Denon AVR-E400 User manual

MODEL JP E3 E2 EK EA E1 E1K E1C
AVR-E400
P
AVR-X2000
P P P P
INTEGRATED NETWORK AV RECEIVER
S0676-0V04DM/DG1305
Ver. 4
• Please use this service manual with referring to the operating instructions without fail.
• Some illustrations using in this service manual are slightly different from the actual set.
• For purposes of improvement, specications and design are subject to change without notice.
• Cautions when replacing the FRONT PANEL(Only AVR-X2000E3):Depending on when the model was
manufactured, there may be washers in the FRONT PANEL screw positions. Washers are not used in the
replacement FRONT PANEL.If you are replacing a FRONT PANEL that has washers, discard the washers.
Please refer to the
MODIFICATION NOTICE.
e
SERVICE MANUAL
e
D&M Holdings Inc.
Copyright 2013 D&M Holdings Inc. All rights reserved.
WARNING: Violators will be prosecuted to the maximum extent possible.

ABOUT THIS MANUAL.............................................................3
What you can do with this manual ............................................3
Using Adobe Reader (Windows version) ..................................4
SAFETY PRECAUTIONS ..........................................................6
NOTE FOR SCHEMATIC DIAGRAM.........................................7
NOTE FOR PARTS LIST ...........................................................7
TECHNICAL SPECIFICATIONS................................................9
DIMENSION .............................................................................10
CAUTION IN SERVICING........................................................11
Initializing INTEGRATED NETWORK AV RECEIVER ............11
Service Jig ..............................................................................11
DISASSEMBLY ........................................................................12
1. FRONT PANEL ASSY ........................................................14
2. PCB MX PORT/PCB RS232C (AVR-X2000E3 only) ........15
3. PCB HDMI..........................................................................16
4. POWER TRANS MAIN ......................................................17
5. PCB VIDEO ASSY .............................................................17
6. PCB SMPS.........................................................................18
7. RADIATOR ASSY...............................................................20
SPECIAL MODE .....................................................................22
Special mode setting button (for E400E3 model)....................22
Special mode setting button (for X2000 model) ......................23
1. µcom/DSP Version display mode.......................................24
2. PANEL/REMOTE LOCK Selection mode...........................28
3. Service Related Selection mode ........................................29
BLOCK DIAGRAM...................................................................32
4. Protection Pass mode ........................................................49
5. DM860A Reboot mode.......................................................49
6. Remote ID Setup mode......................................................50
7. NETWORK Initialization mode ...........................................50
JIG FOR SERVICING ..............................................................52
WHEN THE MICROPROCESSOR IS REPLACED WITH A
NEW ONE ...............................................................................55
PROCEDURE FOR UPGRADING THE VERSION OF
THE FIRMWARE.....................................................................55
1. How to update by DFW ......................................................55
2. How to update by DPMS....................................................59
3. How to update by USB Memory.........................................66
ADJUSTMENT.........................................................................74
TROUBLE SHOOTING............................................................82
1. POWER..............................................................................82
2. Analog video ......................................................................83
3. HDMI/DVI ...........................................................................87
4. AUDIO................................................................................89
5. Network/USB......................................................................92
6. SMPS.................................................................................95
CLOCK FLOW & WAVE FORM IN DIGITAL BLOCK
DIAGRAM ................................................................................98
LEVEL DIAGRAM....................................................................99
BLOCK DIAGRAM.................................................................105
POWER DIAGRAM................................................................106
WIRING DIAGRAM................................................................107
PRINTED WIRING BOARDS.................................................108
SCHEMATIC DIAGRAMS (1/24) ...........................................119
FRONT UNIT (1/1) ................................................................119
INPUT UNIT (1/1)..................................................................120
SMPS UNIT (1/1) ..................................................................121
VIDEO UNIT (1/3) .................................................................122
VIDEO UNIT (2/3) .................................................................123
VIDEO UNIT (3/3) .................................................................124
AMP UNIT (1/2).....................................................................125
AMP UNIT (2/2).....................................................................126
MAIN UNIT (1/2)....................................................................127
MAIN UNIT (2/2)....................................................................128
HDMI UNIT (1/13) .................................................................129
HDMI UNIT (2/13) .................................................................130
HDMI UNIT (3/13) .................................................................131
HDMI UNIT (4/13) .................................................................132
HDMI UNIT (5/13) .................................................................133
HDMI UNIT (6/13) .................................................................134
HDMI UNIT (7/13) .................................................................135
HDMI UNIT (8/13) .................................................................136
HDMI UNIT (9/13) .................................................................137
HDMI UNIT (10/13) ...............................................................138
HDMI UNIT (10/13) ...............................................................139
HDMI UNIT (11/13)................................................................140
HDMI UNIT (12/13) ...............................................................141
HDMI UNIT (13/13) ...............................................................142
EXPLODED VIEW .................................................................143
PARTS LIST OF EXPLODED VIEW......................................145
PACKING VIEW .....................................................................146
PARTS LIST OF PACKING & ACCESSORIES ....................147
SEMICONDUCTORS .............................................................148
1. IC's ...................................................................................148
2. FL DISPLAY .....................................................................170
CONTENTS
2

Jump to the target of a schematic
diagram connector
Click the Ref. No. of the target connector in the red
box around a schematic diagram connector.
•The screen jumps to the target connector.
• Page magnication stays the same as before the
jump.
CP401
CP106
v
ABOUT THIS MANUAL
Read the following information before using the service manual.
What you can do with this manual
Search for a Ref. No. (phrase)
(Ctrl+Shift+F)
You can use the search function in Acrobat Reader to
search for a Ref. No. in schematic diagrams, printed
wiring board diagrams, block diagrams, and parts
lists.
1.Press Ctrl+Shift+F on the keyboard.
• The Search window appears.
2.Enter the Ref. No. you want to search for in the
Search window, and then click the Search button.
•A list of search results appears.
3.Click an item on the list.
• The screen jumps to the page for that item, and the
search phrase is displayed.
Ctrl
Shift
F
3

Using Adobe Reader (Windows version)
• Properties
Click this button and check that the printer is set to a
suitable paper size.
• Pagetoprint
Select the following checkbox.
"More Options" : "Current View"
• PageSizing&Handling
Select the following checkbox.
"Size" / "SizeOptions" : "Fit"
Add notes to this data (Sign)
The Sign function lets you add notes to the data in
this manual.
Save the le once you have nished adding notes.
[Example using Adobe Reader X]
On the "View" menu, click "Sign".
• The Sign pane appears.
[Example using Adobe Reader 9]
On the "Document" menu, click "Sign".
Magnify schematic / printed wiring
board diagrams - 1
(Ctrl+Space, mouse operation)
Press Ctrl+Space on the keyboard and drag the
mouse to select the area you want to view.
• The selected area is magnied.
• When you want to move the area shown, hold
down Space and drag the mouse.
• When you want to show a full page view, press
Ctrl+0 on the keyboard.
Ctrl Space
0
Printamagniedpartofthemanual
The Properties dialog box and functions will vary depending on your printer.
1. Drag the mouse to magnify the part you want to print.
2. On the "File" menu, click "Print".
3. Congure the following settings in the Print dialog box.
4. Click the Print button to start printing.
4

Magnify schematic / printed wiring
board diagrams - 2
(Pan & Zoom function)
The Pan & Zoom function lets you see which part of
a magnied diagram is being shown in a separate
window.
[Example using Adobe Reader X]
On the "View" menu, point to "Zoom", and then click
"Pan & Zoom".
• The Pan & Zoom window appears on the screen.
[Example using Adobe Reader 9]
On the "Tools" menu, point to "Select & Zoom", and
then click "Pan & Zoom Window".
Magnify schematic / printed wiring
board diagrams - 3
(Loupe Tool function)
The Loupe Tool function lets you magnify a specic
part of a diagram in a separate window.
[Example using Adobe Reader X]
On the "View" menu, point to "Zoom", and then click
"Loupe Tool".
• The Loupe Tool window appears on the screen.
[Example using Adobe Reader 9]
On the "Tools" menu, point to "Select & Zoom", and
then click "Loupe Tool Window".
5

SAFETY PRECAUTIONS
The following items should be checked for continued protection of the customer and the service technician.
leakage current check
Before returning the set to the customer, be sure to carry out either (1) a leakage current check or (2) a line to chassis
resistance check. If the leakage current exceeds 0.5 milliamps, or if the resistance from chassis to either side of the
power cord is less than 460 kohms, the set is defective.
Be sure to test for leakage current with the AC plug in both polarities, in addition, when the set's power is in each state
(on, off and standby mode), if applicable.
CAUTION Please heed the following cautions and instructions during servicing and
inspection.
◎Heed the cautions!
Cautions which are delicate in particular for servicing
are labeled on the cabinets, the parts and the chassis,
etc. Be sure to heed these cautions and the cautions
described in the handling instructions.
◎Cautions concerning electric shock!
(1) An AC voltage is impressed on this set, so if you
touch internal metal parts when the set is energized,
you may get an electric shock. Avoid getting an
electric shock, by using an isolating transformer
and wearing gloves when servicing while the set is
energized, or by unplugging the power cord when
replacing parts, for example.
(2) There are high voltage parts inside. Handle with
extra care when the set is energized.
◎Caution concerning disassembly and
assembly!
Through great care is taken when parts were
manufactured from sheet metal, there may be burrs on
the edges of parts. The burrs could cause injury if ngers
are moved across them in some rare cases. Wear gloves
to protect your hands.
◎Use only designated parts!
The set's parts have specic safety properties (re
resistance, voltage resistance, etc.). Be sure to use parts
which have the same properties for replacement. The
burrs have the same properties. In particular, for the
important safety parts that are indicated by the z mark
on schematic diagrams and parts lists, be sure to use
the designated parts.
◎Be sure to mount parts and arrange the wires
as they were originally placed!
For safety seasons, some parts use tapes, tubes or other
insulating materials, and some parts are mounted away
from the surface of printed circuit boards. Care is also
taken with the positions of the wires by arranging them
and using clamps to keep them away from heating and
high voltage parts, so be sure to set everything back as
it was originally placed.
◎Make a safety check after servicing!
Check that all screws, parts and wires removed or
disconnected when servicing have been put back in their
original positions, check that no serviced parts have
deteriorate the area around. Then make an insulation
check on the external metal connectors and between
the blades of the power plug, and otherwise check that
safety is ensured.
(Insulation check procedure)
Unplug the power cord from the power outlet, disconnect
the antenna, plugs, etc., and on the power. Using a 500V
insulation resistance tester, check that the insulation
resistance value between the inplug and the externally
exposed metal parts (antenna terminal, headphones
terminal, input terminal, etc.) is 1MΩ or greater. If it is
less, the set must be inspected and repaired.
Many of the electric and the structural parts used in the
set have special safety properties. In most cases these
properties are difcult to distinguish by sight, and the use
of replacement parts with higher ratings (rated power
and withstand voltage) does not necessarily guarantee
that safety performance will be preserved. Parts with
safety properties are indicated as shown below on the
wiring diagrams and the parts list in this service manual.
Be sure to replace them with the parts which have the
designated part number.
(1) Schematic diagrams.......Indicated by the z mark.
(2) Parts lists.......Indicated by the z mark.
The use of parts other than the
designated parts could cause electric
shocks, res or other dangerous
situations.
CAUTION Concerning important
safety parts
6

NOTE FOR SCHEMATIC DIAGRAM
WARNING:
Parts indicated by the z mark have critical characteristics. Use ONLY replacement parts recommended by the manufacturer.
CAUTION:
Before returning the set to the customer, be sure to carry out either (1) a leakage current check or (2) a line to chassis resistance check. If
the leakage current exceeds 0.5 milliamps, or if the resistance from chassis to either side of the power cord is less than 460 kohms, the set
is defective.
WARNING:
DO NOT return the set to the customer unless the problem is identied and remedied.
NOTICE:
ALL RESISTANCE VALUES IN OHM. k=1,000 OHM / M=1,000,000 OHM
ALL CAPACITANCE VALUES ARE EXPRESSED IN MICRO FARAD, UNLESS OTHERWISE INDICATED. P INDICATES MICRO-MICRO
FARAD. EACH VOLTAGE AND CURRENT ARE MEASURED AT NO SIGNAL INPUT CONDITION. CIRCUIT AND PARTS ARE SUBJECT
TO CHANGE WITHOUT PRIOR NOTICE.
NOTE FOR PARTS LIST
Parts indicated by "nsp" on this table cannot be supplied.
When ordering a part, make a clear distinction between "1" and "I" (i) to avoid mis-supplying.
A part ordered without specifying its part number can not be supplied.
General-purpose Carbon Chip Resistors are not included are not included in the P.W.Board parts list.
(Refer to the Schematic Diagram for those parts.)
Parts indicated by the zmark have critical characteristics. Use ONLY replacement parts recommended by the manufacturer.
General-purpose Carbon Film Resistor in the P.W.Board parts list. (Refer to the Schematic Diagram for those parts.)
Part indicated by "★" mark is not illustrated in the exploded view.
WARNING:
1.
2.
3.
4.
5.
6.
●Resistors
RD : Carbon
RC : Composition
RS : Metal oxide film
RW: winding
RN : Metal film
RK : Metal mixture
P : Pulse-resistant type
NL : Low noise type
NB : Non-burning type
FR : Fuse-resistor
F : Lead wire forming
2B : 1/8 W
2E : 1/4 W
2H : 1/2 W
3A : 1 W
3D : 2 W
3F : 3 W
3H : 5 W
F : ±1%
G:±2%
J : ±5%
K : ±10%
M : ±20%
Ex.: RN
Type
14K
Shape
and per-
formance
2E
Power
182
Resist-
ance
G
Allowable
error
FR
Others
*Resistance
1800ohm=1.8kohm1 8 2
Indicates number of zeros after effective number.
2-digit effective number.
1.2ohm1 R 2
2-digit effective number, decimal point indicated by R.
1-digit effective number.
: Units: ohm
●Capacitors
CE : Aluminum foil
electrolytic
CA : Aluminium solid
electrolytic
CS : Tantalum electrolytic
CQ : Film
CK : Ceramic
CC : Ceramic
CP : Oil
CM: Mica
CF : Metallized
CH : Metallized
HS : High stability type
BP : Non-polar type
HR : Ripple-resistant type
DL : For change and discharge
HF : For assuring high frequency
U : UL part
C : CSA part
W : UL-CSA part
F : Lead wire forming
0J : 6.3 V
1A : 10 V
1C : 16 V
1E : 25 V
1V : 35 V
1H : 50 V
2A : 100 V
2B : 125 V
2C : 160 V
2D : 200 V
2E : 250 V
2H : 500 V
2J : 630 V
F : ±1%
G:±2%
J : ±5%
K : ±10%
M : ±20%
Z : ±80%
: - 20%
P : +100%
C : ±0.25pF
D : ±0.5pF
= : Others
Ex.: CE
Type
04W
Shape
and per-
formance
1H
Dielectric
strength
3R2
Capacity
M
Allowable
error
BP
Others
･Units:μF.
2200μF2 2 2
Indicates number of zeros after effective number.
2-digit effective number. ･Units:μF.
2.2μF2 R 2
2-digit effective number, decimal point indicated by R
1-digit effective number.
*Capacity (electrolyte only)
･When the dielectric strength is indicated in AC,"AC" is included after the dielectric strength value.
*Capacity (except electrolyte)
･Units:pF
2200pF=0.0022μF2 2 2
Indicates number of zeros after effective number. (More than 2)
2-digit effective number. ･Units:pF
220pF2 2 1
2-digit effective number.
Indicates number of zeros after effective number. (0 or 1)
NOTE FOR PARTS LIST
INSTRUCTIONS FOR HANDLING SEMI-CONDUCTORS AND OPTICAL UNIT
Electrostatic breakdown of the semi-conductors or optical pickup may occur due to a potential difference caused by
electrostatic charge during unpacking or repair work.
1. Ground for Human Body
Be sure to wear a grounding band (1 MΩ) that is properly grounded to remove any static electricity that may be
charged on the body.
2. Ground for Workbench
Be sure to place a conductive sheet or copper plate with proper grounding (1 MΩ) on the workbench or other surface,
where the semi-conductors are to be placed. Because the static electricity charge on clothing will not escape through
the body grounding band, be careful to avoid contacting semi-conductors with your clothing
<Incorrect>
CBA
Grounding Band
Conductive Sheet or
Copper Plate
1MΩ
1MΩ
<Correct>
CBA
7

Personal notes:
8

nAudio section
• Power amplifier
Rated output(for E400 model):
Front:
90 W + 90 W (8 Ω/ohms, 20 Hz – 20 kHz with 0.08 % T.H.D.)
125 W + 125 W (6 Ω/ohms, 1 kHz with 0.7 % T.H.D.)
Center:
90 W (8 Ω/ohms, 20 Hz – 20 kHz with 0.08 % T.H.D.)
125 W (6 Ω/ohms, 1 kHz with 0.7 % T.H.D.)
Surround:
90 W + 90 W (8 Ω/ohms, 20 Hz – 20 kHz with 0.08 % T.H.D.)
125 W + 125 W (6 Ω/ohms, 1 kHz with 0.7 % T.H.D.)
Surround back:
90 W + 90 W (8 Ω/ohms, 20 Hz – 20 kHz with 0.08 % T.H.D.)
125 W + 125 W (6 Ω/ohms, 1 kHz with 0.7 % T.H.D.)
Rated output(for X2000 model):
Front:
90 W + 90 W (8 Ω/ohms, 20 Hz – 20 kHz with 0.08 % T.H.D.)
125 W + 125 W (6 Ω/ohms, 1 kHz with 0.7 % T.H.D.)
Center:
90 W (8 Ω/ohms, 20 Hz – 20 kHz with 0.08 % T.H.D.)
125 W (6 Ω/ohms, 1 kHz with 0.7 % T.H.D.)
Surround:
90 W + 90 W (8 Ω/ohms, 20 Hz – 20 kHz with 0.08 % T.H.D.)
125 W + 125 W (6 Ω/ohms, 1 kHz with 0.7 % T.H.D.)
Surround back:
90 W + 90 W (8 Ω/ohms, 20 Hz – 20 kHz with 0.08 % T.H.D.)
125 W + 125 W (6 Ω/ohms, 1 kHz with 0.7 % T.H.D.)
Output connectors: 6 – 16 Ω/ohms
• Analog
Input sensitivity/Input impedance: 200 mV/47 kΩ/kohms
Frequency response: 10 Hz – 100 kHz — +1, –3 dB (DIRECT mode)
S/N : 100 dB (IHF–A weighted, DIRECT mode)
nTuner section
(Note: μV at 75 Ω/ohms, 0 dBf = 1 x 10–15 W)
Receiving Range: FM 87.5 MHz – 107.9 MHz(for E400 model)
AM 520 kHz – 1710 kHz(for E400 model)
FM 87.50 MHz – 108.00 MHz(for X2000 model)
AM 522 kHz – 1611 kHz(for X2000 model)
Usable Sensitivity: FM 1.2 μV (12.8 dBf)
AM 18 μV
50 dB Quieting
Sensitivity:
MONO 2.8 μV (20.2 dBf)
S/N : MONO 70 dB (IHF–A weighted, DIRECT mode)
STEREO 67 dB (IHF–A weighted, DIRECT mode)
Total harmonic
Distortion:
MONO 0.7 % (1 kHz)
STEREO 1.0 % (1 kHz)
nGeneral
Power supply:
AC 120 V, 60 Hz
AC 230 V, 50/60 Hz
Power consumption: 460 W
Power consumption in standby mode: 0.1 W
Power consumption in CEC standby mode:0.5 W
Power consumption in network standby mode: 2.7 W
TECHNICAL SPECIFICATIONS
9

Unit : in. (mm)
11 11/32 (288.0)
12 63/64 (330.0)
6 15/32 (164.5)
2 1/8
(54.0)
2 47/64
(69.5)
37/64 (14.5)6 (152.5)
6 67/64 (167.0)
17 3/32 (434.0)
13 35/64 (344.0)
2 23/64
(60.0)
1 49/64
(45.0)
1 49/64
(45.0)
47/64
(18.5)
59/64
(23.5)
Weight : 20 lbs 15 oz (9.5 kg)
Unit : in. (mm)
11 11/32 (288.0)
13 5/32 (334.0) 6 15/32 (164.5)
2 1/8
(54.0)
2 47/64
(69.5)
37/64 (14.5) 5 13/16 (147.5)
6 3/8 (162.0)
17 3/32 (434.0)
13 35/64 (344.0)
2 23/64
(60.0)
1 49/64
(45.0)
1 49/64
(45.0)
47/64
(18.5)
1 5/64
(27.5)
Weight : 20 lbs 12 oz (9.4 kg)
[AVR-E400 model]
[AVR-X2000 model]
DIMENSION
10

InitializingINTEGRATEDNETWORKAVRECEIVER
INTEGRATED NETWORK AV RECEIVER initialization should be performed when the μcom, peripheral parts of μcom, and
Digital PCB were replaced.
1. Turn off the power pressing "Power operation (X)" button.
2. Press "Power operation (X)" button while simultaneously while pressing "ZONE2 SOURCE" and "DIMMER" buttons.
3. Check that the entire display is ashing at intervals of about 1 second, and then release the 2 buttons.
The microprocessor will be initialized.
[AVR-E400E3 model]
[AVR-X2000 model]
Service Jig
When you repair the printing board, you can use the following JIG (Extension cable kit).
Please order it from Denon Ofcial Service Distributor in your region if necessary.
8U-110084S : EXTENSION UNIT KIT : 1 Set
8U-110136S : EXTENSION UNIT KIT : 1 Set
(Refer to 52 page.)
When you update the rmware by DFW, you can use the following JIG (RS232C to internal connector conversion adapter
with 4P FFC kit ).
Please order it from Denon Ofcial Service Distributor in your region if necessary.
8U-210100S : WRITING KIT : 1 Set
(Refer to 55 page.)
NOTE: • If step 3 fails, start over from step 1.
• All user settings will be lost and the factory setting will be recovered after the set is initialized.
So make sure to note down your setting beforehand for restoring after the initialization.
CAUTION IN SERVICING
11

DISASSEMBLY
• Disassemble in order of the arrow in the following gure.
• In the case of the re-assembling, assemble it in order of the reverse of the following ow.
• In the case of the re-assembling, observe "attention of assembling".
• If wire bundles are untied or moved to perform adjustment or replace parts etc., be sure to rearrange them neatly as
they were originally bundled or placed afterward.
Otherwise, incorrect arrangement can be a cause of noise generation.
FRONT PANEL ASSY
Refer to "DISASSEMBLY
1. FRONT PANEL ASSY"
and "EXPLODED VIEW"
PCB FRONT HDMI ASSY
(Ref. No. of EXPLODED VIEW : P1)
PCB USB ASSY
(Ref. No. of EXPLODED VIEW : P2)
PCB FRONT ASSY
(Ref. No. of EXPLODED VIEW : P3)
PCB FUNCTION ASSY
(Ref. No. of EXPLODED VIEW : P4)
PCB CNT ASSY
(Ref. No. of EXPLODED VIEW : P5)
PCB F/H_GUIDE ASSY
(Ref. No. of EXPLODED VIEW : P6)
RADIATOR ASSY
Refer to "DISASSEMBLY
7. RADIATOR ASSY"
and "EXPLODED VIEW"
PCB AMP ASSY
(Ref. No. of EXPLODED VIEW : P7)
PCB GUIDE R
(Ref. No. of EXPLODED VIEW : P17)
PCB TOP_GUIDE
(Ref. No. of EXPLODED VIEW : P18)
POWER TRANS MAIN
Refer to "DISASSEMBLY
4. POWER TRANS MAIN"
and "EXPLODED VIEW"
POWER TRANS
(Ref. No. of EXPLODED VIEW : 13)
TOP COVER
PCB HDMI
Refer to "DISASSEMBLY
3. PCB HDMI"
and "EXPLODED VIEW"
PCB HDMI ASSY
(Ref. No. of EXPLODED VIEW : P13)
PCB MX PORT/PCB RS232C
(AVR-X2000E3 only)
Refer to "DISASSEMBLY
2. PCB MX PORT/PCB RS232C"
and "EXPLODED VIEW"
PCB RS232C ASSY
(Ref. No. of EXPLODED VIEW : P14)
PCB MX PORT ASSY
(Ref. No. of EXPLODED VIEW : P15)
PCB VIDEO ASSY
Refer to "DISASSEMBLY
5. PCB VIDEO ASSY"
and "EXPLODED VIEW"
PCB MAIN ASSY
(Ref. No. of EXPLODED VIEW : P9)
PCB INPUT ASSY
(Ref. No. of EXPLODED VIEW : P10)
PCB FRONT CNT ASSY
(Ref. No. of EXPLODED VIEW : P11)
PCB VIDEO ASSY
(Ref. No. of EXPLODED VIEW : P12)
BACK CHASSIS
PCB SMPS
Refer to "DISASSEMBLY
6. PCB SMPS"
and "EXPLODED VIEW"
PCB SMPS ASSY
(Ref. No. of EXPLODED VIEW : P8)
12

About the photos used for "descriptions of the DISASSEMBLY" section
• The shooting direction of each photograph used herein is indicated on the left side of the respective photograph as
"Shooting direction: ***".
• Refer to the diagram below about the shooting direction of each photograph.
• Photographs with no shooting direction indicated were taken from the top of the set.
• The photograph is AVR-E400 E3 model.
The viewpoint of each photograph
(Shooting direction)
［View from the top］
Front side
Shooting direction: B
Shooting direction: D
Shooting direction: C
Shooting direction: A
13

1. FRONT PANEL ASSY
Cautions when replacing the FRONT PANEL (Only AVR-X2000E3)f
Depending on when the model was manufactured, there may be washers in the FRONT PANEL screw positions. Washers
are not used in the replacement FRONT PANEL.If you are replacing a FRONT PANEL that has washers, discard the
washers.
This caution does not apply to models that are not originally tted with washers.
Proceeding : TOP COVER →FRONT PANEL ASSY
(1) Remove the screws.
(2) Disconnect the connector wires and FFC. Remove the screws.
View from the bottom
N2801 FFC
CP4400
FFC
STYLE PIN : Loosen
STYLE PIN : Loosen
Please refer to "EXPLODED VIEW" for the disassembly method of each P.W.B included in FRONT PANEL ASSY.
14

2. PCB MX PORT/PCB RS232C (AVR-X2000E3 only)
Proceeding : TOP COVER →BACK CHASSIS →PCB RS232_CNT(AVR-X2000E3 only)
→PCB RS232C(AVR-X2000E3 only)
(1) Remove the screws.
(2) Disconnect the connector board.
Shooting of photograph: A
Board to board
PCB RS232_CNT
PCB RS232
Please refer to "EXPLODED VIEW" for the disassembly method of PCB RS232_CNT/PCB RS232.
15

3. PCB HDMI
Proceeding : TOP COVER →BACK CHASSIS →PCB HDMI
(1) Remove the screws.
(2) Cut the wire clamp band, then disconnect the connector wires and FFC. Disconnect the connector board.
Shooting of photograph: A
N2801
Board to board
Board to board
N3405FCC N3601 FCC
cut
cut
STYLE PIN : Loosen
16

4. POWER TRANS MAIN
Proceeding : TOP COVER →BACK CHASSIS →PCB HDMI →POWER TRANS MAIN
(1) Disconnect the connector wires, then remove the screws.
5. PCB VIDEO ASSY
Proceeding : TOP COVER →BACK CHASSIS →PCB HDMI →PCB VIDEO ASSY →PCB INPUT ASSY
(1) Disconnect the connector board.
CP4142
CP5003
CP4000
CP4400 STYLE PIN : Loosen
cut
PCB VIDEO
PCB INPUT
PCB VIDEO
Please refer to "EXPLODED VIEW" for the disassembly method of each PCB.
17

6. PCB SMPS
Proceeding : TOP COVER →BACK CHASSIS →PCB HDMI →PCB VIDEO ASSY →PCB INPUT ASSY
→PCB FRONT CNT →PCB MAIN →PCB SMPS
(1) Remove the screws.
(2) Disconnect the connector wire.
View from the bottom
CP5003
PCB FRONT CNT
18

(3) Disconnect the connector wires, then remove the screws.
(4) Remove the screw.
POWER TRANSPCB MAIN
CP4000CP4001 CP405
CP4142
CP403
PCB SMPS
Please refer to "EXPLODED VIEW" for the disassembly method of each PCB.
19

7. RADIATOR ASSY
Proceeding : TOP COVER →RADIATOR ASSY
(1) Remove the screws.
(2) Cut the wire clamp band, then disconnect the connector wires and FFC.
View from the bottom
STYLE PIN : Loosen
cut
N2801
FFC
FFC
CP402 CP403 CP405
CP401
N3405
20
