Delta DVP04TC-H2 User manual

http://www.delta.com.tw /industr ialautoma tion/
5011652100-T2E0
2007-01-09
Temperature Measurement Module
Instruction Sheet
Warning
9Please read this instruction sheet carefully before use.
9Switch off the power before wiring.
9DVP04TC-H2 is an OPEN-TYPE device and therefore should be installed in an enclosure free of airborne dust,
humidity, electric shock and vibration. The enclosure should prevent non-maintenance staff from operating the device
(e.g. key or specific tools are required to open the enclosure) in case danger and damages on the device may occur.
9DO NOT connect input AC power supply to any of the I/O terminals; otherwise serious damage may occur. Check all
the wiring again before switching on the power.
9DO NOT touch any terminal when the power is switched on.
9Make sure the ground termnial is correctly grounded in order to prevent electromagnetic interference.
9Keep the wire as short as possible between RTD and PLC and the power wire as far away as possible from I/O wire to
prevent interference.
Introduction
1.1 Model Explanation & Peripherals
Thank you for choosing Delta’s DVP series. DVP04TC-H2 is able to receive 4 points of external thermocouple
temperature sensors (J-type, K-type, R-type, S-type, T-type) and convert them into 14-bit digital signals.
Besides, through FROM/TO instructions in DVP-EH2 MPU program, DVP04TC-H2 is able to read and write the
data in the module. There are 49 16-bit control registers (CR) in DVP04TC-H2.
The power unit and module of DVP04TC-H2 are separate, compact in size and easy to install.
DVP04TC-H2 displays temperatures in Celsius (resolution: 0.1°C) and Fahrenheit (resolution: 0.18°F).
Nameplate Explanation
04TC-H2 0T6500001
VX.XXXX
24Vdc 2.5W
TYPEJ, K, R, S,T
MADE IN XXXXXX
14 BITS
MODEL:
POWER INPUT:
THERMOCOUPLESE:
RESOLUTION:
Delta PLC model name
Power input specification
Analog I/O module specification
Barcode, serial No., Version
Model/Serial No. Explanation
DVP series
AD: Analog input
DA: Analog output
PT: Temperature measurement (PT-100)
TC: Temperature measurement
(thermocouple)
Points (input + output)
Model type
XA: Mixed analog I/O
HC: High-speed counter input
PU: Single-axis position control
H: For EH series MPU
H2: Fo r EH2 s er ies M PU
Model name
Production No.
Production week
Production year (2006)
Production plant (Taoyuan)
Ver si on No .
1.2 Product Profile (Indicators, Terminal Block, I/O Terminals)
Unit: mm
D - L + L - L +
24V 0V
L - L + L - L + L -
D + SLD
8
SLD SLD SLD
CH 1 CH 2 CH 3 CH4RS-485
1 DIN rail (35mm) 6 Terminals
2 Connection port for extension unit/module 7 Mounting hole
3 Model name 8 I/O terminals
4 POWER, ERROR, A/D indicator 9 Mounting port for extension unit/module
5 DIN rail clip
1.3 External Wiring
CH1
CH4
DC/ DC
5V
AG
+15V
-15V
AG
24+
0V
SLD
L -
L+
*2
*3
+
-
10 k
MUX
+
-SLD
L -
L+
Thermocouple
Thermocouple
Shielding
cable *1
Shielding
cable *1
Cold-Junct ion
Compensation
Converter
System
grounding
Termin al of
power module
Earth
(100 or less)
*1: The wiring used for analog input should adopts the connection cable or shielding cable of thermocouple temperature
sensor J-type or K-type and should be separated from other power cable or wirings that may cause interference. The
screw torque of the terminal should be 1.95 kg-cm (1.7 in-lbs).
*2: Terminal SLD is the ground location for noise suppression.
*3: Please connect the terminal on both the power module and DVP04TC-H2 to the system earth point and ground the
system contact or connect it to the cover of power distribution cabinet.
Note: DO NOT wire empty terminal .
Note: Use 60/75°C copper conductor only.
Specifications
2.1. Functions
Temperature measurement
(04TC) module Celsius (°C) Fahrenheit (°F)
Power supply voltage 24 VDC (20.4VDC ~ 28.8VDC) (-15% ~ +20%)
Analog output channel 4 channels/module
Applicable sensor
types J-type, K-type, R-type, S-type, T-type thermocouple
Range of input
temperature
J type: -100°C ~ 700°C
K type: -100°C ~ 1,000°C
R type: -10°C ~ 1,700°C
S type: -10°C ~ 1,700°C
T type: -100°C ~ 350°C
J type: -148°F ~ 1,292°F
K type: -148°F ~ 1,832°F
R type: -14°F ~ 3,092°F
S type: -14°F ~ 3,092°F
T type: -148°F ~ 662°F
Range of digital
conversion
J type: K-1,000 ~ K7,000
K type: K-1,000 ~ K10,000
R type: K-100 ~ K17,000
S type: K-100 ~ K17,000
T type: K-1,000 ~ K3,500
J type: K-1,480 ~ K12,920
K type: K-1,480 ~ K18,320
R type: K-140 ~ K30,920
S type: K-140 ~ K30,920
T type: K-1,480 ~ K6,620
Resolution 14 bits (0.1) 14 bits (0.18)
Overall accuracy
±0.5% when in full scale (25°C, 77°F)
±1% when in full scale within the range of 0 ~ 55°C, 32 ~ 131°F
Response time 200 ms × the number of channels
Isolation Isolation between digital area and analog area. No isolation among channels.
Digital data format 13 significant bits out of 16 bits are available; in 2’s complement
Average function Yes; available for setting up in CR#2 ~ CR#5; range: K1 ~ K20
Self-diagnosis Upper and lower bound detection/channel
Protection
The voltage output is protected by short circuit. Please also be aware that being
short circuit for too long period of time may cause damage on internal circuit. The
current output can be open circuit.
Communication mode
(RS-485)
ASCII/RTU mode.
Communication speed: 4,800/9,600/19,200/38,400/57,600 /115,200 bps
ASCII data format: 7-bit, Even bit, 1 stop bit (7, E, 1)
RTU data format: 8-bit, Even bit, 1 stop bit (8, E, 1)
RS-485 cannot be used when connected to PLC MPU.
When connected to
DVP-PLC MPU in
series
The modules are numbered from 0 to 7 automatically by their distance from MPU.
No. 0 is the closest to MPU and No. 7 is the furthest. Maximum 8 modules are
allowed to connect to MPU and will not occupy any digital I/O points.
2.2. Others
Power Supply
Max. rated power
consumption 24 VDC (20.4VDC ~ 28.8VDC) (-15% ~ +20%), 2.5W supplied by external power.
Environment
Environment spec. Same as that of DVP-PLC MPU
Control Register
DVP04TC-H2 Description
CR
#
RS-485
P
arameter
address
Latched
Register content b15
b14
b13
b12
b11
b10
b9
b8
b7
b6
b5
b4
b3
b2
b1
b0
#0
H’4096
○
R
Model name Set up by the system. DVP04TC-H2 model code = H’6403
Reserved CH4 CH3 CH2 CH1
#1
H’4097
○
R/W
Thermocouple type
Take the setting of CH1 for example:
1. When (b2, b1, b0) is set as (0,0,0), choose J-type
2. When (b2, b1, b0) is set as (0,0,1), choose K-type
3. When (b2, b1, b0) is set as (0,1,0), choose R-type
4. When (b2, b1, b0) is set as (0,1,1), choose S-type
5. When (b2, b1, b0) is set as (1,0,0), choose T-type
#2
H’4098
○
R/W
CH1 average time
#3
H’4099
○
R/W
CH2 average time
#4
H’409A
○
R/W
CH3 average time
#5
H’409B
○
R/W
CH4 average time
Range of settings in CH1 ~ CH4: K1 ~ K20
Default = K10
#6
H’409C
╳
R
Average °C temp. measured
at CH1
#7
H’409D
╳
R
Average °C temp. measured
at CH2
#8
H’409E
╳
R
Average °C temp. measured
at CH3
#9
H’409F
╳
R
Average °C temp. measured
at CH4
Average Celsius temperature measured at CH1 ~ CH4.
Unit: 0.1°C
#10
H’40A0
╳
R
Average °F temp. measured
at CH1
#11
H’40A1
╳
R
Average °F temp. measured
at CH2
#12
H’40A2
╳
R
Average °F temp. measured
at CH3
#13
H’40A3
╳
R
Average °F temp. measured
at CH4
Average Fahrenheit temperature measured at CH1 ~ CH4
Unit: 0.1°F
#14
H’40A4
╳
R
Present °C temp. measured
at CH1
#15
H’40A5
╳
R
Present °C temp. measured
at CH2
#16
H’40A6
╳
R
Present °C temp. measured
at CH3
#17
H’40A7
╳
R
Present °C temp. measured
at CH4
Present Celsius temperature measured at CH1 ~ CH4
Unit: 0.1°C
#18 Reserved
#19
H’40A9
╳
R
Present °F temp. measured
at CH1
#20
H’40AA
╳
R
Present °F temp. measured
at CH2
#21
H’40AB
╳
R
Present °F temp. measured
at CH3
#22
H’40AC
╳
R
Present °F temp. measured
at CH4
Present Fahrenheit temperature measured at CH1 ~ CH4
Unit: 0.1°F
#23 Reserved
#24
H’40AE
○
R/W
OFFSET value of CH1
#25
H’40AF
○
R/W
OFFSET value of CH2
#26
H’40B0
○
R/W
OFFSET value of CH3
#27
H’40B1
○
R/W
OFFSET value of CH4
Adjustable OFFSET settings at CH1 ~ CH4.
Range: -1,000 ~ +1,000
Default = K0
Unit: 0.1°C
#28 ~ #29 Reserved
#30
H’40B4
╳
R
Error status Register for storing all error status. See the table of error status for more
information.
#31
H’40B5
○
R/W
Communication address
setting
For setting RS-485 communication address. Range: 01 ~ 255
Default = K1
#32
H’40B6
○
R/W
Communication speed (baud
rate) setting
For setting up communication speed:
4,800/9,600/19,200/38,400/57,600/115,200 bps
ASCII data format: 7-bit, Even bit, 1 stop bit (7, E, 1)
RTU data format: 8-bit, Even bit, 1 stop bit (8, E, 1) Default: H’0002
b0: 4,800 bps b1: 9,600 bps (default)
b2: 19,200 bps b3: 38,400 bps
b4: 57,600 bps b5: 115,200 bps
b6 ~ b13: reserved
b14: High/low bit exchange of CRC checksum (only valid in RTU mode)
b15: Switch between ASCII/RTU modes; 0 = ASCII mode (default)
b15
b14
b13
b12
b11
b10
b9
b8
b7
b6
b5
b4
b3
b2
b1
b0
ERR LED CH4 CH3 CH2 CH1
#33
H’40B7
○
R/W
Returning to default setting
Take the setting of CH1 for example:
1. b0 is reserved.
2. b1 is reserved.
3. When b2 is set as 1, all the settings will return to default settings.
ERR LED definition: default of b12 ~ b15 = 1111
1. b12 corresponds to CH1. When b12 = 1 or the scale exceeds the range,
ERR LED will flash.
2. b13 corresponds to CH2. When b13 = 1 or the scale exceeds the range,
ERR LED will flash.
3. b14 corresponds to CH3. When b14 = 1 or the scale exceeds the range,
ERR LED will flash.
4. b15 corresponds to CH4. When b15 = 1 or the scale exceeds the range,
ERR LED will flash.
#34
H’40B8
○
R
Firmware version Displaying the current firmware version in hex; e.g. version 1.0A is indicated
as H’010A
#35 ~ #48 For system use
Symbols
○: latched (when written in through RS-485 communication)
╳:non-latched
R: Able to read data by FROM instruction or RS-485 communication
W: Able to write data by TO instruction or RS-485 communication
Explanations:
1. CR#0: Model name. The user can read the model name from the program and see if the extension module
exists.

2. CR#1: The working mode of the 4 channels in the sensors selected by the temperature measurement module.
There are 2 modes (J-type and K-type) for each channel which can be set up separately. For example, if the
user needs to set up CH1: mode 0 (b2 ~ b0 = 100); CH2: mode 1 (b5 ~ b3 = 001); CH3: mode 0 (b8 ~ b6 =
000) and CH4: mode 1 (b11 ~ b9 = 001), CR#1 has to be set as H0208 and the higher bits (b12 ~ b15) have
to be reserved. The default value = H’0000.
3. CR#2 ~ CR#5: The times to average the temperatures measured at CH1 ~ CH4. Range: K1 ~ K20. Default =
K10. Please note that when PLC MPU writes in the average time by TO/DTO instruction, please use the
rising/falling edge contact detection instructions (LDP/LDF…) in case you may not obtain the correct average
temperature.
4. CR#6 ~ CR#9: The average Celsius temperature measured at CH1 ~ CH4 obtained from the average time
settings in CR#2 ~ CR#5. For example, if the average time is set as 10, the content in CR#6 ~ CR#9 will be
the average of the most recent 10 temperature signals in Celsius at CH1 ~ CH4.
5. CR#10 ~ CR#13: The average Fahrenheit temperature measured at CH1 ~ CH4 obtained from the average
time settings in CR#2 ~ CR#5. For example, if the average time is set as 10, the content in CR#10 ~ CR#13
will be the average of the most recent 10 temperature signals in Fahrenheit at CH1 ~ CH4.
6. CR #14 ~ CR #17: Displaying the present temperature in Celsius at CH1 ~ CH4
7. CR#18, CR#23, CR#28 and CR#29 are reserved.
8. CR #19 ~ CR #22: Displaying the present temperature in Fahrenheit at CH1 ~ CH4
9. CR #24 ~ CR #27: The adjusted OFFSET value of CH1 ~ CH4. Range: -1,000 ~ +1,000. Unit: 0.1°C.
Temperature measured by the module – OFFSET value = Actual temperature displayed.
10. CR #30: Error status (see the table below)
Error status Content b15 ~ b8
b7
b6
b5
b4
b3
b2
b1
b0
Abnormal power supply K1(H’1) 0 0 0 0 0 0 0 1
Scale exceeds the range
or wiring to empty external
contact
K2(H’2) 0 0 0 0 0 0 1 0
Incorrect mode setting K4(H’4) 0 0 0 0 0 1 0 0
OFFSET/GAIN error K8(H’8) 0 0 0 0 1 0 0 0
Hardware malfunction K16(H’10)
0 0 0 1 0 0 0 0
Abnormal digital range K32(H’20)
0 0 1 0 0 0 0 0
Incorrect average times
setting K64(H’40)
0 1 0 0 0 0 0 0
Instruction error K128(H’80)
reserved
1 0 0 0 0 0 0 0
Note: Each error status is determined by the corresponding bit (b0 ~ b7) and there may be more than 2 errors occurring at the same time.
0 = normal; 1 = error
11. CR#31: The setting of RS-485 communication address. Range: 01 ~ 255. Default = K1.
12. CR#32: The setting of RS-485 communication speed. b0: 4,800bps; b1: 9,600bps (default); b2: 19,200bps; b3:
38,400bps; b4: 57,600bps; b5: 115,200bps; b6 ~ b13: reserved; b14: high/low bit exchange of CRC checksum
(only valid in RTU mode); b15: switching between ASCII mode and RTU mode.
13. CR#33: b0 ~ b11: For returning the CR settings to default settings.
b12 ~ b15: ERR LED definition. Default: b12 ~ b15 = 1111.
14. CR#34: Firmware version of the model.
15. CR#35 ~ CR#48: Parameters for system use.
16. CR#0 ~ CR#34: The corresponding parameter address H’4096 ~ H’40B8 are for users to read/write data by
RS-485 communication. When using RS-485, the user has to separate the module with MPU first.
a. Communication baud rate: 4,800/9,600/19,200/38,400/57,600/115,200 bps.
b. Modbus ASCII/RTU communication protocol: ASCII data format (7-bit, Even bit, 1 stop bit (7, E, 1));
RTU data format (8-bit, Even bit, 1 stop bit (8, E, 1)).
c. Function: H’03 (read register data); H’06 (write 1 word datum into register); H’10 (write many word data
into register).
d. Latched CR should be written by RS-485 communication to stay latched. CR will not be latched if written
by MPU through TO/DTO instruction.
Temperature/Digital Curve
Temperature measurement modes
J-type thermocouple
+7,000(12 ,920)
-1,000(-1,4 80)
+700-100 CC
F)
(-148
F)
(+1,292
Digital output
Measured
temperature input
K-type thermocouple
+10,000(18,320)
-1,000(-1,480)
+1,000-100 CC
(-1,832 F)
Digital output
Measured
tempe rat ure input
R & S-type thermocouple
+17,000(30,920)
-100(-140)
+1,700-10 CC
F)
(-14
F)
(+3,092
Digital output
Measured
temperature input
T-type thermocouple
+3,500(6,620)
-1,000(-1,480)
+350
-100 CC
F)
(-148
F)
(+662
Digital output
Measured
temperature input
Trial Operation & Troubleshooting
LED Display
1. When the module is powered for the first time, POWER LED will be on and ERROR LED will be on for
0.5 second. After this, A/D LED will start to flash.
2. When the power supply is normal, POWER LED will be on and ERROR LED should be off. When the
power supply is less than 19.5V, ERROR LED will keep being on until the power supply goes higher
than 19.5V.
3. When controlled by RS485, RS-485 LED on the module will flash after receiving the RS-485
instruction.
4. When the input or output value exceeds the upper bound or falls below the lower bound after
conversion, ERROR LED will flash.
Program Example
M1000
FROM K0
= H6403 D0
TO K0
FROM K0
FROM K0
FROM K0
FROM K0
END
M1002
K0
K2
K6
K10
K14
K19
D0
D10
D20
D24
D30
D34
K1
K4
K4
K4
K4
K4
Read the model name from K0 and see if it is DVP04TC-H2: H’6403
Set the average times in CH1 ~ CH4 as D10 ~ D13.
If D0 = H’6403, read the average temperature (°C) measured in CH1 ~ CH4 from CR#6 ~ CR#9 and store the
4 data in D20 ~ D23.
Read the average temperature (°F) measured in CH1 ~ CH4 from CR#10 ~ CR#13 and store the 4 data in
D24~ D27.
Read the average temperature (°C) measured in CH1 ~ CH4 from CR#14 ~ CR#17 and store the 4 data in
D30~ D33.
Read the average temperature (°F) measured in CH1 ~ CH4 from CR#19 ~ CR#22 and store the 4 data in
D34~ D37.
Relevant Instructions
API
78
D
FROM
P
Read CR data in special modules
Instruction
Explanation
: No. of special module (m1 = 0 ~ 7) : CR# in special module to be read
: Device for storing read data : Number of data to be read at a time
Program
Example
Read CR#24 of special module No. 0 into D0 and CR#25 into D1. Only 2 groups of data are
read at a time (n = 2).
X0
FROM K0 K24 D0 K2
API
79
D
TO P
Write CR data into special module
Instruction
Explanation
: No. of special module (m1 = 0 ~ 7) : CR# in special module to be written
: Data to be written into CR : Number of data to be written at a time
Program
Example
Use 32-bit instruction DTO to write the content in D11 and D10 into CR#7 and CR#6 of special
module No. 0. Only 1 group of data is written in at a time (n = 1).
X0
DTO
K0 K6
D10
K1
Remarks
Operand rules
1. : The No. of special modules connected to PLC MPU. No. 0 is the module closest to te
MPU. Maximum 8 modules are allowed to connected to a PLC MPU and they will not occupy
any I/O points.
2. : CR#. CR (control register) is the 49 16-bit memories built in the special module,
numbered in decimal as #0 ~ #48. All operation status and settings of the special module are
contained in the CR.
3. FROM/TO instruction is for reading/writing 1 CR at a time. DFROM/DTO instruction is for
reading/writing 2 CRs at a time.
CR #10 CR #9
Lower16-bit
De s ig na t ed C R nu m be r
Hi gh er 16-b it
4. Number of groups “n” to be transmitted: n = 2 in 16-bit instructions and n = 1 in 32-bit
instructions mean the same.
D0
D1
D2
D3
D4
D5
CR #5
CR #6
CR #7
CR #8
CR #9
CR #10
D0
D1
D2
D3
D4
D5
CR #5
CR #6
CR #7
CR #8
CR #9
CR #10
Designated device
Designated CR
Designated device
Designated CR
16-bit instruction when n=6
32-bit instruction when n=3
M1083 for switching instruction modes in EH2 series models
1. When M1083 = Off, during the execution of FROM/TO instruction, all external or internal
interruption subroutines will be forbidden. The interruptions are allowed only after FROM/TO
instruction finishes its execution. FROM/TO instruction can also be used in an interruption
subroutine.
2. When M1083 = On and an interruption signal occurs during the execution of FROM/TO
instruction, the interruption will be processed first (with a 100us delay) and the execution of
FROM/TO will be stopped. After the interruption subroutine finishes its execution, the
program will jump to the next instructio of FROM/TO. FROM/TO cannot be used in an
interruption subroutine.
The content of this instruction sheet may be revised without prior notice. Please consult our distributors or
download the most updated version at http://www.delta.com.tw/industrialautomation
