Denon DRA-697CI Administrator guide

16 October 2006
1/10
DENON DRA697CI RC CODE
FORMAT SHARP
DATA CONSTRUCTION 15bits C14 0 C15 0=NOT INVERTED,1=INVERTED
AVP SYSTEM ADDRESS(C1～C5) : 00110 , EXTENSION BIT(C12,C13) : 01
No. Data (C6～C11) Key Name No. Data (C6～C11) Key Name
0 000000 16 000010
MULTI ZONE2/3 CD
1 100000 17 100010
MULTI ZONE2/3 TUNER
2 010000 18 010010
MULTI ZONE2/3 DVD/VDP
3 110000 19 110010
MULTI ZONE2/3 V.AUX
4 001000 20 001010
MULTI ZONE2/3 VCR
5 101000 21 101010
6 011000 22 011010
MULTI ZONE2/3 PRESET UP
7 111000 23 111010
MULTI ZONE2/3 PRESET DOWN
8 000100 24 000110
9 100100 25 100110
10 010100 26 010110
11 110100 27 110110
12 001100 28 001110
MULTI ZONE2/3 CDR/TAPE
13 101100
MULTI ZONE2 VOLUME UP 29 101110
14 011100
MULTI ZONE2 VOLUME DOWN 30 011110
15 111100
MULTI ZONE2/3 PHONO 31 111110
No. Data (C6～C11) Key Name No. Data (C6～C11) Key Name
32 000001 48 000011
CH VOLUME UP
33 100001 49 100011
CH VOLUME DOWN
34 010001 50 010011
35 110001 51 110011
36 001001 52 001011
37 101001 53 101011
38 011001 54 011011
39 111001 55 111011
40 000101 56 000111
41 100101 57 100111
SHIFT A
42 010101 58 010111
SHIFT B
43 110101 59 110111
SHIFT C
44 001101 60 001111
SHIFT D
45 101101 61 101111
SHIFT E
46 011101 62 011111
47 111101
CH SELECT 63 111111

16 October 2006
2/10
RCVR SYSTEM ADDRESS(C1～C5) : 00110 , EXTENSION BIT(C12,C13) : 10
No. Data (C6～C11) Key Name No. Data (C6～C11) Key Name
0 000000 16 000010
1 100000 17 100010
2 010000 18 010010
VCR (VCR-1)
3 110000 19 110010
4 001000 20 001010
DVD/VDP
5 101000 21 101010
6 011000 22 011010
7 111000 23 111010
8 000100 24 000110
PHONO
9 100100 25 100110
TUNER
10 010100
SHIFT 26 010110 CD
11 110100
MUTING 27 110110 V.AUX
12 001100
MASTER VOLUME DOWN 28 001110 CDR/TAPE
13 101100
MASTER VOLUME UP 29 101110
14 011100
PRESET CH UP 30 011110
15 111100
PRESET CH DOWN 31 111110
No. Data (C6～C11) Key Name No. Data (C6～C11) Key Name
32 000001 48 000011
33 100001 49 100011
34 010001 50 010011
35 110001 51 110011
36 001001 52 001011
37 101001 53 101011
38 011001 54 011011
39 111001 55 111011
40 000101
POWER ON 56 000111
41 100101
SPEAKER-B 57 100111
42 010101
SPEAKER-A 58 010111 POWER OFF
43 110101 59 110111
44 001101 60 001111
45 101101 61 101111
46 011101 62 011111
STATUS
47 111101 63 111111

16 October 2006
3/10
TUNER SYSTEM ADDRESS(C1～C5) : 00110 , EXTENSION BIT(C12,C13) : 11
No. Data (C6～C11) Key Name No. Data (C6～C11) Key Name
0 000000 16 000010
1 100000
TUNER PRESET CH 1 17 100010
2 010000
TUNER PRESET CH 2 18 010010
3 110000
TUNER PRESET CH 3 19 110010
4 001000
TUNER PRESET CH 4 20 001010
5 101000
TUNER PRESET CH 5 21 101010
6 011000
TUNER PRESET CH 6 22 011010
7 111000
TUNER PRESET CH 7 23 111010
8 000100
TUNER PRESET CH 8 24 000110
9 100100 25 100110
10 010100 26 010110
11 110100 27 110110
12 001100 28 001110
13 101100 29 101110
14 011100 30 011110
15 111100 31 111110
DIMMER
No. Data (C6～C11) Key Name No. Data (C6～C11) Key Name
32 000001 48 000011
33 100001 49 100011
34 010001 50 010011
35 110001 51 110011
36 001001 52 001011
37 101001 53 101011
38 011001 54 011011
39 111001 55 111011
40 000101 56 000111
41 100101 57 100111
42 010101 58 010111
43 110101 59 110111
44 001101 60 001111
45 101101 61 101111
46 011101 62 011111
47 111101 63 111111

16 October 2006
4/10
S.AMP SYSTEM ADDRESS(C1～C5) : 01000 , EXTENSION BIT(C12,C13) : 10
No. Data (C6～C11) Key Name No. Data (C6～C11) Key Name
0 000000 16 000010
1 100000 17 100010
2 010000 18 010010
3 110000 19 110010
4 001000 20 001010
5 101000 21 101010
6 011000 22 011010
7 111000 23 111010
8 000100 24 000110
9 100100 25 100110
10 010100 26 010110
11 110100 27 110110
12 001100 28 001110
13 101100 29 101110
14 011100 30 011110
15 111100 31 111110
No. Data (C6～C11) Key Name No. Data (C6～C11) Key Name
32 000001 48 000011
33 100001 49 100011
34 010001 50 010011
35 110001 51 110011
36 001001 52 001011
37 101001
MULTI ZONE3 VOLUME DOWN 53 101011
38 011001
MULTI ZONE3 VOLUME UP 54 011011
39 111001 55 111011
40 000101 56 000111
41 100101 57 100111
MAIN ZONE ON
42 010101 58 010111
MAIN ZONE OFF
43 110101 59 110111
MULTI ZONE2 ON
44 001101 60 001111
MULTI ZONE2 OFF
45 101101 61 101111
MULTI ZONE3 ON
46 011101 62 011111
MULTI ZONE3 OFF
47 111101 63 111111

16 October 2006
5/10
DENON DRA697CI RC CODE
FORMAT KASEIKYO
DATA CONSTRUCTION 48bits
GENRE：K7-6 (ZONE1)
DENON CODE Parity GENRE1
４５２３ ０ 7
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24
0 0 1 0 1 0 1 0 0 1 0 0 1 1 0 0 0 0 0 0 1 1 1 0
GENRE2 Data parity Key Name
No. 25 26 27 28 29 30 31 32 33 34 35 36 37 38 39 40 41 42 43 44 45 46 47 48
2 011001000000000 0 01101010ALLPOWERON
3
11000000000 0 01100010ALLPOWEROFF
5
10100000000 0 01100100ZONE1ON/OFF
6
01100000000 0 01101000ZONE1ON
7 1 1 1 0 0 0 0 0 0 0 0 0 01100000ZONE1OFF
16 0 0 0 0 1 0 0 0 0 0 0 0 11101110KEY1
17 1 0 0 0 1 0 0 0 0 0 0 0 11100110KEY2
18 0 1 0 0 1 0 0 0 0 0 0 0 11101010KEY3
19 11001000000 0 11100010
KEY4
20 00101000000 0 11101100
KEY5
21 10101000000 0 11100100
KEY6
22 01101000000 0 11101000
KEY7
23 11101000000 0 11100000
KEY8
24 00011000000 0 11101111
KEY9
25 10011000000 0 11100111
KEY10 (0)
27 11011000000 0 11100011CURSOR UP
28 00111000000 0 11101101CURSOR DOWN
29 10111000000 0 11100101CURSOR LEFT
30 01111000000 0 11101001CURSOR RIGHT
31 11111000000 0 11100001ENTER
48 00001100000 0 10101110PHONO
49 10001100000 0 10100110TUNER(HDRADIO)
50 01001100000 0 10101010CD
51 11001100000 0 10100010TAPE-1
59 11011100000 0 10100011iPOD
64 00000010000 0 01001110DVD
69 10100010000 0 01000100VCR-1
73 10010010000 0 01000111V.AUX-1
80 00001010000 0 11001110TUNINGUP
81 10001010000 0 11000110TUNINGDOWN
82 01001010000 0 11001010PRESET CH UP
83 11001010000 0 11000010PRESET CH DOWN
84 00101010000 0 11001100SHIFT
87 11101010000 0 11000000FM/AM
88 00011010000 0 11001111BAND
91 11011010000 0 11000011
XM
92
00111010000 0 11001101MODE
96
00000110000 0 00001110MEMORY
118
01101110000 0 10001000MENU(SYSTEM SETUP)

16 October 2006
6/10
GENRE：K7-6 (ZONE1)
DENON CODE Parity GENRE1
４５２３ ０ 7
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24
0 0 1 0 1 0 1 0 0 1 0 0 1 1 0 0 0 0 0 0 1 1 1 0
GENRE2 Data parity Key Name
No. 25 26 27 28 29 30 31 32 33 34 35 36 37 38 39 40 41 42 43 44 45 46 47 48
120 0 1 1 0 0 0 0 1 1 1 1 0 0 0 0 0 10001111
SEARCH
128 0 0 0 0 0 0 0 1 0 0 0 0 01111110SHIFTA
129 1 0 0 0 0 0 0 1 0 0 0 0 01110110SHIFTB
130 0 1 0 0 0 0 0 1 0 0 0 0 01111010SHIFTC
131 11000001000 0 01110010
SHIFT D
132 00100001000 0 01111100
SHIFT E
133 10100001000 0 01110100
SHIFT F
134 01100001000 0 01111000
SHIFT G
259 11000000100 0 01101010
PURE DIRECT
272 00001000100 0 11100110
VOLUME UP
273 10001000100 0 11101110
VOLUME DOWN
274 01001000100 0 11100010
MUTING
310 01101100100 0 10100000TONEDEFEAT
317 10111100100 0 10101101LOUDNESS
321 10000010100 0 01001110SP-A
324 00100010100 0 01000100SP-B
368 00001110100 0 10000110VIDEOSELECT
400 00001001100 0 11110110STATUS
416 00000101100 0 00110110DIMMER

16 October 2006
7/10
GENRE：K7-7 (ZONE2)
DENON CODE Parity GENRE1
４５２３ ０ 7
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24
0 0 1 0 1 0 1 0 0 1 0 0 1 1 0 0 0 0 0 0 1 1 1 0
GENRE2 Data parity Key Name
No. 25 26 27 28 29 30 31 32 33 34 35 36 37 38 39 40 41 42 43 44 45 46 47 48
5 111010100000000 0 11100100ZONE2ON/OFF
6
01100000000 0 11101000ZONE2ON
7 1 1 1 0 0 0 0 0 0 0 0 0 11100000ZONE2OFF
16 0 0 0 0 1 0 0 0 0 0 0 0 01101110KEY1
17 1 0 0 0 1 0 0 0 0 0 0 0 01100110KEY2
18 0 1 0 0 1 0 0 0 0 0 0 0 01101010KEY3
19 11001000000 0 01100010
KEY4
20 00101000000 0 01101100
KEY5
21 10101000000 0 01100100
KEY6
22 01101000000 0 01101000
KEY7
23 11101000000 0 01100000
KEY8
24 00011000000 0 01101111
KEY9
25 10011000000 0 01100111
Key10 (0)
48 00001100000 0 00101110PHONO
49 10001100000 0 00100110TUNER(HDRADIO)
50 01001100000 0 00101010CD
51 11001100000 0 00100010TAPE-1
59 11011100000 0 00100011iPOD
64 00000010000 0 11001110DVD
69 10100010000 0 11000100VCR-1
73 10010010000 0 11000111V.AUX-1
82 01001010000 0 01001010PRESET CH UP
83 11001010000 0 01000010PRESET CH DOWN
84 00101010000 0 01001100SHIFT
87 11 1 01010000 0 01000000FM/AM
88 00011010000 0 01001111BAND
91 11 0 11010000 0 01000011XM
120 00011110000 0 00001111SEARCH
128 00000001000 0 11111110SHIFTA
129 10000001000 0 11110110
SHIFT B
130 01000001000 0 11111010
SHIFT C
131 11000001000 0 11110010
SHIFT D
132 00100001000 0 11111100
SHIFT E
133 10100001000 0 11110100
SHIFT F
134 01100001000 0 11111000
SHIFT G
272 00001000100 0 01100110
VOLUME UP
273 10001000100 0 01101110
VOLUME DOWN
274 01001000100 0 01100010
MUTING

16 October 2006
8/10
GENRE：K7-8 (ZONE3)
DENON CODE Parity GENRE1
４５２３ ０ 7
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24
0 0 1 0 1 0 1 0 0 1 0 0 1 1 0 0 0 0 0 0 1 1 1 0
GENRE2 Data parity Key Name
No. 25 26 27 28 29 30 31 32 33 34 35 36 37 38 39 40 41 42 43 44 45 46 47 48
5 000110100000000 0 00010100ZONE3ON/OFF
6
01100000000 0 00011000ZONE3ON
7 1 1 1 0 0 0 0 0 0 0 0 0 00010000ZONE3OFF
16 0 0 0 0 1 0 0 0 0 0 0 0 10011110KEY1
17 1 0 0 0 1 0 0 0 0 0 0 0 10010110KEY2
18 0 1 0 0 1 0 0 0 0 0 0 0 10011010KEY3
19 11001000000 0 10010010
KEY4
20 00101000000 0 10011100
KEY5
21 10101000000 0 10010100
KEY6
22 01101000000 0 10011000
KEY7
23 11101000000 0 10010000
KEY8
24 00011000000 0 10011111
KEY9
25 10011000000 0 10010111
Key10 (0)
48 00001100000 0 11011110PHONO
49 10001100000 0 11010110TUNER(HDRADIO)
50 01001100000 0 11011010CD
51 11001100000 0 11010010TAPE-1
59 11011100000 0 11010011iPOD
64 00000010000 0 00111110DVD
69 10100010000 0 00110100VCR-1
73 10010010000 0 00110111V.AUX-1
82 01001010000 0 10111010PRESET CH UP
83 11001010000 0 10110010PRESET CH DOWN
84 00101010000 0 10111100SHIFT
87 11 1 01010000 0 10110000FM/AM
88 00011010000 0 10111111BAND
91 11 0 11010000 0 10110011XM
120 00011110000 0 11111111SEARCH
128 00000001000 0 00001110SHIFTA
129 10000001000 0 00000110
SHIFT B
130 01000001000 0 00001010
SHIFT C
131 11000001000 0 00000010
SHIFT D
132 00100001000 0 00001100
SHIFT E
133 10100001000 0 00000100
SHIFT F
134 01100001000 0 00001000
SHIFT G
272 00001000100 0 10010110
VOLUME UP
273 10001000100 0 10011110
VOLUME DOWN
274 01001000100 0 10010010
MUTING

16 October 2006
9/10
GENRE：K4-1 (AV AMP_ZONE1))
DENON CODE Parity GENRE1
４５２３ ０ 4
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24
0 0 1 0 1 0 1 0 0 1 0 0 1 1 0 0 0 0 0 0 0 0 1 0
GENRE2 Data parity Key Name
No. 25 26 27 28 29 30 31 32 33 34 35 36 37 38 39 40 41 42 43 44 45 46 47 48
800 100000000100110 0 11001110∧（ iPod）
801
10000100110 0 11000110∨（ iPod）
802
01000100110 0 11001010＜（ iPod）
803
11000100110 0 11000010＞（ iPod）
804 0 0 1 0 0 1 0 0 1 1 0 0 11001100
ENTER（iPod）
805 1 0 1 0 0 1 0 0 1 1 0 0 11000100
PLAY/PAUSE（iPod）
807 1 1 1 0 0 1 0 0 1 1 0 0 11000000
STOP（for iPod）
808 00010100110 0 11001111F-SKIP（for iPod）
809 10010100110 0 11000111B-SKIP（for iPod）
810 01010100110 0 11001011FWD（for iPod）
811 11010100110 0 11000011RWD（iPod）
812 00110100110 0 11001101REPEAT ONE（iPod）
813 10110100110 0 11000101REPEAT ALL（iPod）
814 01110100110 0 11001001REPEAT OFF（iPod）
815 11110100110 0 11000001SHUFFLESONGS（iPod）
816 00001100110 0 01001110SHUFFLEALBUMS（iPod）
817 10001100110 0 01000110SHUFFLEOFF（iPod）
818
01001100110-001001010MODEMENU（iPod）
819 1 1 0 0 1 1 0 0 1 1 0 0 01000010
MODE BROWSE（iPod）
820 0 0 1 0 1 1 0 0 1 1 0 0 01001100
MODE REMOTE（iPod）

16 October 2006
10/10
GENRE：K2-3 (iPod)
DENON CODE Parity GENRE1
４５２３ ０ 2
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24
0 0 1 0 1 0 1 0 0 1 0 0 1 1 0 0 0 0 0 0 0 1 0 0
GENRE2 Data parity Key Name
No. 25 26 27 28 29 30 31 32 33 34 35 36 37 38 39 40 41 42 43 44 45 46 47 48
1 110010000000000 0 11001100PLAY/PAUSE（iPod）
4
00100000000 0 11000110F-SKIP（for iPod）
5
10100000000 0 11001110B-SKIP（for iPod）
8
00010000000 0 11000101STOP（for iPod）
21 1 0 1 0 1 0 0 0 0 0 0 0 01001110
FWD（for iPod）
22 0 1 1 0 1 0 0 0 0 0 0 0 01000010
RWD（iPod）
