Delta Children J is for JEEP CROSS COUNTRY SPORT PLUS User manual

Customer Service: 1-(800)-377-3777
www.DeltaChildren.com
DCP-IM-02282018
CROSS COUNTRY
SPORT PLUS
JOGGING STROLLER
Read all instructions BEFORE assembly and USE of product. KEEP INSTRUCTIONS FOR FUTURE USE.
INSTRUCTION MANUAL
This stroller is not from, sponsored or endorsed by Graco Children’s Products Inc.
This stroller is not from, sponsored or endorsed by Evenflo Company, Inc.
This stroller is not from, sponsored or endorsed by Artsana S.p.A.
Copyright Britax. All rights reserved.
Fits Graco® SnugRide® Click Connect™ Infant Car Seat (not included)
Fits Evenflo® Embrace™ Select Infant Car Seat (not included)
Fits Evenflo® Nurture™ Infant Car Seat (not included)
Fits Chicco®Keyfit 30™ Infant Car Seat (not included)
Fits Britax®B-Safe 35™ Infant Car Seat (not included)
WARNING:
Adult assembly required because of
small parts. Keep assembly parts
out
of reach of children under 3 years.
CHOKING HAZARD
STYLES AND COLORS MAY VARY
12988

WARNING: Please follow all of these instructions to ensure the safety of your child. Keep these
instructions for future reference.
WARNING: Failure to follow these instructions could result in serious injury or death.
WARNING: Avoid serious injury from falling or sliding out. Always insure that the child is properly
positioned by using the safety harness according to these instructions.
WARNING: Never leave children unattended.
WARNING: FALL HAZARD from tip over. Before running, jogging, or walking fast, LOCK the front wheel
from swiveling.
CAUTION: This is a single occupant jogging stroller for one child only. The use of more than one child
may cause an unstable condition which can injure your child. Do not place parcels, diaper bags or
accessory items on jogging stroller as this can cause an unstable condition.
• The maximum weight that can be carried in the lower basket, child tray, parent fabric tray and carry all
parent organizer each is 3 lbs (1.36 kg).
• Before allowing the children near the stroller, be certain the stroller is fully erect and latched in the
open locked position.
• Use of the stroller with children weighing more than 50 pounds (22.62 kg) or over 42 inches (106.7
cm) tall, may cause a hazardous unstable condition to the stroller.
• NEVER use the stroller on stairways.
• NEVER use the stroller in conjunction with bicycles, skateboards, roller skates, or in-line skates.
Please discuss using the jogging stroller with your health care provider prior to jogging use. We
recommend that the child occupant needs to be 6 months of age, at the minimum, before use of the
stroller.
• To clean the stroller use a mild household soap with warm water on a sponge or clean cloth.
• Check your stroller for loose screws, worn parts, torn material or stitching on a regular basis. Replace
or repair parts as needed.
• Discontinue use of stroller if it should become damaged or malfunctions. Please contact our customer
service number 1-800-377-3777 to arrange for repair or obtain replacement parts.
• If you experience any difficulty with assembly, missing parts or use, please DO NOT return this item to
the store. Retail stores are unable to properly assist you. Contact our Customer Service Department
directly for assistance 1-800-377-3777.
Customer Service Tel. [phone] www.DeltaChildren.com
2
CARE AND MAINTENANCE

EXTENDED WARRANTY
DON’T MISS YOUR CHANCE TO BE COVERED FOR ALL OF LIFES MISHAPS!
With Delta’s Extended Warranty, you’re covered for mechanical failure from normal use or if
your item stops working due to normal wear and tear, plus all those unexpected surprises.
2 YEARS OF PROTECTION
For Additional Information:
Simply visit our Website, register your product, and add the Extended Warranty
https://www.deltachildren.com/pages/product-registration
Extended Warranty only available in the following States: Arkansas, Colorado, Delaware, District of Columbia, Georgia, Idaho,
Illinois, Indiana, Iowa, Kansas, Kentucky, Louisiana, Maryland, Michigan, Mississippi, Missouri, Nebraska, Nevada, New Hampshire,
New York, North Carolina, North Dakota, Pennsylvania, Rhode Island, South Dakota, Tennessee, Utah, West Virginia
STOP
Please DO NOT return this product to the store.
If you experience any difficulty with assembly, missing parts or use, please
DO NOT return this item to the store. Retail stores are unable to properly
assist you. Contact our Customer Service Department directly for
assistance 1-800-377-3777.
www.DeltaChildren.com • [email protected]
©2018 Delta Children’s Products, Inc. New York, NY 10001

Customer Service Tel. [phone] www.DeltaChildren.com
3
Carry All Parent Organizer
Chicco Car Seat Adapters
Left
Side View
Left Side
Front View-
When Facing
The Stroller
When Facing
The Stroller
Left Side
Front View
Right Side
Front View-
Right Side
Front View
Britax Car Seat Adapters
Child Tray
Parent Fabric Tray
Rear Wheels
Front Wheel
Part # 50218 Part # 50219
Part # 50174
Part # 50229 Part # 50171
Part # 50172
Part # 50217
Part # 50232 Part # 50231
Front Wheel Retainer Plate
Front Wheel Axel Lock Nuts
Stroller
Right
Side View

Front Wheel
Customer Service Tel. [phone] www.DeltaChildren.com
4
ASSEMBLY
FRONT WHEEL
IMPORTANT! To ensure safe operation of your stroller, please follow these instructions carefully. Please
keep these instructions for future reference.
IMPORTANT! Before assembly and each use, inspect this product for damaged hardware, loose joints,
missing parts or sharp edges. NEVER use stroller if any parts are missing or broken. IMPORTANT! Adult
assembly is required.
• Remove stroller from box. The front wheel, rear wheels, parent tray and child tray need to be installed
prior to use.
WARNING: This front wheel utilizes a front wheel axle lock nut system. Please follow all of these
instructions to ensure the safety of your child. Failure to follow these instructions could result in serious
injury or death.
1. Lean the stroller backwards so the rear axle
frame is resting on a flat surface and the front
wheel forks are pointing upward (Fig. 1).
2. Hook the front wheel axle into the front fork’s
slots (Fig. 1A).
Fig. 1
Fig. 1A
www.DeltaChildren.com
• To attach the front wheel, unfold stroller as
described in the following section:

Customer Service Tel. [phone] www.DeltaChildren.com
5
ASSEMBLY
WARNING:
FALL HAZARD
Wheel can detach and cause tip over. Pull on the wheel to assure it is securely attached and make sure
the front swivel wheel is in a locked position during running, jogging or walking fast.
WARNING: ALWAYS check that both front axle lock nuts are fully tighten before each use to ensure that
the front wheel is securely fastened to the frame.
3. Slide the retainer plate onto the front wheel
axle. Be sure that the retainer plate’s bent tab
is facing towards the front fork slot. The bent
tab on the retainer plate must be lined up with
and trapped inside the front fork slot before
tightening the wheel (Fig. 1B).
4. Install the axle lock nuts and tighten with
standard wrench, box or open end wrench.
The front axle lock nut will be fully tighten and
securely fastened when there is significant
resistance to front fork. Repeat on other side.
The wheel should be held tightly in place
(Fig. 1C).
Fig. 1B
TESTING FOR PROPER WHEEL INSTALLATION
Axle Lock Nut
Retainer Plate
Front Forks
Axle and Hub
Slot
Fig. 1C

Customer Service Tel. [phone] www.DeltaChildren.com
6
5. Lift the front wheel off of the ground and
sharply strike the top of the tire. (Fig. 1D) The
wheel should not be loose or come off.
6. To attach the rear wheels, lay stroller on its
side. Align back wheel axle to the stroller's
rear wheel axle housing (Fig. 2). Push the
back wheel axle inward until you hear a "click"
(Fig. 2A). Once in a fully locked position,
check to make sure back wheel is in a fully
locked position by pulling outward. Repeat
steps for other side back wheel. NEVER use
stroller if any wheels are not in a fully locked
position. Please contact our customer service
department immediately at 1-800-377-3777 for
assistance.
REAR WHEEL
Fig. 1D
Fig. 2
Fig. 2A
ASSEMBLY

Customer Service Tel. [phone] www.DeltaChildren.com
7
7. To attach parent fabric tray take velcro strap,
wrap around jogger handle and put strap through
clip (Fig. 3). Pull strap tight (Fig. 3A), and make
sure velcro section is attached (Fig. 3B). Repeat
4X times on all sides until fabric tray is attached.
To open the canopy: pull forward on the front
edge of the canopy until fully opened. (Fig. 5) To
close canopy: push backward on front edge until
canopy is all the way collapsed. (Fig. 5A)
To attach parent organizer take velcro strap, wrap
around jogger handle and put strap through clip
(Fig. 4). Pull strap tight (Fig. 4A), and make sure
velcro section is attached (Fig. 4B). Repeat on
opposite handle until parent organizer is attached.
PARENT TRAY
CANOPY
CARRY ALL PARENT ORGANIZER
WARNING: The maximum weight that can be carried in the parent tray is 3 lbs (1.36 kg). NEVER place
hot liquids in the parent tray as can cause serious burns and NEVER place more then 3lbs (1.36kg) in
parent tray as may cause an unstable condition.
Open
Fig. 5
Fig. 3
Fig. 4 Fig. 4A
Fig. 4B
Close
Fig. 5A
Fig. 3A Fig. 3B
ASSEMBLY
9.
8.

Customer Service Tel. [phone] www.DeltaChildren.com
8
To open the sun visor: grab front edge of sun
visor under canopy and pull down and rotate
forward until fully extended. (Fig. 6)
To open, flip backwards to show peek-a-boo
window. (Fig. 7)
SUN VISOR
PEEK-A-BOO-WINDOW
CHILD TRAY
SUN VISOR
ASSEMBLY
To attach the child tray: Rotate and align left
and right side of child tray posts with the left
and right side stroller tray posts. Press left
and right side child tray posts into left and
right side stroller tray posts into a fully locked
position. Press left side child tray button and
snap child tray onto stroller tray posts. Release
button to lock child tray onto stroller (Fig. 8).
Repeat on right side of child tray. Check to
make sure the child tray is securely attached
to the stroller by pulling upward on the child
tray.
10.
11.
12.
Fig. 6
Fig. 7
Fig. 8

To access child seat: press left or right release
buttons (Fig. 8A) and rotate tray upward (Fig. 8B).
ADJUSTABLE HANDLE
Fig. 8A
Fig. 8B
ASSEMBLY
Customer Service Tel. [phone] www.DeltaChildren.com
9
To remove the child tray: Press the right and
left release buttons and pull upward on child
tray. (Fig. 8C)
To adjust handle, first press handle release
button (Fig. 9) and push handle upward or
downward to desired position (Fig. 9A). When
you here a "click" handle is safely locked into
handle position.
Fig. 8C
13.
14.
15.
At the same time
press inward here
on both sides
(Fig. 9)
Rotate handle upward
or downward
(Fig. 9A)

Customer Service Tel. [phone] www.DeltaChildren.com
10
Rear Wheel Brakes: To lock rear wheel brakes,
press downward on brake lever located on
each rear wheel. (Fig. 10) Please note in
order to line up the break tab with brake tab
slots stroller may need to be moved forward
or backwards slightly. Check to make sure the
brakes are in a fully locked position, so stroller
will not move when pushed. To release brakes,
gently push up on the brake lever.
Fig. 10
SAFETY
BRAKES
WARNING: Always lock brakes when not in use on a hill or incline as stroller may roll away or slide down
the hill.
WARNING: Never leave child unattended in stroller.
Fig. 14
Rear Wheel
Brakes
16.

TO SECURE THE CHILD
Customer Service Tel. [phone] www.DeltaChildren.com
11
1
Securing Child
• Place your child in the stroller. Position the crotch belt between your
child’s legs.
• Pull shoulder straps over child’s arm and shoulder and fasten both strap
ends to the restraint system.
• Fasten both waist belts to the buckle on each side of the crotch belt.
Make sure you hear a “click” on both sides.
• Check to be sure the restraint system is securely attached by pulling it
away from your child. The restraint system should remain attached.
3
To tighten the waist belts and shoulder straps:
• Feed the anchored end of a waist belt up through the buckle to form a
loop A. Pull the free end of the waist belt B.
• Repeat this procedure to tighten the other waist belt.
• Feed the top end of the shoulder strap through the plastic stay to form
a loop . Pull the bottom end down to tighten the strap .
• Repeat this procedure to tighten the other shoulder strap.
To loosen the waist belts and shoulder straps:
• Feed the free end of the waist belt up through the buckle to form a
loop A. Enlarge the loop by pulling on the end of the loop toward the
buckle. Pull the anchored end of the waist belt to shorten the free end of
the waist belt B.
• Repeat this procedure to loosen the other waist belt.
• Feed the bottom end of the shoulder strap through the plastic stay to form
a loop . Pull the top end up to loosen the strap .
• Repeat this procedure to loosen the other shoulder strap.
Please note: After adjusting the restraint system to fit your child, make sure
you pull on it to be sure it is securely fastened.
TIGHTEN
LOOSEN
Crotch Belt
Waist BeltWaist Belt
5 Point Safety
Harness
2
• Tighten each waist belt and shoulder strap so that the restraint
system is snug against your child. Please refer to the next section
for instructions to tighten the waist belts.
Restraint System
C
C
D
D
Before Placing your Child in Stroller:
Close Canopy. Press both brake pedals down until they “click” into the locked position.
Make sure the brake pedals are pressed down completely.
Always set both brake pedals when parking the stroller.

12
SEAT BACK RECLINE POSITIONING
Fig. 11 Fig. 11A
Fig. 11B
17.
18.
To return to an upright position, hold bottom
cord loops while squeezing cord housing
and move cord housing upwards towards the
backseat, as shown in Fig. 11A.
Snap the three back buttons located on the
back of the seat, as shown in Fig. 11B.
Squeeze both sides on cord housing and pull
away to recline seat, as shown in Fig. 11.
ASSEMBLY
Customer Service Tel. [phone] www.DeltaChildren.com
WARNING: Always keep the three back buttons attached to the back of the seat at all times.

Customer Service Tel. [phone] www.DeltaChildren.com
13
HOW TO ATTACH GRACO AND EVENFLO
CAR SEATS
To use the car seat feature, lock back wheels,
close the canopy as described in the canopy
section (Please see Page 7, Fig. 5A). Recline
seat by squeezing both sides of cord housing
as described in seat back positioning section
(Please see Page 12, Fig. 11). Turn and lock
grey latches (Fig. 12). Align car seat as shown
in Fig. 12A. Angle feet first, while lowering car
seat into a locked position on the child tray.
Car seat is in a locked position when the car
seat "CLICKS" into the child tray. Graco car
seat locked position (Fig. 12B) Evenflo car
seat locked position (Fig. 12C). Make sure car
seat is locked in place by pulling upward on
car seat. Make sure car seat is locked in place
by pulling upward on car seat.
Fig. 12A
Fig. 12
Fig. 12A
Car Seat Safety
Grey Latches
19.
20.
® ®
ASSEMBLY
Evenflo®locked position -
grey locking tab clicks
Back of Evenflo®Car Seat
Graco locked position -
red locking tab clicks
®
Back of Graco Car Seat
®
Fig. 12B Fig. 12C
Britax Car
Seat Velcro
Graco, Evenflo, and
Chicco Car Seat
Velcro
Fig. 12D
Fig. 12E
Final step is to secure the car seat to
the stroller using the straps with velcro.
(Fig. 12D)
•The top strap is to secure Graco,
Chicco, and Evenflo car seats only.
•The lower velcro strap is to secure
Britax car seats only.
Secure the footrest side of car seat onto
the stroller, use the straps with velcro to
secure seat onto stroller. (Fig. 12E).
Check that car seat is securely attached
by pulling up on the car seat. To remove,
undo latches.
A
B
A
B
www.DeltaChildren.com
Fig. 12E
Fig. 12E
Fig. 12E

Customer Service Tel. [phone] www.DeltaChildren.com
14
Fig. 13A
Fig. 13B
22. Locate the Chicco left / right adapter. They are
labeled on the inside (L This Side Facing In)
and (R This Side Facing In). Line up the bottom
of Chicco right side adapter (R This Side Facing
In) with stroller arm post labeled "R" (Fig. 13A).
Insert Chicco adapter into stroller right arm post
(Fig. 13B). Make sure release button is securely
fastened into right side slot by pulling upward
to make sure Chicco adapter stays in place.
Repeat with left side Chicco adapter.
Left Side
Front View
Right Side
Front View
L
R
R
Insert With Locking
Tab Facing Inward
Chicco Car Seat
Adapters Attached
To Stroller
Correct Placement
When Facing Into Stroller
Fig. 13
HOW TO ATTACH CHICCO CAR SEATS
®
21. To use Chicco Keyfit 30 Car seat first,
lock the back wheels, close the canopy as
described in the canopy section (Please
see Page 7, Fig. 5A). Recline seat by
squeezing both sides of cord housing as
described in seat back positioning section
(Please see Page 12, Fig. 11) remove child
tray (Please see Page 9, Fig. 8C) and child
tray attachment arms. Press the release
buttons located on the inner side of stroller
arm. Press release button and pull upward
at the same time until tray attachment arm
is released (Fig. 13).

Customer Service Tel. [phone] www.DeltaChildren.com
15
Fig. 13C
Fig. 13D
Lock tab will
"Click" when
locked in place.
23. To attach Chicco car seat, line up foot end
of car seat toward stroller (Fig. 13C). Slide
car seat into Chicco adapters. Make sure car
seat is locked in place by pulling upward on
car seat. Car seat is secured when both side
lock tabs have "clicked" into place and car
seat does not lift up. (Fig. 13D) To remove car
seat, lift the back lever located on the back of
the car seat and lift car seat upward to fully
remove.
24.
Britax Car
Seat Velcro
Graco, Evenflo, and
Chicco Car Seat
Velcro
Fig. 13E
Fig. 13F
Final step is to secure the car seat to
the stroller using the straps with velcro.
(Fig. 13E)
•The top strap is to secure Graco,
Chicco, and Evenflo car seats only.
•The lower velcro strap is to secure
Britax car seats only.
Secure the footrest side of car seat onto
the stroller, use the straps with velcro to
secure seat onto stroller. (Fig. 13F).
Check that car seat is securely attached
by pulling up on the car seat. To remove,
undo latches.
A
B
A
B
www.DeltaChildren.com
Fig. 13F
Fig. 13F
Fig. 13F

Fig. 14
25.
HOW TO ATTACH BRITAX CAR SEATS
To use Britax B-Safe 35 Car seat first, lock the
back wheels, close the canopy as described in
the canopy section (Please see Page 7, Fig. 5A).
Recline seat by squeezing both sides of cord
housing as described in seat back positioning
section (Please see Page 12, Fig. 11) remove child
tray (Please see Page 9, Fig. 8C) and child tray
attachment arms. Press release button and pull
upward at the same time until tray attachment arm
is released. (Fig. 14)
16
Customer Service Tel. [phone] www.DeltaChildren.com
Fig. 14A
Fig. 14B
Fig. 14C
26. Locate the Britax left / right adapter. They are
labeled on the inside (L This Side Facing In)
and (R This Side Facing In) (Fig. 14A). Line up
the bottom of Britax right side adapter (R This
Side Facing In) with stroller arm post labeled
"R" (Fig. 14B). Insert Britax adapter into stroller
right arm post (Fig. 14C). Make sure release
button is securely fastened into right side slot
by pulling upward to make sure Britax adapter
stays in place. Repeat with left side Britax
adapter.
Insert With
Locking
Tabs Facing
Inward
L
R
Inner Side of Adapters
THIS SIDE FACING IN
L
BRITAX
THIS SIDE FACING IN
BRITAX
R
Correct Placement
When Facing Into Stroller

Britax Car
Seat Velcro
Graco, Evenflo, and
Chicco Car Seat
Velcro
27. To attach Britax B-Safe 35 car seat, line up foot
end of car seat toward stroller (Fig. 14D). Glide
car seat into Britax attachments. Make sure car
seat is locked in place by pulling upward on car
seat. Car seat is secure once both side lock tabs
have "clicked" into place and car seat does not
lift up. (Fig. 14E) To remove car seat, lift the back
lever located on the back of the car seat and lift
car seat upward to fully remove.
Fig. 14D
Fig. 14F
Fig. 14E
Car seat will
"CLICK" when
locked in place.
17
Customer Service Tel. [phone] www.DeltaChildren.com
Final step is to secure the car seat to
the stroller using the straps with velcro.
(Fig. 14F)
•The top strap is to secure Graco,
Chicco, and Evenflo car seats only.
•The lower velcro strap is to secure
Britax car seats only.
Secure the footrest side of car seat onto
the stroller, use the straps with velcro to
secure seat onto stroller. (Fig. 14G).
Check that car seat is securely attached
by pulling up on the car seat. To remove,
undo latches.
28.
A
B
A
B
Fig. 14G
Fig. 14G
Fig. 14G
Fig. 14G

Customer Service Tel. [phone] www.DeltaChildren.com
18
JOGGING WITH YOUR STROLLER
Close the canopy as described in the canopy
section (Please see Page 7 Fig. 5A). Recline
seat by releasing buckle as described in seat
back positioning section (Please see Page 12
Fig. 11).
• The stroller is folded by simultaneously pulling
each trigger fold located on right and left
handle above the canopy (Fig. 16). When the
fold latches are released, the handle will begin
to rotate and lower toward the floor.
Fig. 16
TO FOLD STROLLER
WARNING: Care must be taken when folding and unfolding the stroller to prevent finger entrapment.
When you are jogging with your child, use the
following safety features:
• LOCK THE FRONT SWIVEL WHEEL BY
PUSHING UPWARD ON THE FRONT
SWIVEL WHEEL LOCK PUTTING THE
FRONT WHEEL INTO A STRAIGHT
POSITION. (Fig. 15)
• SAFETY TETHER STRAP: Always connect
the safety tether strap to either right or left
wrist when jogging. The tether strap will keep
the stroller from moving or rolling away in the
event that you trip or stumble while running.
(Fig. 15A) The safety tether strap must remain
connected to the rear lower frame cross
member at all times. The safety tether strap
can be stored on the left or right side of the
stroller with the velcro attachment, when not in
use. (Fig. 15B)
Fig. 15A
Fig. 15
Push Upward To
Lock Front Swivel
Wheel
Fig. 15B
29.
30.
Front Swivel
Wheel Lock
• NOTE: Do not remove the safety tether strap
from the bottom wheel axle as it is intended to
prevent the stroller from tipping backwards if
the stroller happens to move or roll away in the
event that you trip or stumble.
ASSEMBLY

Fig. 16A
Fig. 17
Fig. 17A
WARNING: Care must be taken when folding and unfolding the stroller to prevent finger entrapment.
Release the fold buttons and move handle
downward until the stroller is completely folded.
The stroller is in a fully locked position when
the locking fold latch is locked over the “T” post,
located on the right side of the stroller. (Fig. 16A)
Place the stroller on the ground with all three
wheels touching the ground. Release the
locking folding latch, which is located on
the right side. (Fig. 17)
• Lift up on the stroller handle with both hands
until the stroller frame is in a fully opened and
locked open position. (Fig. 17A) The stroller
is in a fully locked position when both side
handle latches are in a fully locked position.
Prior to placing your child into the stroller, test
to make sure both latches are fully engaged
and fully locked.
TO UNFOLD STROLLER
Customer Service Tel. [phone] www.DeltaChildren.com
31.
32.
19
ASSEMBLY
