing a Phy Ethernet Board SFP+ (PEBS) 3-9...........................
3.3.1. Removing a PEBS 3-10.............................................
3.3.2. Installing a PEBS 3-12..............................................
3.4. Servicing a PCIe Blade 3-14.................................................
3.4.1. Removing a PCIe Blade 3-15........................................
3.4.2. Installing a PCIe Blade 3-17........................................
3.5. Servicing a sWitch Ethernet One Gigabit (WEO) 3-19........................
3.5.1. Removing a sWitch Ethernet One Gigabit (WEO) 3-19...............
3.5.2. Installing a sWitch Ethernet One Gigabit (WEO) 3-21................
Chapter 4. Servicing UBox Components 4-1........................................
4.1. Servicing a UBox Power Supply Unit (PSU) 4-1.............................
4.1.1. Removing a UBox PSU 4-2.........................................
4.1.2. Installing a UBox PSU 4-3.........................................
4.2. Servicing a UBox UNB fan module 4-5......................................
4.2.1. Removing a UBox UNB fan module 4-6.............................
4.2.2. Installing a UBox UNB fan module 4-8.............................

ii Customer Service Guide
Chapter 5. Other Maintenance Tasks 5-1...........................................
5.1. Resetting the Baseboard Management Controller (BMC) 5-1................
5.1.1. Restarting the BMC 5-2............................................
5.1.2. Resetting the BMC to Default Factory Settings 5-3..................
5.2. Resetting the Local Management Controller (LMC) 5-4......................
5.2.1. Using the Reset Button 5-5........................................
5.2.2. Using the Server Hardware Console (SHC) 5-5.....................
5.2.3. Using the Command Line 5-6......................................
5.3. Recovering Firmware 5-7..................................................
5.3.1. Recovering the BMC Firmware 5-8.................................
5.3.2. Recovering the BIOS Firmware 5-9................................
5.3.3. Recovering the PEB or PEBS Flash Firmware 5-10....................
5.3.4. Recovering the LMB Firmware 5-11.................................

Chapter 1. Servicing Compute Unit Components 1-1
Chapter 1. Servicing Compute Unit Components
1.1. Servicing a FDB Disk
Important ATTENTION: Please read carefully the safety instructions
before you perform the procedures described in this
manual.
Multilingual Safety Notices Guide
C009 CAUTION
C009:
Cabinet doors must remain locked at all times except during
maintenance operations.
Qualified personnel only are authorized to open the cabinet doors.
C004 CAUTION
C004:
Static electricity can damage the server and other electronic devices. To
avoid damage, keep static-sensitive devices in their static-protective
packages until you are ready to install them.
To reduce the possibility of damage from electrostatic discharge,
observe the following precautions:
Limit your movement. Movement can cause static electricity to build up
around you.
Wear an electrostatic-discharge wrist strap.
Handle the device carefully, holding it by its edges or its frame.
Do not touch solder joints, pins, or exposed circuitry.
Do not leave the device where others can handle and damage it.
While the device is still in its static-protective package, touch it to an
unpainted metal surface on the outside of the server for at least 2
seconds. This drains static electricity from the package and from your
body.
Remove the device from its package and install it directly into the
server without setting down the device. If it is necessary to set down
the device, put it back into its static-protective package. Do not place
the device on the server cover or on a metal surface.
Take additional care when you handle devices during cold weather.
Heating reduces indoor humidity and increases static electricity.
See Description Guide to locate the FDB disk

1-2 Customer Service Guide
1.1.1. Removing a Disk
Required Tools
None
Procedure
1. Unpack the new component on a clean ESD-protected work surface
2. Open the cabinet front door
3. Remove the bezel
1. Press the latches (A) to unlock the bezel

Chapter 1. Servicing Compute Unit Components 1-3
2. Remove the bezel
4. Remove the disk from the Front Disk Blade (FDB)
1. Push the latch to the right to unlock the disk.

1-4 Customer Service Guide
2. Remove the disk by using its latch.

Chapter 1. Servicing Compute Unit Components 1-5
1.1.2. Installing a Disk
Required Tools
None
Procedure
1. Take hold of the new component
2. Install the disk
Carefully push the disk into the Front Disk Blade (FDB) until it stops and the
latch locks.

1-6 Customer Service Guide
3. Reattach the bezel
1. Put the bezel back into place.
2. Clip the latches (A) to secure the bezel.
4. Close the cabinet front door

Chapter 1. Servicing Compute Unit Components 1-7
1.2. Servicing a Front Disk Blade (FDB)
Important ATTENTION: Please read carefully the safety instructions
before you perform the procedures described in this
manual.
Multilingual Safety Notices Guide
C009 CAUTION
C009:
Cabinet doors must remain locked at all times except during
maintenance operations.
Qualified personnel only are authorized to open the cabinet doors.
C004 CAUTION
C004:
Static electricity can damage the server and other electronic devices. To
avoid damage, keep static-sensitive devices in their static-protective
packages until you are ready to install them.
To reduce the possibility of damage from electrostatic discharge,
observe the following precautions:
Limit your movement. Movement can cause static electricity to build up
around you.
Wear an electrostatic-discharge wrist strap.
Handle the device carefully, holding it by its edges or its frame.
Do not touch solder joints, pins, or exposed circuitry.
Do not leave the device where others can handle and damage it.
While the device is still in its static-protective package, touch it to an
unpainted metal surface on the outside of the server for at least 2
seconds. This drains static electricity from the package and from your
body.
Remove the device from its package and install it directly into the
server without setting down the device. If it is necessary to set down
the device, put it back into its static-protective package. Do not place
the device on the server cover or on a metal surface.
Take additional care when you handle devices during cold weather.
Heating reduces indoor humidity and increases static electricity.
See Description Guide to locate the FDB.

1-8 Customer Service Guide
1.2.1. Removing a FDB
W074 WARNING
W074:
This operation must be performed quickly. Risk of overheating.
W085 WARNING
W085:
Disks must be removed before the front disk blades (FDB). Please
comply with the procedure.
Required Tools
None
Procedure
1. Unpack the new component on a clean ESD-protected work surface
2. Open the cabinet front door
3. Remove the bezel
1. Press the latches (A) to unlock the bezel

Chapter 1. Servicing Compute Unit Components 1-9
2. Remove the bezel
4. Remove both disks
For each disk, perform the following steps.
1. Push the latch to the right to unlock the disk.

1-10 Customer Service Guide
2. Remove the disk by using its latch.
5. Keep the disks in a safe place
6. Remove the FDB
1. Carefully turn the FDB handle outwards.
2. Pull the FDB out using the FDB handle.

Chapter 1. Servicing Compute Unit Components 1-11
1.2.2. Installing a FDB
W074 WARNING
W074:
This operation must be performed quickly. Risk of overheating.
W085 WARNING
W085:
Disks must be removed before the front disk blades (FDB). Please
comply with the procedure.
Required Tools
None
Procedure
1. Take hold of the new component
2. Install the FDB
1. Push the FDB into the main box until it stops.

1-12 Customer Service Guide
2. Turn the FDB handle inwards to secure the FDB in place.
3. Install both disks
Carefully push the disk into the Front Disk Blade (FDB) until it stops and the
latch locks.

Chapter 1. Servicing Compute Unit Components 1-13
4. Reattach the bezel
1. Put the bezel back into place.
2. Clip the latches (A) to secure the bezel.
5. Close the cabinet front door

1-14 Customer Service Guide
1.3. Servicing a Memory Module
Important ATTENTION: Please read carefully the safety instructions
before you perform the procedures described in this
manual.
Multilingual Safety Notices Guide
C009 CAUTION
C009:
Cabinet doors must remain locked at all times except during
maintenance operations.
Qualified personnel only are authorized to open the cabinet doors.
C004 CAUTION
C004:
Static electricity can damage the server and other electronic devices. To
avoid damage, keep static-sensitive devices in their static-protective
packages until you are ready to install them.
To reduce the possibility of damage from electrostatic discharge,
observe the following precautions:
Limit your movement. Movement can cause static electricity to build up
around you.
Wear an electrostatic-discharge wrist strap.
Handle the device carefully, holding it by its edges or its frame.
Do not touch solder joints, pins, or exposed circuitry.
Do not leave the device where others can handle and damage it.
While the device is still in its static-protective package, touch it to an
unpainted metal surface on the outside of the server for at least 2
seconds. This drains static electricity from the package and from your
body.
Remove the device from its package and install it directly into the
server without setting down the device. If it is necessary to set down
the device, put it back into its static-protective package. Do not place
the device on the server cover or on a metal surface.
Take additional care when you handle devices during cold weather.
Heating reduces indoor humidity and increases static electricity.
See Description Guide to locate the memory module.
