Delta 7886 User manual

Conforms to
ASTM F1169-10a Full
Size Crib & F1821
Safety Standards
Style #:
Lot:
Date:
___________
___________
___________
C
4 in 1 Crib
Consumer Care:
www.DeltaChildren.com
Delta Children’s Products
114 West 26th Street
New York, NY 10001
Tele.212-645-9033
FACTORYREV
THIS PRODUCT IS NOT INTENDED FOR INSTITUTIONAL OR COMMERCIAL USE.
To register your product for important safety alerts and updates to your product please
visit www.DeltaChildren.com and click on Product Registration.
When contacting Delta Consumer Care please reference
the above information. Before contacting Delta Consumer
Care please ensure that the information above matches the
information found on the label on the Crib End bottom rail,
please reference the information found on the product
when contacting Delta Consumer Care.
Read all instructions before assembly and use.
KEEP INSTRUCTIONS FOR FUTURE USE.
ADULT ASSEMBLY REQUIRED
Due to the presence of small parts during assembly, keep out of
reach of children until assembly is complete.
AUGUST 30, 2013, 21127, R12 ©2013 DELTA ENTERPRISE CORP.

WARNING:
*Infants can suffocate on soft bedding. Never add a pillow or comforter. Never place additional padding
under an infant.
*Failure to follow these warnings and the assembly instructions could result in serious injury or death.
DO NOT use this crib if you cannot exactly follow the accompanying instructions.
*To reduce the risk of SIDS, pediatricians recommend healthy infants be placed on their backs to
sleep, unless otherwise advised by your physician.
*Strangulation Hazard: STRINGS CAN CAUSE STRANGULATION! Do not place items with a string
around a child's neck, such as hood strings or pacifier cords. Do not suspend strings over a crib or
attach strings to toys.
*Strangulation Hazard: To help prevent strangulation tighten all fasteners. A child can trap parts of
the body or clothing on loose fasteners.
*Strangulation Hazard: Do not place crib near window or patio door where cords from blinds or
drapes may strangle a child.
*Fall Hazard: When child is able to pull to a standing position, set mattress to lowest position and
remove bumper pads, large toys and other objects that could serve as steps for climbing out. This crib
has an adjustable mattress support. For the convenience of the parent when the baby is very small, the
mattress support may be used in the highest position. Important: with the mattress support and
mattress in the highest position, be absolutely sure that the top of the front crib side is at least 3 inches
higher than the top surface of the mattress. If it is not, lower the mattress support and the mattress to
the next highest position.
*Fall Hazard: Stop using crib when child begins to climb out or reaches a height of 35in. (89cm),
whichever occurs first. The child should be placed in a youth or regular bed.
*Check this product for damaged hardware, loose joints, loose bolts or other fasteners, missing parts,
or sharp edges before and after assembly and frequently during use. Securely tighten loose bolts and
other fasteners. Do not use crib if any parts are missing, damaged or broken. Contact Delta
Children's Products for replacement parts and instructional literature if needed. Do not substitute parts.
*Follow warnings on all products in a crib.
*If refinishing, use a non-toxic finish specified for children's products.
*Never use plastic shipping bags or other plastic film as mattress covers because they can cause
suffocation.
*Infants can suffocate in gaps between crib sides and a mattress that is too small.
*Ensure a safe environment for the child by checking regularly, before placing the child in the crib, that
every component is properly and securely in place.
*To avoid head injury, do not allow any child to play underneath the crib.
*Never add an accessory such as a bassinet or changing table that extends over the sleeping area.
*In Canada Only - Use a crib mattress that is no thicker than 15 cm and is of such a size that, when it
is pushed firmly against any side of the crib, it does not leave a gap of more than 3 cm between the
mattress and any part of the sides of the crib. Do not use this crib for a child who can climb out of it or
who is taller than 90 cm.
CAUTION:
ANY MATTRESS USED IN THIS CRIB SHALL
BE AT LEAST 27 1/4 BY 51 5/8 IN. WITH A
THICKNESS NOT EXCEEDING 6 IN.

3
TODDLER BED
WARNING
INFANTS HAVE DIED IN TODDLER BEDS FROM ENTRAPMENT.
Openings in and between bed parts can entrap head and neck of a small child.
NEVER use bed with children younger than 15 months.
ALWAYS follow assembly instructions.
The maximum user weight is 50lbs (22.7kg)
WARNING
STRANGULATION HAZARD
NEVER place bed near windows where cords from blinds or drapes may strangle a child.
NEVER suspend strings over a bed.
NEVER place items with a string, cord, or ribbon, such as hood strings or pacifier cords,
around a child's neck. These items may catch on bed parts.
CAUTION
ENTRAPMENT HAZARD
To avoid dangerous gaps, any mattress used in this bed shall be a full-size crib mattress
at least 51 5/8 in (1310mm) in length, 27 1/4 in (690mm) in width and 4 in (100mm) in
thickness. The mattress thickness must not exceed 6 in (150mm).
NOTES ON ASSEMBLY:
-During the assembly process whenever using screws or bolts, check each by placing the screw/bolt on
the diagram of the item which is drawn actual size and design. Be sure to use the proper size and shape
specified in the instructions.
-To assemble this unit you may be required to place the unit on it’s side and face. It is strongly
recommended that assembly is done on a soft, non-abrasive surface to avoid damaging the finish.
NOTES ON CARE AND MAINTENANCE:
- Do not scratch or chip the finish.
- Inspect the product periodically, contact Delta Children's Products for replacement parts or questions.
- Do not store the product or any parts in extreme temperatures and conditions such as a hot attic or a
damp, cold basement. These extremes can cause a loss of structural integrity.
-To preserve the luster of the high quality finish on your product, it is recommended to place a doily or
felt pad under any items you place on the finish.
-Clean with a damp cloth, then a dry cloth to preserve the original luster and beauty of this fine finish.
-Do not use abrasive chemicals.
-Do not spray cleaners directly onto furniture.
-Lift slightly when moving on carpeting to prevent leg breakage.
-Use of a vaporizer near furniture will cause wood to swell and finish to peel.
NOTES ON USE:
Keep children and others safe by following these simple rules:
- Do not allow any child to play on furniture
- Do not allow climbing on any piece of furniture.
- Do not allow hanging from any piece of furniture.
- Always monitor your child’s activity when in the nursery.

PARTS: MAKE SURE THAT ALL PRE-ASSEMBLED PARTS ARE TIGHT.
A. Back Rail Top x 1
B. Back Rail Bottom x 1 C. Left Rear Leg x 1
D. Right Rear Leg x 1
E. Left Crib End x 1
J. Front Rail x 1
G. Left Front Leg x 1
H. Right Front Leg x 1
K. Stabilizer Bar x 1
L. Mattress Support x 1
4
F. Right Crib End x 1
INSIDE
PRODUCT LABEL
OUTSIDE
WARNING LABEL
POUCH ATTACHED TO MATTRESS SUPPORT
- KEEP INSTRUCTIONS IN THIS POUCH
AFTER ASSEMBLY.
WARNINGS RELATED TO THE SAFE USE OF
THIS CRIB ARE PRINTED ON THE POUCH.
Part # 21116
Part # 21117
Part # 21118
Part # 21119
Part # 21120 Part # 21121
Part # 21122
Part # 21123
Part # 21124
Part # 21125
Part # 16945

PARTS:
5
M4 Allen Wrench Supplied
M. M6 x 80 mm Bolt x 2
N. M6 x 55 mm Bolt x 14
P. M6 x 45 mm Bolt x 4
R. M6 x 40 mm Bolt x 6
S. M6 x 18 mm Bolt x 8
HARDWARE AND TOOLS
V. Adapter Plate x 2
No drills necessary. Do not
use power screwdriver.
Flat Head Screwdriver
(not supplied)
T. Φ4x30 mm Metal Pin x 4
U. M6 x 17 mm Barrel Nut x 2

6
C. Left Rear
Leg x 1
G. Left Front
Leg x 1
D. Right Rear
Leg x 1
H. Right Front
Leg x 1
M4 Allen Wrench Supplied
Attach (1) Left Crib End (Part E) to (1) Left Rear Leg (Part C) and (1) Left Front Leg (Part G) using (1)
Φ4x30mm Metal Pins (Part T), (2) M6x45mm Bolts (Part P) and (3) M6x40mm Bolts (Part R). Tighten
with the M4 Allen Wrench. Use the Flat Head Screwdriver to hold the Barrel Nut in the proper alignment.
Repeat on the Right Crib End (Part F).
E
C
G
Left Crib End
NOTE: AFTER ASSEMBLY, THE “STEPPED HOLES” IN BOTH POSTS ARE ON THE SAME SIDE.
E. Left Crib
End x 1
F. Right Crib
End x 1
INSIDE
PRODUCT LABEL
OUTSIDE
WARNING LABEL
OUTSIDE
WARNING LABEL
PRODUCT LABEL
P. M6 x 45 mm Bolt x 4
R. M6 x 40 mm Bolt x 6
T
P
P
R
R
ON INSIDE FACE
Step 1
Section 1: Crib Assembly
Parts and tools required to complete step.
T. Φ4x30 mm Metal Pin x 2

7
From Step 1
M4 Allen Wrench
Supplied
Attach (1) Back Rail Bottom (Part B) tothe assemblies from step 1 using (4) M6x55mm Bolts (Part N) .
NOTE :THE SLOT INPART B MUST FACE UP.
Insert the tenon of the Back Rail Top (Part A) into the slot on top of the Back Rail Bottom (Part B), then insert the
M6x55mm Bolts (Part N), through the legs into the insert nuts onto the Back Rail Top (Part A) as shown.
Tighten with the M4 Allen Wrench.
A
TENON
N
WARNING LABEL
A. Back Rail Top x 1
B. Back Rail Bottom x 1
N. M6 x 55 mm Bolt x 6
B
N
N
N
SLOT
Step 2
Section 1: Crib Assembly
Parts and tools required to complete step.

8
From Step 2
M4 Allen Wrench
Supplied
L. Mattress Support x 1
! WARNINGS ON POUCH MUST FACE UP.
L
ALL CORNERS
UP
S. M6 x 18 mm Bolt x 4
S
Step 3
Section 1: Crib Assembly
Parts and tools required to complete step.
WARNING:
!
!
Attach the Mattress Support (Part L) in all corners using (1) M6 x 18 mm Bolt (Part S) in each corner.
Tighten with the M4 Allen Wrench.
The Warnings printed on the pouch attached to the
mattress support must face up, the springs must face up.
This crib has (3) adjustment positions, use the highest only
for new borns, move the mattress down as the child grows.
Fall Hazard: When child is able to pull to a standing position,
set mattress to lowest position and remove bumper pads,
large toys and other objects that could serve as steps
for climbing out.

9
From Step 3
M4 Allen Wrench
Supplied
J
J. Front Rail x 1
N. M6 x 55 mm Bolt x 8
Attach (1) Front Rail (Part J) to the assembly from 3 using (8) M6x55mm Bolts (Part N). Tighten with
the M4 Allen Wrench.
N
N
N
N
Step 4
Section 1: Crib Assembly
Parts and tools required to complete step.

10
Assembly Instruction
Booklet
WARNING: SEE PAGE 2 FOR INFORMATION
AI BAG
Step 5
Section 1: Crib Assembly
Parts and tools required to complete step.
Store the assembly instruction booket in the pouch attached to the mattress support. Store all parts
and tools separately, in a safe place.
Style #:
Lot:
Date:
___________
___________
___________
MAY23, 2012, 7886, R10 ©2012 DELTAENTERPRISE CORP.
A
4 in 1 Crib
Conformsto
ASTMF1169-10a Full
SizeCrib & F1821
SafetyStandards
Consumer Care:
www.DeltaChildren.com
Delta Children’s Products
114 West 26th Street
New York, NY 10001
Tele.212-645-9033
FACTORYREV
THIS PRODUCT IS NOT INTENDED FOR INSTITUTIONAL OR COMMERCIAL USE.
To register your product for important safety alerts and updates to your product please
visit www.DeltaChildren.com and click on Product Registration.
When contacting Delta Consumer
Care you will need to reference the
above numbers. They can also be
found on the label on the Crib End
bottom rail.
Read all instructions before assembly and use.
KEEP INSTRUCTIONS FOR FUTURE USE.
ADULT ASSEMBLY REQUIRED
Due to the presence of small parts during assembly, keep out of
reach of children until assembly is complete.
Style #:
Lot:
Date:
___________
___________
___________
MAY23, 2012, 7886, R10 ©2012DELTA ENTERPRISE CORP.
A
4 in 1 Crib
Conformsto
ASTMF1169-10a Full
SizeCrib & F1821
SafetyStandards
Consumer Care:
www.DeltaChildren.com
DeltaChildren ’s Products
114West 26th Street
NewYork, NY 10001
Tele.212-645-9033
FACTORYREV
THIS PRODUCT IS NOT INTENDED FOR INSTITUTIONAL OR COMMERCIAL USE.
Toregister your product for important safety alerts and updates to your product please
visit www.DeltaChildren.com and click on Product Registration.
When contacting Delta Consumer
Care you will need to reference the
above numbers. They can also be
found on the label on the Crib End
bottom rail.
Read all instructions before assembly and use.
KEEP INSTRUCTIONS FOR FUTURE USE.
ADULT ASSEMBLY REQUIRED
Dueto the presence of small parts during assembly, keep out of
reachof children until assembly is complete.

11
M4 Allen Wrench
Supplied
Remove the Front Rail installed in step 4 of section 1 crib assembly.
J
N
N
N
N
N
N
Step 1
Section 2: Toddler Bed Conversion
Parts and tools required to complete step.
Finished Crib

12
M4 Allen Wrench Supplied
From Step 1 Section 2
Attach (1) Stabilizer Bar (Part K) to the assembly from step 1 section 2 using (2) Φ4x30 mm Metal Pins
(Part T), (2) M6x80 mm Bolts (Part M) and (2) M6 x 17mm Barrel Nuts (Part U).
GENTLY PULL THE LEFT AND RIGHT FRONT LEG APART. TO INSTALL THE STABILIZER
BAR - BE VERY CAREFUL NOT TO SCRATCH THE FINISH.
Use the Flat Head Screwdriver to hold the Barrel Nut in the proper alignment. Tighten with the M4
Allen Wrench.
K
K. Stabilizer Bar x 1
M
U
M. M6 x 80 mm Bolt x 2
M
U
PULL GENTLY
U
T
M
Step 2
Section 2: Toddler Bed Conversion
Parts and tools required to complete step.
U. M6 x 17mm Barrel Nut x 2 T. Φ4x30 mm Metal Pin x 2

13
WARNING:
TODDLER BED WARNINGS
SEE PAGE 3 FOR
Step 3
Section 2: Toddler Bed Conversion
The mattress support must be in the lowest position.
Store all hardware safely.
Read all warnings on page 3.
As shown, use as a day bed or love seat sofa.
Do Not use without stabilizer bar intalled.
Stabilizer bar must be used when converted
to a toddler bed.
A toddler bed guardrail is available for this
crib.
Please see your crib retailer, visit
www.DeltaChildren.com or contact delta
consumer care for more information.
This crib uses Delta Style # 0081 Guardrail.

14
M4 Allen Wrench
Supplied
J
N
N
G
H
N
N
Step 1
Section 3: Full Size Bed Conversion
Parts and tools required to complete step.
You have the option to convert the crib to a Full Size Bed. Simply follow steps in reverse order to
disassemble the crib. Then remove the rear legs from the Left Crib End (Part E) and Right Crib End
(Part F) with the M4 Allen Wrench as shown.
Attach the Left Front Leg (Part G) and the Right
Front Leg (Part H) to the Front Rail (Part J) with
(8) M6 x 55mm Bolts (Part N) using the M4 Allen
Wrench as shown.
Store all parts and hardware in a safe place.

15
M4 Allen Wrench
Supplied
S. M6 x 18 mm Bolt x 4
V
V
V. Adapter Plate x 2
S
V
S
Step 2
Section 3: Full Size Bed Conversion
Parts and tools required to complete step.
Attach Adapter Plates (Part V) to bottom of
Rear Side Rail Legs using (4) M6x18mm
Bolts (Part S). Hand tighten bolts in place.
Adjust up or down to allow for connection to
Bed Rail. Adapter “Tabs” will keep Adapter
Plate from rotating.
Stand Headboard up. Attach to Bed Frame with
bolts and nuts (supplied by Bed Frame manufacturer).
Adapter Plates (Part V) can be adjusted up or
down to best suit Bed Frame. Tighten all bolts
once Bed Rail is adjusted.
Note: Bed Frames are not supplied with this system,
but can be purchased at mattress stores.

Warranty: This Delta Crib is warranted to be free from defects for a period
of 1 year from the date of purchase under normal use. This warranty extends
only to the original retail purchaser and is valid only when supplied with proof of
purchase, or if received as a gift, when the registration is on file with Delta.
Consumer Care:
www.DeltaChildren.com
Delta Children’s Products
114 West 26th Street
New York, NY 10001
Tele.212-645-9033
Please do not return this item to the store before contacting
us about missing parts or with any questions.
To register your product for important safety alerts and updates to
your product please visit www.DeltaChildren.com
To report a problem, please log on to www.DeltaChildren.com and
click the Consumer Care Tab, or contact us by phone at
[phone].
In the event that you need to contact our customer service
department please have the Style Number and Lot Number available.
Use the space below to make note of those numbers. They can be
found on the label on the Crib End bottom rail.
Lot No. : _______________________
Pack Date:_____________________
Date of Purchase: _____________ (you should also keep your receipt)
COLOR FTY
REV
STYLE No: 7886 C
