Dell™ PowerVault™ 725N NAS Systems
Upgrading Your 39160
SCSI Card Firmware

Notes, Notices, and Cautions
NOTE: A NOTE indicates important information that helps you make better use of your computer.
NOTICE: A NOTICE indicates either potential damage to hardware or loss of data and tells you
how to avoid the problem.
CAUTION: A CAUTION indicates a potential for property damage, personal injury,
or death.
____________________
Information in this document is subject to change without notice.
© 2002 Dell Computer Corporation. All rights reserved.
Reproduction in any manner whatsoever without the written permission of Dell Computer Corporation is strictly forbidden.
Trademarks used in this text: Dell, the DELL logo, PowerVault, and Dell OpenManage are trademarks of Dell Computer
Corporation; Microsoft and Windows are registered trademarks of Microsoft Corporation; Intel is a registered trademark
of Intel Corporation.
Other trademarks and trade names may be used in this document to refer to either the entities claiming the marks and
names or their products. Dell Computer Corporation disclaims any proprietary interest in trademarks and trade names
other than its own.
October 2002 Rev. A00

Upgrading Your 39160 SCSI Card Firmware 1-1
Depending on your environment, you can use either of the following methods to update
your firmware on the 39160 SCSI card.
• Use a dedicated system running the Microsoft®Windows®2000 operating system
(recommended).
• Use a system running Windows 2000 on the same network.
Disabling Console Redirection
Before you update your 39160 firmware, you must disable console redirection in the BIOS.
To disable console redirection, perform the following steps:
1Shut down your NAS system.
2Attach a keyboard, mouse, and monitor to your NAS system.
3Turn on your NAS system.
4On the keyboard connected to the NAS system, press <F2> immediately after the
following message appears:
Press <F2> to enter the Function Select menu.
5From the Function Select menu, select 1.
6In the BIOS Setup Utility, press the right-arrow key until Advanced is selected.
7Press the down-arrow key until Remote Access Configuration is selected and press
Enter.
8Ensure that Remote Access is selected and press Enter.
9Select Disabled and press Enter.
10 Press <F10> to exit the BIOS Setup Utility and select OK to save the changes.
To enable console redirection after the 39160 firmware is updated, perform step 1 through
step 10, except select Serial (ANSI) instead of Disabled in step 9.
Using a Dedicated System Running Windows 2000
Requirements
• Crossover cable included with your NAS system
• Client system running Windows 2000 (Professional or Server Family)
•Resource CD included with your NAS system

1-2 Upgrading Your 39160 SCSI Card Firmware
www.dell.com | support.dell.com
Procedure
To restore your NAS system to the Dell default settings, perform the following steps:
1Connect a client system running Windows 2000 to the NAS system.
aShut down the NAS system, and do not turn it back on until instructed.
bTurn off the client system, if it is running.
cConnect the crossover cable (labeled "Cross Over Ethernet Cable") to the
Ethernet port labeled "LAN 1" on the NAS system and the Ethernet port on the
client system.
2Connect a keyboard, monitor, and mouse to the NAS system.
For information about system connectors, see your User’s Guide.
3Turn on the client system running Windows 2000.
4Log in to the client system with an account that has administrator privileges.
5Create a new user with the name pv725 and the password set to password:
aFrom the desktop of your client system, right-click My Computer, and then select
Manage.
bOn the left side of the Computer Management window, double-click Local Users
and Groups.
cRight-click Users and select New User.
dIn the New User window, type pv725 as the user name.
eTy p e password for the password, and type it again in the Confirm password
field.
fClear the User must change password at next logon check box.
gClick Create and then click Close.
6Change the name of the client system running Windows 2000 to pv725rec:
aFrom the desktop of your client system, right-click My Computer, and then select
Properties.
bIn the System Properties window, click Network Identification.
cClick Properties.
dIn the Identification Changes window, type pv725rec for the system name.
eClick OK, but do not reboot when prompted.
fClick OK to close the Properties window.

Upgrading Your 39160 SCSI Card Firmware 1-3
7Change the IP address on the network adapter of the client system to 10.40.10.1, the
subnet mask to 255.255.255.0, and the gateway to 10.40.10.1:
aFrom the desktop of the client system, right-click My Network Places and select
Properties.
bIn the Network and Dial-up Connections window, right-click the network
interface controller that you connected to the NAS system with the crossover
cable in step 1.
cClick Properties.
dIn the Local Area Connection Properties window, click Internet Protocol
(TCP/IP), and then click Properties.
eClick Use the following IP address.
fFor IP address, type 10.40.10.1.
gFor Subnet mask, type 255.255.255.0.
hFor Default Gateway, type 10.40.10.1.
iClick OK, and then click OK to close the Local Area Connection Properties
window.
jIf you are prompted to reboot the client system, click No.
8Create a share for the SCSI firmware:
aIf you are not already logged in, log in to the client system with an account that
has administrator privileges.
bDownload the new SCSI firmware and utilities from support.dell.com and place
them in a directory on your client system.
Ensure that both 39160.rom and flash4.exe are downloaded to this directory.
cDouble-click My Computer and browse to the directory where you downloaded
the firmware.
dRight-click this directory, and select Sharing.
eClick Share this folder.
fTy p e SCSI for the name of the share, and then click OK to confirm the share
settings.
9Install the Dell Reinstallation Console from the Resource CD:
aInsert the Resource CD into the CD drive of your client system.
The Dell PowerVault 725N Resource CD window displays in a browser window.
NOTE: If the CD does not run automatically, double-click the start.bat file on the CD.

1-4 Upgrading Your 39160 SCSI Card Firmware
www.dell.com | support.dell.com
bClick Resources.
cClick Install Reinstallation Console.
dWhen the File Download window displays, click Open this file from its current
location, and then click OK.
eClick Next and follow the instructions on the screen.
fWhen prompted to reboot the client system, click Yes.
10 Create a reinstallation diskette from the Resource CD:
aEnsure that the Resource CD is in the CD drive of your client system.
NOTE: If the CD does not run automatically, double-click the start.bat file on the CD.
bIn the Resource CD Main Menu window, click Resources.
cIn the Resources window, click Firmware Update Diskette.
dWhen the File Download window displays, click Run this program from its
current location, and then click OK.
eClick Yes if you receive a security warning.
A DOS screen appears and prompts you to insert a diskette into the diskette drive
of the client system.
fInsert a formatted diskette into the diskette drive of your client system, and then
press <Enter>.
The DOS screen closes after the reinstallation diskette is made.
11 Update the boot image:
aIf it is not still in the diskette drive, insert the reinstallation diskette that you
created in step 10 into the diskette drive of the networked client system running
Windows 2000.
bClick the Start button and point to Programs→Dell Reinstallation Console→
Update boot image.
A DOS window opens.
cAfter the DOS window closes, remove the diskette from the diskette drive.
dReboot the client system.

Upgrading Your 39160 SCSI Card Firmware 1-5
12 Enable the Dell OpenManage™ Kick-Start utility and manually create your DHCP
settings:
aIf it is not on, turn on the NAS system.
The NAS system must be turned on to set the IP address using the Kick-Start
utility.
bClick the Start button and point to Programs→Dell Reinstallation Console→
Dell OpenManage Kick-Start.
cWhen asked if you want to run the program, click Yes.
dAt the bottom of the Dell OpenManage Kick-Start window, click Setup.
eClick Add.
fIn the Add Scope window, enter the following information, and then click OK.
•Starting IP Address: 10.40.10.10
•Ending IP Address: 10.40.10.20
•Subnet Mask: 255.255.255.0
•Gateway IP Address: 10.40.10.1
gClick OK to close the Add Scope window.
hClick Interfaces for DHCP Server so that it is checked.
iClick OK to close the Setup window.
jClick Enabled at the bottom of the Dell OpenManage Kick-Start window to start
the integrated DHCP server.
13 Start the Intel®PXE server and verify that the services are running:
aClick the Start button and point to Programs→ Dell Reinstallation Console→
Intel PXE Server.
bIn the PXE Configuration Utility window, right-click the server name,
PV725REC, and then select Start/Stop Services.
cVerify that the proxy DHCP/Boot PXE and M/TFTP services are installed and
running correctly by selecting Stop and then selecting Start.
If the services are running, the indicator displays Running after you click Start
and displays Stopped after you click Stop.
dClick OK.
14 Reboot your NAS system by pressing the power button.

1-6 Upgrading Your 39160 SCSI Card Firmware
www.dell.com | support.dell.com
15 On the keyboard connected to the NAS system, press <F2> immediately after you see
the following message:
Press <F2> to enter the Function Select menu.
16 From the menu, select option 4, Reinstallation, and then type yto confirm the
selection.
This setup process might take several minutes.
17 When the screen warns that you are going to update the firmware, type y.
18 Press yagain to confirm the selection.
19 When the screen prompts you to reboot your NAS system, do so.
The SCSI firmware update is complete.
Using a Client System Running Windows 2000 on the Same Network
If you have a client system running Windows 2000 on the same network, you can update
the SCSI firmware whether the network does or does not have a DHCP server.
Requirements
• Client system running Windows 2000 (Professional or Server Family) with a diskette
drive and a CD drive on the same subnet as the NAS system
•Resource CD included with your NAS system
• Range of available IP addresses
Procedure
To update your firmware, perform the following steps:
1Shut down the NAS system, and do not turn it back on until instructed.
2Turn off the client system running Windows 2000, if it is running.
3Connect a keyboard, monitor, and mouse to the NAS system.
For information about system connectors, see your User’s Guide.
4Turn on the client system running Windows 2000.
5Log in to the client system with an account that has administrator privileges.

Upgrading Your 39160 SCSI Card Firmware 1-7
6Create a new user with the name pv725 and the password set to password:
aFrom the desktop of your client system, right-click My Computer, and then select
Manage.
bOn the left side of the Computer Management window, double-click Local Users
and Groups.
cRight-click Users and select New User.
dIn the New User window, type pv725 as the user name.
eTy p e password in Password, and type it again in Confirm password.
fClick User must change password at next logon to clear the check box.
gClick Create, and then click Close.
7Create a share for the SCSI firmware on the client system:
aIf not already logged in, log in to the client system with an account that has
administrator privileges.
bDownload the new SCSI firmware and utilities from support.dell.com and place
them in a directory on your client system.
Ensure that both 39160.rom and flash4.exe are downloaded into this directory.
cDouble-click My Computer and browse to the directory where you downloaded
the firmware.
dRight-click this directory, and select Sharing.
eClick Share this folder.
fTy p e SCSI for the name of the share, and then click OK to confirm the share
settings.
8Install the Dell Reinstallation Console from the Resource CD:
aInsert the Resource CD into the CD drive of your client system.
The Dell PowerVault 725N Resource CD screen displays in a browser window.
NOTE: If the CD does not run automatically, double-click the start.bat file on the CD.
bClick Resources.
cClick Install Reinstallation Console.
dWhen the File Download window displays, click Open this file from its current
location, and then click OK.
eClick Next and follow the instructions on the screen.
fWhen prompted to reboot the client system, click Yes.

1-8 Upgrading Your 39160 SCSI Card Firmware
www.dell.com | support.dell.com
9Create a reinstallation diskette from the Resource CD:
aEnsure that the Resource CD is in the CD drive of your client system.
NOTE: If the CD does not run automatically, double-click the start.bat file on the CD.
bIn the Resource CD Main Menu window displays, click Resources.
cIn the Resources window, click Firmware Update Diskette.
dWhen the File Download window displays, click Run this program from its
current location, and then click OK.
eClick Yes if you receive a security warning.
A DOS screen appears and prompts you to insert a diskette into the diskette drive
of the client system.
fInsert a formatted diskette into the diskette drive of your client system, and then
press <Enter>.
The DOS screen closes after the reinstallation diskette is made.
10 Edit the go.bat file for the renamed client system and CD drive:
aIn Windows Explorer, right-click the go.bat file on the diskette, and then select
Edit to edit the file to the following variable value for your environment:
\\server_name\\share_name, where server_name is the name of the client system
and share_name is the name of the SCSI share (for example, \\PV725\SCSI).
bSave and exit the go.bat file.
11 Update the boot image:
aIf it is not still in the diskette drive, insert the firmware reinstallation diskette that
you created in step 9 into the diskette drive of the networked client system
running Windows 2000.
bClick the Start button and point to Programs→Dell Reinstallation Console→
Update boot image.
A DOS window displays.
cAfter the DOS window closes, remove the diskette from the diskette drive.
dReboot the client system.
12 If the Resource CD is still in the CD drive, remove it.

Upgrading Your 39160 SCSI Card Firmware 1-9
13 If a DHCP server is not on the network, enable the Kick-Start utility and manually
create the DHCP settings. Otherwise, if a DHCP server is on the network, go to
step 14.
NOTE: If you do not have a DHCP server, you must perform the following steps to create
the DHCP settings for the NAS server.
aTurn on your NAS system.
bClick the Start button and point to Programs→Dell Reinstallation Console→
Dell OpenManage Kick-Start.
cWhen asked if you want to run the program, click Yes.
dAt the bottom of the Dell OpenManage Kick-Start window, click Setup.
eClick Add.
fIn the Add Scope window, enter the IP network and subnet mask information.
If you are not sure about the information you need to enter in these fields, contact
your network administrator.
NOTE: If you run the Kick-Start utility in a non-DHCP environment, you must enter a
gateway IP address.
gClick OK to close the Add Scope window.
hClick Interfaces for DHCP Server so that it is checked.
iClick OK to close the Setup window.
jClick Enabled at the bottom of the Dell OpenManage Kick-Start window to start
the integrated DHCP server.
14 Start the Intel PXE server and verify that the services are running.
aClick the Start button and point to Programs→ Dell Reinstallation Console→
Intel PXE Server.
bIn the PXE Configuration Utility window, right-click the server name,
PV725REC, and then select Start/Stop Services.
cVerify that the proxy DHCP/Boot PXE and M/TFTP services are installed and
running correctly by selecting Stop and then selecting Start.
If the services are running, the indicator displays Running after you click Start
and displays Stopped after you click Stop.
dClick OK.
15 If it is off, turn on your NAS system. If it is already on, reboot your system.

1-10 Upgrading Your 39160 SCSI Card Firmware
www.dell.com | support.dell.com
16 On the keyboard connected to the NAS system, press <F2> immediately after you see
the following message:
Press <F2> to enter the Function Select menu.
17 From the menu, select option 4, Reinstallation, and then type yto confirm the
selection.
This setup process might take several minutes.
18 When the screen warns that you are going to update your firmware, type y.
19 Press yagain to confirm the selection.
20 When the screen prompts you to reboot your system, reboot the system.
The SCSI firmware update is complete.
