DeLonghi FXG 175AT Installation instructions manual

5712710261/04.10
De’Longhi America, Inc.
250 Pehle Avenue, Suite 405
Saddle Brook, NJ 07663
1-800-322-3848
De’Longhi Canada, Inc.
6150 McLaughlin Road
Mississauga, Ontario
L5R 4E1 Canada
1-888-335-6644
Fiducia Italiana S.A de C.V.
Erasmo Castellanos Quinto
calle B manzana II #29 - Col. Educación
C.P. 04400
Deleg. Coyoacán – Mexico D.F.
Lada sin costo: 01800 711 8805
www.delonghi.com

STEAM IRON - FXG175AT
IMPORTANT INSTRUCTIONS - SAVE THESE
INSTRUCTIONS
Register this product online and receive a free trial issue of Co-
ok’s Illustrated.
Visit http:// www.delonghiregistration.com.
Visit www.delonghi.com for a list of service centers near you.
(U.S. and Canada only).
FER À VAPEUR - FXG175AT
MODE D’EMPLOI IMPORTANT - CONSERVEZ
LES PRESENTES INSTRUCTIONS
Enregistrez ce produit en ligne et recevez un numéro gratuit de
Cook’s Illustrated. Visitez http:// www.delonghiregistration.com.
Visitez www.delonghi.com pour y voir une liste des centres de
réparation proches de chez vous. (É.-U. et Canada seulement).
PLANCHA DE VAPOR - FXG175AT
INSTRUCIONES IMPORTANTES - REPASE
Y GUARDE ESTAS INSTRUCCIONES- LEA
ESTE INSTRUCTIVO ANTES DE UTILIZAR EL
APARATO
Registre este producto en línea y reciba un ejemplar gratis de
Cook’s Illustrated.
Visite http:// www.delonghiregistration.com.
Visite www.delonghi.com para ver la lista de centros de servi-
cios cercanos a usted.
(Sólo Estados Unidos y Canada)
ELECTRONIC CHARACTERISTICS - CARACTÉRISTIQUES ÉLEC-
TRIQUES - CARACTERISTICAS ELECTRICAS: 120V˜60Hz 1750W

A GHI
B
C
D
E
F
L
M
123
300mL

4
INDEX
DESCRIPTION OF THE APPLIANCE ............................... 7
USING THE APPLIANCE FOR THE FIRST TIME.................. 8
PREPARATIONS FOR USE.......................................... 8
What water to use..........................................................................8
Filling the tank................................................................................8
Adjusting plate temperature. ........................................................9
STEAM IRONING .................................................... 9
DRY IRONING.......................................................10
VERTICAL IRONING................................................10
TURBO FUNCTION .................................................11
SPRAY BUTTON ....................................................11
NO-DRIP SYSTEM .................................................11
AUTO-OFF ..........................................................11
AFTER IRONING....................................................12
Cleaning and maintenance ..........................................................12
Limescale prevention and SELF CLEAN .......................................12
LIMITED WARRANTY ..............................................13

5
EN
IMPORTANT SAFETY
INSTRUCTIONS
When using electrical appliances, basic safety precautions
should always be followed, including the following:
READ ALL INSTRUCTIONS BEFORE USING
1. Use appliance only for it’s intended use.
2. To protect against a risk of electric shock, do not immerse
the appliance in water or other liquids.
3. The appliance should always be turned to “MIN” before
plugging or unplugging from outlet. Never yank the cord
to disconnect from outlet, instead grasp plug and pull to
disconnect.
4. Always disconnect appliance from electrical outlet before
filling with water, emptying or when not in use.
5. Do not allow cord to touch hot surface. Let iron cool
completely before putting away. Loop cord loosely around
iron when storing.
6. Do not operate the iron with a damaged cord or in the event
the iron has been dropped or damaged. To avoid risk of
electric shock, do not disassemble the iron. Take it to a
qualified serviceman for examination and repair. Incorrect
assembly might result in a risk of electric shock when the
iron is used after reassembly.
7. Not intended for use by children. Close supervision is
necessary for any appliance being used by or near children.
Unsupervised use can result in fire or personal injury. Do
not leave the appliance unattended while plugged in ,on an
ironing board, or while it is still hot.
8. Burns can occur from touching hot metals parts, hot water
or steam . Use caution when you turn the iron upside down.
There may be hot water in the reservoir.

6
9. The use of an accessory attachment is not recommended by
Dè Longhi and may result in fire, electric shock or personal
injury.
SPECIAL INSTRUCTION
1. To avoid a circuit overload, do not operate a high
wattage appliance on the same circuit.
2. If an extension cord is absolutely necessary, a cord
with an ampere rating equal to or greater than the
maximum rating of the iron shall be used. A cord
rated for less amperage can result in a risk of fire or
electric shock due to overheating. Care shall be taken
to arrange the cord so that it cannot be pulled or be
tripped over.
3. After removing the packing, make sure the appliance
is not damaged. If in doubt do not use the appliance
and contact an authorized Customer Service Center.
4. To repair or if power cable is damaged and requires
replacement, contact your local dealer or an
authorized Customer Service Center, in order to avoid
compromising the efficiency of your appliance. For
the same reason you are always recommended to use
original spare parts.
The use of all electrical appliances implies the observance
of some fundamental rules. IN PARTICULAR:
• Never touch the appliance with wet or damp hands or
feet.
DO NOT IMMERSE THE APPLIANCE IN WATER.
• Neveruseapplianceinbathrooms.
• Neverpullthepowercableortheappliancewithwet
or damp feet.
• Neverletchildrenoruntpersonsusetheappliance

7
EN
without supervision.
• Neverleavetheappliancepluggedinasitcouldbea
safety hazard.
• Beforecleaningorservicing,disconnecttheappliance
by unplugging it from the outlet.
• Neverlltheapplianceunderrunningwater.
• Donotdirectthesteamjettowardpeople,animals,or
iron clothes when they are being worn as this could
be dangerous.
• After ironing, allow the iron to cool before putting
away.
• The iron must be used and rested on a stable
surface.
• Whenplacingtheirononitsstand,ensurethatthe
surface on which the stand is placed is stable.
• Theironisnottobeusedifithasbeendropped,if
there are visible signs of damage or if it is leaking.
SAVE THESE INSTRUCTIONS
THIS APPLIANCE IS FOR HOUSEHOLD
USE ONLY
DESCRIPTION OF THE APPLIANCE
(page 3)
A. Plate
B. Spray
C. Tank fill hole cap
D. Steam regulator
E. Spray button
F. ON/auto-off light (certain models only)
G. “Steam ready” light

8
H. Thermostat knob
I. “Self Clean” button
L. “Turbo” button
M. Water measure
USING THE APPLIANCE FOR THE FIRST TIME
• Thersttimeyouusetheiron,removetheplateprotection
(if present).
• When used for the first time, the appliance may give off
smoke and an odor for several minutes. This is caused
by heating and subsequent drying of the sealers used
in assembling the appliance. You are recommended to
ventilate the room.
PREPARATIONS FOR USE
What water to use
The machine works with normal tap water.
If the water is very hard, we recommend using demineralized
water diluted 50/50 with tap water.
Never use distilled water alone.
Never use chemical substances or detergents (e.g. perfumed
water, essences, descaling solutions, etc).
Filling the tank
Danger!
It is important that the iron is always unplugged from the outlet
every time you fill up the water tank.
• Makesuretheapplianceisunpluggedfromtheoutlet.
• Make sure the steam regulator Dis in the position
(“dry”) (fig. 1).
• OpenthetankllholecapC.
• Fillthemeasuretothelevelmark(300ml),thenpourthe
water into the iron (fig. 2).
• Closethetankllholecap.

9
EN
Adjusting plate temperature.
Please note:
On the back of the iron there is a useful guide giving information
on the temperature to set according to the garment being
ironed:
• Plugtheironintotheoutlet.(Models with auto-off only: the
light Fcomes on to indicate that the appliance is connected
to an electricity supply.)
• The“steamready”lightGcomes on.
• Selecttherequiredtemperaturebyturningthethermostat
knob H(fig. 3).
• Afteraboutaminute(formaximumtemperature),thesteam
ready light “G” goes off to indicate that the iron is ready for
use.
STEAM IRONING
Please note:
Before steam ironing, make sure the fabric
is suitable for this kind of ironing.
Remember that the steam function can
only be used when the thermostat is on the segment indicated
by the steam symbol.
• Fillthetankandsetplatetemperatureasdescribedabove.
• Movethesteamregulatortoselecttherequiredamountof
steam: .
• Waitforthe“steamready”lightGto go off.
To discharge steam, just place the iron in a horizontal position.

10
Steam stops when the iron is placed upright on the rear rest (the
recommended position during pauses in ironing).
DRY IRONING
• Setplatetemperatureasdescribedabove.
• Movethesteamregulatortothe position (“dry”).
• Waitforthe“steamready”lightGto go off.
The iron is ready to use.
If the fabric to be ironed is slightly damp or you iron fast, you can
use a higher temperature. If, on the other hand, the garments
are dry or you iron slowly, you are recommended to use a lower
temperature.
VERTICAL IRONING
This function enables delicate garments to be steamed without
resting them on the ironing board. Pay particular attention to
the temperature when steaming curtains.
• Make sure the steam regulator D is in the position
(“dry”) (fig. 1).
• Setplatetemperatureto MAX.
• Waitforthe“steamready”lightGto go off.
• Holdtheironverticallyandmoveitnearthegarment.
• PressandreleasetheTurbobutton(L).
For correct vertical ironing, wait a few seconds between one
burst of steam and the next until the “steam ready” light Ggoes
off.
Danger of burns!
Never direct the “vertical” steam jet at a garment hanging in a
wardrobe or worn by a person.
Vertical ironing should always be carried out with the garment
hanging on a clothes stand and always away from other
garments, elements, people and animals.

11
EN
TURBO FUNCTION
Press this button to obtain a powerful jet of steam, useful to
eliminate creases.
• SetplatetemperaturetoMAX.
• Move the steam regulator to the steam
position.
• Waitforthe“steamready”lightGto go off.
• PressandreleasetheTurbobutton(L).
To use the turbo function correctly, wait a few seconds between
one burst of steam and the next.
SPRAY BUTTON
If during ironing, you note particularly resistant creases or if
your garment requires a higher level of dampness, you can use
the spray.
• Fillthetankandsetplatetemperatureasdescribedabove.
• Press the spray  button (E) repeatedly, directing the
spray jet towards the parts of the garment to be dampened.
Never use the spray when ironing silk as the drops of water
could mark the fabric.
NO-DRIP SYSTEM
This iron has a no-drip system which automatically shuts off
steam production when the temperature is set too low.
During operation, the device may emit creaking noises as the
iron heats up and cools down.
This is perfectly normal and part of correct operation.
AUTO-OFF
• If the iron is left unused in a horizontal position for 30
seconds, it goes off automatically.
• Iftheironisnotusedinanuprightposition,theauto-off

12
device trips after 8 minutes.
The light (F) flashes to indicate auto-off. To begin ironing again,
shake the iron slightly forwards until the light (F) comes on
steadily.
AFTER IRONING
To extend the working life of the iron, whenever you finish
ironing, you are recommended to empty the tank as follows:
• Unplugtheironfromtheoutlet.
• Emptytheironbyholdingittipdownwardsandshakingit
gently over a basin or sink.
• Todryresidualmoisture, turn theirononagain withthe
thermostat at maximum for about 2 minutes.
• Unplugtheironfromtheoutletandallowtocool.
• Cleantheplatewithadryclothastracesofmoisturecould
mark it.
• Windthepowercable.
• Storetheironinanuprightposition.
Cleaning and maintenance
After use, always wait until the iron is cold before putting away.
Leave to cool in an upright position.
• Keepthesurfaceoftheplateclean.
• Cleantheplatewithadampclothonly,neveruseabrasives
or solvents.
• Donotrestorusetheirononzips,hooks,ringsetc.toavoid
scratching the soleplate.
Limescale prevention and SELF CLEAN
The resin filter installed in the tank filters impurities, thus
ensuring constant steam delivery during ironing.
The resin softens the water and improves the long term
performance of the iron.

13
EN
ThiswarrantyappliestoallproductswithDe’LonghiorKenwood
brand names.
LIMITED WARRANTY
What does the warranty cover?
We warrant each appliance to be free from defects in material and wor-
kmanship. Our obligation under this warranty is limited to repair at our
factory or authorized service center of any defective parts or part thereof,
other than parts damaged in transit. In the event of a products replace-
ment or return, the unit must be returned transportation prepaid. The
repaired or new model will be returned at the company expense.
This warranty shall apply only if the appliance is used in accordance with
the factory directions, which accompany it, and on an Alternating current
( AC ) circuit.
How long does the coverage last?
This warranty runs for one year ( 1 ) from the purchase date found on
your receipt and applies only to the original purchaser for use.
However, if the amount of stream drops during use, this could
be caused by a build-up of limescale.
To remove, proceed as follows:
• Fillthetank.
• Plugtheapplianceintotheoutletandplacethethermostat
in the MAX position.
• Whentheironhasreachedtherequiredtemperature(light
off), unplug the appliance.
• Placeoverasinkandinahorizontalposition.
• PresstheSELFCLEANI button and hold it down.
• Shaketheappliancegentlytodrainthewaterinthetank
through the plate, taking the impurities with it.
• ReleasetheSELFCLEANbutton.
• Plugtheapplianceintotheoutletandleaveinoperationfor
at least two minutes to dry the plate.
• Afterthistime,unplugtheappliancefromtheoutlet.
• Leave the iron to cool and clean the outside with a soft
cloth.

14
What is not covered by the warranty?
The warranty does not cover defects or damage of the appliance, which
result from repairs or alterations to the appliance outside our factory or
authorized service centers, nor shall it apply to any appliance, which has
been subject to abuse, misuse, negligence or accidents. Also, conse-
quential and incidental damage resulting from the use of this product or
arising out of any breach of contract or breach of this warranty are not
recoverable under this warranty. Some states do not allow the exclusion
or limitation of incidental or consequential damage, so the above limita-
tion may not apply to you.
How do you get service?
If repairs become necessary, see contact information below:
U.S. Residents: Please contact our toll free hotline at 1-800-322-3848 or
log onto our website at www.delonghi.com.
For all accessories, spare parts or replacement parts, please contact our
parts division at 1-800-865-6330.
Residents of Canada: Please contact our toll free hotline at 1-888-335-
6644 or log onto our website at www.delonghi.com.
Residents of Mexico: Please refer to the Limited Warranty statement
for Mexico.
Please refer to the back page of the manual for De’Longhi addresses.
The above warranty is in lieu of all other express warranties and repre-
sentations. All implied warranties are limited to the applicable warranty
period set forth above. This limitation does not apply if you enter into an
extended warranty with De’Longhi. Some states do not allow limitations
on how long an implied warranty lasts, so the above exclusions may not
apply to you. De’Longhi does not authorize any other person or company
to assume for it any liability in connection with the sale or use of its
appliance.
How does state law apply?
This warranty gives you specific legal rights, and you may also have
other rights, which vary from state to state.

15
FR
INDEX
DESCRIPTION DE L’APPAREIL .................................. 19
PREMIÈRE MISE EN SERVICE................................... 19
PRÉPARATION..................................................... 19
Quelle eau utiliser ? .....................................................................19
Remplir le réservoir .....................................................................20
Régler la température de la semelle.............................................20
REPASSAGE À LA VAPEUR ...................................... 21
REPASSAGE À SEC................................................ 21
DÉFROISSAGE VERTICAL........................................ 21
FONCTION TURBO ................................................ 22
TOUCHE SPRAY ................................................... 22
SYSTÈME ANTI-GOUTTES ....................................... 23
ARRÊT AUTOMATIQUE .......................................... 23
APRÈS LE REPASSAGE........................................... 23
Entretien et nettoyage ..................................................................24
Anticalcaire et SELF CLEAN .........................................................24
GARANTIE LIMITÉE ............................................... 25

16
CONSIGNES DE SÉCURITÉ
L’utilisation d’un appareil électrique quel qu’il soit implique
le respect de quelques simples de sécurité :
LISEZ ATTENTIVEMENT LES INSTRUCTIONS
AVANT D’UTILISER L’APPAREIL
1. Utilisez l’appareil exclusivement pour l’usage auquel il
a été destiné.
2. Pour éviter les décharges électriques, évitez d’immerger
l’appareil dans l’eau ou dans d’autres liquides.
3. Relez l’appareil sur “MIN” avant de le brancher ou de le
débrancher. Ne tirez jamais le cordon d’alimentation pour
débrancher l’appareil. Saisissez la fiche et extrayez-la de la
prise.
4. Always disconnect appliance from electrical outlet before
filling with water, emptying or when not in use.
5. Débranchez toujours l’appareil avant de remplir ou de vider
le réservoir d’eau et si vous ne l’utilisez pas.
6. Évitez d’allumer l’appareil s’il est tombé, s’il a subi des
dégâts ou si le cordon est abîmé. Pour éviter les décharges
électriques, ne démontez pas l’appareil ; apportez-le
dans un centre de Service agréé pour le faire contrôler et
éventuellement réparer. Un réassemblage mal effectué
pourrait provoquer des décharges électriques pendant
l’utilisation.
7. Veillez à ce que les enfants ne touchent pas à l’appareil.
Soyez très vigilant quand l’appareil est utilisé en présence
d’enfants Ne laissez jamais le fer sans surveillance lorsqu’il
est branché ou posé sur la table à repasser.
8. Le contact avec des pièces métalliques chaudes, de l’eau
bouillante ou de la vapeur peut provoquer des brûlures.
Faites attention quand vous renversez l’appareil : le réservoir
pourrait contenir de l’eau bouillante.

17
FR
9. De’Longhi déconseille les accessoires car ils pourraient
provoquer des incendies, des décharges électriques ou des
blessures.
INSTRUCTIONS
1. Pour éviter les surcharges, n’utilisez pas d’autres
appareils à haut voltage branchés sur le même
circuit.
2. Si vous avez besoin d’un cordon plus long, utilisez
une rallonge ayant un ampérage pareil ou supérieur
au classement maximal du fér. Les cordons ayant un
ampérage inférieur risquent de surchauffer. Placez le
cordon de manière à ne pas le tirer ni vous prendre les
pieds dedans.
3. Après avoir déballé l’appareil, vérifiez son intégrité. Si
vous avez des doutes, ne l’utilisez pas et adressez-
vous à votre revendeur ou dans un centre de Service
agréé.
4. Pour toute réparation et pour remplacer le cordon
d’alimentation s’il est détérioré, adressez-vous à votre
revendeur habituel ou au Centre de Service Agréé :
votre appareil conservera ainsi toute son efficacité.
Pour la même raison, nous conseillons de toujours
utiliser des pièces de rechange d’origine.
L’emploi de tout appareil électrique implique le respect
de quelques règles fondamentales. EN PARTICULIER :
• Netouchezpasl’appareillesmainsoulespiedsmouillésou
humides. N’immergez pas l’appareil dans l’eau.
• N’utilisezpasl’appareildanslasalledebains.
• Netirezpaslecordond’alimentationnil’appareilles
mains ou les pieds mouillés ou humides.
• Ne laissez pas les enfants ni les incapables utiliser

18
l’appareil sans surveillance.
• Ne laissez pas l’appareil inutilement branché et
sans surveillance, il se transformerait en source de
danger.
• Avant toute opération de nettoyage ou d’entretien,
débranchez l’appareil pour couper l’alimentation
électrique.
• Ne mettez jamais l’appareil sous le robinet pour
ajouter de l’eau.
• Évitezdedirigerlejetdevapeursurlespersonnes,les
animaux ou des vêtements à repasser quand il sont
endossés, c’est dangereux !
• After ironing, allow the iron to cool before putting
away.
• Le fér doit être utilisée et posée sur une surface
stable.
• Lorsquevousposezlefersursonrepose-fer,veillezà
ce que celui-ci soit posé sur une surface stable.
• Évitezd’utiliserlefers’ilesttombé,s’ilprésentedes
signes de dommages visibles ou s’il fuit.
CONSERVEZ CES
INSTRUCTIONS
CET APPAREIL EST DESTINÉ À UN
USAGE EXCLUSIVEMENT DOMESTIQUE.

19
FR
DESCRIPTION DE L’APPAREIL
(page 3)
A Semelle
B Spray
C Clapet remplissage réservoir
D Régulateur de vapeur
E Touche spray
F Témoin marche/auto shut-off (seulement sur certains modè-
les)
G Voyant ‘vapeur prête’
HBouton réglage thermostat
I Touche “Self Clean” (nettoyage automatique)
L Touche “Turbo”
MDoseur d’eau
PREMIÈRE MISE EN SERVICE
• Lorsdelapremièremiseenservice,retirezl’éventuellepro-
tection de la semelle.
• Lors de la première utilisation, l’appareil peut produire un
peu de fumée pendant quelques minutes et une odeur due
au réchauffement et au séchage des colles utilisées pour
l’assemblage. Il est conseillé d’aérer la pièce.
PRÉPARATION
Quelle eau utiliser ?
Ce fer fonctionne avec de l’eau du robinet
Si l’eau est très dure, nous vous suggérons de diluer de l’eau
déminéralisée à 50% dans de l’eau du robinet.
N’utilisez jamais de la simple eau distillée.
Évitez les substances chimiques et détergentes (eaux parfumées,
essences, solutions détartrantes, etc.).
