Delta Regis ERGO15A Series Quick guide

INSTRUCTIONS FOR USE, ASSEMBLY
AND MAINTENANCE
ERGO15A
ORTHOGONAL REACTION ARM
ENG
Rev. Description Date
0 First release 02/17/2020
Delta Regis_ERGO15A_M_R0.0

2
Model Part Number
FOLDED TORQUE ARM - R 450 ERGO15A-1
FOLDED TORQUE ARM - R 600 ERGO15A-2
1 MODEL RANGE
We recommend reading this manual and
included safety instruction. In advance of
any use or intervention on the product.
The contents must be clearly understood
by the inal user. Product characteristics
maybe changed by Builder/Umandustry
without notice in advance.

3
2 PRELIMINARY INFORMATION
2.1 SYMBOLS USED IN THIS MANUAL
GENERAL WARNINGS
•All operations must be carried out either by builder’s personnel or by builder’s authorized
personnel, but professionally trained and educated, under supervision of a responsible person.
•User is recommended to use personal protection equipment (PPE) according to current
regulations, according to type of operation to be performed and should have adequate tooling.
•Missing compliance with following paragraphs, will relieve builder of any responsibility in case
of accidents, damages or malfunctioning of the machinery.
2.2 BUILDER IDENTIFICATIONS
Builder: Delta Regis Tools, Inc.
Address: 7370 Commercial Circle, Fort Pierce, FL 34951- U.S.A.
Main phone: [phone]
e-mail: www.deltaregis.com
Service Contact: [email protected]
Care point annotation
Warning sign. Maximum care required
Individual protection is mandatory, e.g. protective
gloves

4
PRODUCT SPECIFICATIONS
2.3 GENERAL PROPERTIES
The torque reaction arms are an excellent support for hand held tool assembly operations, e.g.
assembly with electronic tools.
They relieves efforts on operator arm, wrist and shoulders caused by repetitive tasks, vibrations, forces
and loads. Even a low rate of repetitive actions could cause severe disorders.
ERGO15A Torque reaction arms have a wide range of performance and are exceptionally easy to
install and use. They are designed for long-lasting.
ERGO15A folded torque arms are designed to absorb torque reaction forces applied in
orthogonal direction of arm axis..
Tool torque capacity must not exceed the maximum torque value specied for the torque reaction
arm in use.
It is recommended to use ERGO15A arms together with an appropriate balancers.
Arm bracket
-
Balancer attachment
Tool holder
Arm attachment
Column
Linear bushing support
First armFirst arm
Second armSecond arm

5
2.4 GENERAL SPECIFICATIONS

6
2.5 WORKING AREA
2.6 MODEL RANGE
Model
Max
Torque
(Nm)
R min
(mm)
R
max
(mm)
A
(mm)
B
(mm)
C
(mm)
Max
tool
weight
(Kg)
ERGO15A-1 15 100 467 988 218 467
(0°)
454
(22,5°)
420
(45°) 1.5
ERGO15 A2 15 100 600 988 294 618
(0°)
600
(22,5°)
547
(45°) 1.5

7
2.7 INSTALLATION (individual protections are mandatory)
12
3
5
7
6
4 x M6 x 25 mm (10 Nm)
p/n 00.00.04.0495
B
4 x washers
p/n 00.00.04.0786
C
4 x M5 x 16 mm (24,6 Nm)
p/n 00.00.04.0468
A
4
A
BC
45 mm
MAX
12 mm
Mandatory: arm must be assembled in horizontal position
Lift here Lift here
Recommended:
Arm vertical tilting up must be performed by two people.
After this operation, the arm will be ready for tool’s installa-
tion and balancers adjustment.

8
2.8 ARM INCLINATION CHANGE (individual protections are mandatory)

9
2.9 TOOL CLAMP ORIENTATION CHANGE (individual protections are mandatory)
1 X M8
(24,6 Nm)

10
2.10 INSTALLATION GUIDELINES
Fixation of torque arm
(bench installation)
•The reaction arm
should be always installed
in front of the operator
(considering his preferred
hand)
•Fix arm to workstation
bench or support through
attachment screws (see
page 7, pic. 7).
•Fix the power tool in
the tool holder.
•Adjust the balancer
tension.
•In order to nd an
optimal ergonomic
position, please consider
the following parameters
(see picture):
B: distance between tightening point and the rst arm. To be chosen in function of the dimension
of the part to be assembled, in order to avoid interference between parts and arm and for the
operator’s comfort.
C: maximum height of the tool from the oor. It should be achievable by the operator without
excessive vertical rotation of the shoulder (Y). Ergonomic practice suggest having all operation
below the center of the shoulder.
D: minimum and maximum work height. It is also dened as “stroke” of the arm. The arm
installation height should be chosen to allow an upper tool position which can be possibly far
from operator’s body, in order to prevent accidental contacts.
Others:
- it is suggested having the the tightening point positioned indicatively 100mm below the
operator’s elbow center (X). Therefore, height of table and eventual jigs for the part clamping
should be calculated accordingly.
x
Y

11
3 ACCESSORIES
3.1 ENCODER KIT
Model Part Number
ENCODER KIT XY ERGO-A-EKIT-XY
ENCODER KIT XYZ ERGO-A-EKIT-XYZ

12
3.2 ENCODERS INSTALLATION (individual protections are mandatory)
X encoder
D
E
1
Q
R
1 2
3
L
G
1
2
1
2
2
D
3
U
2 x M8 x 50 mm (20 Nm)
p/n 00.00.04.0524
J
4 x M5 x 30 mm (5 Nm)
p/n 00.00.04.0472
K
Cover
p/n 01.01.26.0063
L
Coupling
Z encoder
3 x M5 x 12 mm (2,5 Nm)
p/n 00.00.04.0466
M
Pre-mounted
p/n 00.00.04.0466
M*
Cable tie (not included)
P
Y encoder
F
Encoder
p/n 01.01.22.0957
Shaft (8 Nm)
p/n 00.00.04.2871
2 x M3 x 6 mm (1,5 Nm)
p/n 00.00.04.2942
E
D
F
H
I
J
K
M
M*
P
T
S
Lock x 3
(Hex. key; Allen 1,5)
Lock x 3
(Hex. key Allen 1,5)
I
Encoder
p/n 00.00.03.1191
2 x M4 x 12 mm (1,5 Nm)
p/n 00.00.04.0446
Nut M6
p/n 00.00.04.0695
H
G
Shaft (8 Nm)
p/n 01.01.22.0955
Q
Encoder’s plate
p/n 01.01.22.0956
R
2 x M4 x 10 mm (2,5 Nm)
p/n 00.00.04.0577
S
Cover
p/n 01.01.26.0068
T
4 x M3 x 6 mm (2,5 Nm)
p/n 00.00.04.2942
U

13
4 MAINTEINANCE
Maintenance operations must be carried out by qualied and authorized personnel.
●● Prior to start any maintenance operation: disconnect the tool from electric source.
●● Grinded hardened shaft: periodically clean the shaft from dust with a clean and soft cloth. After
cleaning swipe the shaft with light lubrication oil to prevent any corrosion.
●● Roller bearing bushing: grease yearly.
●● Hinges: grease yearly.t
Lubricant type: NLGI 2 or similar
4.1 PRODUCT DISPOSAL
Dispose components and parts in compliance with the country laws and safety procedures.

14
5 SAFETY
This product is designed to fit power tools having the maximum torque equal or lower than those
indicated for each arm model. No other use is permitted. This device is intended only for
professional use.
5.1 GENERAL SAFETY ISSUE
In order to reduce risk of injuries, any person which should use, install, repair, make servicing, install
accessories and even works nearby this device should read and clearly understand this manual in
advance of making any kind of activity. Our target is to make torque reaction arms which can increase
work safety and efciency. Please remember that USER is the most imporhant safety device for this
product and related tools. In fact, user’s attention ad care to his work is a fundamental contribute for
injuries and damages prevention. Our torque reaction arms must be installed by tined and qualied
personnel. In case of doubt, we suggest contacting the reference dealer or our technical support.
5.2 FOR ADDITIONAL SAFETY INFORMATION
• Any other document and information included with this product.
• Your company management, union and/or category association.
•The “Safety Code for Portable Air Tools” (ANSIB186.1), which latest release can be found at
Global Engineering Documents, by accessing http://global.ihs.com/, or calling 1 800 854 7179. In
case of problems for finding ANSI regulation copies, it is possible to contact them directly,
through the site http://www.ansi.org
Additional information about work safety and health can be found in the following web sites:
•http://www.osha.gov (USA)
•http://europe.osha.eu.int (Europe)
5.3 INSTALLATION RELATED RISKS
Firmly install the reaction arm either to the existing structure or to specically made structure in the
workplace. Verify that the reaction arm support has a safety factor of minimum ve times the value
obtained by the sum of maximum sustained load plus the reaction arm weight.
Example of calculation:
Optimal Safety Factor = (Max support load + torque arm weight + tool weight ) x 5
The reaction arm will have to be xed through the pre-drilled wall attachment interface, as shown in
Pic. 7, page 8.

15
5.4 WHEN USING AN EXTERNAL BALANCER
•Verify that the balancer suspension support has a safety factor of minimum ve times the value
obtained by the sum of maximum sustained load plus the balancer weight. Example of calcula-
tion:
Optimal Safety Factor = (Max support load + balancer weight + torque arm weight + tool
weight ) x 5
•Install and x an additional cable or chain to a separate support which is independent from
those supporting the balancer.
•Verify that suspension hooks, cable and chain do not show signs of wear. If so, replace the
wornparts before installation.
•Check that tool holder is rmly tightened before using the reaction arm.
5.5 USE RELATED RISKS
•Do not exceed the recommended load or torque capacity ranges indicated for the torque
arm model in use.
•Operators must be physically able to manoeuvre the torque arm. If you are unfamiliar with the
torque arm, adjust the tool to a low torque setting the rst time you operate it.
•Daily verify the torque arm attachment and all structural parts for wear or cracks. Replace the
entire arm if extensive wear, damage or cracks are detected.
•Do not operate the torque arm if damaged or malfunctioning. Examine balancer suspen- sion
hooks, cables, cable stops and chains daily for wear. Replace worn parts before further use.
•Daily check that there are no loosen screws or nuts. Replace worn nuts or washers before
further use.
•Regularly perform a complete functionality check, including fully extending and retracting
the torque arm throughout its complete range of movements. In case high friction is detected,
check whether one or more tubes is deformed or damaged or look for presence of any dust or
deposits over the tubes. In case of tubes contamination, clean ad described previously and try
the functionality again. In case any tubes deformation is detected the entire torque arm must be
replaced.
•This product and its accessories must not be modied
5.6 WORK RELATED RISK
•Slip/Trip/Fall is a major cause of serious injury or death. Be aware of excess hose left on the
walking or work surface.

16
•Proceed with care in unfamiliar surroundings. Be aware of potential hazards created by your
work activity
5.7 RESIDUAL RISKS
This paragraph lists the residual risks or dangers against which the reduction achieved, through design
and construction, is not fully or partially effective.
The description of the residual risk takes into account the following elements:
• type of risk to which persons operating with the machine and third persons are subjected;
• category of people exposed to this danger;
• main prevention measures that must be taken to reduce the risk of injury.
The following prevention requirements must be integrated with all instructions in this manual and with
the laws and rules of accident prevention already in force on-site.
Failing to observe these measures could expose people to risks that could cause minor or medium-
serious injuries.
RESIDUAL RISK EXPOSED PERSON
There is a possibility of hand/nger crushing
between the end stroke plate (1) and the
mobile stroke limiter (2) present on the middle
joint
To signicantly reduce the risk, there is a
pictogram warning the operator for potential
crushing. However, the risk is not avoidable, so
the exposed persons must be informed about
correct use of the arm.
Installation operators, users, maintenance
operators and third persons
PICTOGRAM/ LABEL
PREVENTION MEASURE
• Adequately train the exposed persons
• Do not remove the pictogram sticker
•Do not maneuver the arm grabbing the
middle joint

17
RESIDUAL RISK EXPOSED PERSON
There is a possibility of hand/nger shearing
between the arm bracket (1) and the mobile
stroke limiter (2) present on the middle joint
To signicantly reduce the risk, there is a
pictogram warning the operator for potential
crushing. However, the risk is not avoidable, so
the exposed persons must be informed about
correct use of the arm.
Installation operators, users, maintenance
operators and third persons
PICTOGRAM/ LABEL
PREVENTION MEASURE
• Train the exposed persons
• Do not remove the pictogram sticker
•Do not maneuver the arm grabbing the
middle joint
RESIDUAL RISK EXPOSED PERSON
There is a possibility of hand/nger crushing
between the arm support bushing (1)
and the arm attachment (2) and/or the
balancer attachment (3) because of the
quick sliding of the arm support bushing
along the grinded hardened shaft. This may
happen when the arm is being assembled.
To signicantly reduce the risk, there is a
pictogram warning the operator for potential
crushing. However, the risk is not avoidable, so
the exposed persons must be informed about
correct use of the arm.
Installation operators, maintenance
operators
PICTOGRAM/ LABEL
PREVENTION MEASURE
• Train the exposed persons
• Do not remove the pictogram sticker
•Carefully read through and follow the
installation instructions in this publication

18
RESIDUAL RISK EXPOSED PERSON
There is the possibility of accidental impact
between the horizontal arm (1) and the
operator’s body in case it is left free to rotate
around the axis of the column (2)
To signicantly reduce the risk, there is a label
warning the operator to fold the arm after
each use. However, the risk is not avoidable, so
the exposed persons must be informed about
correct use of the arm.
Installation operators, users, maintenance
operators and third persons
PICTOGRAM/ LABEL
PREVENTION MEASURE
• Train the exposed persons
• Do not remove the pictogram sticker
•Always put in rest position the front arm
after any operation

19
6 LIMITED WARRANTY
•This product is product is warranted against defective workmanship or materials, for a maxi-
mum period of 12 (twelve) months or 1.000.000 cycles (whichever condition occurs rst) following
the date of purchase from DELTA REGIS or their agents, provided that its usage is conform to
prescriptions described in this manual.
•During the validity of warranty period, should the product show any material or functional
defect, it must be returned to DELTA REGIS or their agents, together with a short description of the
alleged defect. DELTA REGIS shall, at its sole discretion, arrange to repair or replace free of charge
such items as are deemed faulty by reason of defective workmanship or materials.
•This warranty ceases to apply to products which have been abused, misused or modied, or
which have been repaired using other than genuine or authorized DELTA REGIS spare parts or by
someone other than DELTA REGIS or its authorized service agents.
•Should DELTA REGIS incur any expense correcting a defect resulting from abuse, misuse,
accidental damage or unauthorized modication, they will require that such expense shall be
reimbursed in full.
•DELTA REGIS will not accept claims either for labour or other expenditure made upon defective
products.
•Any direct, incidental or consequential damages whatsoever arising from any defect are ex-
pressly excluded.
•This warranty is given in lieu of all other warranties, or conditions, expressed or implied, as to the
quality, merchantability or tness for any particular purpose.
•No one, whether an agent or employee of DELTA REGIS, is authorized to add to or modify the
terms of this limited warranty in any way.

EC DECLARATION OF CONFORMITY
According to Enclosure II.A of EC Directive 2006/42/CE on Machinery and other applicable Directives
DECLARATION IN ORIGINAL LANGUAGE
We, (Company name)
Address: (address of the company)
As manufacturer, hereby declare under our responsibility that the product(s):
ERGO15A — Orthogonal reaction arms
Model e part number: See table at page 1
To which this declaration refers is in conformity with the following legal requirements:
European Union Directive 2006/42/CE on Machinery safety
It is also conform to following harmonised standards:
EN 12100:2010
Machinery safety—General principles for design - Risk assessment and risk reduction
Authorized issuer of the present technical document is Mr/Mrs:
(Title, Name, address of the authorized person)
(Date and place of declaration)
(Title, Name)
(General Manager)
(image of signature)
