Delta M100A 280 User manual

Solar inverter
M100A_280 (Delta part number RPI104M280000, product version 0)
European Union
Graphical Installation Guide
Graphical Installation Guide M100A_280 RPI104M280000 Product Version 0 EU V1.0 EN 2022-01-03

2Graphical Installation Guide M100A_280 RPI104M280000 Product Version 0 EU V1.0 EN 2022-01-03
This manual applies to the inverter models:
●M100A_280 (Delta part number RPI104M280000,
product version 0)
and DSS software version 6.0 or higher
The Delta part number can be found on the type plate of
the inverter.
Delta manuals undergo continuous revision in order to
provide you with complete information regarding the
installation and operation of its inverters. Therefore,
before starting installation work, always consult solarso-
lutions.delta-emea.com to check whether a newer ver-
sion of the Quick Installation Guide or the Installation and
Operation Manual is available.
© Copyright – Delta Electronics (Netherlands) B.V. – All
rights reserved.
This manual is intended for use by electrical installers
who are trained and approved for installation and com-
missioning of grid-connected solar inverters.
The information in this manual is to be treated as con-
dential and no part of this manual may be reproduced
without prior written permission from Delta Electronics.
The information in this manual may not be used for any
purpose not directly connected to the use of the inverter.
All information and specications can be modied without
prior notice.
All translations of this manual not authorized by Delta
Electronics (Netherlands) B.V. must include the annota-
tion: "Translation of the original operation manual".
Delta Electronics (Netherlands) B.V.
Tscheulinstraße 21
79331 Teningen
Germany
Authorized representative for this product in the EU:
Delta Electronics (Netherlands) B.V.
Zandsteen 15
2132 MZ Hoofddorp
Netherlands
Information about the versions of this manual
Version Date Changes Page
1.0 2022-01-03 First edition for product version 0
Notesontheproductversions

3
Graphical Installation Guide M100A_280 RPI104M280000 Product Version 0 EU V1.0 EN 2022-01-03
O...............0
M50A_260
P/N: RPI503260000
200-1000Vdc, MPPT 390-900Vdc
MAX Idc: 26A*6 MPPT, 1000Vdc max
MAX Idc: 50A*6 MPPT
220/380Vac, 230/400Vac
3P4W/3P3W, 50/60Hz
83.4A max., cosφ 0.8ind ~ 0.8 cap
50kW/50kVA nom, 50kW/55kVA max
IP Code
IP66
Product version Changes to the previous model
0This is a new product.
The last letter of the serial number indicates the product version.

4Graphical Installation Guide M100A_280 RPI104M280000 Product Version 0 EU V1.0 EN 2022-01-03
Safety Instructions
DANGER
Electric shock
Potentially fatal voltages are present in the
inverter during operation. When the inverter
is disconnected from all power sources, this
voltage remains in the inverter for up to 60
seconds.
You should therefore always carry out the fol-
lowing steps before working on the inverter:
1. Turn both DC isolating switches to the
OFF position.
2. Disconnect the inverter from all AC and
DC voltage sources and make sure that
none of the connections can be restored
accidentally.
3. Wait at least 60 seconds for the internal
capacitors to discharge.
DANGER
Electric shock
Potentially fatal voltages are present at the
DC connections of the inverter. When light
falls on the solar modules, they immediately
start to generate electricity. This also hap-
pens when light does not fall directly on the
solar modules.
►Never disconnect the inverter from the
solar modules when it is under load.
►Turn both DC isolating switches to the
OFF position.
►Disconnect the connection to the grid so
that the inverter cannot feed energy into
the grid.
►Disconnect the inverter from all AC and
DC voltage sources. Make sure that
none of the connections can be restored
accidentally.
►Ensure that the DC cables cannot be
touched accidentally.
DANGER
Electric shock
The inverter has a high leakage current
value.
►Always connect the ground cable rst,
then the AC and DC cables.
WARNING
Electric shock
The IP66 protection degree is no longer
guaranteed when the door is open.
►Only open the door when absolutely
necessary.
►Do not open the door if water or dirt might
enter the inverter.
►After work is completed, ensure that the
door is properly shut and tightened again.
Check that the door is properly sealed.
WARNING
Heavy weight
The inverter is heavy.
►Lift and carry the inverter with at least two
people, or use a suitable lifting device.
WARNING
Hot surfaces
The surface of the inverter can get very hot
during operation.
►Always wear safety gloves when touching
the inverter.
NOTICE
Use of aluminum cables
►Always observe the applicable regulations
and rules for the use of aluminum cables.
For detailed information, refer to the com-
plete Installation and Operation Manual.
NOTICE
Working in freezing conditions
In freezing conditions, the rubber seal on the
front door can freeze to the housing and tear
when opened.
►Before opening the front door, defrost the
rubber seal with some warm air.
●To comply with IEC 62109-5.3.3 safety requirements
and avoid injury or material damage, the inverter
must be installed and operated in accordance with
the safety and operating instructions set out in this
manual. Delta Electronics is not responsible for
damage resulting from failure to follow the safety
and operating instructions set out in this manual.
●The inverter may only be installed and commis-
sioned by installers who have been trained and
approved for the installation and operation of grid-
connected solar inverters.
●All repair work on the inverter must be carried out
by Delta Electronics. Otherwise the warranty will be
void.

5
Graphical Installation Guide M100A_280 RPI104M280000 Product Version 0 EU V1.0 EN 2022-01-03
●Warning notices, warning symbols and other mark-
ings attached to the inverter by Delta Electronics
must not be removed.
●To avoid the risk of arcing, do not disconnect cables
when the inverter is under load.
●To prevent damage due to lightning strikes, follow
the applicable regulations in your country.
●All external connections must be su󰀩ciently sealed
in order to ensure an IP66 protection degree. Seal
any unused connections with the cover caps sup-
plied.
●The covers inside the inverter do not have to be
removed for the standard installation. All connec-
tions required for the standard installation are also
accessible with the covers attached.
●Only equipment in accordance with SELV
(EN 60950) may be connected to the RS485 inter-
faces.
Safety Instructions

INV-I
1x
6Graphical Installation Guide M100A_280 RPI104M280000 Product Version 0 EU V1.0 EN 2022-01-03
1x
MOU-H
INV-Q
1x
INV-X
1x
Scope of Delivery
Do not use any damaged components.

7
Graphical Installation Guide M100A_280 RPI104M280000 Product Version 0 EU V1.0 EN 2022-01-03
Scope of Delivery
Amphenol H4 – 4/6 mm
2
DC+ (H4CFC4D●MS)
DC-P+
16x
Amphenol H4 – 4/6 mm
2
DC– (H4CMC4D●MS)
DC-P–
16x
6x
DC-B
2x
DC-T
DC
AC
AC-C2
1x
AC-C1
1x
AC-PE
1x

8Graphical Installation Guide M100A_280 RPI104M280000 Product Version 0 EU V1.0 EN 2022-01-03
Accessories and software
Accessories must be ordered separately.
2x
MOU-G
Delta Service Software
(DSS )
DOWNLOAD
partnerportal.delta-emea.com/en/portal-login.htm
Windows PC
RS485/USB Adapter
0,25 ... 1,5 mm2
A Windows PC with a RS485/USB adapter is required.
Delta Service Software (DSS) must be installed on the
PC.

9
Graphical Installation Guide M100A_280 RPI104M280000 Product Version 0 EU V1.0 EN 2022-01-03
Information on the type plate
60 seconds
Risk of death due to electric shock
Potentially fatal voltage is present inside the inverter during operation and this voltage
remains for 60 seconds after the power supply is disconnected.
Before working on the inverter, read the supplied manual and follow the instructions
provided.
The housing of the inverter must be grounded if local regulations require additional
grounding or equipotential bonding.
The inverter has no galvanic isolation.
WEEE
The inverter may not be disposed of alongside normal household waste. Always follow
the waste disposal regulations for electrical appliances in your country or region.

10 Graphical Installation Guide M100A_280 RPI104M280000 Product Version 0 EU V1.0 EN 2022-01-03
Dimensions
82 82 82
410
82 82
460 11
3117
27 20
95
25
595 263,4
max. 1,8
699
144,5
629
538
7
6,5
mm

11
Graphical Installation Guide M100A_280 RPI104M280000 Product Version 0 EU V1.0 EN 2022-01-03
Sub-1G
739
80
mm
340
310
130 75
15
12,5
60
60
mm
Dimensions

> 300 > 300
> 600
> 200 > 200
> 150
12 Graphical Installation Guide M100A_280 RPI104M280000 Product Version 0 EU V1.0 EN 2022-01-03
P
UV
2020
2021
2022
2023
2024
...
Installation

> 300 > 300
> 200 > 200
>150
> 200
> 300 ... 600
> 830
> 380
A
A
> 50 > 300 > 300
> 200
AA
13
Graphical Installation Guide M100A_280 RPI104M280000 Product Version 0 EU V1.0 EN 2022-01-03
Installation

14 Graphical Installation Guide M100A_280 RPI104M280000 Product Version 0 EU V1.0 EN 2022-01-03
Wall mounting
8 x
Ø 6,5 mm
A1 A2
77 kg
Ø 8,5 mm / 10 Nm
Ø 8,5 mm / 10 Nm
A3 A4
A5 A6

15
Graphical Installation Guide M100A_280 RPI104M280000 Product Version 0 EU V1.0 EN 2022-01-03
Floor mounting
Ø13 mm
24,5 Nm
Ø13 mm
77 kg
B1 B2
B3 B4

16 Graphical Installation Guide M100A_280 RPI104M280000 Product Version 0 EU V1.0 EN 2022-01-03
SWITCH 1
OFF OFF
ON ON
SWITCH 2
1 2
3 4
5 6
Mounting

17
Graphical Installation Guide M100A_280 RPI104M280000 Product Version 0 EU V1.0 EN 2022-01-03
Communication card
RS485

RS485 Data logger
ON
OFF
ON
OFF
ON
OFF
RS485 RS485 Data logger
18 Graphical Installation Guide M100A_280 RPI104M280000 Product Version 0 EU V1.0 EN 2022-01-03
RS485
1
2
VCC
GND
DATA+
DATA-
DATA+
DATA-
RS485
CAT5 / CAT6
Ø7,2 / 8,0 / 10,0 mm; 0,25 ... 1,5 mm2
1
(1) RS485 terminal block • (2) DIP switch for RS485
termination resistor
Switch on the RS485 terminator resistor of the data log-
ger or connect a termination resistor.
If the data logger does not have an integrated RS485
terminator resistor, connect the data logger in the middle
of the RS485 bus.

19
Graphical Installation Guide M100A_280 RPI104M280000 Product Version 0 EU V1.0 EN 2022-01-03
V1 K0 K1 K2 K3 K4 K5 K6
CAT5 / CAT6
Ø7,2 / 8,0 / 10,0 mm; 0,25 ... 1,5 mm2
3
Digital inputs
Pin
Pin
V1 – –
K0 – External power-o󰀨
(EPO)
K1 V1 + K1 Pmax = 0%
K2 V1 + K1 Pmax = 30%
K3 V1 + K1 Pmax = 60%
K4 V1 + K1 Pmax = 100%
K5 Reserved –
K6 Reserved –
Digital inputs | Dry contacts
3
4
A B
4
Dry contacts
The event at which the relays of the dry contacts trip can
be set with the Delta Service software.

20 Graphical Installation Guide M100A_280 RPI104M280000 Product Version 0 EU V1.0 EN 2022-01-03
Connect a PC
VCC
GND
DATA+
DATA-
DATA+
DATA-
RS485 RS485/USB Adapter
Delta Service Software
(DSS )
Windows PC
Connect the PC to the inverter via the RS485/USB
adapter.
