Denon AVR-5805 Manual

29.Mar.06
1/25
DENON AVR/AVC control protocol
Ver. 4.37a
Application model :AVR-5805/AVC-A1XV
Application terminal : RS-232C/ Ethernet
Connector specification
1. RS-232C
Connector type : DB-9pin female type, slave straight connection (DCE type)
( 1pin : GND , 2pin : TxD , 3pin : RxD , 5pin : Common(GND) , 4,6,7,8,9pin : NC )
Communication format :
Synchronous system : Tone step synchronization
Communication system : A half duplex
Communication speed : 9600bps
Character length : 8 bits
Parity control : None
Start bit : 1 bit
Stop bit : 1 bit
Communication procedure : Non procedural
Communication data length : 135 bytes (maximum)


29.Mar.06
2/25
2. Ethernet
Connector type ：RJ-45(10BASE-T/100BASE-TX)
Communication format ：
Communication system : A half duplex
Communication speed : 10Mbps/100Mbps
Communication port : TCP port 23 (telnet)
Communication data length : 135bytes (maximum)
PC AVR/AVC
Ethernet
Cross cable
PC AVR/AVC
HUB
Ethernet
Straight
cable
Ethernet
Straight
cable
Example ①
Example ②

29.Mar.06
3/25
NETWORK SETUP of AVR-5805/AVC-A1XV
>Procedure of Network Setup mode.
(1)Push the POWER switch during STANDARD button and 9CH STEREO button press simultaneously.
(2)Press SYSTEM SETUP button, then System Setup Menu appears on FL-display(and OSD)
(3)Select Option Setup and select Network Setup.
(4)Set parameters described below.
<DHCP> "ON"---Use this setting when DHCP server is on the local network.
"OFF"---Use this setting when DHCP server is not on the local network.
<IP Address> When <DHCP> sets "OFF”, please set IP address.
When <DHCP> sets "ON”, you can confirm the IP address that is set by server.
<Subnet Mask> When <DHCP> sets "OFF”, please set Subnet Mask.
When <DHCP> sets "ON”, you can confirm the Subnet Mask that is set by server.
<Gateway> Set the address of Gateway when Gateway is on the local network.
Do not set this parameter when Gateway is not on the local network.
<Primary DNS> Do not set this parameter.
<Second DNS> Do not set this parameter.
<Proxy> Set this parameter "OFF".
<Network Option:Standby Mode Power Saving>
“OFF”---Use this setting when using the AVR-5805/AVC-A1XV connected in a network.
“ON”--- Use this setting when not using the AVR-5805/AVC-A1XV connected in a network.
This setting is reducing the power consumption in the standby mode.

29.Mar.06
4/25
Protocol specification
The following three data forms is defined.
COMMAND : The message sent to a system(AVR/AVC) from a controller(Touch Panel etc.)
A command to a system is given from a controller.
EVENT : The message sent to a controller(Touch Panel etc.) from a system(AVR/AVC)
The result is sent, when a system is operated directly and a state changes.
*The form of EVENT presupposes that it is the same as that of COMMAND.
**Refer to the following table for the contents of COMMAND and EVENT.
RESPONSE : The message sent to a controller(Touch Panel etc.) from a system(AVR/AVC)
if the ‘request command’ (COMMAND+?+CR(0x0D)) has came from a controller.
The RESPONSE should be sent within 200ms of receiving the COMMAND.
*The form of RESPONSE presupposes that it is the same as that of EVENT.
Basic specification : The command by ASCII CODE, parameter expression
*ASCII CODE which can be used is from 0x20 to 0x7F : the alphabet and the number of 0-9 , and space (0x20) , Some signs ,
AND carriage return(0x0D)--- It is used only as a pause sign.
Command structure : COMMAND + PARAMETER + CR(0x0D)
COMMAND : ASCII CODE of 2 characters
ex. SI : Select Input source
MS : surround Mode Setting
MV : Master Volume setting
PW : system PoWer setting
PARAMETER : ASCII CODE ( up to 25 characters)
ex. DVD : function name
CDR/TAPE : function name
THX SURROUND EX : surround mode name
SUPER STADIUM : surround mode name
*Special Parameter--- ? : for request command

29.Mar.06
5/25
The example of a command * <CR> is the meaning of 0x0D.
SIDVD<CR> : Select Input source DVD
MSTHX SURROUND EX<CR> : surround Mode Set to THX SURROUND EX
MVUP<CR> : Master Volume UP
PWON<CR> : system PoWer ON
PWSTANDBY<CR> : system PoWer STANDBY
SI?<CR> : Request command for now playing input source>> Return RESPONSE ‘SI***<CR>’

29.Mar.06
6/25
Others
A) COMMAND is receivable also during transmission of EVENT.
B) Since CHANNEL VOLUME changes simultaneously when the SURROUND MODE changes, the value of the channel volume of all channels
returns as EVENT.
C) CHANNEL VOLUME returns the data of ALL channels by the present SURROUND MODE also including an intact channel. In this case,
the data of an intact channel is set to "50".
D) Since SURROUND MODE changes simultaneously when the INPUT source changes, the SURROUND MODE (andalso the value of the channel
volume of all channels , It described in B) ) returns as EVENT.
E) When SURROUND MODE is the same in between INPUT source change before and after, EVENT of SURROUND MODE and CHANNEL VOLUME
does NOT return.
F) Although EVENT of SURROUND MODE returns when the present SURROUND MODE is set up again, CHANNEL VOLUME does NOT return.
G) When SURROUND MODE is changed, before returning SURROUND MODE after change as EVENT, the present SURROUND MODE is returned.
H) The RESPONSE should be sent as opposed to the request command by all the commands with which an EVENT exists , not need to
the another request commands(ex. SV command).
I) The PARAMETER (with COMMAND and RESPONSE, EVENT) of minimum level of MASTER VOLUME defines “99”.
J) If the MASTER VOLUME & ZONE2 VOLUME（ZONE2 THEATER:5.1ch or 7.1ch system）& CHANNEL VOLUME set with 0.5dB step, the PARAMETER
(with COMMAND and RESPONSE, EVENT) defines three ASCII characters as bellows.
ex. MASTER VOLUME = +1.0dB : MV81<CR>
+0.5dB : MV805<CR>
0dB : MV80<CR>
-0.5dB : MV795<CR>
-1.0dB : MV79<CR>
| |
-79.5dB : MV005<CR>
-80.0dB : MV00<CR>
--- : MV99<CR>
* At the **.0dB step, only uses two ASCII characters as PARAMETER, same as usual.

29.Mar.06
7/25
COMMAND and PARAMETER list
COMMAND PARAMETER function example
PW ON POWER ON/STANDBY change PWON<CR>
STANDBY PWSTANDBY<CR>
MV UP MASTER VOLUME UP/DOWN , direct change to ***dB MVUP<CR>
DOWN MVDOWN<CR>
** **:00 to 99 by ASCII , 80=0dB, 99=---(MIN) MV80<CR>
CV FL UP CHANNEL VOLUME UP/DOWN , direct change to ***dB CVFL UP<CR>
FL DOWN ---FRONT Lch CVFL DOWN<CR>
FL ** **:38 to 62 by ASCII , 50=0dB CVFL 50<CR>
FR UP CVFR UP<CR>
FR DOWN ---FRONT Rch CVFR DOWN<CR>
FR ** **:38 to 62 by ASCII , 50=0dB CVFR 50<CR>
C UP CVC UP<CR>
C DOWN ---CENTER ch CVC DOWN<CR>
C ** **:38 to 62 by ASCII , 50=0dB CVC 50<CR>
SW1 UP ---SWLeft or SWFront or SWMain ch (SWch 2 or 3SP) CVSW1 UP<CR>
SW1 DOWN ---SUBWOOFER (When SWch is 1SP) CVSW1 DOWN<CR>
SW1 ** **:00,38 to 62 by ASCII , 50=0dB, 00=OFF CVSW1 50<CR>
SW2 UP CVSW2 UP<CR>
SW2 DOWN ---SWRight or SWBack ch (SWch 2 or 3SP) CVSW2 DOWN<CR>
SW2 ** **:00,38 to 62 by ASCII , 50=0dB, 00=OFF CVSW2 50<CR>
LFE UP CVLFE UP<CR>
LFE DOWN ---LFEch (SWch 2 or 3SP) CVLFE DOWN<CR>
LFE ** **:00,38 to 62 by ASCII , 50=0dB, 00=OFF CVLFE 50<CR>
SLA UP CVSLA UP<CR>
SLA DOWN ---SURROUND L(A)ch CVSLA DOWN<CR>
SLA ** **:38 to 62 by ASCII , 50=0dB CVSLA 50<CR>
SRA UP CVSRA UP<CR>
SRA DOWN ---SURROUND R(A)ch CVSRA DOWN<CR>
SRA ** **:38 to 62by ASCII , 50=0dB CVSRA 50<CR>
MV , CV COMMAND : "*" parameter uses two or three ASCII characters. (see page4 J) section)
The BOLD COMMANDS are new.

29.Mar.06
8/25
COMMAND PARAMETER function example
CV SLB UP CVSLB UP<CR>
SLB DOWN ---SURROUND L(B)ch CVSLB DOWN<CR>
SLB ** **:38 to 62 by ASCII , 50=0dB CVSLB 50<CR>
SRB UP CVSRB UP<CR>
SRB DOWN ---SURROUND R(B)ch CVSRB DOWN<CR>
SRB ** **:38 to 62 by ASCII , 50=0dB CVSRB 50<CR>
SBL UP CVSBL UP<CR>
SBL DOWN ---SURROUND BACK Lch (SBch 2SP) CVSBL DOWN<CR>
SBL ** **:38 to 62 by ASCII , 50=0dB CVSBL 50<CR>
SBR UP CVSBR UP<CR>
SBR DOWN ---SURROUND BACK Rch (SBch 2SP) CVSBR DOWN<CR>
SBR ** **:38 to 62 by ASCII , 50=0dB CVSBR 50<CR>
SB UP CVSBL UP<CR>
SB DOWN ---SURROUND BACKch (SBch 1SP) CVSBL DOWN<CR>
SB ** **:38 to 62 by ASCII , 50=0dB CVSBL 50<CR>
EXLA UP CVEXLA UP<CR>
EXLA DOWN ---EX L(A) ch CVEXLA DOWN<CR>
EXLA ** **:38 to 62 by ASCII , 50=0dB CVEXRA 50<CR>
EXRA UP CVEXRA UP<CR>
EXRA DOWN ---EX R(A) ch CVEXRA DOWN<CR>
EXRA ** **:38 to 62 by ASCII , 50=0dB CVEXRA 50<CR>
EXLB UP CVEXLB UP<CR>
EXLB DOWN ---EX L(B) ch CVEXLB DOWN<CR>
EXLB ** **:38 to 62 by ASCII , 50=0dB CVEXRB 50<CR>
EXRB UP CVEXRB UP<CR>
EXRB DOWN ---EX R(B) ch CVEXRB DOWN<CR>
EXRB ** **:38 to 62 by ASCII , 50=0dB CVEXRB 50<CR>
CV COMMAND : "*" parameter uses two or three ASCII characters. (see page4 J) section)
The BOLD COMMANDS are new.

29.Mar.06
9/25
CV COMMAND : "*" parameter uses two or three ASCII characters. (see page4 J) section)
The BOLD COMMANDS are new.
COMMAND PARAMETER function example
CV EXLC UP CVEXLC UP<CR>
EXLC DOWN ---EX L(C) ch CVEXLC DOWN<CR>
EXLC ** **:38 to 62 by ASCII , 50=0dB CVEXLC 50<CR>
EXRC UP CVEXRC UP<CR>
EXRC DOWN ---EX R(C) ch CVEXRC DOWN<CR>
EXRC ** **:38 to 62 by ASCII , 50=0dB CVEXRC 50<CR>
MU ON OUTPUT MUTE ON/OFF change MUON<CR>
OFF MUOFF<CR>
SI PHONO Select INPUT source SIPHONO<CR>
CD SICD<CR>
TUNER SITUNER<CR>
DVD SIDVD<CR>
VDP SIVDP<CR>
TV SITV<CR>
DBS SIDBS<CR>
VCR-1 SIVCR-1<CR>
VCR-2 SIVCR-2<CR>
VCR-3 SIVCR-3<CR>
VCR-4 SIVCR-4<CR>
V.AUX SIV.AUX<CR>
CDR/TAPE SICDR/TAPE<CR>
DTU SIDTU<CR>
ZM ON MAIN-ZONE ON/OFF change ZMON<CR>
OFF ZMOFF<CR>
SV DVD VIDEO SELECT mode set , and select source SVDVD<CR>
VDP SVVDP<CR>
TV SVTV<CR>
DBS SVDBS<CR>
VCR-1 SVVCR-1<CR>
VCR-2 SVVCR-2<CR>
VCR-3 SVVCR-3<CR>
VCR-4 SVVCR-4<CR>
V.AUX SVV.AUX<CR>
SOURCE VIDEO SELECT mode cancel SVSOURCE<CR>

29.Mar.06
10/25
COMMAND PARAMETER function example
SD AUTO set DIGITAL INPUT AUTO mode SDAUTO<CR>
PCM set DIGITAL INPUT force PCM mode SDPCM<CR>
DTS set DIGITAL INPUT force DTS mode SDDTS<CR>
RF ---Invalid at AVR-5805 SDRF<CR>
ANALOG set force ANALOG INPUT mode SDANALOG<CR>
EXT.IN-1 set EXT.IN-1 or EXT.IN mode SDEXT.IN-1<CR>
EXT.IN-2 set EXT.IN-2 mode SDEXT.IN-2<CR>
MS DIRECT SURROUND mode set MSDIRECT<CR>
PURE DIRECT MSPURE DIRECT<CR>
STEREO MSSTEREO<CR>
MULTI CH IN ---This is received as "SATNDARD". MSMULTI CH IN<CR>
MULTI CH DIRECT MSMULTI CH DIRECT<CR>
MULTI CH PURE D MSMULTI CH PURE D<CR>
DOLBY PRO LOGIC All are received as "STANDARD" , MSDOLBY PRO LOGIC<CR>
DOLBY PL2 the surround mode which changed return as EVENT. MSDOLBY PL2<CR>
DOLBY PL2x MSDOLBY PL2X<CR>
DOLBY DIGITAL MSDOLBY DIGITAL<CR>
DOLBY D EX MSDOLBY D EX<CR>
DTS NEO:6 MSDTS NEO:6<CR>
DTS SURROUND MSDTS SURROUND<CR>
DTS ES DSCRT6.1 MSDTS ES DSCRT6.1<CR>
DTS ES MTRX6.1 MSDTS ES MTRX6.1<CR>
DOLBYH/P MSDOLBYH/P<CR>
DTS+DOLBYH/P MSDTS+DOLBYH/P<CR>
HOME THX CINEMA All are received as "THX SURROUND" , MSHOME THX CINEMA<CR>
THX5.1 the surround mode which changed return as EVENT.MSTHX5.1<CR>
THX U2 CINEMA MSTHX U2 CINEMA<CR>
THX MUSIC MODE MSTHX MUSIC MODE<CR>
THX GAMES MODE MSTHX GAMES MODE<CR>
THX6.1 ---Operate as Matrix6.1 or Discrete6.1 MSTHX6.1<CR>
THX SURROUND EX MSTHX SURROUND EX<CR>
WIDE SCREEN MSWIDE SCREEN<CR>
The BOLD COMMANDS are new.

29.Mar.06
11/25
COMMAND PARAMETER function example
MS 5CH STEREO Both are received as "5CH/7CH/9CH STEREO" , MS5CH STEREO<CR>
7CH STEREO the surround mode which changed return as EVENT. MS7CH STEREO<CR>
9CH STEREO MS9CH STEREO<CR>
SUPER STADIUM MSSUPER STADIUM<CR>
ROCK ARENA MSROCK ARENA<CR>
JAZZ CLUB MSJAZZ CLUB<CR>
CLASSIC CONCERT MSCLASSIC CONCERT<CR>
MONO MOVIE MSMONO MOVIE<CR>
MATRIX MSMATRIX<CR>
VIDEO GAME MSVIDEO GAME<CR>
MPEG2 AAC ---Invalid at AVR model MSMPEG2 AAC<CR>
AAC+DOLBY EX ---Invalid at AVR model MSAAC+DOLBY EX<CR>
USER1 MSUSER1<CR>
USER2 MSUSER2<CR>
USER3 MSUSER3<CR>
PS TONE DEFEAT ON PARAMETER setting PSTONE DEFEAT ON<CR>
TONE DEFEAT OFF TONE DEFEAT ON/OFF PSTONE DEFEAT OFF<CR>
SB:MTRX ON SURROUND BACK SP MODE set PSSB:MTRX ON<CR>
SB:NON MTRX ---MTRX ON = SURR.EX ON = DSCRT ON PSSB:NON MTRX<CR>
SB:PL2xCINEMA (@THX) (@ES DSCRT) PSSB:PL2X CINEMA<CR>
SB:PL2xMUSIC PSSB:PL2X MUSIC<CR>
SB:OFF PSSB:OFF<CR>
CINEMA EQ.ON CINEMA EQ. ON/OFF PSCINEMA EQ.ON<CR>
CINEMA EQ.OFF PSCINEMA EQ.OFF<CR>
MODE : MUSIC CINEMA / MUSIC / GAME / PL mode change PSMODE:MUSIC<CR>
MODE : CINEMA (This parameter can change DOLBY PL2,PL2x,NEO:6 mode.) PSMODE:CINEMA<CR>
MODE : GAME ---SB=ON：PL2x mode / SB=OFF：PL2 mode PSMODE:GAME<CR>
MODE : PRO LOGIC --- GAME can change DOLBY PL2 & PL2x mode PSMODE:PRO LOGIC<CR>
--- PL can change ONLY DOLBY PL2 mode
The BOLD COMMANDS are new.

29.Mar.06
12/25
COMMAND PARAMETER function example
PS ROOM EQ:AUDYSSEY ROOM EQ mode direct change PSROOM EQ:AUDYSSEY<CR>
ROOM EQ:FRONT PSROOM EQ:FRONT<CR>
ROOM EQ:FLAT PSROOM EQ:FLAT<CR>
ROOM EQ:MANUAL PSROOM EQ:MANUAL<CR>
ROOM EQ:OFF PSROOM EQ:OFF<CR>
DELAY UP AUDIO DELAY UP/DOWN , direct change to ***dB PSDELAY UP<CR>
DELAY DOWN ***:000 to 999 by ASCII , 000=0ms, 200=200ms PSDELAY DOWN<CR>
DELAY *** ---AVR5805 can be operated from 0 to 200 PSDELAY 200<CR>
TF UP TUNER Frequency UP/DOWN , direct change TFUP<CR> *
DOWN TFDOWN<CR> *
****** (6 digits) --- ****.** kHz at AM band (>050000 is AM.)
****.** MHz at FM band (<050000 is FM.) TF105000<CR> (1050.00kHz at AM)
TP UP TUNER PRESET CH UP/DOWN , direct change to No.** TPUP<CR>
DOWN TPDOWN<CR>
**(PRESET No.) TPA1<CR>
(PRESET No.”A1”)
TM TUNER BAND , MODE Select
AM ---Band set to AM TMAM<CR>
FM ---Band set to FM TMFM<CR>
AUTO ---Tuning mode set to AUTO mode TMAUTO<CR> *
MANUAL ---Tuning mode set to MANUAL mode TMMANUAL<CR> *
TF, TP, TM COMMAND : '*' parameters can NOT operate when INPUT source isn’t TUNER.
The BOLD COMMANDS are new.

29.Mar.06
13/25
COMMAND PARAMETER function example
Z2CV Z2FL UP MULTI ZONE-2 CHANNEL VOLUME UP/DOWN ,
direct change to **dB Z2CVFL UP<CR>
FL DOWN ---FRONT Lch Z2CVFL DOWN<CR>
FL ** **:38 to 62 by ASCII , 50=0dB Z2CVFL 50<CR>
FR UP Z2CVFR UP<CR>
FR DOWN ---FRONT Rch Z2CVFR DOWN<CR>
FR ** **:38 to 62 by ASCII , 50=0dB Z2CVFR 50<CR>
C UP Z2CVC UP<CR>
C DOWN ---CENTERch Z2CVC DOWN<CR>
C ** **:38 to 62 by ASCII , 50=0dB Z2CVC 50<CR>
SW UP ---SUBWOOFERch Z2CVSW UP<CR>
SW DOWN **:00,38 to 62 by ASCII , 50=0dB Z2CVSW DOWN<CR>
SW ** 00=OFF Z2CVSW 50<CR>
SL UP Z2CVSL UP<CR>
SL DOWN ---SURROUND Lch Z2CVSL DOWN<CR>
SL ** **:38 to 62 by ASCII , 50=0dB Z2CVSL 50<CR>
SR UP Z2CVSR UP<CR>
SR DOWN ---SURROUND Rch Z2CVSR DOWN<CR>
SR ** **:38 to 62 by ASCII , 50=0dB Z2CVSR 50<CR>
SBL UP Z2CVSBL UP<CR>
SBL DOWN ---SURROUND BACK Lch (SBch 2SP) Z2CVSBL DOWN<CR>
SBL ** **:38 to 62 by ASCII , 50=0dB Z2CVSBL 50<CR>
SBR UP ---SURROUND BACK Rch (SBch 2SP) Z2CVSBR UP<CR>
SBR DOWN Z2CVSBR DOWN<CR>
SBR ** **:38 to 62 by ASCII , 50=0dB Z2CVSBR 50<CR>
SB UP ---SURROUND BACKch (SBch 1SP) Z2CVSB UP<CR>
SB DOWN Z2CVSB DOWN<CR>
SB ** **:38 to 62 by ASCII , 50=0dB Z2CVSB 50<CR>
Z2CV COMMAND : "*" parameter uses two or three ASCII characters. (see page4 J) section)
The BOLD COMMANDS are new.

29.Mar.06
14/25
COMMAND PARAMETER function example
Z2 PHONO MULTI ZONE-2 mode set , and select source Z2PHONO<CR>
| ---The name of PARAMETER is |
CDR/TAPE the same as that of the time of SI COMMAND. Z2CDR/TAPE<CR>
SOURCE MULTI ZONE-2 mode cancel Z2SOURCE<CR>
UP MULTI ZONE-2 VOLUME UP/DOWN , direct change to ***dB Z2UP<CR>
DOWN Z2DOWN<CR>
** **:00 to 99 by ASCII , 80=0dB, 99=---(MIN) Z280<CR>
ON MULTI ZONE-2 ON/OFF change Z2ON<CR>
OFF Z2OFF<CR>
Z2MU ON ZONE2 OUTPUT MUTE ON/OFF change Z2MUON<CR>
OFF Z2MUOFF<CR>
Z2SV DVD ZONE2 VIDEO SELECT mode set , and select source Z2SVDVD<CR>
VDP Z2SVVDP<CR>
TV Z2SVTV<CR>
DBS Z2SVDBS<CR>
VCR-1
Z2SVVCR-1<CR>
VCR-2
Z2SVVCR-2<CR>
VCR-3
Z2SVVCR-3<CR>
VCR-4
Z2SVVCR-4<CR>
V.AUX
Z2SVV.AUX<CR>
SOURCE
ZONE2 VIDEO SELECT mode cancel Z2SVSOURCE<CR>
Z2SD AUTO MULTI ZONE-2 set DIGITAL INPUT AUTO mode Z2SDAUTO<CR>
ANALOG
MULTI ZONE-2 set force ANALOG INPUT mode Z2SDANALOG<CR>
Z2 COMMAND : "*" parameter uses two or three ASCII characters. (see page4 J) section)
The BOLD COMMANDS are new.

29.Mar.06
15/25
COMMAND PARAMETER function example
Z2MS STEREO SURROUND mode set Z2MSSTEREO<CR>
DOLBY PRO LOGIC
All are received as "STANDARD" , Z2MSDOLBY PROLOGIC<CR>
DOLBY PL2 the surround mode which changed return as EVENT. Z2MSDOLBY PL2<CR>
DOLBY PL2x
Z2MSDOLBY PL2X<CR>
DOLBY DIGITAL
Z2MSDOLBY DIGITAL<CR>
DOLBY D EX Z2MSDOLBY D EX<CR>
DTS NEO:6
Z2MSDTS NEO:6<CR>
DTS SURROUND
Z2MSDTS SURROUND<CR>
DTS ES DSCRT6.1 Z2MSDTS ES DSCRT6.1<CR>
DTS ES MTRX6.1 Z2MSDTS ES MTRX6.1<CR>
WIDE SCREEN
Z2MSWIDE SCREEN<CR>
5CH STEREO
Both are received as "5CH/7CH STEREO" , Z2MS5CH STEREO<CR>
7CH STEREO the surround mode which changed return as EVENT. Z2MS7CH STEREO<CR>
SUPER STADIUM
Z2MSSUPER STADIUM<CR>
ROCK ARENA
Z2MSROCK ARENA<CR>
JAZZ CLUB
Z2MSJAZZ CLUB<CR>
CLASSIC CONCERT
Z2MSCLASSIC CONCERT<CR>
MONO MOVIE
Z2MSMONO MOVIE<CR>
MATRIX
Z2MSMATRIX<CR>
VIDEO GAME
Z2MSVIDEO GAME<CR>
VIRTUAL
Z2MSVIRTUAL<CR>
MPEG2 AAC
---Invalid at AVR model Z2MSMPEG2 AAC<CR>
AAC+DOLBY EX
---Invalid at AVR model Z2MSAAC+DOLBY EX<CR>
USER1 Z2MSUSER1<CR>
USER2 Z2MSUSER2<CR>
USER3 Z2MSUSER3<CR>
The BOLD COMMANDS are new.

29.Mar.06
16/25
COMMAND PARAMETER function example
Z2PS TONE DEFEAT ON PARAMETER setting Z2PSTONE DEFEAT ON<CR>
TONE DEFEAT OFF TONE DEFEAT ON/OFF Z2PSTONE DEFEAT OFF<CR>
SB:MTRX ON SURROUND BACK SP MODE set Z2PSSB:MTRX ON<CR>
SB:NON MTRX ---MTRX ON = SURR.EX ON = DSCRT ON Z2PSSB:NON MTRX<CR>
SB:PL2xCINEMA (@THX) (@ES DSCRT) Z2PSSB:PL2X CINEMA<CR>
SB:PL2xMUSIC Z2PSSB:PL2X MUSIC<CR>
SB:OFF Z2PSSB:OFF<CR>
CINEMA EQ.ON CINEMA EQ. ON/OFF Z2PSCINEMA EQ.ON<CR>
CINEMA EQ.OFF Z2PSCINEMA EQ.OFF<CR>
MODE : MUSIC CINEMA / MUSIC / GAME / PL mode change Z2PSMODE:MUSIC<CR>
MODE : CINEMA (This parameter can change DOLBY PL2,PL2x,NEO:6 mode.) Z2PSMODE:CINEMA<CR>
MODE : GAME ---SB=ON：PL2x mode / SB=OFF：PL2 mode Z2PSMODE:GAME<CR>
MODE : PRO LOGIC --- GAME can change DOLBY PL2 & PL2x mode Z2PSMODE:PRO LOGIC<CR>
--- PL can change ONLY DOLBY PL2 mode
DELAY UP AUDIO DELAY UP/DOWN , direct change to ***dB Z2PSDELAY UP<CR>
DELAY DOWN ***:000 to 999 by ASCII , 000=0ms, 200=200ms Z2PSDELAY DOWN<CR>
DELAY *** ---AVR5805 can be operated from 0 to 200 Z2PSDELAY 200<CR>
The BOLD COMMANDS are new.

29.Mar.06
17/25
COMMAND PARAMETER function example
Z3 PHONO MULTI ZONE-3 mode set , and select source Z3PHONO<CR>
| ---The name of PARAMETER is |
CDR/TAPE the same as that of the time of SI COMMAND. Z3CDR/TAPE<CR>
SOURCE
MULTI ZONE-3 mode cancel Z3SOURCE<CR>
UP MULTI ZONE-3 VOLUME UP/DOWN , direct change to ***dB Z3UP<CR>
DOWN
Z3DOWN<CR>
** **:00 to 99 by ASCII , 80=0dB, 99=---(MIN) Z380<CR>
ON MULTI ZONE-3 ON/OFF change Z3ON<CR>
OFF Z3OFF<CR>
Z3MU ON ZONE3 OUTPUT MUTE ON/OFF change Z2MUON<CR>
OFF Z2MUOFF<CR>
Z4 PHONO MULTI ZONE-4 mode set , and select source Z4PHONO<CR>
| ---The name of PARAMETER is |
CDR/TAPE the same as that of the time of SI COMMAND. Z4CDR/TAPE<CR>
SOURCE
MULTI ZONE-4 mode cancel Z4SOURCE<CR>
UP MULTI ZONE-4 VOLUME UP/DOWN , direct change to ***dB Z4UP<CR>
DOWN
Z4DOWN<CR>
** **:00 to 99 by ASCII , 80=0dB, 99=---(MIN) Z480<CR>
ON MULTI ZONE-4 ON/OFF change Z4ON<CR>
OFF Z4OFF<CR>
Z4MU ON ZONE4 OUTPUT MUTE ON/OFF change Z2MUON<CR>
OFF Z2MUOFF<CR>
SR PHONO REC SELECT mode set , and select source SRPHONO<CR>
| ---The name of PARAMETER is |
CDR/TAPE the same as that of the time of SI COMMAND. SRCDR/TAPE<CR>
SOURCE REC SELECT mode cancel SRSOURCE<CR>
Z3,Z4 COMMAND : "*" parameter uses two or three ASCII characters. (see page4 J) section)
The BOLD COMMANDS are new.

29.Mar.06
18/25
EVENT(or RESPONSE) and PARAMETER list
EVENT PARAMETER function example *RES.
PW ON POWER ON/STANDBY change PWON<CR>
STANDBY PWSTANDBY<CR>
MV ** MASTER VOLUME change , **:00 to 98 by ASCII MV80<CR>
98 = +18dB(MAX)
80 = 0dB
10 = -70dB
00 = -80dB
99 = ---(MIN)
CV FL ** CHANNEL VOLUME change , **:00 to 62 by ASCII CVFL 50<CR>
FR ** 62 = +12dB(MAX) CVFR 50<CR>
C ** 50 = 0dB CVC 50<CR>
SW1 ** 38 = -12dB(MIN) CVSW1 50<CR>
SW2 ** 00 = OFF (define ONLY SWch) CVSW2 50<CR>
LFE ** CVLFE 50<CR>
SLA ** CVSLA 50<CR>
SRA ** CVSRA 50<CR>
SLB ** CVSLB 50<CR>
SRB ** CVSRB 50<CR>
SBL ** (at SBch 2SP) CVSBL 50<CR>
SBR ** (at SBch 2SP) CVSBR 50<CR>
SB ** (at SBch 1SP) CVSB 50<CR>
EXLA ** CVEXLA 50<CR>
EXRA ** CVEXRA 50<CR>
EXLB ** CVEXLB 50<CR>
EXRB ** CVEXRB 50<CR>
EXLC ** CVEXLC 50<CR>
EXRC ** CVEXRC 50<CR>
*RES. : NOT returns '*' parameters as RESPONSE.
MV , CV COMMAND : "*" parameter uses two or three ASCII characters. (see page4 J) section)
The BOLD COMMANDS are new.

29.Mar.06
19/25
EVENT PARAMETER function example *RES.
MU ON OUTPUT MUTE ON/OFF change MUON<CR>
OFF MUOFF<CR>
SI PHONO INPUT source change SIPHONO<CR>
CD SICD<CR>
TUNER SITUNER<CR>
DVD SIDVD<CR>
VDP SIVDP<CR>
TV SITV<CR>
DBS SIDBS<CR>
VCR-1 SIVCR-1<CR>
VCR-2 SIVCR-2<CR>
VCR-3 SIVCR-3<CR>
VCR-4 SIVCR-4<CR>
V.AUX SIV.AUX<CR>
CDR/TAPE SICDR/TAPE<CR>
DTU SIDTU<CR>
SV DVD VIDEO INPUT source change SVDVD<CR>
VDP SVVDP<CR>
TV SVTV<CR>
DBS SVDBS<CR>
VCR-1 SVVCR-1<CR>
VCR-2 SVVCR-2<CR>
VCR-3 SVVCR-3<CR>
VCR-4 SVVCR-4<CR>
V.AUX SVV.AUX<CR>
SOURCE VIDEO SELECT mode cancel SVSOURCE<CR>
The BOLD COMMANDS are new.

29.Mar.06
20/25
EVENT PARAMETER function example *RES.
MS DIRECT SURROUND mode change MSDIRECT<CR>
PURE DIRECT MSPURE DIRECT<CR>
STEREO MSSTEREO<CR>
MULTI CH IN MSMULTI CH IN<CR>
MULTI CH IN
+PL2x CINEMA MSM CH IN+PL2X C<CR>
MULTI CH IN
+PL2x MUSIC MSM CH IN+PL2X M<CR>
MULTI CH DIRECT MSMULTI CH DIRECT<CR>
MULTI CH DIRECT
+PL2x CINEMA MSM CH DRCT+PL2X C <CR>
MULTI CH DIRECT
+PL2x MUSIC MSM CH DRCT+PL2X M <CR>
MULTI CH PURE D MSMULTI CH PURE D<CR>
MULTI CH PURE D
+PL2x CINEMA MSM CH PURE D+PL2X C <CR>
MULTI CH PURE D
+PL2x MUSIC MSM CH PURE D+PL2X M <CR>
DOLBY PRO LOGIC MSDOLBY PRO LOGIC<CR>
DOLBY PL2 CINEMA MSDOLBY PL2 C<CR>
DOLBY PL2 MUSIC MSDOLBY PL2 M<CR>
DOLBY PL2 GAME MSDOLBY PL2 G<CR>
DOLBY PL2x CINEMA MSDOLBY PL2X C<CR>
DOLBY PL2x MUSIC MSDOLBY PL2X M<CR>
DOLBY PL2x GAME MSDOLBY PL2X G<CR>
DOLBY DIGITAL MSDOLBY DIGITAL<CR>
DOLBY D EX MSDOLBY D EX<CR>
DOLBY D
+PL2x CINEMA MSDOLBY D+PL2X C<CR>
DOLBY D
+PL2x MUSIC MSDOLBY D+PL2X M<CR>
DTS NEO:6 CINEMA MSDTS NEO:6 C<CR>
DTS NEO:6 MUSIC MSDTS NEO:6 M<CR>
DTS SURROUND MSDTS SURROUND<CR>
