Dell PowerVault MD3060e Series User manual

Dell PowerVault MD3260/3260i/3660i/3660f/3060e
Storage Arrays
Getting Started Guide
Regulatory Model: E08J Series
Regulatory Type: E08J001

Notes, Cautions, and Warnings
NOTE: A NOTE indicates important information that helps you make better use of your computer.
CAUTION: A CAUTION indicates either potential damage to hardware or loss of data and tells you how to avoid the
problem.
WARNING: A WARNING indicates a potential for property damage, personal injury, or death.
©2012 Dell Inc.
Trademarks used in this text: Dell™, the Dell logo, Dell Precision™, OptiPlex™, Latitude™, PowerEdge™, PowerVault™,
PowerConnect™, OpenManage™, EqualLogic™, Compellent™, KACE™, FlexAddress™, Force10™and Vostro™are trademarks of Dell
Inc. Intel®, Pentium®, Xeon®, Core®and Celeron®are registered trademarks of Intel Corporation in the U.S. and other countries. AMD®
is a registered trademark and AMD Opteron™, AMD Phenom™and AMD Sempron™are trademarks of Advanced Micro Devices, Inc.
Microsoft®, Windows®, Windows Server®, Internet Explorer®, MS-DOS®, Windows Vista®and Active Directory®are either trademarks
or registered trademarks of Microsoft Corporation in the United States and/or other countries. Red Hat®and Red Hat®
Enterprise Linux®are registered trademarks of Red Hat, Inc. in the United States and/or other countries. Novell®and SUSE®are
registered trademarks of Novell Inc. in the United States and other countries. Oracle®is a registered trademark of Oracle Corporation
and/or its affiliates. Citrix®, Xen®, XenServer®and XenMotion®are either registered trademarks or trademarks of Citrix Systems, Inc. in
the United States and/or other countries. VMware®, Virtual SMP®, vMotion®, vCenter®and vSphere®are registered trademarks or
trademarks of VMware, Inc. in the United States or other countries. IBM®is a registered trademark of International Business Machines
Corporation.
2012 - 06
Rev. A00

Installation and Configuration
WARNING: Before performing the following procedure, review the safety instructions that came with the system.
Unpacking A Rack System
WARNING: The weight of your system without the physical disks installed (empty weight) is 19.50 kg (43.0 lb) and
when fully populated with all the physical disks is 105.20 kg (232.0 lb).
WARNING: Your system must be installed by Dell certified service technicians. For safe installation of an empty
system, a minimum of three service technicians are required. To install a fully populated system, a mechanized
lifting tool is required to position the system in a rack.
WARNING: Install the physical disks into the system only after installing the system in the rack. Installing the
system in the rack with the physical disks installed can damage the disks or cause injury.
CAUTION: Before installing your system in the rack, ensure that the weight of the system does not exceed the
rack's weight limit. For more information, see the Rack Installation Instructions that shipped with your system.
NOTE: For weight stability, always load the rack from the bottom up.
Figure 1. Installing the System in a Rack
Unpack your system and identify each item.
Assemble the rails and install the system in the rack following the safety instructions and the rack installation
instructions provided with your system.
3

Opening And Closing The Disk Drawer
Figure 2. Opening and Closing the Disk Drawer
Open the disk drawer to install or remove the physical disk carrier(s).
NOTE: You can open only one disk drawer at a time.
Installing The Physical Disks
Figure 3. Installing the Physical Disk(s)
Install physical disk(s) in the disk drawer.
NOTE: Each disk drawer must have a minimum of four physical disks installed. Always install the physical disks
starting from the front row (slots 0, 3, 6, and 9) in each disk drawer.
4

Connecting The Power Cable(s)
Figure 4. Connecting the Power Cable(s)
Connect the system’s power cable(s) to the system.
Securing The Power Cable(s)
Figure 5. Securing the Power Cable(s)
Open the cable retention bracket by pulling the tabs on its sides, insert the cable, and secure the system power cable,
as shown in the illustration.
Plug the other end of the power cable(s) into a grounded electrical outlet or a separate power source such as an
uninterruptible power supply (UPS) or a power distribution unit (PDU).
5

Turning On The System
Figure 6. Turning on the System
Turn the power switch on the back of the system to the On position. The power indicator should light.
Installing The Bezel
Figure 7. Installing the Bezel
Install the bezel.
Dell Software License Agreement
Before using your system, read the Dell Software License Agreement that came with your system. You must consider
any media of Dell-installed software as BACKUP copies of the software installed on your system’s hard drive. If you do
not accept the terms of the agreement, call the customer assistance telephone number. For customers in the United
States, call 800-WWW-DELL (800-999-3355). For customers outside the United States, visit support.dell.com and select
your country or region from the bottom of the page.
6

Other Information You May Need
WARNING: See the safety and regulatory information that shipped with your system. Warranty information may be
included within this document or as a separate document.
• The Owner’s Manual provides information about system hardware features and describes how to troubleshoot
the system and install or replace system components. This document is available online at support.dell.com/
manuals.
• The Administrator's Guide provides information about Modular Disk Storage Manager software features and
describes how to configure and manage your modular disk system. This document is available online at
support.dell.com/manuals.
• The Deployment Guide provides information about cabling your system and the installation and initial
configuration of the Modular Disk Storage Manager software. This document is available online at
support.dell.com/manuals.
• The rack documentation included with your rack solution describes how to install your system into a rack, if
required.
• Any media that ships with your system that provides documentation and tools for configuring and managing your
system, including those pertaining to the operating system, system management software, system updates, and
system components that you purchased with your system.
NOTE: Always check for updates on support.dell.com/manuals and read the updates first because they often
supersede information in other documents.
NOTE: When upgrading your system, it is recommended that you download and install the systems management
firmware on your system from support.dell.com.
Obtaining Technical Assistance
If you do not understand a procedure in this guide or if the system does not perform as expected, see your Owner’s
Manual . Dell offers comprehensive hardware training and certification. See dell.com/training for more information. This
service may not be offered in all locations.
NOM Information
The following information is provided on the device described in this document in compliance with the requirements of
the official Mexican standards (NOM):
Importer: Dell Inc. de México, S.A. de C.V.
Paseo de la Reforma 2620 -11º Piso
Col. Lomas Altas
11950 México, D.F.
Model number: E08J
Supply voltage: 200 – 240 V CA
Frequency: 50/60 Hz
Current consumption: 7.56 A
7

Technical Specifications
NOTE: The following specifications are only those required by law to ship with your system. For a complete and
current listing of the specifications for your system, go to support.dell.com.
Power
AC power supply (per power supply)
Wattage 1,755 W
Heat dissipation (maximum)
NOTE: Heat dissipation is calculated using the
power supply wattage rating. The heat
dissipation values are for the entire system
which includes chassis and two controllers.
5988 BTU/hr
Voltage
NOTE: This system is also designed to be
connected to IT power systems with a phase
to phase voltage not exceeding 230 V.
220 V AC, autoranging, 50 Hz/60 Hz
Battery 6.6 V DC, 1100 mAh, 7.26 W Lithium Ion Battery
Physical
Height 177.80 mm (7.0 inch)
Width 482.60 mm (19.0 inch) with rack latches
Depth 825.50 mm (32.5 inch) without bezel and handle
Weight (maximum configuration) 105.20 kg (232.0 lb)
Weight (empty) 19.50 kg (43.0 lb)
Environmental
NOTE: For additional information about environmental measurements for specific system configurations, see
dell.com/environmental_datasheets.
Temperature
Operating Continuous operation: 10 °C to 35 °C (50 °F to 95 °F) at 20% to
80% relative humidity (RH), with 26 °C maximum dew point. De-
rate maximum allowable dry bulb temperature at 1 °C/300 m (1
°F per 550 ft) above 900 m (2952.75 ft).
NOTE: For information on supported expanded operating
temperature range and configurations, see the Owner's
Manual at support.dell.com/manuals.
Storage –40 °C to 65 °C (–40 °F to 149 °F) with a maximum temperature
gradation of 20 °C per hour
8

Environmental
Relative humidity
Operating 20% to 80% (noncondensing) with maximum humidity gradation
of 10% per hour
Storage 5% to 95% at a maximum wet bulb temperature of 38 °C (100.4
°F)
Maximum vibration
Operating 0.26 Grms at 5 Hz to 350 Hz in operational orientation
Storage 1.88 Grms at 10 Hz to 500 Hz for 15 minutes (all six sides tested)
Maximum shock
Operating One shock pulse in the positive z axis of the system at 31 G for
2.6 ms in the operational orientation
Storage Six consecutively executed shock pulses in the positive and
negative x, y, and z axes (one pulse on each side of the system)
at 71 G for up to 2 ms
Six consecutively executed shock pulses in the positive and
negative x, y, and z axes (one pulse on each side of the system)
of 22 G faired square wave pulse with velocity change at 200
inches/second (508 centimeters/second)
Altitude
Operating –30.5 m to 3000 m (–100 ft to 9,842 ft)
NOTE: For altitudes above 2950 ft, the maximum operating
temperature is derated 1.8 ºF/1000 ft.
Storage –30.5 m to 12192 m (–100 ft to 40,000 ft)
Airborne contaminant level
Class G1 as defined by ISA-S71.04-1985
9
