Denon HEOS Amp User manual

MODEL JP E3 E2 EK EA E1 E1K E1C
HEOS Amp
P P
Wireless Multi-Room Sound System
Ver. 6
S1147V06DM/DG1511
• Please use this service manual with referring to the operating instructions without fail.
• Some illustrations using in this service manual are slightly different from the actual set.
• For purposes of improvement, specications and design are subject to change without notice.
Please refer to the
MODIFICATION NOTICE.
e
SERVICE MANUAL
e
D&M Holdings Inc.

ABOUT THIS MANUAL.............................................................3
What you can do with this manual ............................................3
Using Adobe Reader (Windows version) ..................................4
SAFETY PRECAUTIONS ..........................................................6
NOTE FOR SCHEMATIC DIAGRAM.........................................7
NOTE FOR PARTS LIST ...........................................................7
TECHNICAL SPECIFICATIONS................................................9
DIMENSION ...............................................................................9
DISASSEMBLY ........................................................................10
1. SIDE COVER AND SIDE KEY PCB...................................12
2. TOP COVER / BOTTOM COVER......................................13
3. CORE MODULE PCB ASSY .............................................14
4. DIGITAL PCB .....................................................................15
5. SUB SMPS PCB ................................................................16
6. MAIN (VOLUME-SMPS) PCB ...........................................17
7. FRONT PANEL ASSY ........................................................17
Procedure after Replacing the Microprocessor, etc. ..........18
Firmware Update Procedure..................................................18
1. MAIN PCB Update Procedure............................................18
2. Updating by USB................................................................20
3. Service region settings update procedures........................21
4. Service Release Type settings update procedures............22
5. Firmware burning procedure after Core Module
replacement ow ....................................................................23
6. How to check the version , Release Type, Locale .............24
TROUBLE SHOOTING............................................................25
1. POWER..............................................................................25
2. AUDIO................................................................................27
AUDIO CHECK PATH .............................................................29
MEASURING METHOD AND WAVEFORMS .........................33
BLOCK DIAGRAM...................................................................36
POWER DIAGRAM..................................................................37
WIRING DIAGRAM..................................................................38
PRINTED Circuit BOARDS.....................................................39
SCHEMATIC DIAGRAMS .......................................................42
MAIN ......................................................................................42
DSP DIR USB .........................................................................43
DAMP......................................................................................44
SMPS ......................................................................................45
FRONT....................................................................................46
MAIN BT NFC KEY .................................................................47
TOUCH PAD ...........................................................................48
EXPLODED VIEW ...................................................................50
PACKING VIEW .......................................................................52
SEMICONDUCTORS ...............................................................53
1. IC's .....................................................................................53
CONTENTS
2

Jump to the target of a schematic
diagram connector
Click the Ref. No. of the target connector in the red
box around a schematic diagram connector.
•The screen jumps to the target connector.
•Pagemagnicationstaysthesameasbeforethe
jump.
CP401
CP106
v
ABOUT THIS MANUAL
Read the following information before using the service manual.
What you can do with this manual
Search for a Ref. No. (phrase)
(Ctrl+Shift+F)
You can use the search function in Acrobat Reader to
search for a Ref. No. in schematic diagrams, printed
wiring board diagrams, block diagrams, and parts
lists.
1.Press Ctrl+Shift+Fonthekeyboard.
• The Search window appears.
2.EntertheRef.No.youwanttosearchforinthe
Search window, and then click the Search button.
•A list of search results appears.
3.Click an item on the list.
• The screen jumps to the page for that item, and the
searchphraseisdisplayed.
Ctrl
Shift
F
3

Using Adobe Reader (Windows version)
• Properties
Click this button and check that the printer is set to a
suitable paper size.
• Page to print
Select the following checkbox.
"More Options" : "Current View"
• Page Sizing & Handling
Select the following checkbox.
"Size" / "Size Options" : "Fit"
Add notes to this data (Sign)
TheSignfunctionletsyouaddnotestothedatain
this manual.
Savetheleonceyouhavenishedaddingnotes.
[Example using Adobe Reader X]
On the "View" menu, click "Sign".
• The Sign pane appears.
[Example using Adobe Reader 9]
On the "Document" menu, click "Sign".
Magnify schematic / printed wiring
board diagrams - 1
(Ctrl+Space, mouse operation)
Press Ctrl+Spaceonthekeyboardanddragthe
mousetoselecttheareayouwanttoview.
• Theselectedareaismagnied.
• Whenyouwanttomovetheareashown,hold
down Space and drag the mouse.
• Whenyouwanttoshowafullpageview,press
Ctrl+0onthekeyboard.
Ctrl Space
0
Print a magnied part of the manual
ThePropertiesdialogboxandfunctionswillvarydependingonyourprinter.
1. Dragthemousetomagnifythepartyouwanttoprint.
2. On the "File" menu, click "Print".
3. CongurethefollowingsettingsinthePrintdialogbox.
4. Click the Print button to start printing.
4

Magnify schematic / printed wiring
board diagrams - 2
(Pan & Zoom function)
ThePan&Zoomfunctionletsyouseewhichpartof
amagnieddiagramisbeingshowninaseparate
window.
[Example using Adobe Reader X]
On the "View" menu, point to "Zoom", and then click
"Pan & Zoom".
• The Pan & Zoom window appears on the screen.
[Example using Adobe Reader 9]
On the "Tools" menu, point to "Select & Zoom", and
then click "Pan & Zoom Window".
Magnify schematic / printed wiring
board diagrams - 3
(Loupe Tool function)
TheLoupeToolfunctionletsyoumagnifyaspecic
part of a diagram in a separate window.
[Example using Adobe Reader X]
On the "View" menu, point to "Zoom", and then click
"Loupe Tool".
• The Loupe Tool window appears on the screen.
[Example using Adobe Reader 9]
On the "Tools" menu, point to "Select & Zoom", and
then click "Loupe Tool Window".
5

SAFETY PRECAUTIONS
The following items should be checked for continued protection of the customer and the service technician.
leakage current check
Beforereturningthesettothecustomer,besuretocarryouteither(1)aleakagecurrentcheckor(2)alinetochassis
resistance check. If the leakage current exceeds 0.5 milliamps, or if the resistance from chassis to either side of the
power cord is less than 460 kohms, the set is defective.
Be sure to test for leakage current with the AC plug in both polarities, in addition, when the set's power is in each state
(on,offandstandbymode),ifapplicable.
CAUTION Please heed the following cautions and instructions during servicing and
inspection.
◎Heed the cautions!
Cautions which are delicate in particular for servicing
are labeled on the cabinets, the parts and the chassis,
etc. Be sure to heed these cautions and the cautions
described in the handling instructions.
◎Cautions concerning electric shock!
(1) AnACvoltageisimpressedonthisset,soifyou
touch internal metal parts when the set is energized,
youmaygetanelectricshock.Avoidgettingan
electricshock,byusinganisolatingtransformer
and wearing gloves when servicing while the set is
energized,orbyunpluggingthepowercordwhen
replacing parts, for example.
(2) Therearehighvoltagepartsinside.Handlewith
extra care when the set is energized.
◎Caution concerning disassembly and
assembly!
Through great care is taken when parts were
manufacturedfromsheetmetal,theremaybeburrson
theedgesofparts.Theburrscouldcauseinjuryifngers
are moved across them in some rare cases. Wear gloves
toprotectyourhands.
◎Use only designated parts!
Theset'spartshavespecicsafetyproperties(re
resistance,voltageresistance,etc.).Besuretouseparts
which have the same properties for replacement. The
burrs have the same properties. In particular, for the
importantsafetypartsthatareindicatedbythezmark
on schematic diagrams and parts lists, be sure to use
the designated parts.
◎Be sure to mount parts and arrange the wires
as they were originally placed!
Forsafetyseasons,somepartsusetapes,tubesorother
insulatingmaterials,andsomepartsaremountedaway
from the surface of printed circuit boards. Care is also
takenwiththepositionsofthewiresbyarrangingthem
andusingclampstokeepthemawayfromheatingand
highvoltageparts,sobesuretoseteverythingbackas
itwasoriginallyplaced.
◎Make a safety check after servicing!
Check that all screws, parts and wires removed or
disconnected when servicing have been put back in their
original positions, check that no serviced parts have
deteriorate the area around. Then make an insulation
check on the external metal connectors and between
the blades of the power plug, and otherwise check that
safetyisensured.
(Insulationcheckprocedure)
Unplug the power cord from the power outlet, disconnect
the antenna, plugs, etc., and on the power. Using a 500V
insulation resistance tester, check that the insulation
resistancevaluebetweentheinplugandtheexternally
exposedmetalparts(antennaterminal,headphones
terminal,inputterminal,etc.)is1MΩorgreater.Ifitis
less, the set must be inspected and repaired.
Manyoftheelectricandthestructuralpartsusedinthe
sethavespecialsafetyproperties.Inmostcasesthese
propertiesaredifculttodistinguishbysight,andtheuse
ofreplacementpartswithhigherratings(ratedpower
andwithstandvoltage)doesnotnecessarilyguarantee
thatsafetyperformancewillbepreserved.Partswith
safetypropertiesareindicatedasshownbelowonthe
wiring diagrams and the parts list in this service manual.
Be sure to replace them with the parts which have the
designated part number.
(1) Schematicdiagrams.......Indicatedbythez mark.
(2) Partslists.......Indicatedbythezmark.
The use of parts other than the
designated parts could cause electric
shocks,resorotherdangerous
situations.
CAUTION Concerning important
safety parts
6

NOTE FOR SCHEMATIC DIAGRAM
WARNING:
Partsindicatedbythezmarkhavecriticalcharacteristics.UseONLYreplacementpartsrecommendedbythemanufacturer.
CAUTION:
Beforereturningthesettothecustomer,besuretocarryouteither(1)aleakagecurrentcheckor(2)alinetochassisresistancecheck.If
the leakage current exceeds 0.5 milliamps, or if the resistance from chassis to either side of the power cord is less than 460 kohms, the set
is defective.
WARNING:
DONOTreturnthesettothecustomerunlesstheproblemisidentiedandremedied.
NOTICE:
ALLRESISTANCEVALUESINOHM.k=1,000OHM/M=1,000,000OHM
ALLCAPACITANCEVALUESAREEXPRESSEDINMICROFARAD,UNLESSOTHERWISEINDICATED.PINDICATESMICRO-MICRO
FARAD.EACHVOLTAGEANDCURRENTAREMEASUREDATNOSIGNALINPUTCONDITION.CIRCUITANDPARTSARESUBJECT
TOCHANGEWITHOUTPRIORNOTICE.
NOTE FOR PARTS LIST
1.Partsindicatedby"nsp"onthistablecannotbesupplied.
2.Whenorderingapart,makeacleardistinctionbetween"1"and"I"(i)toavoidmis-supplying.
3.Apartorderedwithoutspecifyingitspartnumbercannotbesupplied.
4.Partindicatedby" ★" mark is not illustrated in the exploded view.
WARNING: Partsindicatedbythezmarkhavecriticalcharacteristics.UseONLYreplacementpartsrecommendedbythe
manufacturer.
INSTRUCTIONS FOR HANDLING SEMI-CONDUCTORS AND OPTICAL UNIT
Electrostaticbreakdownofthesemi-conductorsoropticalpickupmayoccurduetoapotentialdifferencecausedby
electrostatic charge during unpacking or repair work.
1. GroundforHumanBody
Besuretowearagroundingband(1MΩ)thatisproperlygroundedtoremoveanystaticelectricitythatmaybe
chargedonthebody.
2. GroundforWorkbench
Besuretoplaceaconductivesheetorcopperplatewithpropergrounding(1MΩ)ontheworkbenchorothersurface,
wherethesemi-conductorsaretobeplaced.Becausethestaticelectricitychargeonclothingwillnotescapethrough
thebodygroundingband,becarefultoavoidcontactingsemi-conductorswithyourclothing
<Incorrect>
CBA
Grounding Band
Conductive Sheet or
Copper Plate
1MΩ
1MΩ
<Correct>
CBA
7

Personal notes:
8

nAudio section
Power amplifier Rated output: 2-channel driving
100W+100W (6Ω, 1 kHz, T.H.D. 0.7%)
Output connectors: 4 - 16 Ω/ohms
Input sensitivity/Input impedance: 150 mV/24 kΩ/kohms
Total Distortion: ANALOG IN: 0.1 %(1 kHz)
S/N ratio (10 W, 6 Ω/ohms, IHF-A): ANALOG IN: 83 dB(IHF-A weighted)
Frequency response: 20 Hz to 20 kHz : ±1 dB
nWireless LAN section
Network type: Conforming to IEEE 802.11a/b/g/n
Used frequency range: 2.41GHz - 2.472GHz, 5GHz
nGeneral
Operating temperature: 41°F-95°F (5°C - 35°C)
Power supply: AC 120V, 60Hz (for USA/Canada)
AC 220-240V, 50/60Hz (for Europe)
Power consumption: 60W
Power consumption in network standby mode: 4W
Power consumption in standby mode: 0.3W
TECHNICAL SPECIFICATIONS
DIMENSION
oDimensions (Unit : in. (mm))
6 3/16 (157)
8 45/64 (221)
15/64
(6) 3 27/64 (87)
3 21/32 (93)
8 5/16 (211)
8 27/64 (214)
1 31/32 (50) 4 3/8 (111)
DENON
oWeight : 6 lbs 2.8 oz (2.8 kg)
For the purpose of improvement, the specifications and design are subject to change without notice.
Contents Setup Use Troubleshooting Status LED Appendix
53
Unit : in. (mm)
Weight : 6 lbs 2.8 oz (2.8 kg)
9

DISASSEMBLY
• Remove each part in the order of the arrows below.
• Reassemble removed parts in the reverse order.
• Read "Precautions During Work" before reassembling removed parts.
• If wire bundles are removed or moved during adjustment or part replacement, reshape the wires after completing the
work. Failure to shape the wires correctly may cause problems such as noise.
SIDE COVER
See "DISASSEMBLY
1. SIDE COVER"
and "EXPLODED VIEW"
SIDE KEY PCB
(Ref. No. of EXPLODED VIEW : C11)
DIGITAL PCB
See "DISASSEMBLY
4. DIGITAL PCB"
and "EXPLODED VIEW"
DIGITAL PCB
(Ref. No. of EXPLODED VIEW : C15)
CONNECT PCB
(Ref. No. of EXPLODED VIEW : C8)
MAIN (VOLUME-SMPS) PCB ASSY
See "DISASSEMBLY
6. MAIN (VOLUME-SMPS) PCB ASSY"
and "EXPLODED VIEW"
MAIN(VOLUME/SMPS) PCB
(Ref. No. of EXPLODED VIEW : C1)
REAR LED PCB
(Ref. No. of EXPLODED VIEW : C10)
FRONT PANEL ASSY
See "DISASSEMBLY
7. FRONT PANEL ASSY"
and "EXPLODED VIEW"
FRONT LED PCB
(Ref. No. of EXPLODED VIEW : C4)
FRONT ANTENNA PCB
FRONT LED SUPPRT PCB
(Ref. No. of EXPLODED VIEW : C14)
TOP COVER ASSY
See "DISASSEMBLY
2. TOP COVER / BOTTOM COVER"
and "EXPLODED VIEW"
TOP COVER ASSY
(Ref. No. of EXPLODED VIEW : P3)
CORE MODULE PCB ASSY
See "DISASSEMBLY
3. CORE MODULE PCB ASSY
and "EXPLODED VIEW"
CORE MODULE PCB
(Ref. No. of EXPLODED VIEW : C16)
BOTTOM COVER
See "DISASSEMBLY
2. TOP COVER / BOTTOM COVER"
and "EXPLODED VIEW"
BOTTOM COVER
(Ref. No. of EXPLODED VIEW : P2)
SUB SMPS PCB
See "DISASSEMBLY
5. SUB SMPS PCB"
and "EXPLODED VIEW"
SUB SMPS PCB
(Ref. No. of EXPLODED VIEW : C6)
10

Explanatory Photos for“ DISASSEMBLY”
• The angles from which the photos are taken are shown by “Photo angle: A, B, C, D“ .
• See the diagram below about the shooting direction of each photograph.
• Photographs with no shooting direction indicated were taken from the top of the set.
The viewpoint of each photograph
(Shooting direction)
Shooting direction: B
(Rear side)
Shooting direction: D
(Top side)
Shooting direction: A
(Front side)
Shooting direction: C
(Bottom side)
Shooting direction: E
(Right side)
Shooting direction: F
(Right side)
11

1. SIDE COVER AND SIDE KEY PCB
Proceeding : SIDE COVER →SIDE KEY PCB
(1) Remove the socket head cap screw.
(2) Lift the SIDE COVER.
Put the driver in the groove and push the side panel. Use a φ2mm tool (bit or driver).
(3) The other side do the same.
Shooting direction: C
(Bottom side)
12

(4) Disconnect the connector wire. Remove the SIDE KEY PCB.
2. TOP COVER / BOTTOM COVER
Proceeding : SIDE COVER →TOP COVER / BOTTOM COVER
(1) Remove the screws.
(2) Remove the screws and remove the top cover.
Note: When assembling, be careful to pinch the antenna cable.
(3) Remove the screws and remove the bottom cover.
(4) Remove the screw.
.
Antenna cable
Shooting direction: E
(Right side)
Shooting direction: F
(Left side)
13

3. CORE MODULE PCB ASSY
Proceeding : SIDE COVER →TOP COVER →CORE MODULE PCB ASSY
(1) Remove the screws. And pull up the PCB.
(2) Remove the shield cover and remove the antenna connector.
shield cover
ANTENNA CONNECTOR
Shooting direction: D
(Top side)
14

4. DIGITAL PCB
Proceeding : SIDE COVER →TOP COVER →MODULE PCB →DIGITAL PCB
(1) Remove the screws.
(2)Remove the screws and remove the side connector PCB.
(3) Remove the screws, the connector wire and FFC. Loosen the style pin.
Then remove the PCB from the support.
Shooting direction: B
(Rear side)
FFC
CN13
SUPPORT
STYLE PIN
CN43 Shooting direction: D
(Top side)
Shooting direction: F
(Left side)
15

5. SUB SMPS PCB
Proceeding : SIDE COVER →TOP COVER →CORE MODULE PCB ASSY →DIGITAL PCB
→SUB SMPS PCB
(1) Remove the screws. And connector wires.
CN94
TS92
Shooting direction: D
(TOP side)
16

6. MAIN (VOLUME-SMPS) PCB
Proceeding : SIDE COVER →TOP COVER →CORE MODULE PCB ASSY →DIGITAL PCB
→SUB SMPS PCB →MAIN PCB / REAR LED PCB / AC CONNECTOR PCB
(1) Remove the screws.
(2) Remove the connector wire and FFC.
7. FRONT PANEL ASSY
Proceeding : SIDE COVER →TOP COVER →BOTTOM COVER →FRONT PANEL ASSY
(1) Remove the screw.
Shooting direction: B
(Rear side)
REAR LED PCB
AC CONECTOR PCB
Shooting direction: D
(Top side)
CN43
Shooting direction: D
(Top side)
17

PROCEDURE AFTER REPLACING THE MICROPROCESSOR, ETC.
The procedure after replacing the u-COM (microprocessor), ash ROM, etc. is as follows.
PCB Name Ref. No. Description Procedure after
Replacement Remark
DIGITAL C16 CORE MODULE ASS'Y C / D
Be sure to update the rmware.
Be sure to rewrite the service region setting.
Be sure to rewrite the service Release Type setting.
Procedure after Replacement
A : The software has been written. The software is not written at the time of replacement.
B : The software has been written. The software may need to be rewritten by version updates. Check the version.
C : The software has not been written. Front LED is solid purple. Back LED is solid red.
See "2. Updating by USB", "3. Service region settings update procedures" and
"
4. Service Release Type settings update procedures" for information on writing the software.
D : The software has been written.
See "2. Updating by USB", "3. Service region settings update procedures" and
"
4. Service Release Type settings update procedures" for information on writing the software.
FIRMWARE UPDATE PROCEDURE
1. MAIN PCB Update Procedure
1.1. Items to Be Prepared
・Mobile device
• A broadband internet connection
• Modem
• Router
• Ethernet cable (CAT-5 or greater recommended)
1.2. Connection of HEOS
If you are connecting the HEOS Link to a wired network, connect the included Ethernet cable between the HEOS Link and
your router. Do not connect the Ethernet cable if you are connecting your HEOS Link to a wireless network.
(1) Download the Denon HEOS App Go to the App Store™ or to Google Play™ and search for “Denon HEOS” to
download and install.
(2) Launch the Denon HEOS App
f
Router
RESET
IMPEDANCE : 4 16 Class 2 Wiring
WOOFER
SUB
SPEAKERS
NETWORK
OPTICAL IN
USB
CONNECT
AUX IN
LINE IN
5V1A
18

(3) If there is a software update, follow step 1 to step 4 below.
Step 1 →Step 2 →Step 3 →Step 4
Tap the "Update Now". Tap the "Next". The software is written to this
Unit.
"Update completed" is displayed.
Tap the "Done"
Note:
This display is updating two units at
the same time.
(4) Be sure to rewrite the service region setting.
See 21 page "Service region settings update procedures".
19

2. Updating by USB
The latest rmware can be downloaded to a USB memory for updates.
2.1. Connecting to the USB Memory
(1) Preparation
• USB format: Prepare a USB memory formatted in FAT32.
• Do not run the USB memory through a hub.
• Do not connect a computer to the USB port of this unit using a USB cable.
• Do not use an extension cable when connecting the USB unit.
2.2. Download and update the Firmware.
1. Download the HEOS Player’s rmware from SDI.
2. Save the rmware le to the PC.
3. Copy the rmware to USB memory.
4. Connect the USB memory to the HEOS Player’s USB Port.
5. Updating is started automatically.
6. Player’s status LED should be blinking amber during upgrading the rmware.
Exsample of HEOS Link LED Actions.
LED on the front is blinking amber.
7. One the upgrade is complete, the player reboots automatically.
Exsample of HEOS Link LED Actions.
LED on the front is blinking blue.
8. Ready-Congured and connected to your network.
Exsample of HEOS Link LED Actions.
9. Be sure to rewrite the service region setting.
See 21 page "Service region settings update procedures".
--- Precautions for Updates ---
• Never remove the USB memory before the update is nished.
• Never turn off the power before an update is completed.
Once an update is started, normal operations cannot be performed until it is completed.
(blink)
(off)
(blink)
(off)
(solid)
(off)
20
