Delta Electronics AFB0812EHE Manual

80 x 80 x 38 MM SERIES
AFB
DIMENSIONS DRAWING
P & Q CURVE (AT RATED VOLTAGE) MOUNTING PANEL CUTOUT
http://www.deltaww.com
Bearing Type
Ball Bearings
Material
Impeller & Frame : Plastic(UL 94V-0)
Lead Wires :
UL 1007 AWG #24 OR Equivalent
Red Wire Positive(+)
Black Wire Negative(-)
Weight : 156 g (5.50 OZ)
New
Operating
Voltage
Range
MODEL Rated
Voltage
Maximum
Air Flow
Speed
Maximum
Air Pressure Noise
PART NO. FUNCTION VDC VDC Amp Watt R.P.M. CFM mmH O IN H O dB-A
22
AFB0812SHE -R00 / -F00 12 6.0 to 13.8 0.68 8.16 5000 2.060 72.76 13.89 0.547 46.0
AFB0824SHE -R00 / -F00 24 14.0 to 26.4 0.35 8.40
AFB0812EHE -R00 / -F00 12 6.0 to 13.8 1.00 12.00 5900 2.423 85.55 19.02 0.749 50.5
AFB0824EHE -R00 / -F00 24 14.0 to 26.4 0.50 12.00
AFB0812GHE -R00 / -F00 12 6.0 to 13.8 1.40 16.80 6800 2.804 99.01 25.54 1.006 54.0
AFB0824GHE -R00 / -F00 24 14.0 to 26.4 0.65 15.60
OUTLET SIDE INLET SIDE
(INCH)
(INCH)
mm
mm
UNIT:
UNIT:
LABEL
(3.150 0.020)
(2.815 0.012)
71.5 0.3
80.0 0.5
(3.150 0.020)
80.0 0.5
71.5 0.3
(2.815 0.012)
38.0 0.5
(1.496 0.020)
(2-0.157 0.012)
2-4.0 0.3
(8- 0.177 0.012)
8- 4.5 0.3
325.0 10.0
(12.795 0.394)
(0.394)
10.0
( 3.661)
93.0
( 3.504)
89.0
76.8
(2.815)
(3.024)
71.5
(3.024)
76.8
(2.815)
71.5
(4- 0.177)
4- 4.5
71.5
76.8
(3.024)
(2.815)
76.8
(3.024)
71.5
(2.815)
(4- 0.177)
4- 4.5
1.44 36.0
30.0
24.0
12.0
18.0
6.0
0
2
2
(mm H O)
(IN H O)
0.24
0
0.48
0.96
0.72
1.20
Air Pressure
120.060.00 30.0 90.0
Air Flow
(CFM)
1.500 0.75 2.25 3.00 (M /MIN) 3.75 3
AFB0812/24XE
GH
SH
EH
26
*
*
*
*
* Function type is optional.
* The max. air flow and the speed are measured in free air ; max. air pressure is measured at zero air flow.
* Noise is measured in anechoic chamber in free air, one meter from intake side.
* All readings are typical values at rated voltage.
* Specifications are subject to change without notice.
Input
Power
Input
Current
