Denso BHT-1170BWB-CE User manual

BHT-1100 Series
User's Manual
Barcode Handy Terminal
BHT-1170BWB-CE
BHT-1171BWB-CE






















i
BHT-1170BWB-CE / BHT-1171BWB-CE
Preface
Thank you for using the BHT-1100BWB-CE / BHT-1171BWB-CE DENSO WAVE Barcode Handy Terminal.
Please read this manual thoroughly prior to operation to ensure full use of the product’s functionality, and store safely
in a convenient location for quick reference even after reading.
If the BHT is left with the battery discharged or with the battery removed, or if the battery is replaced incorrectly, data
including files and settings stored in the RAM may be lost. When performing full reset (refer to “Chapter 2 BHT
Preparation” – “2.6 Resetting and Full Resetting”), all data including files and settings stored in the RAM will also be
lost and the RAM will revert to the factory default. It is recommended that any important data be backed up to the
“FLASH” folder or to the computer before full reset. When the BHT turns ON after the data in the RAM is deleted, the
BHT starts from the “Initial Setup” (refer to “Chapter 2 BHT Preparation” – “2.4 Initial Setup”).
Microsoft, ActiveSync, Windows and the Windows logo are trademarks or registered trademarks of Microsoft
Corporation of the US or other countries.
Bluetooth®is a trademark owned by its proprietor. DENSO WAVE uses Bluetooth®wireless technology under license.
Other company names or product names contained in this manual are trademarks or registered trademarks of their
respective holders.
Some of the pixels on the LCD touch screen may not illuminate or stay permanently illuminated. Furthermore, there
may also be inconsistencies in color and brightness. None of these aspects represent an LCD defect.
A thin Newton's ring (rainbow-like patterns) may appear on the touch panel.
This does not necessarily indicate a problem with the touch panel.
Liability Limitations
•DENSO WAVE INCORPORATED does not assume any product liability (including damages for lost profits,
interruption of operations, or the loss of business-related information) arising out of, or in connection with, the
use of, or inability to use the BHT system software or related manuals.
•DENSO WAVE INCORPORATED (“DENSO WAVE”) takes reasonable precautions to ensure its products do not
infringe upon any patents or other intellectual property rights of other(s), however, DENSO WAVE cannot be
responsible for any patent or other intellectual property right infringement(s) or violation(s) arising from any of the
following.
1) The use of DENSO WAVE's products in connection or in combination with other components, products,
devices, data processing systems or software not supplied by DENSO WAVE.
2) The use of DENSO WAVE's products in a manner for which they were not intended nor designed.
3) The modification of DENSO WAVE's products by parties other than DENSO WAVE.
•If it is judged by DENSO WAVE INCORPORATED that malfunction of the product is due to the product having
been dropped or subjected to impact, repairs will be made at a reasonable charge even within the warranty
period.

ii
Barcode Handy Terminal
Customer Registration and Inquiries
Customer Registration
To allow us to provide our customers with comprehensive service and support, we request that all customers
complete a Member Registration Form. Registered members will be offered the following privileges.
•The latest upgrade information
•Free exhibition and event information for new products
•Free Web-information service "QBdirect".
QBdirect Service Contents
Information search service (FAQ) Offers detailed information on each product.
Download service Offers downloads of repair modules for the latest BHT Series
systems or software, and sample programs.
E-mail inquiries Product related queries can be sent in by e-mail.
* Please note that these privileges may be subject to change without prior notice.
−How to Register
Access the URL below and follow the instructions provided.
http://www.qbdirect.net/
Inquiries
−Technical Inquiries (QBdirect)
•BHT product programming method
•Product setup method, usage
•Other technical questions
Inquires relating to the above can be made at our exclusive Web site for registered users (QBdirect).
Access the link below to log on or register.

iii
BHT-1170BWB-CE / BHT-1171BWB-CE
About this Manual
•Due to improvements and so on, the content of this manual may be subject to change without prior notice.
•The reproduction or duplication of the whole or part of this manual is strictly prohibited without prior consent.
•Every attempt has been made to ensure that the content of this manual is thorough and up to date; however, we
kindly ask that any questionable content, mistakes, or omissions be reported to DENSO WAVE.
•The copyright for this User’s Manual belongs to DENSO WAVE INCORPORATED.
•Lettering in the screens in this User’s Manual is a little different from that in the actual screens. File names used
are only for description purposes, and will therefore not display if files have not been set with the same names.
Manual Composition
This manual is made up of the following 9 chapters.
Chapter 1 Outline
Describes the BHT system and provides an overall outline of the BHT.
Chapter 2 BHT Preparation
Describes information required by the user and procedures that must be performed prior to
commencing operation.
Chapter 3 Basic Operation
Describes how to scan barcodes using the BHT, the backlight function, how to use the keypad, and
BHT data transmission.
Chapter 4 System Operation
Describes how to operate the desktop, Start menu and System Menu, and how to make wireless
network settings.
Chapter 5 Communication
Describes technical information on BHT Ethernet communication, Bluetooth®communication, and
wireless communication, and provides details of Microsoft ActiveSync.
Chapter 6 Maintenance
Describes battery replacement, and daily procedures for taking care of the BHT and CU.
Chapter 7 Error Messages
Describes causes and countermeasures for error messages that display during BHT use.
Chapter 8 Specifications
Describes specifications for hardware, readable barcodes, and interfaces.
Chapter 9 Appendices
Describes the CU-1100 Series.

iv
Barcode Handy Terminal
Viewing this Manual
−About the Bookmark
The PDF Bookmark function can be used to jump to the Contents page.
<Procedure>
(1) Click the “Bookmark” tab.
(2) Click to search for the desired item.
(3) Click the item to be read.
(3) Click the item to be read.
(1) Click the “Bookmarks” tab.
(2) Click “+” to search for the desired item.

v
BHT-1170BWB-CE / BHT-1171BWB-CE
−Searching by Word
The PDF search function can be used to jump to the target page by entering words or characters related to the
item being searched.
(1) Click the Search icon. (Or select “Edit” – “Search”.)
(2) Enter the word(s) or character(s) to be searched for.
(3) Click [Search].
<Search Results Example>
(2) Enter the search word(s)
or character(s).
(3) Click [Search].
(1) Click the Search icon.

vi
Barcode Handy Terminal
Related Documentation
•BHT API Reference Manual
•BHT Class Library Reference Manual

vii
BHT-1170BWB-CE / BHT-1171BWB-CE
SAFETY PRECAUTIONS
Be sure to observe all these safety precautions.
Please READ through this manual carefully. It will enable you to use the BHT and CU correctly.
Always keep this manual nearby for speedy reference.
Strict observance of these warnings and cautions is a MUST for preventing accidents that could result in bodily injury
and substantial property damage. Make sure you fully understand all definitions of these terms and symbols given
below before you proceed to the text itself.
Alerts you to those conditions that could cause serious bodily injury or death if the instructions are not followed correctly.
Alerts you to those conditions that could cause minor bodily injury or substantial property damage if the instructions are not followed correctly.
Meaning of Symbols
A triangle ( ) with a picture inside alerts you to a warning of danger. Here you see the warning for electrical
shock.
A diagonal line through a circle ( ) warns you of something you should not do; it may or may not have a picture
inside. Here you see a screwdriver inside the circle, meaning that you should not disassemble.
A black circle ( ) with a picture inside alerts you to something you MUST do. This example shows that you
MUST unplug the power cord.

viii
Barcode Handy Terminal
Handling the battery
•Never disassemble or heat the battery, nor put it into fire or water; doing so could cause battery-rupture
or leakage of battery fluid, resulting in a fire or bodily injury.
•Do not carry or store the battery together with metallic ball-point pens, necklaces, coins, hairpins, etc.
Doing so could short-circuit the terminal pins, causing the batteries to rupture or the battery fluid to leak,
resulting in a fire or bodily injury.
•Never put the battery into a microwave oven or high-pressure container.
Doing so could cause the batteries to break, generate heat, rupture or burn.
•Avoid dropping the battery or letting it undergo any shock or impact.
Doing so could cause the batteries to break, generate heat, rupture or burn.
•Never charge the rechargeable battery where any inflammable gases may be emitted; doing so could
cause fire.
•Only use the dedicated charger for charging the rechargeable battery.
Using a different type of charger could cause battery-rupture or leakage of battery fluid and result in a
fire, bodily injury, or serious damage to property.
Handling the BHT
•Never put the BHT into a microwave oven or high-pressure container.
Doing so could cause the BHT to break, generate heat, rupture or burn.
•Do not poke at the eyes with the stylus that comes with the BHT.

ix
BHT-1170BWB-CE / BHT-1171BWB-CE
Handling the CU
•If smoke, abnormal odors or noises come from the CU, immediately unplug the AC adapter from the
wall socket or CU and contact your nearest dealer.
Failure to do so could cause fire or electrical shock.
•If foreign material or water gets into the CU, immediately unplug theAC adapter from the wall socket or
CU and contact your nearest dealer.
Failure to do so could cause fire or electrical shock.
•If you drop the CU so as to damage its housing, immediately unplug the AC adapter from the wall
socket or CU and contact your nearest dealer.
Failure to do so could cause fire or electrical shock.
•Never use the CU for charging anything other than the specified batteries.
Doing so could cause heat, battery-rupture, or fire.
•Never bring any metals into contact with the output terminals.
Doing so could produce a large current through the CU, resulting in heat or fire, as well as damage to
the CU.
•Never use the CU on the line voltage other than the specified level.
Doing so could cause the CU to break or burn.
•Use the dedicated AC adapter only.
Failure to do so could result in fire.
•If the power cord of the AC adapter is damaged (e.g., exposed or broken lead wires), stop using it and
contact your nearest dealer.
Failure to do so could result in a fire or electrical shock.

x
Barcode Handy Terminal
To System Designers:
•When introducing BHTs in those systems that could affect human lives (e.g., medicines management
system), develop applications carefully through redundancy and safety design which avoids the
feasibility of affecting human lives even if a data error occurs.
Handling the battery
•Never charge a wet or damp rechargeable battery.
Doing so could cause the batteries to break, generate heat, rupture or burn.
Handling the BHT
•If smoke, abnormal odors or noises come from the BHT, immediately turn off the power, pull out the
battery, and contact your nearest dealer.
Failure to do so could cause smoke or fire.
•If foreign material or water gets into the BHT, immediately turn off the power, pull out the battery, and
contact your nearest dealer.
Failure to do so could cause smoke or fire.
•If you drop the BHT so as to damage its housing, immediately turn off the power, pull out the battery,
and contact your nearest dealer.
Failure to do so could cause smoke or fire.
•Do not use batteries or power sources other than the specified ones; doing so could generate heat or
cause malfunction.
•When using the hand belt, exercise due care to avoid getting them caught in other objects or entangled
in rotating machinery.
Failure to do so could result in accident or injury.
Never dis-
assemble
•Never disassemble or modify the BHT; doing so could result in an accident such as break or fire.
•Never put the BHT in places where there are excessively high temperatures, such as inside closed-up
automobiles, or in places exposed to direct sunlight.
Doing so could affect the housing or parts, resulting in a fire.
•Avoid using the BHT in extremely humid or dusty areas, or where there are drastic temperature
changes.
Moisture or dust will get into the BHT, resulting in malfunction, fire or electrical shock.
•In environments where static electricity can build into significant charges (e.g., if you wipe off the plastic
plate with a dry cloth), do not operate the BHT. Doing so will result in malfunction or machine failure.
•Do not apply excessive force when inserting or removing the rechargeable battery.
Doing so will result in damage.
•Tap the LCD only with the stylus that comes with the BHT.
Using the tip of a pen or any pointed object will result in a damaged or broken LCD.
•Put your palm of the hand through the hand belt.
If you put your arm through the hand belt, it can be broken.

xi
BHT-1170BWB-CE / BHT-1171BWB-CE
Handling the CU
•Never disassemble or modify the CU; doing so could result in an accident such as fire or malfunction.
•Never put the CU in places where there are excessively high temperatures, such as inside closed-up
automobiles, or in places exposed to direct sunlight.
Doing so could affect the housing or parts, resulting in a fire.
•Avoid using the CU in extremely humid or dusty areas, or where there are drastic temperature changes.
Moisture or dust will get into the CU, resulting in malfunction, fire or electrical shock.
•Never cover or wrap up the CU or AC adapter in a cloth or blanket.
Doing so could cause the unit to heat up inside, deforming its housing, resulting in a fire.
Always use the CU and AC adapter in a well-ventilated area.
•Do not place the CU anyplace where it may be subjected to oily smoke or steam, e.g., near a cooking
range or humidifier.
Doing so could result in a fire or electrical shock.
•Keep the power cord away from any heating equipment.
Failure to do so could melt the sheathing, resulting in a fire or electrical shock.
•Do not insert or drop foreign materials such as metals or anything inflammable through the openings or
vents into the CU.
Doing so could result in a fire or electrical shock.
•If you are not using the CU for a long time, be sure to unplug the AC adapter from the wall socket for
safety.
Failure to do so could result in a fire.
•When caring for the CU, unplug the AC adapter from the wall socket for safety.
Failure to do so could result in an electrical shock.

xii
Barcode Handy Terminal

1.1 System Configuration··················································································2
1.1.1 Hardware Configuration···················································································2
1.1.2 Software Configuration·····················································································3
1.2 Component Names and Functions······························································4
1.2.1 BHT Front / Rear······························································································4
1.2.2 CU Front / Rear································································································6
1.2.3 Keypad ·············································································································7
1.2.4 BHT Screen······································································································9
BHT-117
0
BWB-
C
E
/
BHT-1171BWB-
C
E
Chapter 1
Outline
This chapter describes the BHT system and provides an overall outline of the BHT.

2
BHT-1170BWB-CE / BHT-1171BWB-CE
1.1 System Configuration
This section describes the hardware required for the barcode data collection system used by the BHT and the BHT
software.
1.1.1 Hardware Configuration
In addition to the BHT, the following hardware is required for the barcode data collection system used by
the BHT.
Please note that certain components of the required hardware will differ depending on the type of
communication used.
Host computer
BHT Wireless LAN access point
(option)
Wireless
communication
BHT
Ethernet
BHT
Ethernet
communication
Bluetooth®-enabled
devices (option)
Bluetooth
®
communication
CU-1111
CU-1133
USB / RS232C
communication

3
Barcode Handy Terminal
1.1.2 Software Configuration
[1] BHT Operating System (OS)
Microsoft Windows Embedded CE 6.0 R3
[2] Application Program Development Environment
Refer to "BHT API Reference Manual".
"BHT Class Library Reference Manual”

4
BHT-1170BWB-CE / BHT-1171BWB-CE
1.2 Component Names and Functions
1.2.1 BHT Front / Rear
(4)
(11)
(1)
(8)
(7)
(5)
(9)
(2)
(3)
(6)
(10)
(12)

5
Barcode Handy Terminal
No. Name Function and Description
(1) Speaker Emits sound
(2) Indicator LED Illuminates in red during charging and turns green upon completion of charging.
Indicates the barcode read status.
Illuminates in blue when the BHT has successfully read a barcode.
(3)
IEEE802.11b/g/n
built-in antenna
Bluetooth®built-in antenna
Used to communicate with the wireless LAN access point.
Do not cover this antenna section with metal-evaporated tape or by hand. Doing so may result in
communication failures.
Used to communicate with other Bluetooth®-enabled devices.
Do not cover this antenna section with metal-evaporated tape or by hand. Doing so may result in
communication failures.
(4) LCD (with Touch panel) Displays the characters and graphic patterns. Data may be entered by tapping the screen
directly with the stylus.
(5) Interface port BHT charge terminals and interface port
(6) Trigger key Press when scanning a barcode.
(This key performs the same function as the Scan key.)
(7) Reading window Align the reading window with barcodes to perform barcode scanning.
(8) Battery cover lock Use this to lock or unlock the battery cover.
(9) Battery cover Remove this cover to replace the battery.
(10) Battery Main BHT power source
(11) Hand belt Always put your hand through this belt to prevent the BHT from being dropped accidentally.
(12) Camera(BHT-1171 only) Use this to take pictures.

6
BHT-1170BWB-CE / BHT-1171BWB-CE
1.2.2 CU Front / Rear
CU is a battery charger with communication function and represents CU-1111 and CU-1133.
Both of these units are referred to collectively as CU in this manual, and unless otherwise indicated,
this represents the CU-1111, CU-1133.
NO. Name Function and Description
(1) LED Panel
Power communication LED
Lights green when the power is applied to the CU.
The green is blanking during communication.
Spare battery charge LED
Illuminates red during battery charge and turns green upon completion of charging.
(2) BHT charge terminals and
interface terminals
BHT charge terminals
Do not stain these terminals; doing so could result in a lower charging efficiency. Clean these
terminals periodically
Interface terminals
Used to exchange data with the BHT.
(3) Spare battery charging slot Do not stain these terminals; doing so could result in a lower charging efficiency. Clean these
terminals periodically
(4) Power inlet connector DC12V : Using dedicated AC adapter
(5) Interface connector
Used to exchange data with the host computer or communication station.
The CU-1111 has an Ethernet port (100Base-T).
The CU-1133 has an RS-232C port and a USB port.
Power communication LED Spare battery charge LED
(3)
(4) (5)
(2)
(1)
CU-1111
CU-1133
(4) (5)

7
Barcode Handy Terminal
1.2.3 Keypad
The BHT key functions can be set at user programs.
The diagram below shows an example of settings for each key function.
(4) (5)
(1) (3)
(2)
(6)
(9)
(10)
(11)
(16)
(12)
(17)
(13)
(14)
(18)
(15)
(8)
(7)
