Denon AVC-A110 User manual

.
AVC-A110
INTEGRATED NETWORK AV AMPLIFIER
Owner’s Manual
Contents Connections Playback Settings Tips Appendix
1
Front panel Display Rear panel Remote Index

Accessories 8
Inserting the batteries 9
Operating range of the remote control unit 9
Features 10
High quality sound 10
High performance 13
Easy operation 17
Part names and functions 18
Front panel 18
Display 22
Rear panel 24
Remote control unit 28
Connections
Speaker installation 33
Connecting speakers 42
Before connecting speakers 42
Speaker configuration and “Amp Assign” settings 46
Connecting 5.1-channel speakers 48
Connecting 7.1-channel speakers 49
Connecting 9.1-channel speakers 54
Connecting 13.1-channel speakers 63
Connecting 15.1-channel speakers 68
Bi-amp connection 74
Connecting 11.1-channel speakers: Second pair of front speakers 76
Connecting multi-zone speakers 77
Connecting a TV 82
Connection 1 : TV equipped with an HDMI connector and
compatible with the ARC (Audio Return Channel) / eARC
(Enhanced Audio Return Channel) 83
Connection 2 : TV equipped with an HDMI connector and
incompatible with the ARC (Audio Return Channel) / eARC
(Enhanced Audio Return Channel) 84
Connection 3 : TV equipped without an HDMI connector 85
Connecting a playback device 86
Connecting a set-top box (Satellite tuner/cable TV) 87
Connecting a DVD player or Blu-ray Disc player 88
Connecting a Blu-ray Disc player compatible with the Denon Link
HD function 89
Connecting a player device compatible with the 8K 90
Connecting a video camcorder or game console 91
Connecting a turntable 92
Connecting a device with a multi-channel output connector 93
Connecting a USB memory device to the USB port 94
Connecting to a home network (LAN) 95
Wired LAN 95
Wireless LAN 96
Connecting an external control device 97
REMOTE CONTROL jacks 97
TRIGGER OUT jacks 98
Connecting the power cord 99
Contents Connections Playback Settings Tips Appendix
2
Front panel Display Rear panel Remote Index

Playback
Basic operation 101
Turning the power on 101
Selecting the input source 101
Adjusting the volume 102
Turning off the sound temporarily (Muting) 102
Playback a DVD player/Blu-ray Disc player 102
Playing a USB memory device 103
Playing files stored on USB memory devices 104
Listening to music on a Bluetooth device 107
Playing music from Bluetooth device 108
Pairing with other Bluetooth devices 110
Reconnecting to this unit from a Bluetooth device 111
Listening to Internet Radio 112
Listening to Internet Radio 113
Playing back files stored on a PC or NAS 114
Playing back files stored on a PC or NAS 115
Getting the HEOS App 118
HEOS Account 119
Playing from streaming music services 120
Listening to the same music in multiple rooms 123
AirPlay function 127
Playing songs from your iPhone, iPod touch or iPad 128
Playing iTunes music with this unit 128
Play a song from your iPhone, iPod touch or iPad on multiple
synced devices (AirPlay 2) 129
Spotify Connect function 130
Playing Spotify music with this unit 130
Convenience functions 131
Adding to HEOS Favorites 132
Playing back HEOS Favorites 132
Deleting a HEOS Favorites 133
Adjusting the audibility of dialog and vocals (Dialog Enhancer) 133
Adjusting the volume of each channel to match the input source
(Channel Level Adjust) 134
Adjusting the tone (Tone) 135
Displaying your desired video during audio playback (Video
Select) 136
Adjusting the picture quality for your viewing environment (Picture
Mode) 137
Playing the same music in all zones (All Zone Stereo) 138
Contents Connections Playback Settings Tips Appendix
3
Front panel Display Rear panel Remote Index

Selecting a sound mode 139
Selecting a sound mode 140
Direct playback 141
Pure Direct playback 142
Auto surround playback 142
Description of sound mode types 143
Sound mode that can be selected for each input signal 148
HDMI Control function 154
Setting procedure 154
Smart Menu function 155
Sleep timer function 157
Using the sleep timer 158
Quick select plus function 159
Calling up the settings 160
Changing the settings 161
Panel lock function 162
Disabling all key button operations 162
Disabling all button operations except VOLUME 162
Canceling the Panel lock function 163
Remote lock function 164
Disabling the sensor function of the remote control unit 164
Enabling the remote sensor function 164
Web control function 165
Controlling the unit from a web control 165
Playback in ZONE2/ZONE3 (Another room) 167
Connecting ZONE 167
Playback in ZONE2/ZONE3 172
Settings
Menu map 174
Menu operations 178
Contents Connections Playback Settings Tips Appendix
4
Front panel Display Rear panel Remote Index

Audio 179
Subwoofer Level Adjust 179
Bass Sync 179
Surround Parameter 180
Restorer 187
Audio Delay 188
Volume 189
Audyssey®190
Graphic EQ 193
Video 195
Picture Adjust 195
HDMI Setup 197
Output Settings 202
Analog Video Out 206
On Screen Display 206
4K/8K Signal Format 207
TV Format 209
Inputs 210
Input Assign 210
Source Rename 212
Hide Sources 213
Source Level 213
Input Select 214
Speakers 215
Audyssey® Setup 215
Procedure for speaker settings (Audyssey® Setup) 217
Error messages 223
Retrieving Audyssey® Setup settings 225
Manual Setup 226
Amp Assign 226
Speaker Config. 236
Distances 242
Levels 243
Crossovers 244
Bass 245
Front Speaker 246
2ch Playback 246
Network 249
Information 249
Connection 249
Wi-Fi Setup 250
Settings 252
Network Control 254
Friendly Name 254
Diagnostics 255
Contents Connections Playback Settings Tips Appendix
5
Front panel Display Rear panel Remote Index

HEOS Account 256
You have not signed in 256
You have already signed in 256
General 257
Language 257
ECO 257
ZONE2 Setup / ZONE3 Setup 261
Zone Rename 263
Quick Select Names 263
Trigger Out 1 / Trigger Out 2 264
Front Display 264
Firmware 265
Information 268
Remote ID 269
Usage Data 270
Save & Load 270
Setup Lock 271
Operating external devices with the remote control unit 272
Registering preset codes 273
Operating devices 276
Operating learning function 279
Operating macro function 282
Specifying the zone used with the remote control unit 286
Setting the Remote ID 287
Setting the display time length of the remote control unit display 287
Setting the back light 288
Restoring all settings of the remote control unit to default 288
Contents Connections Playback Settings Tips Appendix
6
Front panel Display Rear panel Remote Index

Tips
Tips 290
Troubleshooting 292
Power does not turn on / Power is turned off 293
Operations cannot be performed through the remote control unit 294
Display on this unit shows nothing 294
No sound comes out 295
Desired sound does not come out 296
Sound is interrupted or noise occurs 299
No video is shown on the TV 300
The menu screen is not displayed on the TV 302
The color of the menu screen and operations content displayed
on the television is different from normal 302
AirPlay cannot be played back 303
USB memory devices cannot be played back 304
Bluetooth cannot be played back 305
The Internet radio cannot be played back 306
Music files on PC or NAS cannot be played back 307
Various online services cannot be played 308
The HDMI Control function does not work 308
Cannot connect to a wireless LAN network 309
When using HDMI ZONE2, the devices does not function properly 310
Update/upgrade error messages 311
Resetting factory settings 312
Resetting network settings 313
Appendix
About HDMI 314
Video conversion function 318
Playing back a USB memory devices 320
Playing back a Bluetooth device 321
Playing back a file saved on a PC or NAS 322
Playing back Internet Radio 323
Personal memory plus function 323
Last function memory 323
Explanation of terms 324
Trademark information 334
Specifications 337
Index 343
Contents Connections Playback Settings Tips Appendix
7
Front panel Display Rear panel Remote Index

Thank you for purchasing this Denon product.
To ensure proper operation, please read this owner’s manual carefully before using the product.
After reading this manual, be sure to keep it for future reference.
Accessories
Check that the following parts are supplied with the product.
.
Quick Start Guide Safety Instructions Notes on radio Cable labels
Power cord
External antennas for
Bluetooth/wireless
connectivity
Sound calibration
microphone
Sound calibration
microphone stand
Cautions on Using Batteries
Remote control unit
(RC-1221)
LR6/AA batteries
Contents Connections Playback Settings Tips Appendix
8
Front panel Display Rear panel Remote Index

Inserting the batteries
1Slide the rear cover off the remote control unit in the
arrow direction.
.
2Insert two batteries correctly into the battery
compartment as indicated.
.
Batteries
3Put the rear cover back on.
NOTE
0To prevent damage or leakage of battery fluid:
0Do not use a new battery together with an old one.
0Do not use two different types of batteries.
0Remove the batteries from the remote control unit if it will not be in use for long
periods.
0If the battery fluid should leak, carefully wipe the fluid off the inside of the battery
compartment and insert new batteries.
Operating range of the remote control
unit
Point the remote control unit at the remote sensor when operating it.
.
Approx. 7 m
30° 30°
Contents Connections Playback Settings Tips Appendix
9
Front panel Display Rear panel Remote Index

Features
High quality sound
0Powerful 13-channel Amplifier with the Latest Home Cinema
Specs
Featuring a sophisticated power amplifier design, this unit delivers high-
power performance at 150 watts per channel (8 Ω/ohms, 20 Hz - 20
kHz, T.H.D.: 0.05 %, 2ch. driven) to ensure a dynamic and precise
entertainment experience. Low impedance drivers provide operational
stability for a wide range of speakers and create a balanced, tonal
sound.
0Dolby Atmos (v p. 325)
This unit is equipped with a decoder that supports Dolby Atmos audio
format. The placement or movement of sound is accurately reproduced
by the addition of overhead speakers, enabling you to experience an
incredibly natural and realistic surround sound field.
0Speaker Virtualizer (v p. 182)
Speaker Virtualizer enables you to access a more immersive
entertainment experience from traditional channel based speaker
layouts through digital signal processing including Dolby Atmos height
virtualization and surround virtualization.
0Speaker Virtualizer is not for use when both height speakers and surround
speakers are connected.
0Height Virtualization may be applied when surround speakers are connected.
0DTS:X (v p. 328)
This unit is equipped with the DTS:X decoder technology. DTS:X brings
the home theater experience to new heights with its immersive object
based audio technology which removes the bounds of channels. The
flexibility of objects allows for sound to be scaled large or small and
moved around the room with greater accuracy than ever before leading
to a richer immersive audio experience.
0DTS Virtual:X (v p. 329)
DTS Virtual:X technology features DTS’s proprietary virtual height and
virtual surround processing to deliver an immersive sound experience
from any type of input source (stereo to 7.1.4 channel) and speaker
configuration.
0DTS Virtual:X is not for use when Height speakers are connected.
0IMAX Enhanced (v p. 329)
This IMAX Enhanced product have met stringent performance
standards established by IMAX and DTS in order to create a consistent
and higher bar for sound performance. DTS has developed a special
method for reproducing an IMAX signature sound experience in the
consumer’s home. This method combines a unique conversion process
for IMAX theatrical audio mixes utilizing an enhanced DTS codec
technology. The IMAX theatrical audio format with point source
surround speakers closely matches the speaker configuration most
consumers have in their homes today. Coupled with DTS audio
technology, IMAX Enhanced audio products will ensure the best and
most accurate audio reproduction over 5.1 or more speaker channels.
Contents Connections Playback Settings Tips Appendix
10
Front panel Display Rear panel Remote Index

0Audyssey LFC™ (Low Frequency Containment) (v p. 192)
Audyssey LFC™ solves the problem of low frequency sounds
disturbing people in neighboring rooms or apartments. Audyssey LFC™
dynamically monitors the audio content and removes the low
frequencies that pass through walls, floors and ceilings. It then applies
psychoacoustic processing to restore the perception of low bass for
listeners in the room. The result is great sound that no longer disturbs
the neighbors.
0Discrete subwoofers and Audyssey Sub EQ HT™ (v p. 216)
The unit has two subwoofer output capability and can adjust the level
and delay for each subwoofer individually.
Audyssey Sub EQ HT™ makes the integration seamless by first
compensating for any level and delay differences between the two
subwoofers and then applying Audyssey MultEQ® XT32 to both
subwoofers together for improved deep bass response and detail.
0Denon’s unique high quality playback technology “Denon Link
HD” (v p. 333)
This unit is equipped with our exclusive “Denon Link HD” technology.
When connected to a Denon disc player that has Denon Link HD, the
sound localization becomes more precise, with increased detail and
definition. The system works by carrying the critical clock timing signals
via the dedicated Denon Link HD connection, minimizing the jitter
caused by conventional digital connections. This effect can be applied
to an audio source of any media from a Blu-ray Disc player.
This technology enables the playback of 2-channel source audio or
7.1/5.1 multi-channel source audio through a maximum 11.1-channel
speakers, achieving an even broader soundstage.
Contents Connections Playback Settings Tips Appendix
11
Front panel Display Rear panel Remote Index

0Auro-3D
This unit is equipped with an Auro-3D decoder.
With Auro-3D, Front Height (FHL + FHR), Surround Height (SHL + SHR), Center Height (CH/optional) and Top Surround (TS/optional) are added to a
conventional 5.1-channel system to achieve a natural and realistic sound field that is three-dimensional and fully immersive.
You will be able to fully enjoy Auro-3D playback if you properly place the speakers for Auro-3D.
2 Auro-3D playback
.
FHL FHR
SHL SHR
TS
CH
FL FR
SW
SL SR
C
2 Dolby Atmos playback
.
FHL FHR
SHL SHR
TS
FL FR
SW
SL SR
C
CH
0Auro-3D does not support a Dolby Atmos configuration using Top Front, Top Middle or Top Rear speakers.
But it is possible to support both an Auro-3D and Dolby Atmos by adding Front Height and Rear Height speakers* to a 5.1 configuration.
zFor an optimum Auro-3D experience Surround Height speakers are strongly recommended.
Contents Connections Playback Settings Tips Appendix
12
Front panel Display Rear panel Remote Index

High performance
0Masterful Home Theater Experience – 8K Ready
For 110 years, Denon has strived to deliver the most cutting-edge audio
and video technical achievements. To honor that legacy and spirit of
innovation, the AVC-A110 delivers an ultra-premium 8K home theater
experience.
With 8K/60Hz pass-through, 4K/120Hz pass-through for gaming, and
support for the latest HDMI specifications, you can build the best 4K
home theater today and relax in the comfort of knowing that your AV
receiver is 8K ready when you are. Enjoy the highest quality 3D audio
and video for even the most demanding entertainment needs.
0HDCP 2.3
This unit is compatible with HDCP 2.3 copyright protection standard.
0Digital video processor upscales SD (resolution) or HD (720p/
1080p) / 4K to 8K
.
8K Ultra HD
8K 8K
Up to
1080p/4K 60Hz
8K
up scaling
This unit is equipped with a 8K video upscaling function that allows SD
(Standard Definition) or HD (High Definition)/4K 60Hz video to be output
via HDMI at 8K (7680 × 4320 pixels) resolution. This function enables
the device to be connected to a TV using a single HDMI cable, and
produces high definition images for any video source.
0Equipped with HDMI ZONE2 output (v p. 167)
The ZONE2 multi-room output includes an HDMI output that lets you
enjoy a different A/V source in that room, with another program playing
in the main room.
Contents Connections Playback Settings Tips Appendix
13
Front panel Display Rear panel Remote Index

0HDMI connections enable connection to various digital AV
devices (8 inputs, 3 outputs)
.
83
OutIn
For connection to a broad range of digital sources, this unit features 8
HDMI inputs, including 1 on the front panel that lets you quickly and
conveniently connect a camcorder, game console or other HDMI-
equipped device. There are dual HDMI outputs for the main room, and a
third HDMI output for another room.
0eARC (Enhanced Audio Return Channel) function compatibility
The eARC function is compatible with conventional ARC function-
compatible audio formats in addition to multichannel linear PCM, Dolby
TrueHD, Dolby Atmos, DTS-HD Master Audio, DTS:X and other audio
formats a conventional ARC function cannot transmit.
Additionally, connecting to an eARC function-compatible television
enables enjoyment of higher-quality surround playback of the audio
content played from your television.
0The device is equipped with a AirPlay® function in addition to
network functions such as Internet radio etc. (v p. 127)
.
You can enjoy a wide variety of content, including listening to Internet
Radio, playing audio files stored on your PC.
This unit also supports Apple AirPlay which lets you stream your music
library from an iPhone®, iPad®, iPod touch® or iTunes®.
0Supports AirPlay 2® wireless audio
Sync multiple AirPlay 2 compatible devices/speakers for simultaneous
playback.
This unit supports AirPlay 2 and requires iOS 11.4 or later.
Contents Connections Playback Settings Tips Appendix
14
Front panel Display Rear panel Remote Index

0Playback of DSD and FLAC files via USB and networks
This unit supports the playback of high resolution audio formats such as
DSD (5.6 MHz) and FLAC 192 kHz files. It provides high quality
playback of high resolution files.
0Wireless connection with Bluetooth devices can be carried out
easily (v p. 107)
.
You can enjoy music simply by connecting wirelessly with your
smartphone, tablet, PC, etc.
0Multi-Room audio (v p. 138)
.
【MAIN ZONE】【ZONE2】/【ZONE3】
You can select and play back the respective inputs in MAIN ZONE,
ZONE2 and ZONE3.
In addition, when the All Zone Stereo function is used, the music being
played back in MAIN ZONE can be enjoyed in all the zones at the same
time. This is useful when you want to let the background music
propagate throughout the whole house.
0Energy-saving design
This unit is equipped with an ECO Mode function that allows you to
enjoy music and movies while reducing the power consumption during
use, and also an auto-standby function that automatically turns off the
power supply when the unit is not in use. This helps reduce
unnecessary power use.
Contents Connections Playback Settings Tips Appendix
15
Front panel Display Rear panel Remote Index

0Compatible with the “Denon 2016 AVR Remote” Appz for
performing basic operations of the unit with an iPad, iPhone or
Android™ devices (Google, Amazon Kindle Fire)
.
Along with many new features, the graphics and user interface have
been completely overhauled. The new app gives you full control of this
unit as well as access to its setup menu for detailed adjustments from
your phones or tablets. “Denon 2016 AVR Remote” App also gives you
quick access to the receiver's status display, option menus, Denon Blu-
ray Disc player control, and online owner's manual for your
convenience.
zDownload the appropriate “Denon 2016 AVR Remote” App for your iOS or
Android devices. This unit needs to be connected to the same LAN or Wi-Fi
(wireless LAN) network that the iPad, iPhone or Android™ is connected to.
0HEOS provides streaming music from your favorite online music
sources
.
HEOS wireless multi-room sound system that enables you to enjoy your
favorite music anywhere and everywhere around your home. By utilizing
your existing home network and the HEOS App (available for iOS,
Android and Amazon devices), you can explore, browse, and play
music from your own music library or from many online streaming music
services.
When multiple products with HEOS Built-in are connected to the same
network, they can be grouped to play the same music on all products
simultaneously, or different music can be played on each one.
Contents Connections Playback Settings Tips Appendix
16
Front panel Display Rear panel Remote Index

Easy operation
0“Setup Assistant” provides easy-to-follow setup instructions
First select the language when prompted. Then simply follow the
instructions displayed on the TV screen to set up the speakers, network,
etc.
0Easy to use Graphical User Interface
This unit is equipped with a Graphical User Interface for improved
operability.
Contents Connections Playback Settings Tips Appendix
17
Front panel Display Rear panel Remote Index

Part names and functions
Front panel
.
u
rwqe yt
For details, see the next page.
Contents Connections Playback Settings Tips Appendix
18
Front panel Display Rear panel Remote Index

.
u
wqret y
APower operation button (X)
Used to turn the power of the MAIN ZONE (room where this unit is
located) on/off (standby). (v p. 101)
BPower indicator
This is lit as follows according to the power status:
0Green: Power on
0Off: Normal standby
0Red:
0When “HDMI Pass Through” is set to “On” (v p. 197)
0When “HDMI Control” is set to “On” (v p. 199)
0When “Network Control” is set to “Always On” (v p. 254)
CSOURCE SELECT knob
This selects the input source. (v p. 101)
DRemote control sensor
This receives signals from the remote control unit. (v p. 9)
EDisplay
This displays various pieces of information. (v p. 22)
FMASTER VOLUME knob
This adjusts the volume level. (v p. 102)
GDoor
When you are using buttons and/or connectors behind the door, press
the bottom of the door to open it. Be careful not to catch your fingers
when closing the door.
.
Contents Connections Playback Settings Tips Appendix
19
Front panel Display Rear panel Remote Index

With the door open
.
io Q0qw r t y ue
AZONE2 ON/OFF button
This turns the power of ZONE2 (another room) on/off. (v p. 172)
BZONE2 SOURCE button
This selects the input source for ZONE2. (v p. 172)
CZONE3 ON/OFF button
This turns the power of ZONE3 (another room) on/off. (v p. 172)
DZONE3 SOURCE button
This selects the input source for ZONE3. (v p. 172)
ESTATUS button
Each press of this switches the status information that is shown on the
display.
FInformation button (INFO)
This displays the status information on the TV screen. (v p. 269)
GCursor buttons (uio p)
These select items.
HOPTION button
This displays the option menu on the TV screen.
IDIMMER button
Each press of this switches the brightness of the display. (v p. 264)
JQUICK SELECT buttons
With a single press of any of these buttons, you can call up various
settings you’ve registered to each button such as the input source,
volume level and sound mode settings. (v p. 159)
Contents Connections Playback Settings Tips Appendix
20
Front panel Display Rear panel Remote Index
