Hardware User’s ManualHardware User’s ManualHardware User’s Manual

i
BHT-1300-CE Series
Preface
Read this manual thoroughly before using the product to ensure the proper use of the product and its functions, and
keep the manual in a convenient location as a quick reference.
Back up any important data to the “FLASH” folder or to the computer for data protection.
Data including files and settings stored in the RAM;
- could be lost, if the battery is left discharged or removed, or replaced incorrectly.
- will be lost, when performing full reset (refer to “Chapter 2 BHT Preparation” – “2.7 Resetting and Full Resetting”).
The RAM will be restored to the factory default after full reset.
It is strongly recommended to back up any important data before full reset.
Note: When the BHT turns ON after the data in the RAM is deleted, the BHT starts from the “Initial Setup” (refer to
“Chapter 2 BHT Preparation” – “2.4 Initial Setup”).
BHT, QR Code, iQR Code, SQRC and QBdirect are registered trademarks of DENSO WAVE INCORPORATED.
Microsoft, ActiveSync, Windows and the Windows logo are trademarks or registered trademarks of Microsoft
Corporation of the US or other countries.
Bluetooth®is a trademark owned by its proprietor and used by DENSO WAVE under license.
Other company names or product names contained in this manual are trademarks or registered trademarks of their
respective holders.
Some of the pixels on the LCD touch screen may not illuminate or stay permanently illuminated. There may also be
inconsistencies in color and brightness. None of these factors imply an LCD functional defect.
A thin Newton's ring (rainbow-like patterns) may appear on the touch panel.
This does not necessarily indicate a problem with the touch panel.
Liability Limitations
DENSO WAVE INCORPORATED does not assume any product liability (including damages for lost profits,
interruption of operations, or the loss of business-related information) arising out of, or in connection with, the
use of, or inability to use the BHT system software or related manuals.
DENSO WAVE INCORPORATED (“DENSO WAVE”) takes reasonable precautions to ensure its products do not
infringe upon any patents or other intellectual property rights of other(s), however, DENSO WAVE cannot be
responsible for any patent or other intellectual property right infringement(s) or violation(s) arising from any of the
following.
1) The use of DENSO WAVE's products in connection or in combination with other components, products,
devices, data processing systems or software not supplied by DENSO WAVE.
2) The use of DENSO WAVE's products in a manner for which they were not intended nor designed.
3) The modification of DENSO WAVE's products by parties other than DENSO WAVE.
If it is determined by DENSO WAVE INCORPORATED that malfunction of the product is due to the product
having been dropped or subjected to impact, repairs will be made at a reasonable charge even within the
warranty period.

Barcode / 2D Code Handy Terminal
Customer Registration and Inquiries
Customer Registration
To allow us to provide our customers with comprehensive service and support, we request that all customers
complete a Member Registration Form. Registered members will be offered the following privileges.
The latest upgrade information
Free exhibition and event information for new products
Free Web-information service "QBdirect".
QBdirect Service Contents
Information search
service (FAQ)
Offers detailed information on each product.
Download service Offers downloads of repair modules for the latest BHT Series systems or
software, and sample programs.
E-mail inquiries Product related queries can be sent in by e-mail.
* Please note that these privileges may be subject to change without prior notice.
−How to Register
Access the URL below and follow the instructions provided.
0Hhttp://www.qbdirect.net/
Inquiries
−Technical Inquiries (QBdirect)
BHT product programming method
Product setup method, usage
Other technical questions
Inquires relating to the above can be made at our exclusive Web site for registered users (QBdirect).
Access the link below to log on or register.
1Hhttp://www.qbdirect.net/
ii

iii
BHT-1300-CE Series
About this Manual
The contents of this manual may be subject to change without prior notice.
The reproduction or duplication of the whole or part of this manual is strictly prohibited without prior consent.
Every reasonable effort has been taken to ensure that the information contained in this manual is complete and
accurate; however, should you notice any questionable points, errors or omissions, please contact DENSO
WAVE.
The copyright for this User’s Manual belongs to DENSO WAVE INCORPORATED.
All screens in this User’s Manual are simulated. Actual screens may differ. File names used are only for
explanation purposes and will not be displayed if file names are not exactly the same.
Manual Contents
This manual consists of the following 6 chapters. Refer to the User’s Manual (Software) for details on the desktop,
start and system menus as well as on the wireless network.
Chapter 1 Outline
Describes the BHT system and overall outline of the BHT.
Chapter 2 BHT Preparation
Describes information and preparations required prior to operation.
Chapter 3 Basic Operation
Describes how to read barcodes using the BHT, the backlight function, how to use the keypad, and
BHT data transmission.
Chapter 4 Communication
Describes technical information on BHT Ethernet communication, Bluetooth®communication, and
wireless communication, and provides details of Microsoft ActiveSync.
Chapter 5 Maintenance
Describes battery replacement, and daily procedures for taking care of the BHT and CU.
Chapter 6 Specifications
Describes specifications for hardware, readable barcodes, and interfaces.
Appendices
Describes the CU-1300 Series.

Barcode / 2D Code Handy Terminal
Related Documentations
User’s Manual (Software)
BHT API Reference Manual
BHT Class Library Reference Manual
Bluetooth Library Reference Manual
kbifCE User’s Guide
SQRC Setting User’s Guide
Remote Desktop Plug-in Reference Manual
iv

v
BHT-1300-CE Series
SAFETY PRECAUTIONS
Be sure to observe all these safety precautions.
Read through this manual carefully. It will enable you to use the BHT and CU correctly.
Always keep this manual nearby for easy reference.
Strict observance of these warnings and cautions is a MUST for preventing accidents that could result in bodily injury
and substantial property damage. Make sure you fully understand all definitions of these terms and symbols given
below before you proceed to the text itself.
Alerts you to those conditions that could cause serious bodily injury or death if the instructions
are not followed correctly.
Alerts you to those conditions that could cause minor bodily injury or substantial property
damage if the instructions are not followed correctly.
Meaning of Symbols
A triangle ( ) with a picture inside alerts you to a warning of danger. Here you see the warning for electrical
shock.
A diagonal line through a circle ( ) warns you of something you should not do; it may or may not have a picture
inside. Here you see a screwdriver inside the circle, meaning that you should not disassemble.
A black circle ( ) with a picture inside alerts you to something you MUST do. This example shows that you
MUST unplug the power cord.

Barcode / 2D Code Handy Terminal
Handling the battery
Failure to follow all instructions listed below may cause electrical shock, overheating, smoking, fire, or an
explosion.
Do not disassemble or modify the battery.
Do not connect the battery (+) and (-) terminals with a metal object such as a wire.
Do not carry or store the battery together with metallic ball-point pens, necklaces, coins, hairpins, etc.
Do not use or store the battery in places exceeding the service or storage temperature.
Do not expose the battery to fire or heat.
Do not use or leave the battery in the vicinity of high-temperature locations (50 °C or higher) such as a fire
or heater.
Do not put or wet the battery with water or seawater.
Do not charge the battery near a fire or in direct sunlight.
Failure to follow this instruction may lead to liquid spill, blowout or combustion due to the increased
temperature in the battery.
Do not charge the rechargeable battery where any inflammable gases may be emitted
Do not hammer nails into the battery, hit it with a hammer, or step on it.
Do not subject the battery to strong impact or throw it.
Do not use a damaged or deformed battery.
Do not solder directly to the battery.
If smoke, abnormal odor, noises, or anything unusual is noticed, stop using the battery immediately.
Do not put the battery into a microwave oven or high-pressure container.
During use, charging, or storage of the battery, if any odor comes from the battery or it is overheated,
discolored, deformed, or anything unusual is noticed, remove the battery from the BHT or charger. Do
not use the battery.
If any battery fluid leaks out from the battery and gets into your eyes or comes into contact with the skin,
wash thoroughly with clean water such as tap water without rubbing, and seek medical attention
immediately. Failure to follow instruction may result in eye or skin injuries.
Stop charging if the charge does not complete after the specified time has elapsed.
vi

vii
BHT-1300-CE Series
To System Designers
In a life-critical system such as a medicines management system, even a simple data error may cause a
potential life-threatening situation. Always provide a redundant design and fail-safe system to protect
human lives.
Handling the BHT
Failure to follow all instructions listed below may cause electrical shock, overheating and smoking.
Do not disassemble or modify the BHT.
Do not insert foreign objects in the BHT.
Do not wet the BHT with water or seawater.
Do not put the BHT into a microwave oven or high-pressure container.
Do not leave the BHT in places where there are excessively high temperatures, such as inside
closed-up automobiles or in places exposed to direct sunlight.
Do not use the BHT in dusty or humid environments or places where a sharp temperature change is
expected.
Do not use the BHT with the damaged case.
Do not use the power supply other than the battery specified by DENSO WAVE.
Do not ingest or inhale liquid crystal､and do not contact liquid crystal with skin, in the event of liquid
crystal leaking out of a broken LCD screen.
Do not poke anyone’s eyes with the stylus that comes with the BHT.
Do not stare into the laser light.
Do not point the code reading window at anyone’s eyes.
BHT-1361QWB-CE/BHT-1361Q-CE
If smoke, abnormal odor, noises, or anything unusual is noticed, immediately turn the BHT off and
remove the battery from the BHT.
If the battery fluid leaks out from the battery and gets into your eyes, or comes into contact with the skin,
wash thoroughly with clean water such as tap water without rubbing, and seek medical attention
immediately. Failure to follow instruction may result in eye or skin injuries.
Be careful of broken glass if the LCD screen is accidentally cracked or broken. It may cause bodily
injury.
レーザ光 ク 2 ラスレーザ製品 ビ
ー
ムを
の
ぞ
6
き
8
こ
0
ま
2
:
な
0
1mW MAXIMUN OUTPUT; 650nm LASER IEC60825-1 Ed.2:2007
2
いこ
と
CLASS 2 LASER PRODUCT
最大出力波長1mW 650nm J I S C 11
LASER LIGHT-DO NOT STARE INTO BEAM
Code reading window
(Laser light radiation aperture)

Barcode / 2D Code Handy Terminal
Handling the BHT
Failure to follow all instructions listed below may cause not only incorrect operation, but also overheating, smoking
and malfunction.
When using the hand belt, avoid getting it caught in other objects or entangled it in rotating machinery.
Do not use the BHT near wireless devices such as personal radios and ham radios.
Do not place magnetic cards such as cash cards, credit cards, etc., close to the BHT speaker.
Failure to follow this instruction may result in the loss of magnetic data.
Do not place your ear close to the speaker when sounds are emitted.
Failure to follow this instruction may result in hearing loss.
Do not use excessive force when inserting or removing the rechargeable battery.
Do not use the BHT in environments where static electricity can build into significant charges.
Do not drop the BHT on the floor or subject it to strong impact.
Do not use anything other than the stylus pen that comes with this product. This may result in scratches
on the screen or breakage.
Do not touch the BHT with greasy hands or gloves.
If the BHT or battery cartridge is wet, damp or moistened, do not place it in the CU.
This product is embedded with a connector specially designed for microSD cards. Do not insert any
other cards than microSD cards. Be careful not to insert a card in the other way round or in an oblique
direction, or force it to the slot. This may cause the card or the connector to break.
viii

ix
BHT-1300-CE Series
Declaration of Conformity
For European Union
English: Hereby, DENSO WAVE INCORPORATED, declares that the devices BHT-1361BWB-CE and
BHT-1361QWB-CE each contain a Wireless LAN and Bluetooth®Module (type: DWWB003). The modules are in
compliance with the essential requirements and other relevant provisions of Directive 1999/5/EC.
Български: Снастоящето DENSO WAVE INCORPORATED декларира, че всяко от устройствата
BHT-1361BWB-CE иBHT-1361QWB-CE съдържа Bluetooth®ибезжичен LAN имодул (тип: DWWB003). Модулът
иплатката съответстват на съществените изисквания идругите приложими разпоредби на Директива
1999/5/EО.
Česky: Společnost DENSO WAVE INCORPORATED tímto prohlašuje, že zařízení BHT-1361BWB-CE a
BHT-1361QWB-CE obsahují modul Bluetooth®a Wireless LAN (typ: DWWB003). Oba moduly splňují základní
požadavky i ostatní příslušná ustanovení směrnice 1999/5/ES.
Dansk: Undertegnede, DENSO WAVE INCORPORATED, erklærer herved, at følgende udstyr BHT-1361BWB-CE og
BHT-1361QWB-CE hver indeholder et trådløst LAN og Bluetooth®-modul (type: DWWB003). Modulet og kortet
overholder de væsentlige krav og øvrige relevante krav i Rådets direktiv 1999/5/EF
Deutsch: Hiermit erklärt der Hersteller, DENSO WAVE INCORPORATED, dass die Geräte BHT-1361BWB-CE und
BHT-1361QWB-CE jeweils ein drahtloses LAN und Bluetooth®-Modul (Typ: DWWB003) enthalten. Sowohl das Modul
als auch die Platine erfüllen die grundlegenden Anforderungen und alle sonstigen einschlägigen Bestimmungen der
Richtlinie 1999/5/EG.
Eestikeelne: Käesolevaga kinnitab DENSO WAVE INCORPORATED, et seadmed BHT-1361BWB-CE ja
BHT-1361QWB-CE sisaldavad juhtmeta kohtvõrgu ja Bluetooth®moodulit (tüüp: DWWB003). Moodul ja kaart
vastavad direktiivi 1999/5/EÜ põhinõuetele ja nimetatud direktiivist tulenevatele muudele asjakohastele sätetele.
Español: Por medio de la presente, DENSO WAVE INCORPORATED declara que cada uno de los dispositivos
BHT-1361BWB-CE y BHT-1361QWB-CE contiene un Módulo de red LAN y Bluetooth®inalámbrica (tipo: DWWB003).
El módulo y la placa cumplen con los requisitos esenciales y otras disposiciones aplicables o exigibles de la Directiva
1999/5/CE.
Français: Par la présente, DENSO WAVE INCORPORATED déclare que les terminaux BHT-1361BWB-CE et
BHT-1361QWB-CE incluent chacun un module Bluetooth®et LAN sans fil (type : DWWB003). Le module et la carte
sont conformes aux exigences essentielles et aux autres dispositions pertinentes de la directive 1999/5/CE.
Gaeilge: Leis seo, dearbhaíonn DENSO WAVE INCORPORATED go bhfuil Modúl LAN gan sreang agus Bluetooth®
(cineál: DWWB003) sna gléasanna BHT-1361BWB-CE agus BHT-1361QWB-CE. Tá an modúl agus an clár i
gcomhréir le bunriachtanais agus le forálacha ábhartha eile Threoir 1999/5/CE.
Hrvatski: DENSO WAVE INCORPORATED ovime izjavljuje da svaki uređaj BHT-1361BWB-CE i BHT-1361QWB-CE
sadrži bežični LAN i Bluetooth®modul (tip: DWWB003. Modul i pločica u skladu su s osnovnim zahtjevima i drugim
bitnim odredbama Direktive 1999/5/EC.
Íslenska: DENSO WAVE INCORPORATED lýsir því hér með yfir að tækin BHT-1361BWB-CE og BHT-1361QWB-CE
innihalda hvert fyrir sig þráðlausa Bluetooth®og staðarnetseiningu (gerð: DWWB003). Einingin og borðið uppfylla
grundvallarkröfur og samræmast öðrum viðeigandi ákvæðum tilskipunar 1999/5/EB.
Italiano: Con la presente, DENSO WAVE INCORPORATED dichiarA che i dispositivi BHT-1361BWB-CE e
BHT-1361QWB-CE contengono ciascuno un modulo Bluetooth®e LAN wireless (tipo: DWWB003). Il modulo e la
scheda sono conformi ai requisiti essenziali ed alle altre disposizioni pertinenti stabilite dalla Direttiva 1999/5/CE.
Latviešu: Ar šo DENSO WAVE INCORPORATED deklarē, ka katra no ierīcēm BHT-1361BWB-CE un
BHT-1361QWB-CE ietver bezvadu lokālātīkla un Bluetooth®moduli (veids: DWWB003). Modulis un plate atbilst
Direktīvas 1999/5/EK būtiskajām prasībām un citiem ar to saistītajiem noteikumiem.
Lietuvių: Šiuo „DENSO WAVE INCORPORATED“deklaruoja, kad kiekviename iš įrenginiųBHT-1361BWB-CE ir
BHT-1361QWB^CE yra belaidžio LAN tinklo ir „Bluetooth“®modulis (tipas: DWWB003). Modulis ir plokštėatitinka
esminius reikalavimus ir kitas 1999/5/EB Direktyvos nuostatas.
Română: Prin prezenta, DENSO WAVE INCORPORATED declarăcăfiecare dintre aparatele BHT-1361BWB-CE şi
BHT-1361QWB-CE include un modul LAN wireless şi Bluetooth®(tip: DWWB003). Modulul şi placa sunt în
conformitate cu cerinţele esenţiale şi cu alte prevederi pertinente ale Directivei 1999/5/CE.

Barcode / 2D Code Handy Terminal
Magyar: Ezennel a DENSO WAVE INCORPORATED kijelenti, hogy a BHT-1361BWB-CE és a BHT-1361QWB-CE
eszköz vezeték nélküli LAN és Bluetooth®modult tartalmaz (típus: DWWB003). A modul és a lapka megfelel az
1999/5/EK irányelv alapvetőkövetelményeinek és egyéb vonatkozó előírásainak.
Malti: Hawnhekk, DENSO WAVE INCORPORATED tiddikjara li t-tagħmir BHT-1361BWB-CE u BHT-1361QWB-CE
kull wieħed fih Wireless LAN u Bluetooth®Module (tip: DWWB003). Il-module u l-board huma konformi mar-rekwiżiti
essenzjali u ma’ dispożizzjonijiet rilevanti oħrajn ta’ Direttiva 1999/5/KE.
Nederlands: Hierbij verklaart DENSO WAVE INCORPORATED dat de toestellen BHT-1361BWB-CE en
BHT-1361QWB-CE elk een draadloze LAN en Bluetooth®-module (type: DWWB003) bevatten. De module en de kaart
zijn in overeenstemming met de essentiële eisen en de andere relevante bepalingen van richtlijn 1999/5/EG.
Norsk: DENSO WAVE INCORPORATED erklærer med dette at enhetene BHT-1361BWB-CE og BHT-1361QWB-CE
inneholder en trådløs LAN og Bluetooth®-modul (type: DWWB003). Modulen og kortet er i samsvar med regelverk og
øvrige relevante bestemmelser i direktiv 1999/5/EF.
Polski: DENSO WAVE INCORPORATED niniejszym oświadcza, że każde urządzenie BHT-1361BWB-CE i
BHT-1361QWB-CE zawiera bezprzewodowy modułLAN i Bluetooth®(typ: DWWB003). Modułi płyta sązgodne z
zasadniczymi wymogami oraz pozostałymi stosownymi postanowieniami Dyrektywy 1999/5/WE.
Português: DENSO WAVE INCORPORATED declara que os dispositivos BHT-1361BWB-CE e BHT-1361QWB-CE
contêm cada um Módulo Bluetooth®e LAN sem fios (tipo: DWWB003). O módulo e placa estão conforme os requisitos
essenciais e a outras provisões relevantes da Directiva 1999/5/EC.
Slovensky: SpoločnosťDENSO WAVE INCORPORATED týmto vyhlasuje, zariadenia BHT-1361BWB-CE a
BHT-1361QWB-CE obsahuje bezdrôtový LAN a Bluetooth®modul (typ: DWWB003). Modul a doska sú v súlade so
základnými požiadavkami a ostatnými príslušnými ustanoveniami Smernice 1999/5/ES.
Slovenščina: Podjetje DENSO WAVE INCORPORATED izjavlja, da naprave BHT-1361BWB-CE in
BHT-1361QWB-CE vsebujejo Bluetooth®in brezžični modul LAN (vrsta: DWWB003). Modul in plošča sta skladna z
bistvenimi zahtevami in drugimi relevantnimi določili direktive 1999/5/ES.
Suomi: Täten DENSO WAVE INCORPORATED vakuuttaa, että tuotteista BHT-1361BWB-CE ja BHT-1361QWB-CE
jokainen sisältää Bluetooth®ja langattoman LAN-moduulin (tyyppi: DWWB003). Moduuli ja kortti ovat direktiivin
1999/5/EY oleellisten vaatimusten ja sen näitä tuotteita koskevien muiden ehtojen mukaisia.
Svenska: DENSO WAVE INCORPORATED intygar härmed att var och en av produkterna BHT-1361BWB-CE och
BHT-1361QWB-CE innehåller en Bluetooth®och trådlös LAN-modul (typ: DWWB003). Modulen och kortet uppfyller de
väsentliga egenskapskrav och övriga relevanta bestämmelser som framgår av direktivet 1999/5/EG.
Ελληνικά: Με το παρόν, ηDENSO WAVE INCORPORATED, δηλώνει ότι οι συσκευές BHT-1361BWB-CE και
BHT-1361QWB-CE περιέχουν μια λειτουργική μονάδα ασύρματου LAN και Bluetooth®(τύπος: DWWB003). Η
λειτουργική μονάδα και ημητρική πλακέτα πληρούν τις βασικές απαιτήσεις και τις λοιπές σχετικές διατάξεις της
Οδηγίας 1999/5/ΕΚ.
CE marking
Refer http://www.qbdirect.net/ for the DoC (Declaration of Conformity)
Türkiye Cumhuriyeti; AEEE Yönetmeliðine Uygundur
For Australia and New Zealand
This BHT-1361BWB-CE and BHT-1361QWB-CE each contain a Wireless LAN and Bluetooth®Module (type:
DWWB003).
RCM marking
x

xi
BHT-1300-CE Series

BHT-1
300
-
C
E
S
e
ri
es
Chapter 1
Outline
This chapter describes the BHT system and provides an overall outline of the BHT.
1.1 System Configuration···································································· 2
1.1.1 Hardware Configuration ····································································2
1.1.2 Software Configuration······································································3
1.2 Components and Functions···························································· 4
1.2.1 BHT Front/Rear···············································································4
1.2.2 Keypad··························································································5
1.2.3 BHT Screen····················································································7

BHT-1300-CE Series
1.1 System Configuration
This section describes the hardware and software required for the code data collection system using the BHT.
1.1.1 Hardware Configuration
The following figure shows the required hardware for the BHT barcode data collection system.
The required hardware varies according to the communication used.
Host computer
Wireless LAN access point
(option)
USB
communication
Wireless
communication
Ethernet
BHT
Bluetooth
®
communication
Bluetooth®-enabled
devices (option)
BHT
CU-1321
2

3
Barcode / 2D Code Handy Terminal
1.1.2 Software Configuration
[1] BHT Operating System (OS)
Microsoft Windows Embedded Compact 7
[2] Application Program Development Environment
Refer to "BHT API Reference Manual" and "BHT Class Library Reference Manual”.

BHT-1300-CE Series
1.2 Components and Functions
1.2.1 BHT Front/Rear
(12)
(11) (10)
(9)
(8)
(6)
(3)
(7)
(5)
(4)
(1)
(2)
No. Name Function and Description
(1) LCD (Liquid crystal display) Displays the characters and graphic patterns.
(2) Indicator LED Indicates the code read status.
Illuminates in blue when the BHT has successfully read a code.
(3)
(4)
Trigger switches
(M3 and M4 Magic keys)
Press this when scanning a code.
The SF and ENT key functions can be assigned to these magic keys by making settings at the
SYSTEM MENU. Character strings can be assigned at user programs.
Refer to “User’s Manual (Software)” for details on how to operate the SYSTEM MENU.
(5) Stylus Used to operate the touch panel.
(6) Speaker Emits sound.
(7) Hand strap Be sure to put your hand through this strap to prevent you from dropping the BHT accidentally.
(8) Battery cover Remove this cover to replace the battery cartridge.
(9) Battery cover lock Used to lock or unlock the battery cover.
(10) Code reading window Align the reading window with codes to perform code reading.
(11) Charging/communication
terminal Used to communicate and charge the BHT that is set on the CU.
(12) Wireless LAN / Bluetooth®
communication antennas Used to communicate with the wireless LAN access point and the Bluetooth device.
4

5
Barcode / 2D Code Handy Terminal
1.2.2 Keypad
The BHT key functions can be set at user programs.
The figure below shows an example of settings for each key function.
(4)
(5)
(1)
(3)
(8)
(2)
(7)
(10)
(6)
(11)～(14)
(9)
No. Key Name Function and Description
(1)
Cursor keys Used to move the cursor and select menus.
(2) Magic key
[M1]
(3) Tab key [M2]
(4)
Magic key
[M3]
Magic key
[M4]
M2 key is assigned a tab key by default.
Each of the M3 and M4 keys is assigned a trigger switch by default.
The SF, ENT, Backlight, MENU, Control, Alternate or C key functions can be
assigned to these magic keys by making settings at the SYSTEM MENU.
Character strings can be assigned at user programs.
Tab key: Moves a cursor to the next tab stop.
Trigger switch: Used to read a code.
(5) Scan key Used to read a code. Equipped with the same function with the trigger key.

BHT-1300-CE Series
No. Key Name Function and Description
(6) Numerical keys Used to enter data.
(7)
Backspace/clear
key
Deletes the last entered character (backspace). When pressed and held for 1
second or more, cancels entry and returns the LCD display to the previous screen
(clear.)
(8) Enter key Press to finalize entered data or execute operations.
(9) Power key Turns the BHT power ON or OFF.
(10) Shift key Used in combination with other keys such as the numerical keys and key for
special input procedures.
(11) Function
mode key Switches to the function mode.
(12) Alphabetical
mode key Switches to alphabet entry mode.
(13) Escape key Cancels the operation.
(14) Menu key
Display the following setting screens
- Beeper volume
- Vibrator
- LCD display brightness
- Power save
- Key backlight
6

7
Barcode / 2D Code Handy Terminal
1.2.3 BHT Screen.2.3 BHT Screen
All screens in this User’s Manual are simulated. Actual screens may differ depending on user settings and
other factors.
All screens in this User’s Manual are simulated. Actual screens may differ depending on user settings and
other factors.
Note: Taskbar may also differ from the actual screens.Note: Taskbar may also differ from the actual screens.
Shows the battery power level.
Shows the wired LAN with the CU connection status.
: The BHT is connected to a wired network.
: The BHT is disconnected to a wired network.
Shows the wireless device open status and radio field strength.
: Wireless LAN is disconnected or failed to authenticate
 : Vertical bars indicate radio field strength.
Strong Weak
Shows the Bluetooth®power status.
: The Bluetooth® device is powered on. (Blue)
: The Bluetooth® device is powered off. (Grey)
(
This icon does not show in taskbar by default settings.
To show this icon, change the settings in the System Menu or with user programs.)
Shows that shift mode is ON.
Shows that function mode is ON.
Shows that the BHT is communicating with the computer via Microsoft ActiveSync.
Shows that alphabet entry mode is ON. (To change entry mode, press the Alpha key.)
Refer to the BHT Class Library Reference Manual “Chapter 9 Keyboard” for the input character details while in
the ALP mode.
Tap this icon while an application is running to display the desktop.
Tap again to return the original application screen.

8
BHT-1300-CE Series
Shows the software keyboard status.
(Tap this icon to display/hide the software keyboard, or switch the keyboard status ON/OFF.)
: Shows that the software keyboard is ON.
: Shows that the software keyboard is OFF.
Shows that the CPU is in standby mode.
( This icon does not show in taskbar by default settings.
To show this icon, change the settings in the System Menu or with user programs.)
Shows that the Caps Lock key on the software keyboard is ON.
Tap this icon to display/hide the software keyboard menu.
Keyboard : Tap the "Keyboard" to display the software keyboard.
Hide Input Panel : Tap the "Hide Input Panel" to hide the software keyboard.
This function is enabled while software keyboad is displayed.
Note To minimize power consumption, the BHT automatically switches to standby mode after it has
not been operated for a specified period*.
In standby mode, the touch screen is not refreshed, and as a result, icons in the taskbar may
not be displayed or refreshed, and the calendar clock may not display the correct date or time.
* Default is one second, and can be changed to desired time period with the System Menu in
the User’s Manual (Software) or by creating user programs. Refer to the "BHT API
Reference Manual" or "BHT Class Library Reference Manual” for details of the use
r
program creation method.
