Delta Children Jeep SPORT UTILITY User manual

ADULT ASSEMBLY REQUIRED
INSTRUCTION MANUAL
STYLES AND COLORS MAY VARY
12498
SPORT UTILITY
ALL-TERRAIN
STROLLER
Fits Graco® SnugRide® Click Connect™ 30, 35, and 40 Infant Car Seat (not included)
Fits Evenflo® Embrace™ Select Infant Car Seat (not included)
Fits Evenflo® Nurture™ Infant Car Seat (not included)
Fits Chicco®Keyfit 30™ Infant Car Seat (not included)
Fits Britax®B-Safe 35™ Infant Car Seat (not included)
WARNING:
Adult assembly required because of
small parts. Keep assembly parts out
of reach of children
under 3 years.
CHOKING HAZARD
www.DeltaChildren.com
DCP-02052019-V3
Customer Care Tel. [phone]
Read all instructions BEFORE assembly and USE of product. KEEP INSTRUCTIONS FOR FUTURE USE.
This stroller is not from, sponsored or endorsed by Britax®.
This stroller is not from, sponsored or endorsed by Evenflo Company, Inc.
This stroller is not from, sponsored or endorsed by Graco Children’s Products Inc.
This stroller is not from, sponsored or endorsed by Artsana S.p.A.

2
CARE AND MAINTENANCE
WARNING: Please follow all of these instructions to ensure the safety of your child. Keep these
instructions for future reference.
WARNING: Failure to follow these instructions could result in serious injury or death.
WARNING: Avoid serious injury from falling or sliding out. Always insure that the child is properly
positioned by using the safety harness according to these instructions.
WARNING: Never leave children unattended.
WARNING: CHOKING HAZARD Adult assembly required because of small parts.
Keep (assembly parts) out of reach of children under 3 years.
CAUTION: Purses, shopping bags, parcels, diaper bags or accessory items may change the balance of
the stroller and cause hazardous unstable conditions.
• The maximum weight that can be carried in the lower basket, and child tray, each is 3 lbs (1.36 kg).
Excessive weight may cause a hazardous unstable condition to exist.
• Before allowing the children near the stroller, be certain the stroller is fully erect and latched in the
open locked position.
• Use of the stroller with children weighing more than 50 pounds or over 42 inches tall, will cause
excessive wear and stress on the stroller and may cause hazardous unstable condition to exist.
NEVER use the stroller on stairways or escalators.
• NEVER use the stroller with roller skates or in-line skates.
Never allow your stroller to be used as a toy.
To prevent injury:
Make sure all body parts are clear of the stroller when folding and unfolding.
• To clean the plastic parts on stroller use a mild cleaning solution with warm water on a sponge or
damp cloth. Hand wash fabric with damp cloth and air dry. Do not use bleach.
• To keep your stroller wheels from squeaking, use silicone or graphite based lubricant.
• Check your stroller for loose screws, worn parts, torn material or stitching on a regular basis. Replace
or repair parts as needed.
• Discontinue use of stroller if it should become damaged or malfunctions.
• If you experience any difficulty with assembly, missing parts or use, please DO NOT return this item to
the store. Retail stores are unable to properly assist you. Contact our Customer Service Department
directly for assistance 1-646-435-8726.
1-646-435-8726

3
Parts Assembly
IMPORTANT! Please remove all parts from the package and identify them
before assembly.
Customer Service Tel. [phone] www.DeltaChildren.com
Front Wheel
(Lock & Swivel) x 2
Rear Wheel x 2
Seat
Stroller Frame
Part # 50242
Part # 50240
Part # 50243
IMPORTANT! Before assembly and each use, inspect this product for
damaged hardware, loose joints, missing parts, or sharp edges. NEVER use
if any parts are missing or broken. Contact manufacturer for replacement
parts and instructions if needed. Never substitute parts. IMPORTANT! Adult
assembly is required.
Remove stroller from box. The front wheels, rear wheels, seat, canopy, and
child bar need to be installed prior to use.
Child Bar
Canopy
5 in 1 Car Seat
Adapter
Part # 50241
Part # 50247
Fig. 1
Fig. 1B
WARNING: Care must be taken when folding and unfolding
the stroller to prevent finger entrapment.
1
• First, release the locking latch clip which is located on the right side of
the stroller. (Fig. 1)
• Second, lift up on the stroller handle with both hands until the stroller
frame is in a fully opened and locked position. (Fig. 1A) The stroller is in
a fully locked position when both side handle latches are in a fully locked
position and clicks. (Fig. 1B) Prior to placing your child into the stroller,
test to make sure both latches are fully engaged and fully locked.
Opening Stroller
Fig. 1A
WARNING: Care must be taken when folding and unfolding the
stroller to prevent finger entrapment.
Front
Back
Fully Locked
Position Once
Both Sides Click
CLICK
Carry All Parent
Organizer

4
Assembly
Customer Service Tel. [phone] www.DeltaChildren.com
Please follow these instructions for the proper installation of your front wheel assembly.
Attaching Front Wheels
•To attach front wheels: Push each front wheel posts into the front
wheel housing until they “CLICK” into a fully locked position. (Fig. 2)
Note: Pull downward on each wheel to ensure that each wheel is securely
locked.
Removing Front Wheels
Note: Make sure the back brakes are fully engaged.
•To release front wheels: Press the grey button located on the back of
the wheel housing and pull downward to release. (Fig. 2A)
Front Swivel Wheel Lock
• To lock the front swivel wheel lock: Rotate the lever located on the
top of the front wheel housing clockwise until it “CLICKS” into a fully
locked position (Fig. 3).
• To unlock the front swivel wheel lock: Rotate the lever located on
the top of the front wheel housing counter clockwise until it “CLICKS” into
a fully locked position (Fig. 3A).
Fig. 2
Fig. 3 Fig. 3A
Fig. 2A
Note: Before attaching front wheels, make sure the stroller is in a fully open
position.
3
2
Rotate clockwise
to lock
Rotate counter
clockwise to unlock

5
Customer Service Tel. [phone] www.DeltaChildren.com
Assembly
Attaching / Removing Rear Wheels
Attaching Rear Wheels
• To attach rear wheels: Push each rear wheel posts into the rear wheel
housing (Fig. 4) until they “CLICK” into a fully locked position (Fig. 4A).
Note: Pull outward on each wheel to ensure that each wheel is securely
locked.
• Repeat on opposite side.
Removing Rear Wheels
• To remove the rear wheels: Press the grey button located on the
back of the wheel housing (Fig. 4B) and pull wheel outward until wheel is
released (Fig. 4C)
• Repeat on opposite side.
Rear Non-Swivel Wheel Brakes - One Touch Brake System
• To engage brakes: Apply light downward pressure to the linked brake
lever located on the right side of the rear wheel housing. (Fig. 5) Check to
make sure the brakes are in a fully locked position, making sure stroller will
not move when pushed.
• To release brakes: Gently lift up on the linked brake lever. (Fig. 5A)
WARNING: Always lock brakes when the stroller is not being
pushed so that the stroller will not roll away. Never leave stroller
unattended on a hill or incline as the stroller may slide down the hill.
WARNING: NEVER leave child unattended in stroller.
Fig. 4
Fig. 4A
Fig. 4C
Fig. 4B
Fig. 5
Fig. 5A
Push downward on brake
lever to lock stroller
Removing Rear Wheels:
Attaching Rear Wheels:
Fully Locked
Position
CLICK
Push upward on brake
lever to unlock stroller
Please follow these instructions for the proper installation of your rear wheel assembly.
4
5

6
Rear Facing Seat -
Child Facing Parent-
Infant
Front Facing Seat -
Child Facing
Away from Parent
-Toddler
Fig. 6A
Fig. 6
Fig. 6B
Fig. 6C
Attaching / Removing Seat
Attaching Seat
• To attach seat to stroller: Face seat to the preferred direction. Rear
facing seat (Fig. 6) or front facing seat (Fig. 6A). Press seat into right / left
housing until it “CLICKS” into a fully locked position (Fig. 6B).
Note: Pull upward on seat to ensure that the seat is securely locked into
right / left seat housing.
Removing Seat
• To remove or reverse seat from stroller: Press the buttons located
on both sides of the stroller and lift seat upward to fully remove. (Fig. 6C)
6
CLICK
Assembly
Fully Locked
Position
Right / Left Seat
Housing
Customer Service Tel. [phone] www.DeltaChildren.com

7
Customer Service Tel. [phone] www.DeltaChildren.com
Securing Child
1
Securing Child
•Place your child in the stroller. Position the crotch belt between your
child’s legs.
•Pull shoulder straps over child’s arm and shoulder and fasten both strap
ends to the restraint system.
•Fasten both waist belts to the buckle on each side of the crotch belt.
Make sure you hear a “click” on both sides.
•Check to be sure the restraint system is securely attached by pulling it
away from your child. The restraint system should remain attached.
3
To tighten the waist belts and shoulder straps:
•Feed the anchored end of a waist belt up through the buckle to form a
loop A. Pull the free end of the waist belt B.
•Repeat this procedure to tighten the other waist belt.
•Feed the top end of the shoulder strap through the plastic stay to form
a loop . Pull the bottom end down to tighten the strap .
•Repeat this procedure to tighten the other shoulder strap.
To loosen the waist belts and shoulder straps:
•Feed the free end of the waist belt up through the buckle to form a
loop A. Enlarge the loop by pulling on the end of the loop toward the
buckle. Pull the anchored end of the waist belt to shorten the free end of
the waist belt B.
•Repeat this procedure to loosen the other waist belt.
•Feed the bottom end of the shoulder strap through the plastic stay to form
a loop . Pull the top end up to loosen the strap .
•Repeat this procedure to loosen the other shoulder strap.
Please note: After adjusting the restraint system to fit your child, make sure
you pull on it to be sure it is securely fastened.
TIGHTEN
LOOSEN
5 Point Safety
Harness
2
•Tighten each waist belt and shoulder strap so that the restraint system is
snug against your child.
Please refer to the next section for instructions to tighten the waist belts.
C
C
D
D
Before Placing your Child in Stroller:
Close Canopy. Press both brake pedals down until they “click” into the locked position.
Make sure the brake pedals are pressed down completely.
Always set both brake pedals when parking the stroller.
Waist Belt
Waist Belt
Crotch Belt
Restraint System

8
Customer Service Tel. [phone] www.DeltaChildren.com
Fig. 7E
Fig. 7F
Fig. 7G
Attaching Canopy and Canopy and Sun Visor Adjustment
Attaching Canopy
• To attach the canopy: Place canopy onto the top front of the stroller.
(Fig. 7) Then, slide both sides of the canopy locks into both canopy
housings (Fig. 7A) until they “CLICK” into a fully locked position (Fig.
7B). Match the velcro edges of the canopy with the seat velcro (Fig. 7C)
until the canopy is fully attached to the seat. Pull the front edge of the
canopy forward until fully opened. (Fig. 7D)
• To open the sun visor: Grab front edge of the sun visor under canopy
and pull down and rotate forward until fully extended. (Fig. 7E)
• To close canopy: Push backward on the front edge until canopy is all
the way collapsed. (Fig. 7F).
Removing Canopy
• To remove the canopy: First, unvelcro the canopy off the seat. Then, press
the canopy release buttons downward and slide both sides of the canopy
upward off the stroller frame sides to fully remove. (Fig. 7G)
7
Setup and Use
Canopy Adjustment Options:
Velcro
Fig. 7
Fig. 7A
Fig. 7B
Fig. 7C
Fig. 7D
Fully Locked
Position

9
Seat Back Recline Positioning
• To recline seat: Lift recline latch located on the back of the seat and
rotate seat downward to recline seat. (Fig. 8)
• To return to an upright position: Pull the recline latch and push seat
upward into its desired position until it “CLICKS” into a fully locked
position. (Fig. 8A)
Foot Rest Adjustment
• To adjust foot rest: Press both recline buttons located on left/right side
of foot rest. While pressing both recline buttons, rotate foot rest upward or
downward to its desired position until it “CLICKS” into a fully locked
position. (Fig. 9)
Adjustable Handle
• To adjust handle: Press both left / right buttons inward located on the
outside of both sides of the stroller frame. (Fig. 10) While pressing both
buttons rotate the handle upward or downward to its desired position.
(Fig. 10A)
• The handle will “CLICK” on both sides once it is in a fully locked position.
8
910
Fig. 8
Fig. 9
Fig. 8A
RECLINE
Press Recline
Button On Both Sides Rotate Handle Upward
Or Downward Press Both Buttons
Inward
Rotate
Up or Down
UPRIGHT
1
2
2
Fig. 10A
Fig. 10
Setup and Use
Customer Service Tel. [phone] www.DeltaChildren.com

10
Customer Service Tel. [phone] www.DeltaChildren.com
Setup and Use
2
1
Attaching / Removing Child Bar
Attaching Child Bar
• To attach child bar: Insert left / right sides of the child bar into the child
bar housing located on the left / right side of the stroller frame. (Fig. 11)
• The child bar will “CLICK” on both sides once it is in a fully locked position.
(Fig. 11A)
Note: Pull upward on the child bar to ensure it is securely locked onto the
stroller frame.
Removing Child Bar
• To remove child bar: Press both child bar buttons located on both sides
of the stroller frame and pull upward to release. (Fig. 11B)
Removing Child Bar Cover
• To remove child bar cover for cleaning: First, remove the velcro strap.
(Fig. 11C) Then unzip the cover from left to right located under the child bar.
(Fig. 11D)
11
CLICK
Fig. 11 Fig. 11A
Fig. 11B
Fig. 11C
Fig. 11D Unvelcro
Child Bar
Cover
Unzip

11
12
Press Both Side
Buttons And Lift
To Fully Remove
Seat
Car Seat Adapter -
Correct Placement Car Seat Adapter Clicks And Locks
On Both Sides Of The Stroller Frame
When In A Fully Locked Position
Front Back
Insert On
Both Sides
Fig. 12A
Fig. 12B
Fig. 12C
Fig. 12D:
Customer Service Tel. [phone] www.DeltaChildren.com
Attaching Chicco Car Seats - Keyfit 30™:
Lock the rear wheels (Fig.12). Remove seat (Fig. 12A). Attach the car seat
adapter to the stroller frame (Fig. 12B) until it clicks into a fully locked
position (Fig. 12C). Place car seat into car seat adapter until it “CLICKS”
into a fully locked position. Chicco car seats “CLICK” and lock on both
sides of the adapter when in a fully locked position (Fig. 12D). Make sure
car seat is fully fastened by pulling upward.
®
Fig. 12 Push downward on brake
lever to lock stroller
Lock The Rear Wheels:
Attaching Car Seat Adapter:
Securing Car Seat With Velcro Straps:
Remove Seat:
Attaching Chicco Car Seats
®
Chicco Keyfit 30™
®
Fig. 12E
Chicco Car Seat Side Locking Tabs
Lock Under This Area On The Adapter
Locking Tabs
Located On Both
Sides Of Car Seat
Securing Car Seat With Velcro Straps-
Final step to secure the footrest side of car seat onto stroller, use the straps
with velcro to secure seat onto stroller. (Fig. 12E). Check that car seat is
securely attached by pulling up on the car seat. To remove, undo latches and
unlock car seat from adapter.
Removing Car Seat - To remove, squeeze release handle at back of infant
restraint and lift upward out of adapter.
Car Seat In A Fully
Locked Position
Car Seat Locking
Tabs Lock On Both
Sides When In A Fully
Locked Position

12
Attaching Graco Car Seats
®
Graco SnugRide® Click Connect™ 30, 35, and 40
®
Car Seat Back Locking Tab Locks
Under The Back Of The Adapter
When In A Fully Locked Position
Car Seat In A Fully
Locked Position
13
Attaching Graco Car Seats- SnugRide® Click Connect™ 30, 35
and 40:
Lock the rear wheels (Fig.13). Remove seat (Fig. 13A). Attach the car seat
adapter to the stroller frame (Fig. 13B) until it clicks into a fully locked position
(Fig. 13C). Place car seat into car seat adapter until it “CLICKS” into a fully
locked position. Graco car seats “CLICK” and lock on the back and both sides
of the adapter when in a fully locked position (Fig. 13D). Make sure car seat is
fully fastened by pulling upward.
®
Securing Car Seat With Velcro Straps-
Final step to secure the footrest side of car seat onto stroller, use the straps
with velcro to secure seat onto stroller. (Fig. 13E). Check that car seat is
securely attached by pulling up on the car seat. To remove, undo latches and
unlock car seat from adapter.
Removing Car Seat - To remove, squeeze release handle at back of infant
restraint and lift upward out of adapter.
Car Seat Adapter -
Correct Placement Car Seat Adapter Clicks And Locks
On Both Sides Of The Stroller Frame
When In A Fully Locked Position
Front Back
Insert On
Both Sides
Fig. 13B
Fig. 13C
Attaching Car Seat Adapter:
Graco Car Seat Side Locking Tabs Lock
Into This Area On The Adapter
Locking Tabs
Located On Both Sides
Of Car Seat
Car Seat Locking Tabs
Lock On Both Sides When
In A Fully Locked Position
Fig. 13D:
Customer Service Tel. [phone] www.DeltaChildren.com
Press Both Side
Buttons And Lift
To Fully Remove
Seat
Fig. 13A
Fig. 13 Push downward on brake
lever to lock stroller
Lock The Rear Wheels: Remove Seat:
Fig. 13E
Securing Car Seat With Velcro Straps:

13
Customer Service Tel. [phone] www.DeltaChildren.com
Attaching Evenflo Car Seats
®
Evenflo Nurture™ and Embrace™
®
Attaching Evenflo Car Seats - Evenflo® Nurture™ and Embrace™-
Lock the rear wheels (Fig. 14). Remove seat (Fig. 14A). Press both buttons
located on the front side of the adapter and rotate into a downward position
(Fig. 14B). Attach the car seat adapter to the stroller frame (Fig. 14C) until it
clicks into a fully locked position (Fig.14D). Place car seat into car seat adapter
until it “CLICKS” into a fully locked position. Evenflo car seats “CLICK” and
lock on the back of the adapter when in a fully locked position (Fig. 14E). Make
sure car seat is fully fastened by pulling upward.
®
14
Evenflo Car Seat
Fully Locked Position
Securing Car Seat With Velcro Straps-
Final step to secure the footrest side of car seat onto stroller, use the straps
with velcro to secure seat onto stroller. (Fig. 14F). Check that car seat is
securely attached by pulling up on the car seat. To remove, undo latches and
unlock car seat from adapter.
Removing Car Seat - To remove, squeeze release handle at back of infant
restraint and lift upward out of adapter.
Fig. 14B
Car Seat Adapter -
Correct Placement Car Seat Adapter Clicks And Locks
On Both Sides Of The Stroller Frame
When In A Fully Locked Position
Front Back
Fig. 14C
Fig. 14D
Attaching Car Seat Adapter:
Evenflo Locking Latch
Locks Under Center
Of Adapter When In A
Fully Locked Position
Fig. 14E
Fig. 14F
Insert On
Both Sides
Press Both Side
Buttons And Lift
To Fully Remove
Seat
Fig. 14A
Fig. 14 Push downward on brake
lever to lock stroller
Lock The Rear Wheels: Remove Seat:

14
Customer Service Tel. [phone]
Attaching Britax Car Seats
®
Britax Car Seat Clicks and Locks
Into The Sides Of The Adapter
When In A Fully Locked Position
Car Seat Clicks And
Locks Into The Sides Of
The Adapter
Britax B-Safe 35™
®
Attaching Britax Car Seats - B-Safe 35™-
Lock the rear wheels (Fig. 15). Remove seat (Fig. 15A). Attach the car seat
adapter to the stroller frame (Fig. 15B) until it clicks into a fully locked
position (Fig.15C). Place car seat into car seat adapter until it “CLICKS”
into a fully locked position. Britax car seats “CLICK” and lock on the both
sides of the adapter (Fig. 15D). Make sure car seat is fully fastened by
pulling upward.
®
15
Securing Car Seats With Velcro Straps-
Final step to secure the footrest side of car seat onto stroller, use the straps
with velcro to secure seat onto stroller. (Fig. 15E). Check that car seat is
securely attached by pulling up on the car seat. To remove, undo latches and
unlock car seat from adapter.
Removing Car Seat - To remove, squeeze release handle at back of infant
restraint and lift upward out of adapter.
Press Both Side
Buttons And Lift
To Fully Remove
Seat
Fig. 15A
Fig. 15
Push downward on brake
lever to lock stroller
Lock The Rear Wheels: Remove Seat:
Car Seat Adapter -
Correct Placement
Car Seat Adapter Clicks And Locks
On Both Sides Of The Stroller Frame
When In A Fully Locked Position
Front Back
Insert On
Both Sides
Fig. 15B
Fig. 15C
Attaching Car Seat Adapter:
Fig. 15D: Fig. 15E:
www.DeltaChildren.com
Fig. 15E

15
Setup and Use
16
Folding the Stroller
WARNING: Care must be taken when folding and unfolding the
stroller to prevent finger entrapment.
NOTE: Stroller can be folded with seat attached, if folding with
seat attached, make sure canopy is in it’s fully closed position,
seat is in a fully upright position, and footrest is in it’s lowest
position before folding the stroller.
• Folding the Stroller with Seat Attached: Close the canopy as
described on page 8, Fig. 7F, position the seat to a an upright position as
described on page 9, Fig. 8A, and position footrest to it’s lowest position
page 9, Fig. 9. Pull the fold latches located on both sides of the stroller
frame upward and move handle downward, until the stroller is in a fully
folded position. Folding latch will automatically lock once stroller is in a
fully folded and locked position (Fig. 16A).
• Folding the Stroller without Seat Attached: Pull the fold latches
located on both sides of the stroller frame upward and move handle
downward, until the stroller is in a fully folded position. Folding latch will
automatically lock once stroller is in a fully folded and locked position
(Fig. 16A).
Fig.16
Fig. 16A
Fold Latches
Auto Lock
Fully Folded
Position
Customer Service Tel. [phone] www.DeltaChildren.com

16
The stroller features rear bicycle air tires which could become flat. If you have a flat tire, use a standard bicycle hand
air pump to inflate the tires. Inflate the tires 28 psi.
NOTE: The stroller air tires can be taken to a bicycle shop for flat tire repair.
Flat Tire
Customer Service Tel. [phone] www.DeltaChildren.com

17
646-435-8726
