Delta DCS 480 User manual

Description:
Delta DCS 480 is a hot-pluggable, fan-cooled converter which converts typical +24 Vdc input to -48 Vdc (48V) for
various telecommunication applications. The high power density DC/DC module employs the start-of-the-art
technology and provides high performance in efficiency, power density and extended operation temperature range.
Up to 4 DC/DC power modules can be equipped into one 23” wide power shelf. Up to three shelves may be
connected in parallel. The maximum capability can provide more than 5.5kW output power.
Features
• Module design for scaleable, cost effective expansion
• High efficiency
• Automatic load share, N+1 redundancy
• Hot swappable, no system shutdown for maintenance
• Reverse polarity protection design
• EMC Class B
• UL/cUL, TUV/CE Certified
Specification
General
Product name DD 48 V - 480 W – A
Efficiency 48V: > 83 %
Safety EN 1950
UL 1950
CAN/CSA-C22.2 No.950-95
EMI, radiated compliant with FCC Part 15 class B
EN 55022 class B
Cooling Fan cooled
MTBF > 150 K hours
Input
Voltage range 24V: 40 ... 59.5 Vdc
Current maximum 75 A
EMI, conducted compliant with FCC Part 15 class B
EN 55022 class B
Output
Voltage, nominal
48 Vdc,
Voltage adjust range
42 ... 57.5 Vdc
Output current
10 A
Load sharing <± 5%
Power limit 480 W
Mechanics
Width, overall 5.1” / 130 mm
Depth, overall 11.7” / 297 mm
Height, overall 3.1” / 80 mm
Weight 2.22lb/1kg
Environment
Operating temperature 0 ... + 50 °C
Relative humidity 95 % max, non condensing
Altitude - 500 ~ 10000 feet
*Specifications are subject to change
The DCS 480 Converter
