Denon D-AJ03 User manual

PERSONAL AUDIO SYSTEM
D-AJ03
OPERATING INSTRUCTIONS
MODE D’EMPLOI
INSTRUCCIONES DE OPERACION
EQ AUXFM/AM
C D
POWER
VOLUME
SDB
TUNING/
PRESET
REMOTE CONTROLUNIT
EQ AUXFM/AM
C D
POWER
VOLUME
SDB
TUNING/
PRESET
REMOTE CONTROLUNIT
VERTICAL LOADING SYSTEM
COMPACT DISC PLAYER
DIGEST
TRACK
SDB
EQ
REMOTE
SENSOR
CD STEREO RECEIVER
D-AJ03
40-STATIONS PRESET MEMORY
6-MODES PRESET EQUALIZER
FOR ENGLISH READERS PAGE 2 ~ PAGE 38
POUR LES LECTEURS FRANCAIS PAGE 2, 4, 39 ~ PAGE 72
PARA LECTORES DE ESPAÑOL PÁGINA 2, 4, 73 ~ PÁGINA 106

2
ENGLISH FRANCAIS ESPAÑOL
IMPORTANT TO SAFETY
WARNING:
TO PREVENT FIRE OR SHOCK HAZARD, DO NOT
EXPOSE THIS APPLIANCE TO RAIN OR MOISTURE.
CAUTION
1.Handle the power supply cord carefully
Do not damage or deform the power supply cord. If it is
damaged or deformed, it may cause electric shock or
malfunction when used. When removing from wall outlet,
be sure to remove by holding the plug attachment and not
by pulling the cord.
2.Do not open the top cover
In order to prevent electric shock, do not open the top
cover.
If problems occur, contact your DENON DEALER.
3.Do not place anything inside
Do not place metal objects or spill liquid inside the system.
Electric shock or malfunction may result.
Please, record and retain the Model name and serial number
of your set shown on the rating label.
Model No. D-AJ03 Serial No.
CAUTION: TO REDUCE THE RISK OF ELECTRIC
SHOCK, DO NOT REMOVE COVER
(OR BACK). NO USER-
SERVICEABLE PARTS INSIDE.
REFER SERVICING TO QUALIFIED
SERVICE PERSONNEL.
The lightning flash with arrowhead symbol,
within an equilateral triangle, is intended to
alert the user to the presence of uninsulated
“dangerous voltage” within the product’s
enclosure that may be of sufficient magnitude
to constitute a risk of electric shock to persons.
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
The exclamation point within an equilateral
triangle is intended to alert the user to the
presence of important operating and
maintenance (servicing) instructions in the
literature accompanying the appliance.
NOTE:
This system uses the semiconductor laser. To allow you to
enjoy music at a stable operation, it is recommended to use
this in a room of 5°C ( 41°F ) ~ 35°C ( 95°F ).
CAUTION:
USE OF CONTROLS OR ADJUSTMENTS OR REFOR-
MANCE OF PROCEDURES OTHER THAN THOSE
SPECIFIED HEREIN MAY RESULT IN HAZARDOUS
RADIATION EXPOSURE.
THE COMPACT DISC PLAYER SHOULD NOT BE
ADJUSTED OR REPAIRED BY ANYONE EXCEPT
PROPERLY QUALIFIED SERVICE PERSONNEL.
This device complies with Part 15 of the FCC Rules.
Operation is subject to the following two conditions:
(1) This device may not cause harmful interference,
and (2) this device must accept any interference
received, including interference that may cause
undesired operation.
This Class B digital apparatus meets all requirements
of the Canadian Interference-Causing Equipment
Regulations.
Cet appareil numérique de la classe B respecte toutes
les exigences du Règlement sur le matériel brouilleur
du Canada.
CAUTION
TO PREVENT ELECTRIC SHOCK DO NOT USE THIS
(POLARIZED) PLUG WITH AN EXTENSION CORD,
RECEPTACLE OR OTHER OUTLET UNLESS THE
BLADES CAN BE FULLY INSERTED TO PREVENT
BLADE EXPOSURE.
ATTENTION
POUR PREVENIR LES CHOCS ELECTRIQUES NE
PAS UTILISER CETTE FICHE POLARISEE AVEC UN
PROLONGATEUR UNE PRISE DE COURANT OU
UNE AUTRE SORTIE DE COURANT, SAUF SI LES
LAMES PEUVENT ETRE INSEREES A FOND SANS
EN LAISSER AUCUNE PARTIE A DECOUVERT.

3
SAFETY INSTRUCTIONS
1. Read Instructions – All the safety and operating instructions
should be read before the product is operated.
2. Retain Instructions – The safety and operating instructions
should be retained for future reference.
3. Heed Warnings – All warnings on the product and in the
operating instructions should be adhered to.
4. Follow Instructions – All operating and use instructions should
be followed.
5. Cleaning – Unplug this product from the wall outlet before
cleaning. Do not use liquid cleaners or aerosol cleaners.
6. Attachments – Do not use attachments not recommended by
the product manufacturer as they may cause hazards.
7. Water and Moisture – Do not use this product near water – for
example, near a bath tub, wash bowl, kitchen sink, or laundry
tub; in a wet basement; or near a swimming pool; and the like.
8. Accessories – Do not place this product on an unstable cart,
stand, tripod, bracket, or table. The product may fall, causing
serious injury to a child or adult, and serious damage to the
product. Use only with a cart, stand, tripod, bracket, or table
recommended by the manufacturer, or sold with the product.
Any mounting of the product should follow the manufacturer’s
instructions, and should use a
mounting accessory
recommended by the
manufacturer.
9. A product and cart
combination should be
moved with care. Quick
stops, excessive force,
and uneven surfaces may
cause the product and cart
combination to overturn.
10. Ventilation – Slots and openings in the cabinet are provided for
ventilation and to ensure reliable operation of the product and
to protect it from overheating, and these openings must not be
blocked or covered. The openings should never be blocked by
placing the product on a bed, sofa, rug, or other similar
surface. This product should not be placed in a built-in
installation such as a bookcase or rack unless proper
ventilation is provided or the manufacturer’s instructions have
been adhered to.
11. Power Sources – This product should be operated only from
the type of power source indicated on the marking label. If
you are not sure of the type of power supply to your home,
consult your product dealer or local power company. For
products intended to operate from battery power, or other
sources, refer to the operating instructions.
12. Grounding or Polarization – This product may be equipped with
a polarized alternating-current line plug (a plug having one
blade wider than the other). This plug will fit into the power
outlet only one way. This is a safety feature. If you are unable
to insert the plug fully into the outlet, try reversing the plug. If
the plug should still fail to fit, contact your electrician to replace
your obsolete outlet. Do not defeat the safety purpose of the
polarized plug.
13. Power-Cord Protection – Power-supply cords should be routed
so that they are not likely to be walked on or pinched by items
placed upon or against them, paying particular attention to
cords at plugs, convenience receptacles, and the point where
they exit from the product.
15. Outdoor Antenna Grounding – If an outside antenna or cable
system is connected to the product, be sure the antenna or
cable system is grounded so as to provide some protection
against voltage surges and built-up static charges. Article 810
of the National Electrical Code, ANSI/NFPA 70, provides
information with regard to proper grounding of the mast and
supporting structure, grounding of the lead-in wire to an
antenna discharge unit, size of grounding conductors, location
of antenna-discharge unit, connection to grounding electrodes,
and requirements for the grounding electrode. See Figure A.
16. Lightning – For added protection for this product during a
lightning storm, or when it is left unattended and unused for
long periods of time, unplug it from the wall outlet and
disconnect the antenna or cable system. This will prevent
damage to the product due to lightning and power-line surges.
17. Power Lines – An outside antenna system should not be
located in the vicinity of overhead power lines or other electric
light or power circuits, or where it can fall into such power
lines or circuits. When installing an outside antenna system,
extreme care should be taken to keep from touching such
power lines or circuits as contact with them might be fatal.
18. Overloading – Do not overload wall outlets, extension cords, or
integral convenience receptacles as this can result in a risk of
fire or electric shock.
19. Object and Liquid Entry – Never push objects of any kind into
this product through openings as they may touch dangerous
voltage points or short-out parts that could result in a fire or
electric shock. Never spill liquid of any kind on the product.
20.
Servicing – Do not attempt to service this product yourself
as opening or removing covers may expose you to
dangerous voltage or other hazards. Refer all servicing to
qualified service personnel.
21.
Damage Requiring Service – Unplug this product from the
wall outlet and refer servicing to qualified service
personnel
under the following conditions:
a) When the power-supply cord or plug is damaged,
b) If liquid has been spilled, or objects have fallen into the
product,
c) If the product has been exposed to rain or water,
d) If the product does not operate normally by following the
operating instructions. Adjust only those controls that are
covered by the operating instructions as an improper
adjustment of other controls may result in damage and will
often require extensive work by a qualified technician to
restore the product to its normal operation,
e) If the product has been dropped or damaged in any way,
and
f) When the product exhibits a distinct change in performance
– this indicates a need for service.
22. Replacement Parts – When replacement parts are required, be
sure the service technician has used replacement parts
specified by the manufacturer or have the same characteristics
as the original part. Unauthorized substitutions may result in
fire, electric shock, or other hazards.
23. Safety Check – Upon completion of any service or repairs to
this product, ask the service technician to perform safety
checks to determine that the product is in proper operating
condition.
24. Wall or Ceiling Mounting – The product should be mounted to
a wall or ceiling only as recommended by the manufacturer.
25. Heat – The product should be situated away from heat sources
such as radiators, heat registers, stoves, or other products
(including amplifiers) that produce heat.
FIGURE A
EXAMPLE OF ANTENNA GROUNDING
AS PER NATIONAL
ELECTRICAL CODE ANTENNA
LEAD IN
WIRE
GROUND
CLAMP
ELECTRIC
SERVICE
EQUIPMENT
ANTENNA
DISCHARGE UNIT
(NEC SECTION 810-20)
GROUNDING CONDUCTORS
(NEC SECTION 810-21)
GROUND CLAMPS
POWER SERVICE GROUNDING
ELECTRODE SYSTEM
(NEC ART 250, PART H)
NEC - NATIONAL ELECTRICAL CODE

4
ENGLISH FRANCAIS ESPAÑOL
NOTE ON USE / OBSERVATIONS RELATIVES A L’UTILISATION /
NOTAS SOBRE EL USO
• Avoid high temperatures.
Allow for sufficient heat dispersion
when installed on a rack.
• Eviter des températures élevées
Tenir compte d’une dispersion de
chaleur suffisante lors de
l’installation sur une étagère.
• Evite altas temperaturas.
Permite la suficiente dispersión del
calor cuando está instalado en la
consola.
• Handle the power cord carefully.
Hold the plug when unplugging the
cord.
• Manipuler le cordon d’alimenta-tion
avec précaution.
Tenir la prise lors du débranchement
du cordon.
• Maneje el cordón de energía con
cuidado.
Sostenga el enchufe cuando
desconecte el cordón de energía.
• Keep the set free from moisture,
water, and dust.
• Protéger l’appareil contre l’humidité,
l’eau et lapoussière.
• Mantenga el equipo libre de
humedad, agua y polvo.
• Unplug the power cord when not
using the set for long periods of
time.
• Débrancher le cordon d’alimenta-tion
lorsque l’appareil n’est pas utilisé
pendant de longues périodes.
• Desconecte el cordón de energía
cuando no utilice el equipo por
mucho tiempo.
* (For sets with ventilation holes)
• Do not obstruct the ventilation holes.
• Ne pas obstruer les trous d’aération.
• No obstruya los orificios de
ventilación.
• Do not let foreign objects in the set.
• Ne pas laisser des objets étrangers
dans l’appareil.
• No deje objetos extraños dentro del
equipo.
• Do not let insecticides, benzene, and
thinner come in contact with the set.
• Ne pas mettre en contact des
insecticides, du benzène et un
diluant avec l’appareil.
• No permita el contacto de
insecticidas, gasolina y diluyentes
con el equipo.
• Never disassemble or modify the set
in any way.
• Ne jamais démonter ou modifier
l’appareil d’une manière ou d’une
autre.
• Nunca desarme o modifique el
equipo de ninguna manera.

5
ENGLISH
— TABLE OF CONTENTS —
zFeatures …………………………………………………………… 5
xConnections …………………………………………………… 6, 7
cPart Names and Functions ………………………………… 8~10
vRemote Control Unit …………………………………………… 11
bClock Adjustment …………………………………………… 12, 13
nPlaying CDs ………………………………………………… 14~16
mListening to the Radio ……………………………………… 17~19
,Volume and Tone Adjustments ………………………………… 20
.CD Functions ……………………………………………… 21~25
⁄0 Using the Timers …………………………………………… 26~33
⁄1 Cleaning ………………………………………………………… 34
⁄2 CDs ……………………………………………………………… 35
⁄3 Messages ………………………………………………………… 35
⁄4 Troubleshooting …………………………………………… 36, 37
⁄5 Major Specifications …………………………………………… 38
• ACCESSORIES
Please check to make sure the following items are included with the main unit in the carton:
qAM loop antenna ………………………………………………… 1
wFM antenna ……………………………………………………… 1
eRemote control unit (RC - 911) ………………………………… 1
rR 6 P/AA batteries ……………………………………………… 2
tOperating instructions ………………………………………… 1
yService station list ……………………………………………… 1
1FEATURES
1. 40-Stations Preset Memory
(See Page 18)
2. 6-Modes Preset Equalizer
(See Page 20)
3. Built-in deep bass circuit
(See Page 20)
Copyrights
2It is prohibited by law to reproduce, broadcast, rent or play discs in public without the consent of the copyright holder.
CAUTION
✽The ventilation should not be impeded by covering the ventilation openings with item, such as newspapers, table-cloths, curtains,
etc.
✽No naked flame sources, such as lighted candles, should be placed on the apparatus.
✽Please be care the environmental aspects of battery disposal.
✽The apparatus shall not be exposed to dripping or splashing for use.
✽No objects filled with liquids, such as vases, shall be placed on the apparatus.
ewq r
10 cm or greater
• CAUTION ON INSTALLATION
Wall
RATING SHEET

6
ENGLISH
2CONNECTIONS
• Do not plug in the power plug into an outlet until all connections
have been completed.
• Insert the power plug securely. An incomplete connection will
cause noise to occur.
NOTES:
• Do not bundle the (pin plug) connection cables together or place
them close to other electrical products such as TVs since this may
cause hum or other noise.
(1) Connecting Antennas and Audio Equipment
1. Pull out 2. Bend 3. Insert into hole 1. Lower the lever 2. Insert wire 3. Release
Rear Panel Names and Connections
Connection of Audio Equipment
qFM antenna terminal
wMONO output terminal
eAUX input terminal
rAM loop antenna terminals
• These connect the supplied AM loop antenna.
MONO
OUT
AM
LOOP ANT.
FM
AUX IN
ANTENNA
wq e r
50
MIN
To listen to equipment that is connected to the external input
terminals, set the input to “AUX” with the remote control
external input selection button.
Assembly of the AM loop antenna Connection of the AM loop antenna
Super woofer
FM antenna
Power cord
Use a connection cable
that is available on the
market.
Portable player, etc.
AM loop antenna
Note to CATV system installer:
This reminder is provided to call the CATV system installer’s
attention to Article 820-40 of the NEC which provides guidelines
for proper grounding and, in particular, specifies that the cable
ground shall be connected to the grounding system of the
building, as close to the point of cable entry as practical.

7
ENGLISH
(2) Setting Up the Antennas
Setting Up the AM Loop Antenna
Connection of an AM Outdoor Antenna
Ground Rod
Setting Up an FM Indoor Antenna
Tune in an FM broadcast (See Page 17) and while listening to
the sound find the position where distortion and noise are at
a minimum. Secure the antenna at this position by taping the
ends of the antenna in place or by using thumb tacks.
Tune in an AM broadcast (See Page 17) and while listening
to the sound separate the antenna from the main unit as
much as possible and place the antenna in a position where
distortion and noise are at a minimum. In some
circumstances, a reverse polarity of the connection will
provide better reception.
Failure to connect the AM loop antenna, or placement near
metal objects will result in poor reception of AM broadcasts.
Connect the signal wires of the AM outdoor antenna to the
AM antenna terminals (marked AM ANTENNA). Be certain to
leave the supplied AM loop antenna connected.
AM
LOOP ANT.
• A ground connection can serve to prevent an electrical
shock accident. Embed a ground rod in the ground or
make a connection to an iron water pipe.
• Do not make a connection to a gas pipe because this is
very dangerous.
AM antenna terminals
AM outdoor antenna
(10 to 12 meters of vinyl covered wire)
LOOP ANT.

8
ENGLISH
3PART NAMES AND FUNCTIONS
(1) Front Panel
ON/STANDBY OPEN/CLOSE
SKIP
TUNER
VOL.
UP
DOWN
C D
AUX PLAY MODE
q w
tu
i o
e
ry
VERTICAL LOADING SYSTEM
COMPACT DISC PLAYER
REMOTE
SENSOR
CD STEREO RECEIVER
D-AJ03
40-STATIONS PRESET MEMORY
6-MODES PRESET EQUALIZER
!0 !1
!4 !2!3
qPower Operation Switch (ON/STANDBY)
• Press to switch on the power and press again to set
the standby mode.
wTUNER Button
• Press to switch the input to “TUNER”.
eExternal Input Selection Button (AUX)
• See Page 6.
rPlay Mode Select Button (PLAY MODE)
• See Page 22.
tSkip Button (8/9)
• Permits fast reverse and forward of the track.
• Used to adjust the reception frequency when the
function is set to tuner.
yCD Play/Pause Button (CD 1/3)
• Press to switch the input to “CD” and start playing
the CD if one has been loaded.
• Press again to pause the track.
uCD Stop Button (CD 2)
• Use to stop play or recording.
• Press to switch the input to “CD”.
iVolume Control Button (VOL. UP/DOWN)
• Use to lower or raise the volume.
oCD Door Open/Close Button (5)
• Press and the CD door goes down.
• Press again and the CD door goes up.
!0 CD Door
• A press of the CD Door Open/Close button makes the
door go down and allows a CD to be loaded.
!1 Speakers
!2 REMOTE SENSOR
• Aim the supplied remote control at this sensor and
operate.
!3 Display
• See Page 9.
!4 Headphone Jack (PHONES)
• Allows the use of headphones (available on the
market).
• Insertion of the headphone plug switches off the
sound from the speakers and allows you to listen just
from the headphones.

9
ENGLISH
(2) Display
RANDOM PROG
DIGEST
TUNED
STEREO
SLEEP
PLAY
TOTAL REMAIN
TRACK
KHz
MHz
FM
AM
TIMER
SDB
ST
EQ
z
x
qMain Display Portion
• Displays various functions, the time, the timer
settings, etc.
• The following is displayed when the function is
switched to CD.
• Track number display section (TRACK):
When a disc is loaded.
Stop mode:
Total number of tracks on disc
Play and programmed play modes:
Currently playing track.
• Time display section:
When a disc is loaded.
Stop mode:
Total number of tracks on disc.
Play and programmed play modes:
Elapsed time of currently playing track.
• The volume level is displayed when the volume is
being adjusted.
wMode display portion
1:
Lights in the play mode .
3:
Lights in the pause mode.
DIGEST:
Lights in the digest play mode.
RANDOM:
Lights in the random play mode.
:
Lights in the repeat play mode.
PROG:
Lights in the programmed play mode.
TUNED:
Lights when a broadcast is tuned in.
STEREO:
Lights when the tuner is set to the stereo reception
mode.
:
Lights during reception of an AM broadcast.
:
Lights during reception of a FM broadcast.
:
Lights when a stereo broadcast is tuned in.
SLEEP:
Light when the sleep timer is set.
:
Lights when the timer is set.
:
Lights when the everyday timer is set.
PLAY:
Lights when timer playback is set.
/ :
Displays the current tone settings.
SDBEQ
TIMER
ST
FM
AM

C D
POWER
VOLUME
TIMER/DELETE
PLAY MODE
PROG.
ENTER CLEAR
TUNING/
PRESET
EQAUXFM/AM
SDB
RC-911
10
ENGLISH
(3) Names and Functions of the Remote Control Buttons
Power Button (POWER)
CD Play/Pause Button (CD 1/3)
........................................................(14)
CD Stop Button (CD 2)
........................................................(15)
Automatic Search Buttons
(8/9).............................(15 , 17)
Tuning/Preset Button (–/+)
........................................................(18)
ENTER Button (ENTER)
CLEAR Button (CLEAR)
Remote control signal transmitter
Band Select Button (FM/AM)
........................................................(17)
External Input Selection Button
(AUX) ................................................(6)
Volume Adjustment Buttons
(VOLUME / ) ......................(20)
Super Dynamic Bass Button
(SDB) ..............................................(20)
Equalizer Button (EQ)
........................................................(20)
TIMER/DELETE Button
(TIMER/DELETE).....................(12 , 27)
PLAY MODE Select Button
(PLAY MODE) .................................(22)
Program Button (PROG.)
........................................................(23)
Direct Selection Button
........................................................(21)

11
ENGLISH
4REMOTE CONTROL UNIT
2The D-AJ03 can be controlled from a distance using the included remote control unit (RC - 911).
(1) Inserting Batteries
qRemove the remote control unit’s rear cover.
wPlace two R 6 P (AA) batteries in the battery compartment
in the direction indicated by the marks.
eClose the rear cover.
Cautions On Batteries
• Use R6P (AA) batteries in this remote control unit.
• Replace the batteries with new ones approximately
once a year, though this depends on the frequency
with which the remote control unit is used.
• If the remote control unit does not operate from close
to the main unit, replace the batteries with new ones,
even if less than a year has passed.
• The included battery is only for verifying operation.
Replace it with a new battery as soon as possible.
• When inserting the batteries, be careful to do so in the
proper direction, following the <and >marks in the
remote control unit’s battery compartment.
• To prevent damage or battery fluid leakage:
• Do not use a new battery with an old one.
• Do not use two different types of batteries.
• Do not short-circuit, disassemble, heat or dispose of
batteries in flames.
• Remove the batteries when not planning to use the
remote control unit for a long period of time.
• If the batteries should leak, carefully wipe off the fluid
from the inside of the battery compartment, then insert
new batteries.
(2) Using the Remote Control Unit
• When operating the remote control unit, point it at the
remote control sensor as shown on the diagram.
• The remote control unit can be used from a direct
distance of approximately 7 meters. This distance will
be shorter, however, if there are obstacles in the way
or if the remote control unit is not pointed directly at
the remote control sensor.
• The remote control unit can be operated at a horizontal
angle of up to 30° with respect to the remote control
sensor.
DIGEST
TRACK
SDB
EQ
GP
MD
CDSTEREORECEIVER
D-AJ03
40-STATIONSPRESETMEMORY
6-MODESPRESETEQUALIZER
REMOTE
SENSOR
VERTICALLOADINGSYSTEM
COMPACTDISCPLAYER
ON/STANDBYOPEN/CLOSE
SKIP
TUNER
VOL.
UP
DOWN
CD
AUXPLAYMODE
30
30
NOTES:
•It may be difficult to operate the remote control unit if the remote control sensor is exposed to direct sunlight or strong
artificial light.
•Do not press buttons on the main unit and on the remote control unit at the same time. Doing so will result in malfunction.
Approx. 7 meters

12
ENGLISH
5CLOCK ADJUSTMENT
ON/STANDBY OPEN/CLOSE
SKIP
TUNER
VOL.
UP
DOWN
C D
AUX PLAY MODE
(1) Clock adjustment
C D
POWER
VOLUME
TIMER/DELETE
PLAY MODE
PROG.
ENTER CLEAR
TUNING/
PRESET
EQAUXFM/AM
SDB
RC-911
(Example) Set the current time to “PM7:30” (7:30 p.m.).
1Press (or on the remote control) to turn the
power on.
POWER
ON/STANDBY
2Press on the remote control.
TIMER/DELETE
SLEEP 1:00
3
4
5
6
Within 10 seconds, press on the remote control
to select “ TIME ADJUST ”.
TUNING/
PRESET
Within 10 seconds, press on the remote control.
ENTER
Press on the remote control to adjust the hour
“ PM 7 ”, and then press on the remote control.
ENTER
TUNING/
PRESET
Press to adjust the minutes “ 30 ”, and then
press .
ENTER
TUNING/
PRESET
TIME ADJUST
AM12:00
PM 7:00
PM 7:30
Adjust the hour
Adjust the minutes
•The time display will disappear after a few second.
1
ON/STANDBY
Button
1
POWER
Button
4, 5, 6
ENTER
Button
3, 5, 6
TUNING/
PRESET
Button
2
TIMER/
DELETE
Button

13
ENGLISH
(2) To correct the Time
Redo from Operation 1.
✽During this procedure, “STANDBY ”is displayed in
Operation 2 and the current setting time is displayed in
Operation 3.
NOTE:
•The clock setting will be cleared when the unit is
unplugged or the power failure occurs.
Perform “Clock adjustment”form the beginning.

14
ENGLISH
6PLAYING CDs
ON/STANDBY OPEN/CLOSE
SKIP
TUNER
VOL.
UP
DOWN
C D
AUX PLAY MODE
C D
POWER
VOLUME
TUNING/
PRESET
EQAUXFM/AM
SDB
(1) Playing CDs
1
2
3
Press (or on the remote control) to turn the power on.
POWER
ON/STANDBY
Press (or on the remote control) to set the
input to “CD”.
C D
C D
Press of the main unit to open the CD door.
5OPEN/CLOSE
CD NO DISC
CD OPEN
4Set a CD and press to close the door.
5OPEN/CLOSE
•CD door will close automatically.
Load a CD firmly with the label side facing
to ward you.
CD CLOSE
TOTAL
TRACK
CD 16 72:31
The total number
of tracks
The total
playing time
5Press (or on the remote control) to start
playback.
C D
C D
•Play will start from the first track and continue in order. The unit will automatically stop at the completion of the last
track.
✽When opening the CD door, by pressing (or on the remote control), you can close the CD door
automatically.
C D
C D
TRACK
CD 10:01
•Loading a CD
1
ON/STANDBY
Button
5
CD 1/3
Button
3, 4
5OPEN/
CLOSE Button
2
CD 2
Button
2
CD 2
Button
1
POWER
Button
5
CD 1/3
Button

15
ENGLISH
ON/STANDBY OPEN/CLOSE
SKIP
TUNER
VOL.
UP
DOWN
C D
AUX PLAY MODE
C D
POWER
VOLUME
TIMER/DELETE
PLAY MODE
ENTER CLEAR
TUNING/
PRESET
EQAUXFM/AM
SDB
(2) Stopping Play
(3) Pausing
During playback, press (or on the remote
control).
C D
C D
(4) To locate the beginning of a track
During playback, press (or on the remote
control).
C D
C D
✽One more press of the button will start play from the paused position.
[To restart the track being played]
Press (or on the remote
control) once during playback.
SKIP
[When selecting the previous track number]
Press (or on the remote
control) during stop.
SKIP
✽You can skip to any track by pressing the button
repeatedly until the desired track number appears.
✽When playback is started after displaying the desired track number in stop mode, playback starts from the beginning of
that track.
✽The direct selection button of the remote control can be used to select track numbers. (See Page 21.)
[To move to the beginning of the next track]
Press (or on the remote
control) once during playback.
SKIP
[When selecting the next track number]
Press (or on the remote
control) during stop.
SKIP
✽You can skip to any track by pressing the button
repeatedly until the desired track number appears.
TOTAL
TRACK
CD 16 72:31
TRACK
PAUSE
CD 3 1:23
SKIP
Button
CD 1/3
Button
CD 1/3
Button
CD 2
Button CD 2
Button
8,9
Button

16
ENGLISH
ON/STANDBY OPEN/CLOSE
SKIP
TUNER
VOL.
UP
DOWN
C D
AUX PLAY MODE
C D
POWER
VOLUME
TIMER/DELETE
PLAY MODE
ENTER CLEAR
TUNING/
PRESET
EQAUXFM/AM
SDB
(5) Removing the CD
Precautions When Loading the CD
Press (or on the remote control) to stop the CD,
then press .
5OPEN/CLOSE
C D
C D
•After the CD door opens, pull out the CD.
TOTAL
TRACK
CD 16 72:31
CD OPEN
✽When the unit is not being used , press and be sure to close the CD door.
5OPEN/CLOSE
•Load only one CD. The loading of two or more (one above the other) will cause a breakdown and may scratch the CDs.
•Be careful not to get your fingers caught when the CD door opens or closes.
•Do not use CDs that are cracked, misshapen, or have been repaired with adhesives, etc.
•Do not use CDs that have the exposed adhesive or marks remaining from cellophane tape, rental CD labels, or other
sources. Use of CDs in this condition will result in difficulty in removing the CD or could cause breakdown.
CD eject button
CD 2
Button
CD 2
Button
5OPEN/
CLOSE Button

17
ENGLISH
7LISTENING TO THE RADIO
(1) Station Selection
ON/STANDBY OPEN/CLOSE
SKIP
TUNER
VOL.
UP
DOWN
C D
AUX PLAY MODE
C D
POWER
VOLUME
TIMER/DELETE
PLAY MODE
PROG.
ENTER CLEAR
TUNING/
PRESET
EQAUXFM/AM
SDB
(Example) Set the reception frequency to “89.5 MHz, FM”.
1Press (or on the remote control) to turn the power on.
POWER
ON/STANDBY
2Press (or on the remote control) to select FM.
FM/AM
TUNER
✽The tuner mode changes as follow each time the button pressed.
STEREO
MHz
FM
MHz
FM
KHz
AM
87.5 87.5 520
STEREO
MHz
FM
ST
87.5
3Press (or on the remote control) and
set the receive frequency to “89.5 MHz, FM”.
SKIP
•Auto Tuning:
Hold the tuning button down for more than 1 second and release to
automatically receive broadcast stations with strong signals.
To stop auto tuning, press the tuning button of the opposite direction once.
•Manual Tuning:
Press the button in short steps to also permit reception of stations having weak
signals.
TUNED
STEREO
MHz
FM
ST
89.5
2
TUNER
Button
1
ON/STANDBY
Button
3
SKIP
Button
1
POWER
Button
2
FM/AM
Button
3
8/9
Button

18
ENGLISH
(2) Storing Broadcast Stations
2Up to 40 FM and AM stations can be preset.
C D
POWER
VOLUME
TIMER/DELETE
PLAY MODE
PROG.
ENTER CLEAR
TUNING/
PRESET
EQAUXFM/AM
SDB
RC-911
(Example) Store the tuned “89.5 MHz, FM” to preset number “3”.
1Receive the broadcast station “89.5 MHz, FM” that you
want to store to preset memory.
TUNED
STEREO
MHz
FM
ST
89.5
2Press .
ENTER
TUNED
STEREO
MHz
FM
ST
P1 89.5
3Within 5 seconds, press to display the number
that you want to store.
TUNING/
PRESET
TUNED
STEREO
MHz
FM
ST
P 3 89.5
(Which in this example will be “3”.)
4Within 5 second, press .
ENTER
✽When a new station is stored in memory, the station previously memorized will
be erased.
TUNED
STEREO
MHz
FM
ST
P 3 89.5
✽Repeat step 1 to 4 to set other station, or change a preset station.
3
TUNING
/PRESET
Button
2, 4
ENTER
Button

19
ENGLISH
(3) Listening to Preset Stations
(4) To erase the contents of the preset memory
(Example) Listen to the station of preset number “3” that was set in step (2).
ON/STANDBY OPEN/CLOSE
SKIP
TUNER
VOL.
UP
DOWN
C D
AUX PLAY MODE
C D
POWER
VOLUME
TIMER/DELETE
PLAY MODE
PROG.
ENTER CLEAR
TUNING/
PRESET
EQAUXFM/AM
SDB
RC-911
Turn the power on and press
(or on the remote control).
FM/AM
TUNER
1
2Press to select the desired
station.
TUNING/
PRESET
TUNED
STEREO
MHz
FM
ST
P 3 89.5
(Select numbers)
✽The direct button on the remote control allow you
to recall a memorized station.
2To select preset station between 1 to 10:
Select numbers that were registered in to
.
2To select preset station between 11 to 40:
Press , then select the registered numbers.
(Example) To choose 28.
Press /Press /Press .
✽When buttons are pressed in succession, press the
next button within 5 seconds.
C D
POWER
VOLUME
TIMER/DELETE
PLAY MODE
PROG.
ENTER CLEAR
TUNING/
PRESET
EQAUXFM/AM
SDB
RC-911
1Press and hold down for 3
seconds or more.
CLEAR
TUNED
STEREO
MHz
FM
TUNER CLEAR
2Press .
ENTER
TUNED
STEREO
MHz
FM
COMPLETE
NOTE:
•The backup function protect the memorized stations for a few hours should there be a power failure or the AC lead
disconnection.
1
TUNER
Button
2
TUNING/
PRESET
Button
1
FM/AM
Button
2
ENTER
Button
1
CLEAR
Button

20
ENGLISH
8VOLUME AND TONE ADJUSTMENTS
ON/STANDBY OPEN/CLOSE
SKIP
TUNER
VOL.
UP
DOWN
C D
AUX PLAY MODE
C D
POWER
VOLUME
TIMER/DELETE
PLAY MODE
PROG.
ENTER CLEAR
TUNING/
PRESET
EQAUXFM/AM
SDB
RC-911
(1) Adjust the volume
(2) Boosting Bass
(3) Changing the Tone
1Press or (or, or on the
remote control).
VOLUME
VOLUME
VOL.
DOWN
VOL.
UP
VOLUME 12
Volume 0 (Min) ~ MAX
1Press on the remote
control.
SDB
SDB ON
Emphasize Do not Emphasize
SDB OFF
1Press on the remote
control.
Flat response
Suited for Classic
Suited for Jazz
Suited for Rock
Suited for Pops
Vocals are emphasized
FLAT
EQ
CLASSIC
EQ
JA
EQ
ROCK
EQ
POPS
EQ
VOCAL
VOL.
Button
VOLUME
Button
SDB
Button
EQ
Button
