DeLonghi NSL 460 X Quick guide

DE’LONGHI
COOKING
INSTALLATION and SERVICE INSTRUCTIONS
USE and CARE INSTRUCTIONS
NSL 460 X
NSL 590D X
GAS COOKTOPS
distributed by
ELBA Appliances Australia
(a Division of Fisher&Paykel Australia)

22
PRODUCT LABEL
Dear Customer,
Thankyouforhavingpurchasedandgivenyourpreference
to our product.
The safety precautions and recommendations reported
below are for your own safety and that of others. They
will also provide a means by which to make full use of the
features oered by your appliance.
Please keep this booklet in a safe place. It may be useful
in future, either to yourself or to others in the event that
doubts should arise relating to its operation.
This appliance must be used only for the task it
has explicitly been designed for, that is for cooking
foodstus. Any other form of usage is to be considered
as inappropriate and therefore dangerous.
The manufacturer declines all responsibility in the
event of damage caused by improper, incorrect or
illogical use of the appliance or be faulty installation.
This cooktop has been designed and constructed in accordance with the following codes
and specications:
AS 5263.0
AS/NZS 5263.1.1 Approval Requirements for Domestic Gas cooking appliances
AS/NZS 60335.1 Household and similar electrical appliances - Safety General
requirements
AS/NSZ 60335.2.102
Safety Particular requirements for gas, oil and solid-fuel burning
appliances having electrical connections
AS/NZS CISPR 14.1 Electromagnetic Compatibility Requirements

33
IMPORTANT SAFETY PRECAUTIONSAND RECOMMENDATIONS
IMPORTANT: This appliance is designed and manufactured
solely for the cooking of domestic (household) food and is
not suitable for any non domestic application and therefore
should not be used in a commercial environment.
The appliance guarantee will be void if the appliance is used
within a non domestic environment i.e. a semi commercial,
commercial or communal environment.
Read the instructions carefully before installing and using
the appliance.
■This appliance has been designed and manufactured in
compliance with the applicable standards for the household
cooking products and it fullls all the safety requirements shown
in this manual, including those for surface temperatures.
Some people with sensitive skin may have a more pronounced
temperature perception with some components although these
parts are within the limits allowed by the norms.
Thecompletesafetyof theappliance alsodepends onthe correct
use, we therefore recommend to always pay a extreme attention
while using the product, especially in the presence of children.
■After having unpacked the appliance, check to ensure that it is
not damaged.
In case of doubt, do not use it and consult your supplier or a
professionally qualied technician.
■Packing elements (i.e. plastic bags, polystyrene foam, nails,
packing straps, etc.) should not be left around within easy reach
of children, as these may cause serious injuries.
■ Some appliances are supplied with a protective lm on steel and
aluminium parts. This lm must be removed before using the
appliance.
■ IMPORTANT: The use of suitable protective clothing/gloves is
recommended when handling or cleaning this appliance.
■Do not attempt to modify the technical characteristics of
the appliance as this may become dangerous to use. The
manufacturer declines all responsibility for any inconvenience
resulting from the inobservance of this condition.

44
■ CAUTION: this appIiance must only be installed in a permanently
ventilated room in compliance with the applicable regulations.
■Do not carry out cleaning or maintenance operations on the
appliance without having previously disconnected it from the
electric power supply.
■Do not use a steam cleaner because the moisture can get into
the appliance therefore making it unsafe.
■Do not cover the hob with aluminium foils.
■Do not touch the appliance with wet or damp hands (or feet).
■Do not use the appliance whilst in bare feet.
■If you should decide not to use this appliance any longer (or
decide to substitute another model), before disposing of it, it
is recommended that it be made inoperative in an appropriate
manner in accordance to health and environmental protection
regulations, ensuring in particular that all potentially hazardous
parts be made harmless, especially in relation to children who
could play with unused appliances.
■Thevariouscomponentsoftheappliancearerecyclable.Dispose
oftheminaccordancewiththeregulationsinforceinyourcountry.
If the appliance is to be scrapped, remove the power cord.
■ After use, ensure that the knobs/controls are in the o󰀨 position.
■Children less than 8 years of age shall be kept away unless
continuously supervised.
■This appliance can be used by children aged from 8 years and
above and persons with reduced physical, sensory or mental
capabilities or lack of experience and knowledge if they have
been given supervision or instruction concerning use of the
appliance in a safe way and understand the hazards involved.
Children shall not play with the appliance. Cleaning and user
maintenance shall not be made by children without supervision.
■The manufacturer declines all liability for injury to persons or
damage to property caused by incorrect or improper use of the
appliance.
■ WARNING: During use the appliance and its accessible parts
become hot; they remain hot for some time after use.
– Care should be taken to avoid touching heating elements on
the hob.

55
– To avoid burns and scalds, young children should be kept away.
■Make sure that electrical cables connecting other appliances in the
proximity of the cooktop cannot come into contact with the hob.
■ WARNING: Unattended cooking on a hob with fat or oil can be
dangerous and may result in re. NEVER try to extinguish a re
with water, but switch o󰀨 the appliance and then cover ame e.g.
with a lid or a re blanket.
■ WARNING: Danger of re: do not store items on the cooking
surfaces.
■Do not scratch the hob with sharp objects. Don’t use the hob as a
work surface.
■ WARNING: If the hob is cracked or otherwise damaged by falling
objects etc., disconnect the appliance from the electrical power
supply to avoid the possibility of electric shock and call Customer
Service.
■ WARNING: When correctly installed, your product meets all safety
requirements laid down for this type of product category. However
special care should be taken around the underneath of the
appliance as this area is not designed or intended to be touched
and may contain sharp or rough edges, that may cause injury.
■ CAUTION: The cooking process has to be supervised. A short term
cooking process has to be supervised continuously.
■If the power supply cable is damaged, it must be replaced only by
an authorized service agent in order to avoid a hazard.
■DO NOT USE OR STORE FLAMMABLE MATERIALS NEAR THIS
APPLIANCE.
■ DO NOT SPRAY AEROSOLS IN THE VICINITY OF THIS
APPLIANCE WHILE IT IS IN OPERATION.
■DO NOT MODIFY THIS APPLIANCE.
■THIS APPLIANCE SHALL NOT BE USED AS A SPACE HEATER.
■WHERETHISAPPLIANCEISINSTALLEDINMARINECRAFTOR
IN CARAVANS, IT SHALL NOT BE USED AS A SPACE HEATER .

66
INSTALLATION
CAUTION:
■Important: The use of suitable protective clothing/gloves is recommended when
handling or cleaning of this appliance.
■This appliance must be installed in accordance with these installation
instructions, local gas tting regulations, municipal building codes, water
supply regulations, electrical wiring regulations, - Gas Installations and ony
other relevant statutory regulations.
■The appliance must be housed in heat-resistant units.
■We would point out that the adhesive which bonds the plastic laminate to the
furniture must withstand temperatures not less than 150°C to avoid delamination.
■Do not instal the appliance near inammable materials (eg. curtains).
■This appliance is to be installed only by an authorised person.
■This appliance shall be only be serviced by authorized personnel.
■Incorrect installation, for which the manufacturer accepts no responsibility, may
cause personal injury of damage.
■Always disconnect the appliance from mains power supply before carrying out
any maintenance operations or repairs.
■In the room where the appliance is installed, there must be enough air to allow
the gas to burn correctly, according to the current local regulations.
WARNING!
When correctly installed, your product meets all safety requirements laid down for
this type of product category. However special care should be taken around the
underneath of the appliance as this area is not designed or intended to be touched
and may contain sharp or rough edges, that may cause injury.
ELECTRICAL REQUIREMENTS
■The appliance must be connected to the mains checking that the voltage corresponds
to the value given in the rating plate and that the electrical cable sections can withstand
the load specied on the plate.
■The plug must be connected to an earthed socket in compliance with safety standards.
■ If the appliance is supplied without plug, t a standard plug which is suitable for the
power consumed by the appliance.
■ The wires in the power cable are coloured in accordance with the following code:
Green/Yellow = Earth, Blue = Neutral, Brown = Active.
If the colours of the wires in the power cable to the appliance do not correspond with
the coloured markings identifying the terminals in the junction terminal, proceed as
follows:
1. The wire which is coloured green and yellow must be connected to the terminal
marked “E” (Earth) or “ ” coloured Green.
2. The wire which is coloured blue must be connected to the terminal marked “N”
(Neutral) or coloured Black.

77
L N
3. The wire which is coloured brown must be connected to the terminal marked “L”
(Live) or “A” (Active) or coloured Red.
■A suitable isolating switch providing full disconnection from the mains power supply
(under overvoltage category III conditions) shall be incorporated in the permanent
wiring, mounted and positioned to comply with the local wiring rules and regulations.
The isolating switch must be of an approved type and provide a 3 mm air gap contact
separation in all poles (or in all active [phase] conductors if the local wiring rules allow
for this variation of the requirements).
■The power supply cable must not touch the hot parts and must be positioned so that it
does not exceed 50°C above ambient.
■Once theappliancehas beeninstalled, theswitchor socketmustalways beaccessible.
■If the supply cord is damaged it must be replaced by the manufacturer or it’s Service
Agent or a similarly qualied person in order to avoid a hazard.
N.B. The connection of the appliance to earth is mandatory.
If the installation requires alterations to the domestic electrical system call a qualied
electrician.
He should also check that the socket cable section is suitable for the power drawn by the
appliance.
Replacing the power cord must be done by a qualied electrician in accordance
with the instructions supplied by the manufacturer and in compliance with
established electrical regulations.
ELECTRIC DIAGRAM KEYELECTRIC DIAGRAM KEY
AAIgnition coilIgnition coil
PAPA Ignition switches group (4÷6 depending on model)Ignition switches group (4÷6 depending on model)
CACA Spark electrodesSpark electrodes (4÷6 depending on model)(4÷6 depending on model)
MMTerminal blockTerminal block
M
A
PA
CA
Figure 1

88
CLEARANCES
Installation clearances and protection of combustible surfaces shall comply with the current
local regulations e.g. AS/NZS5601.1 (latest edition) - Gas Installations code.
Measures (mm)
Description A B C D E F
(minimum) G (minimum)
Model NSL 460 X 600 510 49 (*) 560 480 60 (**) 200 (***)
Model NSL 590D X 900 510 49 (*) 840 480 60 (**) 200 (***)
650 mm
500 mm
450 mm
E
F
D
G
B
A
C
Cooktop
installed
G
40 mm
Space for
connections
Clearance
Door
Thermal
protection
barrier
The thermal protection barrier must
be:
• removable with the use of a
tool for installation and service;
• heat-resistant;
• made from low thermal
conductivity material.
Figure 2cFigure 2b
Figure 2a

99
(*)From top of countertop
(**)Between the back edge of the cut-out and the back of the countertop.
(***)From the side edge of the cut-out to any vertical combustible surface. If this distance is less than
200 mm, the surface shall be protected (in accordance withAS/NZS5601.1) to a height of not less
than 150 mm above the hob for the full dimension (width or depth) of the cooking surface area.
IMPORTANT NOTE:
THIS APPLIANCE SHALL NOT BE USED AS A SPACE HEATER, ESPECIALLY IF
INSTALLED IN MARINE CRAFT OR CARAVANS.
The installation shall comply with the dimensions in gs. 2a, 2b bearing in mind that:
■A 40mm ventilation gap must be provided between the bottom of the appliance and
any cabinetry, draw unit, thermal protection barrier or appliance.
■If the cooktop is installed directly above an oven (which does not have a cooling fan
motor) or if its base is accessible through a cupboard or drawer space after installation,
a thermal protection barrier must be installed below the base of the cooktop as
indicated in g. 2c.
■If the oven installed below the cooktop has a cooling fan motor, the thermal protection
barrier is not required.
■If the cooktop is installed above an oven, the two appliances shall be connected to the
gas and/or electrical supply with independent connections.
■Overhead clearances - In no case shall the clearance between the highest part of
the hob and a range hood be less than 600 mm, or for an overhead exhaust fan 750
mm. Any other downward facing combustible surface less than 600 mm above the
highest part of the hob shall be protected for the full width and depth of the cooking
surface area in accordance with local regulations in force. However, in no case shall
this clearance to any surface be less than 450 mm.
HEIGHT OF THE TOP OF THE PAN SUPPORTS WITH RESPECT TO THE BENCH
TOP SURFACE: 45.2 mm ±3.
Standards requirement
Temperature of nearby surfaces. Australian and New Zealand Gas Installation Standards
(AS/NZS5601.1) require a cooktop to be installed so that the surface temperature of any
nearby combustible surface will not exceed 65°C above ambient.
This is typically achieved by:
■ having the cooktop spaced away from the wall (see gures 2a, 2b);
AND
■protecting the wall to a height of at least 150 mm along its length (minimum height of
non-combustible material when used on adjacent walls) with non-combustible surface
materials such as:
– 5 mm-thick ceramic tiles (these alone are adequate);
– tempered glass or sheetmetal, minimum thickness 0.4 mm (acceptable when used
in front of a re resistant material).

1010
FASTENING THE COOKTOP
Each cooktop is provided with an installation kit including brackets and screws for fastening
the cooktop to benches from 30 to 40mm thick.
Model NSL 460 X (g. 3a): The kit includes two “F” type brackets (for the front of the
cooktop), two “R” type brackets (for the rear of the cooktop) and four self-threading screws
“S”.
Model NSL 590D X (g. 3b): Thekitincludesfour“F”type brackets(forthefrontof thecooktop),
three “R” type brackets (for the rear of the cooktop) and seven self-threading screws “S”.
• Cuttheunitaccordingtothedimensions
in g. 2a.
• Stretch gasket “G” over the edge of the
hole made, being careful to overlay the
junction edges.
–Fasten the brackets “F” and “R” to
the appropriate socket holes, without
tightening the screws “S” for the
moment. Make sure that the tabs are
mounted correctly, as shown (gs. 3a,
3b, 3c, 3d). Rotate the tabs so that the
cooktop can be put into the cutout.
–Put the cooktop into the cutout and
position it correctly.
–Put the brackets “F” and “R” into place;
tooth “A” of the brackets should go into
the hole (gs. 3c, 3d).
–Tighten screws “S” until the cooktop is
completely secured to the bench.
–Using a sharp cutter or trimmer knife,
trim the excess sealing material around
the edge of the cooktop.
Takecarenotto damagetheworkbench.
30 mm min. 40 mm max.
S
A
F
G
30 mm min.
40 mm max.
40 mm min.
40 mm min.
S
A
R
G
30 mm min. 40 mm max.
S
A
F
G
30 mm min.
40 mm max.
40 mm min.
40 mm min.
S
A
R
G
F
F
F
F
R
R
R
F
F
R
R
F
F
F
F
R
R
R
F
F
R
R
Rear Fixing Brackets Front Fixing Brackets
Figure 3a
Figure 3b
Figure 3dFigure 3c

1111
GAS SUPPLY
■This appliance is suitable for use
with Natural Gas or ULPG (Check
the “gas type” sticker attached to the
appliance).
■For Natural Gas the gas supply must
be regulated to obtain a pressure of 1
kPa:
–withthetwosemi-rapid(SR)burners
operating at the maximum - model
NSL 460 X only;
–with the dual (DB) burner operating
at the maximum (inside and outside
ames in simultaneously at the
maximum) - model NSL 590D X
only.
■For ULPG models connect the gas
supply directly to the appliance test
point adaptor (supplied with the
conversion kit) and ensure that the
supply pressure is regulated to 2.75
kPa.
■Do NOT force the ”elbow“ rotation
prior to loosening nut.
■Do NOT over tighten the nut at the
”elbow“.
1. After connecting the gas supply, check
the piping and connections for leaks
using a soap and water solution. The
presence of bubbles indicates a leak,
tighten or replace connections as
appropriate.
Warning: Do not use any naked ame
to check for leaks.
Gas connection for
NATURAL GAS
Gas inlet pipe
Gasket
Brass conical adaptor
(Thread tight: use
suitable seal)
Gas regulator
Test
point
Gas connection for
ULPG
Test point adaptor
Gasket
Gas inlet pipe
Test
point
Brass conical adaptor
(Thread tight: use
suitable seal)
Figure 4a
Figure 4b
Figure 4c

1212
2. The operation of the appliance MUST be tested before leaving.
3. Adjust the test point pressure or supply pressure to the value which is appropriate for
the gas type.
4. Turn on the appliance gas controls and light each burner. Check for a well dened
blue ame without any yellow tipping. If any abnormality is evident then check that the
burner ame spreader and burner cap/s are both located properly.
5. Check the minimum burner setting by quickly rotating the gas control knob from the
maximum to the minimum position, the ame must not go out. If adjustment is required
carry out the “MINIMUM BURNER SETTING ADJUSTMENT” procedure described
below.
6. If satisfactory performance cannot be obtained, the installer shall check the installation
and notify the local gas supply authority for a gas supply problem, or if it is an appliance
problem,ourCustomerServiceCentreshouldbecalledtoobtainthenearestauthorized
Elba Appl. AUS Service Agent.
7. Where the appliance data plate cannot be easily read with the appliance in the
installed position the duplicate data plate must be attached to adjacent surface and
the duplicate Natural gas / ULPG conversion label should also be included where a
Natural gas / ULPG conversion has been completed.
INSTALLATION WITH A FLEXIBLE HOSE ASSEMBLY
■If this appliance has to be installed with a hose assembly, the installer shall refer to the
network operator or gas supplier for conrmation of the gas type, if in doubt.
■ When used with a exible hose, the connector on the wall should be between 800 mm
to 850 mm above the oor and in the region outside the width of the appliance to a
distance of 250 mm.
The supply connection point shall be accessible with the appliance installed.
■ Flexible hose assemblies should be AS/NZS 1869 Class B or Class D certied.
The thread connection shall be Rp 1/2” (ISO 7-1) male.
■IMPORTANT WARNING: After connection the installer must check that the hose is
not kinked, subjected to abrasion or permanently deformed. The installer must check
also that the hose is not near (or in contact) with any hot surfaces e.g. base of metal
hotplate, underbench oven etc.
■The hose assembly shall be as short as practicable and comply with relevant
AS/NZS5601.1 requirements.
■IMPORTANT WARNING: The installer shall ensure the hose assembly is restrained
from accidental contact with the ue outlet of an underbench oven.

1313
TABLE FOR THE CHOICE OF THE INJECTORS
Natural Gas ULPG
Test Point Pressure [kPa] 1.0 2.75
BURNER Injector
Orifice
Dia.
[mm]
Gas
Consumption
[MJ/h]
Injector
Orifice
Dia.
[mm]
Gas
Consumption
[MJ/h]
Auxiliary (AUX) 0.92 4.20 0.56 4.20
Semi-rapid (SR) 1.17 6.60 0.70 6.20
Rapid (R) (1) 1.54 11.75 0.88 10.78
Double-ring compact (DRC) (2) 1.48 10.70 0.85 9.60
Dual (DB) - inner crown (3) 0.72 2.40 0.43 2.10
Dual (DB) - outer crown (3)1.23 (x2) 13.80 0.66 (x2) 11.40
(1) Only for the model NSL 590D X
(2) Only for the model NSL 460 X
(3) Only for the model NSL 590D X
(Note: Gas type sticker and data plate are attached to the underside of the base of the
appliance.)
CONVERSION PROCEDURE (to convert to Natural gas or to ULPG)
REPLACING THE INJECTORS
The conversion procedure must be carried out only by an authorised person.
This appliance is suitable for use with Natural gas or Universal LPG (check the “gas type”
sticker attached to the appliance).
The nominal gas consumption and injector size details are provided in table above.
To replace the injectors proceed as follows:
■Remove pan supports and burners from the cooktop.
■Using a wrench, substitute the injectors “J” (gs. 5a, 5b, 5c) with those most suitable
for the kind of gas for which it is to be used (see table above).
■ A󰀩x to the appliance the warning label stating that the cooktop has been converted
for use with Natural gas/ULPG (supplied with the Natural gas/ULPG conversion kit).
A second Natural gas/ULPG conversion label should also be a󰀩xed to an adjacent
surface along with the duplicate data plate.
IMPORTANT
■If the cooktop is suitable for use with Natural gas and must be converted for use with
Universal LPG, before connecting to gas main remove the appliance gas regulator and
replace with test point adaptor (see gs. 4a, 4b).

1414
■If the cooktop is suitable for use with
Universal LPG and must be converted
for use with Natural gas, before
connecting to the gas main remove
the appliance test point adaptor and
replace with gas regulator (see gs.
4a, 4b).
NOTE:
Gas regulator and test point adaptor are
supplied with the appliance (packed with
conversion kit).
The burners are designed so that
regulation of primary air is not required.
Figure 5a
J
Double-ring compact burner (only
for the model NSL 460 X)
Figure 5b
J
J
Dual burner (only for the model
NSL 590D X)
Injector for
inner crown Injectors
for outer
crown
Figure 5c
J
Auxiliary, semi-rapid and rapid burner
(rapid only for the model NSL 590D X)

1515
MINIMUM BURNER SETTING ADJUSTMENT
Check whether the ame spreads to all burner ports when the burner is lit with the gas
tap set to the minimum position. If some ports do not light, increase the minimum gas rate
setting.
Check whether the burner remains lit even when the gas tap is turned quickly from the
maximum to the minimum position. If the burner does not remain lit, increase the minimum
gas rate setting.
The procedure for adjusting the minimum gas rate setting is described below.
■Using a screwdriver turn screw “A” until the ame setting is correct (g. 6).
■Dual burner, model NSL 590D X only: For the dual burner set the minimum for both
the gas valves (one for the inner and one for the outer crown). The operations must be
carried out one gas valve at a time.
Normally for ULPG fully tighten the adjustment screw.
LUBRICATING THE GAS TAP
If a gas tap is di󰀩cult to turn, disassemble it, clean it carefully with petrol and spread a little
high-temperature-resistant grease on it.
These operations must be performed by an Authorized person/Service agent.
Note: Servicing of this appliance is only to be carried out by Authorised Person.
A
Figure 6
A
A

1616
USE and CARE
Figure 7a
Model:Model: NSL 460 XNSL 460 X
1
11 9 8 7
2
3
5
Figure 7b
Model:Model: NSL 590D XNSL 590D X
13 12 78 9 10
1
6
2 3
4
CAUTION:
■This appliance must be used only for the task it has explicitly been designed for, that
is for domestic cooking of foodstu󰀨s. Any other form of usage is to be considered as
inappropriate and therefore dangerous. Do not use this appliance as a space heater.
■Do NOT place combustible materials or products on this appliance at any time. Do
NOT use or store ammable materials near this appliance.
■Do NOT spray aerosols in the vicinity of this appliance while it is in use.
■ Before using for the rst time, clean the cooktop with warm soapy water.
■DO NOT MODIFY THIS APPLIANCE.
■IMPORTANT NOTE: THIS APPLIANCE SHALL NOT BE USED AS A SPACE
HEATER, ESPECIALLY IF INSTALLED IN MARINE CRAFT OR CARAVANS.

1717
GAS BURNERS
1. Auxiliary (A)
2. Semirapid (SR)
3. Semirapid (SR)
4. Rapid (R)
5. Double-ring compact (DRC)
6. Dual (DB) (*)
(*)IMPORTANT: The Dual burner is controlled by two separate knobs; one knob for
the inner crown only and one knob for the outer crown only.
The inner and outer crown can be used together or separately.
After using the dual burner check both the control knobs are in the closed
“ ” (o󰀨) position.
CONTROLS DESCRIPTION
7. Burner control knob (1) - Auxiliary
8. Burner control knob (2) - Semi-rapid
9. Burner control knob (3) - Semi-rapipd
10. Burner control knob (4) - Rapid
11. Burner control knob (5) - Double-ring compact
12. Burner control knob (6) - Dual, inner crown only
13. Burner control knob (6) - Dual, outer crown only
NOTES:
■The electric ignition is incorporated in the knobs.
■The appliance has a safety valve system tted, the ow of gas will be stopped if and
when the ame should accidentally go out.

1818
USING GAS BURNERS
■Check that the electricity is switched on to allow spark ignition.
■Make sure that all controls are turned to “ ” (burner o󰀨).
■ The gas ow to the burner is controlled by a tap incorporating a safety cut-o󰀨 valve.
If the burner ame should go out for some reason, the safety valve will automatically
stop the gas ow. The switch of the electric ignition is incorporated in the knobs.
■ You control the ow by turning the knob indicator to line up with the following symbols:
– Symbol : tap closed (burner o󰀨)
– Symbol : High (maximum)
– Symbol : Low (minimum)
■You can control the temperature by the knob to “High” (maximum) from “Low” “Minimum”.
■Other intermediate operating adjustments can be achieved by positioning the indicator
between the maximum and minimum aperture positions and never between the
maximum aperture and the “ ” (o󰀨) position.
■ To switch o󰀨, turn the knob clockwise until you hear the safety click - “ ” (o󰀨) position.
■Note that, if you are using a burner at the minimum setting, you turn the knob clockwise
past the maximum setting before reaching the o󰀨 position.
■ Whenever lighting any of the burners produces an abnormal ame, switch that burner
o󰀨 and relight using the minimum setting.
■ If after relighting the burner, the ame is still abnormal, turn the burner o󰀨 and contact
our Customer Service Centre to obtain the nearest authorized ElbaAppl. AUS Service
Agent.
■In the case of a mains failure light the burner with a match or lighted taper.
■Note: When the cooker top is not being used, check the gas knobs are in their closed
position and also close the cock valve on the gas bottle or the main gas supply line.
Figure 8a Figure 8b

1919
LIGHTING GAS BURNERS FITTED WITH FLAME FAILURE SAFETY DEVICE
In order to light the burner, you must:
1. Turn the knob (gs. 8a - 8b) in anti-clockwise direction up to the maximum aperture
(symbol “ ” ), push in and hold the knob; this will light the gas.
If there is no mains electrical supply, bring a lighted match close to the burner.
2. Wait for about ten seconds after the gas burner has been lit before letting go of the
knob (valve activation delay).
3. Adjust the gas valve to the desired position.
4. After use, turn the knob to the “ ” (o󰀨 ) position.
Important
■ If the burner ame should go out, the safety valve will automatically stop the gas ow
■To re-light the burner, return the knob to closed “ ” position (burner o󰀨), wait for at
least 1 minute and then repeat the lighting procedure.
■N.B. If your local gas supply makes it di󰀩cult to light the burner with the knob set to
maximum, set the knob to minimum and repeat the operation.
DUAL BURNER - MODEL NSL 590D X ONLY
The Dual Burner is a very exible burner which allows di󰀨erent regulations and optimal
cooking.
It is composed by one inner and one outer crown: the inner and outer crown can be used
together or separately.
The Dual burner is controlled by two separate knobs (g. 9):
■one knob for the inner crown only (“ ” symbol identifying the control knob) ;
■one knob for the outer crown only (“ ” symbol identifying the control knob).
The Dual burner can be used:
■ as a small burner (ames produced only by the inner crown);
■ as a Ultra-rapid burner (ames produced only by the outer crown);
■ as a high-power burner (all ames produced simultaneously by inner and outer crown).
IMPORTANT: After using the dual burner check both the control knobs
are in the closed “ ” (o󰀨) position.

2020
12
1 2 1+2
12
1 2 1+2
Figure 9
DUAL BURNER OPERATION / CONTROL KNOBS
MODEL NSL 590D X ONLY
IMPORTANT: After using the dual burner check both the control
knobs are in the closed “ ” (o󰀨) position.
