Delta Solivia 2.5 Specification sheet

Operation and installation manual
2.5

1
1 Scopeofdelivery 2
2 Generalwarnings/Notesonsafety 2
3 Introduction 3
4 System 3
4.1  Dataevaluationandcommunication 3
4.2  Technicalstructureofthesolarinverter 4
4.3  Equipmentoverview 5
5 Installation 6
6 Installationofequipment 6
6.1  Installationlocation 6
6.2  Minimumrequirements 6
6.3  Maintenance 7
6.4  Installation 7
6.5  Ambienttemperature 8
6.6  Gridconnection 8
6.7  ConnectionofPVmodules 8
 6.7.1 OutputpoweroverPVvoltage 10
 6.7.2 OutputpoweroverACvoltage 10
 6.7.3 Efficiency 11
6.8  InterfaceconnectionRS485(EIA485) 11
6.9  Electricalconnectionandoperationalstart-up 13
6.10 Setup/settings 14
6.11 LEDoperationandfaultdisplay 15
7 Operatingconcept 16
7.1  Thedisplay 16
7.2  Navigationinthedisplay 16
7.3  Mainmenu 16
 7.3.1 Autotest(onlyforItaly) 18
 7.3.2 SubmenuN(Now) 21
 7.3.3 SubmenuD(Day) 21
 7.3.4 SubmenuW(Week) 22
 7.3.5 SubmenuM(Month) 22
 7.3.6 SubmenuY(Year) 22
 7.3.7 SubmenuT(Total) 23
 7.3.8 SubmenuS(Setup) 23
  7.3.8.1 SubmenuS:SolarISO/GND 24
  7.3.8.2 SubmenuS:Countrysettings 24
  7.3.8.3 SubmenuS:Firmware 25
8 Diagnosticsanddataevaluation 25
8.1  Malfunctionrectification 25
8.2  Displaymessages 26
9 Technicaldata 28
10 Appendix 29
10.1 Connectionexamples 29
10.2 Overviewofconnectiondiagrams 30
11 Glossary 32
12 Certificates 34
Table of Contents

2
1 Scope of delivery
•SOLARINVERTERSOLIVIA2.5EUG3
•Mountingplate
•Operationandinstallationmanual
•ACconnector
2 General warnings / Notes on safety
CongratulationsonthepurchaseofthetechnicallyadvancedSOLARINVERTERSOLIVIA2.5EU
G3.
Thesedirectionswillhelpyoubecomefamiliarwiththisproduct.
Pleaseobservethesafetyregulationsoftheindividualcountries(e.g.forGermany:VDE,BDEW,
BGFE,technicalconnectionconditionsforlocalutilitycompany).Carefulhandlingofyourproduct
willcontributetoitsservicelifedurabilityandreliability.Theseareessentialprerequisitesformaxi-
mumyieldfromyourproduct.
Please observe the following notes on safety:
•Duringoperationofelectricaldevices,certainpartsareunderdangerousvoltage.
•Inappropriatehandlingcanleadtophysicalinjuryandmaterialdamage!
•Adheretotheinstallationregulations.
•Installationandoperationalstart-upworkmaybeimplementedonlythroughqualiedelectrical
 experts.
•Repairworkonthedeviceshouldbecarriedoutbythemanufactureronly.
•Pleaseobserveallpointsintheoperatingandinstallationmanual!
•IsolatethedevicefromthegridandthePVmodulesbeforecarryingoutanyworkonit.
•Asaresultofveryhightemperatures,thedevicesurfacecanbecomehot.
•Sufcientcoolingisnecessary.
•Asthesolarinverterisheavy(weight>18kg),itshouldbeliftedbyatleasttwopersons.
•Rememberthattheunithasahighleakagecurrent.ThePEconductorMUSTbeconnectedprior
 tocommencingoperation.
Toavoidriskofelectricalshock,donotopenthesolarinverter.Theinverter
containsnouser-serviceableparts.Openingthecoverwillinvalidatethe
warranty.
Dangerousvoltageispresentfor5minutesafterdisconnectingallsources
ofpower.
©Copyright–DeltaEnergySystems(Germany)GmbH-Allrightsreserved.
Thismanualaccompaniesourequipmentforusebytheendusers.
Thetechnicalinstructionsandillustrationscontainedinthismanualaretobetreatedascondentialandnopartmaybereprodu-
cedwithoutthepriorwrittenpermissionofDeltaEnergySystemsServiceengineersandendusersmaynotdivulgetheinformation
containedhereinorusethismanualforpurposesotherthanthosestrictlyconnectedwithcorrectuseoftheequipment.
Allinformationandspecicationsaresubjecttochangewithoutnotice.

3
3 Introduction
Withthisdeviceyouhaveacquiredasolarinverterforconnectionofphotovoltaicsystemstothe
grid.ThisEuropeansolarinvertercanbeusedinandisapprovedforthefollowingcountries:Ger-
many, France, Spain, Italy, Portugal, Greece, Czech Republic and Belgium. The solar inverter
ischaracterizedbyitsadvancedhousingdesignandstate-of-the-arthigh-frequencytechnology,
whichenablethehighestlevelsofefciency.
Thesolarinverterincludesmonitoringunits,suchasanti-islandingprotection.Thefunctionofthe
anti-islandingprotection(automaticisolationpointforin-plantgenerationsystems)stipulatescom-
pliancewiththespecicationsofDINVDE0126-1-1,EN50438,ENELG.L.12/2008,RD1663,
andcompliancewiththedirectivesforparalleloperationofpowergenerationplantsonlow-voltage
gridofyourlocalutilitycompanies.Thesearedeclaredbycerticates(CECertication-see§12).
Theinverterisusableindoorsandoutdoors(IP65).
Inthefollowingtechnicaldescription,theprecisefunctionsareexplainedtotheinstaller,aswell
astheuser,whicharerequiredfortheinstallation,operationalstart-upandhandlingofthesolar
inverter.
4 System
Thesolarinverterconvertsdirectcurrentfromthesolarcellsintoalternatingcurrent.Thisenables
youtofeedyourself-producedsolarenergyintothepublicgrid.
ThankstoefcientMPPtracking,maximumcapacityutilizationofthesolarenergyplantisensured
eveninthecaseofcloudyskyconditions.
ThestringconceptmeansthatPVmodulesarealwaysconnectedinseries(inastring)and/orthat
stringswiththesamevoltageareconnectedinparalleltothesolarinverterwiththeaimofsigni-
cantlyreducingthephotovoltaicsystem’scablingrequirements.
Thefactthatthemodulesareconnectedinstringsalsomeansthatthephotovoltaicsystemcanbe
perfectlymatchedtothesolarinverter’sinputvoltagerange.
4.1 Data evaluation and communication
Theintegrateddatadisplay,processingandcommunicationofthedeviceenableseasyoperationof
thesolarinverter.Monitoringoftheoperationalstatusandsignalingofoperationalfailuresareca-
pableofbeingcalledupoverthedevicedisplay.Thedatainterfaceenablesthedownloadingofdata
whichcanbeevaluatedwithaPCsystemandguaranteescontinuousrecordingofoperatingdata.
Thebestwayofaccessingthisfunctionalityisviatheavailableaccessories(e.g.WEB´log);com-
prehensiveandseamlesssolarinvertermonitoringisensured.
Thedataread-outovertheintegratedinterfaceandthedisplayispossibleonlyinsolaroperation.

4
4.2 Technical structure of the solar inverter
AgalvanicalisolationofthesolarinverterfromthegridisachievedthroughaDC/ACconverterwith
anintegratedhigh-frequencytransformer.Thephotovoltaicvoltageisadjustedsothatthemaximum
poweroutputofthePVmodulesisalsoachievedwithvaryingsolarirradiationlevelsandtempera-
tures(MPP-Tracking).
TheMPPrangeofthesolarinverterisbetween150Vand450V.ThisfacilitatestheuseofPV
modulesbyavarietyofmanufacturers.Measuresmustbetakentoensurethatthemaximumopen-
circuitvoltageof540VDCisneverexceeded.Pleasenotethatthemaximumopen-circuitvoltage
will occur at the lowest temperatures anticipated. You will nd more detailed information about
temperaturedependencyinthedatasheetofthePVmodules.Thedevice’spowerconsumptionis
kepttoaminimum.
Thehigh-qualityaluminumcasingcorrespondstoprotectionclassIP65(water-jet-proofanddust-
proof)andisprotectedagainstweatheringprocessesbysurfacerenement.Thecoolingcharac-
teristicproleisdesignedsothatoperationoftheinverterispossiblewithambienttemperatures
from-25°Cto+70°C.
Acoolingcharacteristicproleisusedfortheremovalofthepowerdissipationcausedthroughthe
voltage conversion.An internal temperature control protects the device against excessive tem-
peraturesintheinteriorofthesolarinverter.Incaseofhighambienttemperatures,themaximum
transferablepowerislimited.
Thesolarinverteriscontrolledbymicrocontrollers,whichalsoimplementinterfacecommunication
andthemonitoringofvaluesandmessagesonthedisplay.
Twoindependentandredundantmicrocontrollerscontrolthemonitoringofthegrid,whichiscon-
sistentwiththefeed-indirectivesofyourlocalutilitycompanyandDINVDE0126-1-1,EN50438,
ENELG.L.12/2008andRD1663(anti-islandingprotection).Thisenablesaninstallationofthesolar
inverterinthein-houseelectricalgrid.
OperatorprotectionrequirementsaremetbyelectricallyisolatingthegridfromthePVmodule.The
electricalisolationbetweenthegridandthePVmoduleisequivalenttobasicinsulation.Maximum
operatorprotectionisensuredbyreinforcedisolationbetweenthegrid,PVmodulesandaccessible
interfaces(displayandRS485interface).Relevantstandardsconcerningelectromagneticcompat-
ibility(EMC)andsafetyarefullled.
Thesolarinverterisfunctionalinon-gridoperationexclusively.Anautomatedisolationpoint,which
isapprovedbyacerticationagency,guaranteessecuredisconnectionincaseofcircuitisolationor
interruptionsinpowersupplyandavoidsisolatedoperation.
Thedisconnectionequipmentallowsforautomaticisolationforin-plantgenerationsystemsofnomi-
nalpower≤4.6kVA,withsingle-phaseparallelfeed-inthroughthesolarinverterintothepublicgrid.

5
4.3 Equipment overview
(1)Connectionsforsolarmodules
(2)DCdisconnector
(3)Gridconnection
(4)InterfaceconnectionRS485(EIA485)
(5)Displayforstatusmessagesandkeypadforoperation
(6)Light-emittingdiodesforoperationalstatusdisplay
(1) (2) (3)
(5)
(6)
(4)

6
5 Installation
Installationandcommissioningmustonlybecarriedoutbyqualiedelectricalexperts.
Therecommendedsafetyregulations,thetechnicalinterfaceconditions(TAB2000),aswellasDIN
VDE0126-1-1,EN50438,ENELG.L.12/2008andRD1663specications,shouldbecomplied
with.
Tocarryoutanenergymeasurement,ametermustbeattachedbetween thegridfeed-inpoint
andthesolarinverter(inaccordancewithyourlocalutilitycompanydirectiveconcerning„In-plant
generationsystemsonthelow-voltagegrid“).
By means of the integrated anti-islanding protection, the function of the recommended section
switchisfullledinaccordancewithyourlocalutilitycompanydirective.
Caution:Thesecondaryshort-circuitcurrentratingisincreasedatthetransferconnectionpointto
thepublicelectricitysupplysystembythenominalcurrentoftheconnectedsolarinverter.
6 Installation of equipment
6.1 Installation location
•Installthedeviceonanon-ammablesupportbase.
•Avoidinstallationonresonatingbodies(lightconstructionwallsetc.).
•Installationispossiblebothindoorsandinprotectedoutdoorareas.
•AnincreasedambienttemperaturecanreducetheefciencyofthePVsystem.
•Noisegenerationispossible(avoidinstallationinresidentialareas).
•EnsurelegibilityoftheLEDsandthedisplay(checkread-offangleandinstallationheight).
•AlthoughtheunitisttedwithUVresistantcomponents,directexposuretosunlightshouldbe
avoided.
•DespitehavinganIP65enclosureandbeingcertiedinaccordancewithsoilingcategoryIII,the
unitmustnotbeallowedtobecomeheavilysoiled.
•Dustyconditionssoilingcanimpairtheunit’sperformance.
6.2 Minimum requirements
•Freeconvectionaroundthesolarinvertermustnotbeimpaired.
•Forproperaircirculationtodissipateheat,allowaclearanceofapprox.10cmtothesideand
 approx.50cmaboveandbelowtheunit.
•Thegridimpedancerequirementatthesupplyterminalistobeobserved(cablelength,cable
 cross-section).
•Therecommendedinstallationpositionistobeadheredto(vertical).
•UnusedDCconnectors(Tyco)andinterfacesmustbesealedairtightwithsealingplugstoen-
 sureprotectionclassIP65forthewholesystem(inverter&cables).

7
319.5
150
320
200
6.5
12
Ø
12.5
90
38
12
410 ± 0.5
6.3 Maintenance
Makesurethatthedeviceremainsuncoveredwhileinoperation.Toavoidthecasingofthesolar
inverterbecomingsoiled,itshouldbecleanedperiodically.
User-serviceablepartsarenotcontainedinthedevice.Undernocircumstancesshouldthesolar
inverterbeopened!
6.4 Installation
Youshouldutilizethedeliveredmountingplateforproblem-freeinstallationofthesolarinverter.
Installationtothewallshouldbeimplementedwiththeproperscrews.Mountthewallbracketso
thatthesolarinvertercanbeeasilyattachedtothewall.Afterthat,thedeviceshouldbeboltedon
securely.
Assemblyinstructions
1. Mountthemountingplatewithappropriatescrews(max.Ø6mm)intoatleastfourof
 theeightholestoxthewallbracketinplace.Youcanemploythemountingplateasa
 templateformarkingthepositionsoftheboreholes.
2. Asthesolarinverterweighs21.5kg,itshouldbeliftedoutofthetransportcratebyat
 leasttwopersons.
3. Placethesolarinverterontothemountingplatewithatleasttwopersons.
4. Fastenthesuppliedmountingnutsandwashersonthethreadedboltintendedforsecu-
 ringthedevice.
5. Checkthatthesolarinverterissecurelyseated.
Mounting
plate
Lockingscrew
Lockingscrew

8
6.5 Ambient temperature
Thesolarinvertercanbeoperatedinanambienttemperaturebetween-25°Cto+60°C.
Thefollowingdiagramillustrateshowthepowersuppliedbythesolarinverterisreducedautoma-
ticallyinaccordancewithambienttemperature.
Thedeviceshouldbeinstalledinawell-ventilated,coolanddrylocation.
6.6 Grid connection
Thegrid(ACoutput)isconnectedoveraWielandRST25i3SACconnector.Youcanndthecor-
rectallocationonthescrew-typeterminalconnectionoftheconnector.Thesolarinvertermustbe
connectedtothegridoverathree-coreline(L,N,PE).TheconnectedAClinemustbeswitched
potential-freebeforethedisconnectionortheinsertionoftheACconnector.
TheconnectiontotheWielandACconnectormustbemadewithaexiblelineandaconductor
crosssectionofmin.2.5mm²tomax.4.0mm².
AnautomaticcircuitbreakeristobeprovidedinthelineLupstreamofeverydevice,withanominal
currentof16AandtrippingcharacteristictypeB.Inaddition,attentionistobepaidtotheselectivity
ofthefuseunitattachedupstreamoftheautomaticcircuitbreaker.
ThesolarinvertermustbegroundedviatheACconnector’sPEconductor.Todothis,connectthe
PEconductortothedesignatedterminal.Ifyouwishtointegratemorethanoneinverterintothe
installation,pleaseproceedasillustratedinthedrawingsintheappendix.
Pleasenotethecablelengthandthecablecross-section,duetotheriskofundesirabletemperature
riseandpowerlosses.
TheACconnectorisprotectedfromunintentionaldisconnectionbyaclipmechanismwhichcanbe
releasedwithascrewdriver.
6.7 Connection of PV modules
Beforethephotovoltaicsystemisconnected,thepolarityofthePVvoltageattheTycoconnectors
mustbecheckedtoensurethatitiscorrect.
TheconnectionofthePVmoduleisimplementedusingTycoSolarlokconnectors,wheretheDC
negativepoleislocatedontheconnectorupperrowandtheDCpositivepoleontheconnector
lowerrow.Theconnectorsarecodedtopreventyoufromaccidentallypluggingthemintothewrong
terminal.
Pleaseensurethefollowingatalltimes:
•Thatthereisneveranyriskofanyonecomingintocontactwiththesolarinverterconnection
 terminals,duetotheriskofdangerousvoltagesacrossthem.
•ThatundernocircumstancesarethePVmodulestobedisconnectedfromthesolarinverterunder
load.Ifadisconnectionshouldbenecessary,rstswitchthegridoffsothatthesolarinverter
 cannotabsorbanyfurtherpower.Next,opentheupstreamDCdisconnector.
Themaximuminputvoltageofthesolarinverteris540V.Themaximumcurrentloadofeachindi-
vidualTycoconnectoris18A.

9
ThesolarinverterhasaninsulationandgroundingmonitoringontheDCside.Theoptionscanbe
conguredintheSetupmenu“6.S->SolarISO/GND”(seepage23,section7.3.8).
Theinsulationmonitoringhastwomodes:
•ISO-ON-Error(thesolarinverterisdisconnectedfromthegridintheeventofaninsulation
 fault)
•ISO-ON-Warning(thesolarinverterindicatesthefaultbutisnotdisconnectedfromthegrid).
Deltassolarinvertersarefactory-settoISO-ON-Warningmodeondelivery.
Thegroundingmonitoringhastwomodes:
•PV+grounding(groundingmonitoringofthepositivepoleofthePVgenerator)
•PV-grounding(groundingmonitoringofthenegativepoleofthePVgenerator).
Inthesemodesthesolarinverterremainsinfeed-inoperationandwillnotbedisconnectedfromthe
gridincaseofafault.Theerrormessage“PV+groundingfault”or“PV-groundingfault”willappear
onthedisplay.
IfyouneedtoconnectthepositiveornegativepoleofthePVsystemtomeetrequirementsset
outbythemodulemanufacturer,youcandothis.Earthcontinuitymustbeimplementedcloseto
theinverter.WesuggestusingDeltasgroundingkit“GroundingSetASolar”(EOE99000115).The
groundingconnectionismonitoredandshouldbeconguredintheSetupmenu(seeabove).
Alternatively,itispossibletoturnofftheinsulation-andgroundingmonitoring:
•ISO/GNDOFF.
RequiredcablecouplertypesforDCcableconnectiontoinverter:
CABLE
COUPLER
POLARITY
WIRE SIZE
2.5 MM2
(AWG 14)
WIRE SIZE
4.0 MM2
(AWG 12)
WIRE SIZE
6.0 MM2
(AWG 10)
FEMALE CA-
BLE COUPLER
PLUS CODED
FEMALE CABLE
COUPLER
MINUS CODED
TYCO
ORDER
NUMBER
Plus
coupler • • 1394462-1
Minus
coupler • • 1394462-2
Plus
coupler • • 1394462-3
Minus
coupler • • 1394462-4
Plus
coupler • • 1394462-5
Minus
coupler • • 1394462-6

10
6.7.1 Output power over PV voltage
150 VDC 200 VDC 250 VDC 300 VDC 350 VDC 400 VDC 450 VDC
2500 W
2700 W
2900 W
3100 W
3300 W
3500 W
3700 W
6.7.2 Output power over AC voltage
2500 W
2700 W
2900 W
3100 W
3300 W
3500 W
3700 W
190 VAC
210 VAC 230 VAC 250 VAC 270 VAC

11
6.8 Interface connection RS485 (EIA485)
Theinterfacesnotusedmustalwaysbeclosedoff.Incaseofutilizationofaninterface,onlythe
counterpartttingontheinterfaceconnectoristobeemployed.
MatingconnectorsupplierHARTINGDeutschlandGmbH&Co.KG(P.O.2451,D-32381Minden;
www.harting.com).
Orderdesignation: 09451451510,CableManagerBlueIP67Push-PullDataPlug
  09451451500,CableManagerWhiteIP67Push-PullDataPlug
-
~
-
~
-
~
-
~
230 V - House connection line
RS485 (EIA485) - Connection
Datalogger
RS485 (EIA485)
terminating resistor
6.7.3 Efciency
Thebestefciencyofthesolarinverterisobtainedatinputvoltages>250V.
84 %
86 %
88 %
90 %
92 %
94 %
96 %
0 W 400 W 800 W 1200 W 1600 W 2000 W 2400 W
2500 W @ 125 V 2500 W @ 250 V 2500 W @ 350 V 2500 W @ 450 V

12
81
Pin
1 Not used
2 Not used
3 Not used
4 GND (RS485)
5 TERM (RS485)
6 RX_B (RS485)
7 TX_A (RS485)
8 Not used
Top View
Connector pin assignment RS485 (EIA485)
+5V
Not used
Not used
0R
0R
121R
TX_A
RX_B
TERM
GND
Pin 7
Pin 6
+5V
Not used
Not used
0R
0R
121R
TX_A
RX_B
TERM
GND
Pin 6
Pin 5
100 ... 150
Ohm, 0,25W
When several devices are connected in series and the total length of the data line measures 2 m or
more, the following options are available for terminating the RS485 (EIA485) interface:

13
6.9 Electrical connection and operational start-up
Theelectricalconnectionsareutilizedonthissolarinverterusingtheconnectorcontactswhichare
attachedtothecasing.Undernocircumstancesshouldthedevicebeopened!
Power
controller
Anti-
islanding
protection
Communi-
cation
Operating- and system control
MPP-
Tracker -
-
Booster
-
-
Isolation
DC-Bus
-
~
Solar inverter
DC
DC
DC
String A
String B
String C
AC
Public
grid

14
In order to set up the device, follow these procedures carefully:
1.TurnofftheDCdisconnector.
2.DCconnection:First,connectthePVmodulestringstotheDCTycoSolarlokconnectors(ensure
 correctpolarity).
3.ACconnection:PleaseinstalltheWielandACmatingconnectortotheACoutputcableandthen
 plugtheACconnectortothesolarinverter.Pleasemakesure,thatthesleevenutisproperly
 xedandtighten.
4.Beforeswitchingonthepower,checkallfeedersandconnectionsonelasttime.
5.TurnontheDCdisconnector.
6.ClosethecircuitbreakerontheACoutputside.
7.IncaseofsufcientPVvoltage(UPV>150V),thedevicenowgoesintothefeed-inoperation.
8.Incaseofanewinstallationthetimeanddatehavetobesetinsub-menuS(Setup)(seepage
 23,section7.3.8).
Allunoccupiedconnectorsandinterfacesmustbesealedusingtheprovidedsealing
plugs.
6.10 Setup / settings
ThedefaultdisplaylanguageforsolarinvertersleavingtheDeltafactoryissettoEnglish.
AfterconnectingtocorrectDCvoltageandrunningthroughself-test,youwillbeaskedtospecify
thenetworkIDandtoselectthedesiredcountry(seepage23,section7.3.8)(countriesavailable:
Germany,France,Italy,Spain,Greece,Portugal,CzechRepublicandBelgium)).
Theselectionhastobeconrmedanothertimebytheuser.Onceconrmed,thenetworkIDandthe
countryselectionarestoredtothecontrollermemory–andthesolarinverterisreadyforoperation.
Pleasenotethattheenterkeysonthedisplayarelocked,ifthereisnoinputentrywithin5
minutes.Tounlocktheenterkeys,youneedtoswitchofftheDCvoltageandthenswitchitonagain.
Country selection
Increase network ID Decrease network ID
Down *
Up *
Enter network ID
ENTER *
ESC *
Select country
Next country Country before
Down *
Up * ENTER *
Normal mode
* Timeout if no key is pressed (within 5 minutes)
Possible countries:
Belgium
Czech
France
Germany
Greece continent
Greece island
Italy (50Hz/49Hz)
Italy (51Hz/49Hz)
Portugal
Spain (51Hz/49Hz)
Spain (51Hz/48Hz)

15
Operation (A)
Earth Fault (B)
Failure (C)
•LED(A),green:„Operation“displaysthe
 operationalstate.
•LED(B),red:„EarthFault“displaysaninsula-
 tionresistancefaultorPVgrounding(GND)
faultontheDCside.
•LED(C),yellow:„Failure“displaysexisting
 faultsinternallyorexternallyandwhetherthe
 gridfeed-inoperationhasbeeninterrupted.
6.11 LED operation and fault display
Threelight-emittingdiodes(LEDs),whichdisplaytheoperationalstateofthesolarinverter,areat-
tachedonthefront:
Pleasenote,thatoncethecountryhasbeenselectedandconrmed,itisonlypossibletochange
thecountrybyfollowingthestepsaslistedbelow:
1.PleaseclickESC+forfewsecondstogetthekeyinformation.
2.ProvidethekeycodetotheSolarSupportTeamat[e-mail]togetthePIN
 code(validforoneuseonly!).
3.OnceyougetthePINcode,youneedtopressESC+.
4.Then,youwillbeaskedtoinsertthePINcodeandtoconrmittwice.
5.Afterconrmation,youwillthenbeabletoselectthedesiredcountry.
Note:Thesestepsmustbeexecutedwithoutinterruption.Otherwise,youwillstayinthecountry
selectionmode.
LED STATUS OPERATIONAL STATE EXPLANATION
green:<off>
red:<off>
yellow:<off> Nightdisconnection. Theinputvoltage(UPV)islowerthan100V.
Thesolarinverterisnotfeedingpowertothegrid.
green:<on>
red:<on>
yellow:<on> Initialization. Inputvoltages:
UPV:100Vto150V
(selftestongoing).
green:<ashes>
red:<off>
yellow:<off>
Input-andgridmoni-
toring. Startingconditionsaretested.
green:<on>
red:<off>
yellow:<off> Feed-inoperation. Normaloperationalstate:
UPV:150Vto450V.
green:<off>
red:<on/off>
yellow:<on/off> Equipmentfault. Internalorexternalfault
(interruptedfeed).
Seealsodisplaymessages!
green:<off>
red:<on/off>
yellow:<on>
Generalerror
condition.
Solarinverterisnotconnectedtothegrid.
Nopowerisdelivered.
Seealsodisplaymessages!
green:<on/off>
red:<on/off>
yellow:<ashes> Warningmessage. Youcancarryonusingthesolarinverter.
Seealsodisplaymessages!

16
7 Operating concept
7.1 The display
Thedisplayonthedeviceindicatesvariedinformation.Theenterkeysareusedfortheadjustment
ofthedeviceandfortheretrievalofinformation.Themeasureddatacandeviatewithatolerance
ofupto5%.
ESC
(A) (B) (C) (D)
7.2 Navigation in the display
Lightingofthedisplay
AfterpressingtheENTERkeyinautomaticoperation,thedisplaylightingisswitchedon.Ifnokey
ispressedwithin30seconds,thedisplaylightingautomaticallygoesout.Thesetupmenuenables
selectionbetweencontinuousorautomaticlighting.ThroughpressingtheENTERkey,thedisplay
lightingisswitchedonagain.
Key(A),ESC: Toswitchfromthemenu
 itemstothemainmenuand
 toexiteachsub-menu.
Key(B)and(C):Forscrollingintheindividual
menuitemsand/orcarrying
outadjustmentsinthesetup
menu.
Key(D),ENTER: ENTERkeyforchanginginto
 themenulevelsandforinput
acknowledgementinthe
setupmenu.
7.3 Main menu
Themainmenuconsistsof8menuitemswhicharesubdividedintosubmenus:
•MenuAutotest
•MenuN(Now)
•MenuD(Day)
•MenuW(Week)
•MenuM(Month)
•MenuY(Year)
•MenuT(Total)
•MenuS(Setup)
Handlingofthemenuitems:
Youcanscrollthemainmenubyactivatingtheselectorkeys
.
PresstheENTERkeytoselectthesubmenus.Inordertoexitthemenusagain,activatetheESC
key.

17
User menu
Menu N - Now (act data)
Menu D - Day statistic
Menu W - Week statistic
Menu M - Month statistic
Menu Y - Year statistic
Menu T - Total statistic
Menu S - Setup inverter
Down
Down
Down
Down
Down
Down
Up
Up
Up
Up
Up
Up
Down to 2 1
Up to 1
2
Submenu N - Now
Submenu D - Day
Submenu W - Week
Submenu M - Month
Submenu Y - Year
Submenu T - Total
Submenu S - Setup
ESC
ESC
ESC
ESC
ESC
ESC
ESC
ENTER
ENTER
ENTER
ENTER
ENTER
ENTER
ENTER
Remarks:
ESC in main menu jumps to first entry of
corresponding sub menu
Menu Autotest
(only for Italy)
Down
Up
Submenu Autotest
ESC
ENTER

18
Therstlineshowsthelimitsaccordingthestandard.Thesecondlineshowstheactualmeasured
gridvoltageandtheteststatus,positive(pass)ornegative(fail).Pressingthetestisconrmed
andtheauto-testroutinecontinue.Ifnoispressed,theresultisshownfor1minute.Afterthis
time,theresultisconrmedautomatically.
Autotest Passed
Start Autotest?
Therstlineshowstheactualauto-teststatuswhichcouldbe“passed”or“failed”.Pressingthe
auto-testroutinestarts.ThersttestperformedistheOVT,overvoltagetest,whichverifytheover
voltageprotection.Thedisplayshows:
7.3.1 Autotest (only for Italy)
ThisfunctionisavailableonlyfortheItaliancountry.
Theinverterissuppliedwithanauto-testfunctionabletoverifythecorrectoperationoftheinterface
protection.
Inthemainmenu,usingbuttons,selecttheauto-testmenu.Thedisplayshows,forexample:
L: 262 V < 0.1 S
Start OVT test?
Therstlineshowstheactualovervoltagelimitanddetectiontimesettingsaccordingtothestan-
dards.Pressingtheteststarts.Pressing“ESC”thedisplaygoesbacktothemainmenu.
Ifhasbeenpressedthedisplayshows,forexample:
L: 262 V OVT
A: 230 V RUN
L: 230 V 0.044 S
A: 230 V OV pass
L: 186 V < 0.2 S
Start UVT test?
Afterfewsecondsneededfromtheinvertertoswitchtothetestmode,thelimit“L:”willdecreasetill
crossingtheactualmeasuredgridvoltage“A:”.Reachedthisconditiontheinverterdisplayshows,
forexample:
Ifthetestisconrmed,theinverterperformstheUVTtest,undervoltagetest,whichverifytheunder
voltageprotection.Thedisplayshows:
Therstlineshowstheactualundervoltagelimitanddetectiontimesettingsaccordingtothestan-
dards.Pressingtheteststarts.Teststartsalsoautomaticallyafter1minuteifnoispressed.
Ifhasbeenpressedthedisplayshows,forexample:
L: 186 V UVT
A: 230 V RUN
