Delta Electronics DPS-180KB-4 Series User manual

FEATURES
Complies with TFX12V
Remote
High Reliability
Built-in EMI Filter
TTL Compatible Power Good Signal
All Outputs SELV (Safety Extra Low Voltage)
Fan Speed Control Function Inside
Optional PFC Circuit
On/Off
Low Acoustic Noise
Meets IEC 60950: 1999/UL 60950 3 Edition
rd
ENVIRONMENTAL
MTBF:
Dielectric Withstand:
Input to Output: 1800Vac for 1 sec
Input to Frame Ground: 1800Vac for 1 sec
>100,000 hours at Max. Load, 115Vac and 25
ambient conditions
ESD: IEC 61000-4-2
Surge: IEC 61000-4-5
Harmonic: IEC 61000-3-2 Class D
ELECTRICAL SPECIFICATIONS
Input
Output
Frequency 47-63Hz
Input Current 6A @ 115Vac; 3A @ 230Vac
Efficiency >68% @ Max. Load, Nominal Line
EMI/RFI FCC Part 15 Class B
CISPR 22 Class B
Maximum Power 180 Watts
Holdup Time >17mS @ Max. Load,
Rise Time 0.2mS ~ 20mS
Leakage Current <0.75mA @ 250Vac
Overvoltage Protection: +3.3V, +5V, +12V, -12V
Short-Circuit Protection:
Latch off all main outputs reset by cycling On/Off control
or AC power.
Power Good Signal:
TTL/CMOS compatible on delay 100mS to 500mS, off
delay 1mS minimum.
Input Range 90-135/180-265Vac, Switch-Select
Nominal Line
Overcurrent Protection: <240VA
85(W)x65(H)x175(L)mm
www.deltaww.com
V1 +3.3V +/-5% 0.5A 16.7A - 50mV
V2 +5V +/-5% 0.3A 12.0A - 50mV
V3 +12V +/-5% 2.0A 10.0A 13.0A 120mV
V4 -12V +/-10% 0A 0.3A - 120mV
V5 +5Vsb +/-5% 0A 2.0A - 50mV
Output Voltage Regulation Minimum Maximum Peak Ripple & Noise
Load Load Load Vp-p
DELTA PRODUCTS CORPORATION
4405 CUSHING PARKWAY
FREMONT, CA 94538, U.S.A.
TEL : [phone]
FAX : [phone]
DELTA ELECTRONICS, INC.
3, TUNG YUAN ROAD,
CHUNGLI INDUSTRIAL ZONE
TAOYUAN SHIEN, TAIWAN, R.O.C.
TEL : [phone]
FAX : [phone]
mail: [email protected]
DELTA ELECTRONICS EUROPE LTD.
2 YOUNG PLACE
KELVIN INDUSTRIAL ESTATE
EAST KILBRIDE, GLASGOW G75 OTD, U.K.
TEL : [phone]
FAX : [phone]
DELTA ELECTRONICS (JAPAN) INC.
DELTA SHIBADAIMON BLDG.
2-1-14 SHIBADAIMON, MINATO-KU,
TOKYO, 105-0012, JAPAN
TEL : [phone]
FAX : [phone]
DPS-180KB-4 Series
1. Peak-to-peak with 20MHz bandwidth and 10 F in parallel with a 0.1 F capacitor.
2. Total combined power on +3.3V & +5V rails are 61W maximum.
All specifications are subject to change without prior notice.
