Delta Electronics AHB1748VHG Manual

AHB
DIMENSIONS DRAWING
P & Q CURVE (AT RATED VOLTAGE)
Bearing Type
Ball Bearing
Material
Impeller : Plastic (UL 94V-0)
Frame : Die-cast Aluminum
Lead Wires :
UL 1007 AWG #24 OR Equivalent
Red Wire Positive (+)
Black Wire Negative (-)
Weight : 820g (28.93 oz)
s
*
*
*
*
* Function type is optional.
* The max. air flow and the speed are measured in free air ; max. air pressure is measured at zero air flow.
* Noise is measured in anechoic chamber in free air, one meter from intake side.
* All readings are typical values at rated voltage.
* Specifications are subject to change without notice.
Operating
Voltage
Range
MODEL
Rated
Voltage
Maximum
Air Flow
Speed
Maximum
Air Pressure Noise
UNIT: (INCH)
mm
http://www.deltaww.com
AHB1748VHG -R00 / -F00 48 32.0 to 80.0 0.71 34.08 4000 8.760 309.37 29.75 1.171 59.5
AHB1748SHG -R00 / -F00 48 32.0 to 80.0 0.88 42.24 4400 9.773 345.13 36.34 1.431 61.5
AHB1748EHG -R00 / -F00 48 32.0 to 80.0 1.22 58.56 4800 10.636 375.62 43.24 1.702 64.0
AHB1748GHG -R00 / -F00 48 32.0 to 80.0 1.52 72.96 5200 11.564 408.39 52.02 2.048 66.5
PART NO. 3
FUNCTION VDC VDC Amp Watt R.P.M. m /min CFM mmH O IN H O dB-A
22
41
MOUNTING PANEL CUTOUT
mm
(INCH)
UNIT:
OUTLET SIDE INLET SIDE
1.05
0.70
0.35
(IN H O)
0
2
Air Pressure
300.0
7.5
(mm H O)
0
0
2
0
200.0
Air Flow
100.0
5.02.5
18.0
9.0
27.0
12.5
400.0
10.0
(CFM)
(M /MIN)
3
2.10
1.40
AHB1748XG
36.0
45.0
54.0
1.75
VH
GH
EH
SH
172 x 50.8 MM SERIES
Input
Power
Input
Current
